Made in China Residential use only Indoor use only Fabriqué en Chine Usage résidentiel seulement Usage intérieur seulement Hecho en China Uso residencial solamente Uso interior solamente Rev. 11-23-2020 ITM. / ART. : 1500325 Model / Modèle / Modelo: FLP14-SRC-C-T Ultra-Thin LED Panel - Sunray TM INSTRUCTION MANUAL IMPORTANT, KEEP FOR FUTURE REFERENCE: PLEASE READ CAREFULLY. Panneau à DEL ultra mince - Sunray MC MANUEL D’INSTRUCTIONS IMPORTANT, À CONSERVER POUR FUTURE RÉFÉRENCE: LIRE ATTENTIVEMENT. Panel LED ultra delgado - Sunray MR MANUAL DE INSTRUCCIONES IMPORTANTE, CONSERVAR PARA FUTURA REFERENCIA : LEER DETENIDAMENTE. 2 INSTRUCTION MANUAL / MANUEL D’INSTRUCTIONS / MANUAL DE INSTRUCCIONES EN INCLUDED FR INCLUS ES INCLUIDO WHAT YOU WILL NEED...VOUS AUREZ BESOIN DE...LO QUE NECESITARÁ... Screwdriver Tournevis Destornillador Item Pièce Pieza Description Description Descripción Quantity Quantité Cantidad Junction box screw Vis de boîte de jonction Tornillo de caja de conexiones x 2 Wire connector Capuchon de connexion Conector de cable x 3 Retaining screw Vis de fixation Tornillo de fijación x 6 Wall anchor Ancrage mural Anclaje de pared x 6 Mounting plate Plaque de montage Placa de montaje x 1 LED panel with 2 wired hooks Panneau à DEL avec 2 crochets câblés Panel LED con 2 ganchos x 1 Drill Perceuse Taladro ¼-in. drill bit (6.5 mm) Mèche de ¼ po (6,5 mm) Broca de ¼ plg (6,5 mm) Pencil Crayon Lápiz 3 EN CAUTION If using a dimmer, it must be LED compatible. IMPORTANT The installer and/or user must read, understand and follow these instructions before installing the product. This product must be properly installed before it is used. If instructions are not followed, the manufacturer will not be held responsible for any problems or product malfunctions. Failure to follow installation and/or operating instructions will voids the warranty. We recommend that this product be installed by a certified electrician. In some states or provinces, it is legally required that for this type of product to be installed by a certified electrician, according to the electrical and building codes effective in the region where the unit is being used. FR ATTENTION Si un gradateur est utilisé, celui-ci doit être compatible avec les lumières à DEL. IMPORTANT Avant l’installation de ce produit, l’utilisateur et/ou l’installateur doit avoir lu et compris ces instructions. Cet appareil doit être installé convenablement avant usage. Si ces instructions ne sont pas respectées, le fabricant ne pourra être tenu responsable d’aucun problème ou de dysfonctionnement du produit. Le non-respect des instructions d’installation et/ou d’utilisation annulera la garantie en vigueur. Nous recommandons que ce produit soit installé par un électricien certifié. Dans certains états ou provinces, il est légalement requis que ce type de produit soit installé par un électricien certifié conformément aux codes de l’électricité et du bâtiment en vigueur. ES ATENCIÓN Si utiliza un regulador, debe asegurarse de que sea compatible con las luces LED. IMPORTANTE El instalador o usuario debe leer detenidamente las instrucciones antes de instalar el producto y seguirlas fielmente. El producto debe estar correctamente instalado antes de su uso. Si no sigue las instrucciones, el fabricante no se hará responsable de problemas o de un funcionamiento incorrecto del producto. Si no sigue las instrucciones de instalación o de uso, se anulará la garantía. Le recomendamos que el producto sea instalado por un electricista certificado. En algunos estados o provincias, se requiere por ley que este tipo de producto sea instalado por un electricista certificado siguiendo los códigos eléctricos y de construcción de la región. WARNING: Risk of electrical shock. Turn off power at the breaker panel. AVERTISSEMENT : Risque de décharge électrique. Éteindre le disjoncteur sur le panneau électrique. ADVERTENCIA: Riesgo de descarga eléctrica. Desconecte la corriente eléctrica del panel (disyuntor). Switch off the main electrical supply from the fuse box/circuit breaker before installing the unit or doing any maintenance. Do not use outdoors. Il est important de couper l’alimentation électrique du disjoncteur avant de procéder à l’installation ou à l’entretien. Ne pas utiliser à l’extérieur. Desconecte la instalación eléctrica en la caja de circuitos/disyuntor antes de instalar esta unidad o realizar tareas de mantenimiento en ella. No usar en exteriores. This product is compatible with most LED dimmers Compatible avec la plupart des gradateurs à DEL Compatible con la mayoría de los reguladores LED 4 INSTRUCTION MANUAL / MANUEL D’INSTRUCTIONS / MANUAL DE INSTRUCCIONES EN INSTALLATION ON DRYWALL CEILING, SURFACE MOUNTING 1. Turn off power at the breaker panel and the light switch. Ensure that the power is turned off before continuing. 2. Temporarily install the mounting plate to the junction box using the two junction box screws. Position the mounting plate so that the arrow label is pointing to the left (fig. 1a). FR INSTALLATION SUR PLAFOND DE GYPSE, MONTAGE EN SURFACE 1. Couper le courant électrique au niveau du disjoncteur et sur l’interrupteur du luminaire. S’assurer que le courant est éteint avant de continuer. 2. Installer la plaque de montage temporairement sur la boîte de jonction à l’aide des deux vis de boîte de jonction. Placer la plaque de montage de manière à ce que la flèche autocollante pointe vers la gauche (fig. 1a). ES INSTALACIÓN EN CIELO RASO DE YESO, MONTAJE SUPERFICIAL 1. Desconecte la electricidad en el panel y apague el interruptor. Asegúrese de que la corriente esté desconectada antes de continuar. 2. Instale la placa de montaje temporalmente en la caja de conexiones utilizando los tornillos de la caja de conexiones. Coloque la placa de montaje de modo que la etiqueta de la flecha indique hacia la izquierda (fig. 1a). WARNING: Risk of electrical shock. Turn off power at the breaker panel. AVERTISSEMENT : Risque de décharge électrique. Éteindre l…
