2AUGB-SM6Temperature and Vibration Sensor

For questions regarding content in this guide or for any other support related items, contact [email protected] or call 1-800-574-WAITES VERSION 1.1 SM6 SENSOR MOTE USER GUIDE Updated July 2023 MODELS: SM6-1150 SM6-2250 SM6-0864 Confidential and Proprietary Waites Sensor Technologies, Inc. 20 West 11th Street, Suite 200, Covington, Kentucky 41011 Phone 1-800-574-WAITES Email [email protected] The Waites logo is a registered trademark of Waites Sensor Technologies, Inc. Other trademarks found in this document have been used for identification purposes only and may be the trademarks of other companies. The information in this document is subject to change without notice. © 2023 Waites Sensor Technologies, Inc. WAITES SM6 SENSOR MOTE USER GUIDE 1TABLE OF [email protected] | 1-800-574-WAITES TABLE OF CONTENTS 1 SM6 Overview 2 2 Installing and Configuring the SM6 3 Performing Pre-Installation Steps 3 Locating the Sensor Installation Point 4 Preparing the Sensor Installation Point Location 4 Selecting a Mounting Technique 4 Stud Mount 4 Mounting Pad 5 Direct Epoxy 5 Mounting the SM6 5 Using a Stud Mount 6 Using a Mounting Pad 6 Using Direct Epoxy 7 Replacing the Battery in the SM6 7 3 Removing and Reinstalling the SM6 10 4 Troubleshooting the SM6 12 A FCC Compliance Statement 13 WAITES SM6 SENSOR MOTE USER GUIDE 2SM6 [email protected] | 1-800-574-WAITES SM6 Overview The SM6 is a high-frequency, high-G, 3-axis wireless vibration sensor that helps keep your equipment running properly by alerting you before unexpected failures occur. This all-in-one condition monitoring device is made to withstand the harshest conditions. The image below identifies the main parts of a SM6: 1 - SM6 Compression Ring 2 - SM6 Cap 3 - SM6 Base 4 - Battery 1 WAITES SM6 SENSOR MOTE USER GUIDE 3Installing and Configuring the [email protected] | 1-800-574-WAITES Installing and Configuring the SM6 All SM6 models will arrive to your facility in hibernation mode with batteries pre-installed to conserve power. This chapter provides information on how to install and configure the SM6. Note the following: • If a SM6 needs to be replaced, you must replace it with the same model number (for example, SM6-1150) unless otherwise instructed by a Waites support associate. • You should avoid touching the board inside the SM6 as much as possible, and the use of gloves is highly recommended. • If you need to replace a battery in a SM6, you must use the required battery type. See "Replacing the Battery in the SM6" on page 7 for details. • There is no need for you to open the SM6 prior to installation, unless directed by Waites personnel. • You must bring the SM6 out of hibernation mode before installation. See "Performing Pre- Installation Steps" on page 3 for details. Performing Pre-Installation Steps Note: There is no need for you to open a SM6 prior to installation, unless directed by Waites personnel. Once you are ready to install a SM6, you must bring the SM6 out of hibernation mode. To bring a SM6 out of hibernation mode: • Hold a magnet over the top of the SM6 and do not remove it until the indicator light comes on and goes back off (usually takes about 3-5 seconds). If the light stays on longer than 10 seconds with the magnet nearby, then it is already out of hibernation mode and ready to connect. Note: There will be additional flashes after the magnet is removed while the SM6 syncs with the network. The standard boot sequence performs a power-on self-test immediately on start-up and will turn on the LED light with a long flash if the self-test passes and a short flash if the self-test fails. If the self-test fails, try again and contact Waites Support if you need additional help. Next, the device will start searching for a gateway. If a gateway is found, it rapidly flashes the LED light indicating that it is paired with a gateway. 2 WAITES SM6 SENSOR MOTE USER GUIDE 4Installing and Configuring the [email protected] | 1-800-574-WAITES A quick magnet swipe will invoke the standard boot sequence. If you invoke another magnet swipe prior to completing the operation, the SM6 will restart the sequence from the beginning. Hibernation mode cannot be reactivated once the standard boot sequence has been initiated. Locating the Sensor Installation Point After your SM6 has been added in the Waites Self-Service Dashboard, the next step is to determine the physical installation point. Note: The sensor installation point should have enough space for the sensor to sit without touching any other part of the equipment other than the point being monitored. This prevents equipment from picking up additional background vibrations. To determine an installation point for a SM6: • Locate a flat area that is approximately 1 sq. in (6.45 sq. cm) that provides the most metal-to-metal contact between the equipment and the base of the SM6. • Identify the SM6 axes and note that the X-axis is the most sensitive axis. Preparing the Sensor Installation Point Location After you have located a sensor installation point, you must prepare the location. To prepare the sensor installation point location: 1. Clean the location of the sensor installation point by removing all dirt and grease on any exposed surface of the equipment. If the equipment surface is painted, remove the paint as well. 2. If required, grind down the equipment surface to create a flat area for the sensor to be mounted. Optionally, you can use the mill attachment in the Accelerometer Installation Tool Kit to create a flat surface area of 1.25 inches in diameter. Selecting a Mounting Technique After you have prepared the sensor installation point location, you must select a mounting technique: stud mount, mounting pad, or direct epoxy. Stud Mount The stud mount technique is recommended whenever possible, since it provides the most metal surface area contact between the machine and the sensor. This technique involves screwing the sensor directly into a 1/4"-28 stud tap an…
