2AUHG-OUT-LPCOUTDOOR LIGHT

Made in China Fabriqué en Chine Hecho en China Residential use only Usage résidentiel seulement Uso residencial solamente Indoor or outdoor use Usage intérieur ou extérieur Uso interior o exterior LED Wall light - Lennox Pro TM INSTRUCTION MANUAL IMPORTANT: READ CAREFULLY AND KEEP. Luminaire mural à DEL - Lennox Pro MC MANUEL D’INSTRUCTIONS IMPORTANT: À LIRE ATTENTIVEMENT ET À CONSERVER. Luminaria LED de pared - Lennox Pro MR MANUAL DE INSTRUCCIONES IMPORTANTE: LEER DETENIDAMENTE Y CONSERVAR. Model / Modèle / Modelo: OUT-LPC-MBJ OUT-LPC-SSJ Rev. 10-12-2022 2 ITEM PIÈCE PIEZA DESCRIPTION DESCRIPTION DESCRIPCIÓN QUANTITY QUANTITÉ CANTIDAD A Mounting bracket Support de montage Soporte de montaje × 1 B Wire connector Capuchon de connexion Conector de cable × 3 C Junction box screw Vis de boitier de raccordement Tornillo de caja de conexiones × 2 D Canopy screw Vis de la base Tornillo del dosel × 2 + 1 extra E Rubber washer Rondelle en caoutchouc Arabella de Caucho × 2 F Light fixture Luminaire Lámpara × 1 INCLUDED HARDWARE MATÉRIEL INCLUS HERRAMIENTAS INCLUIDO 3 STEP-BY-STEP INSTALLATION INSTALLATION DÉTAILLÉE INSTALACIÓN ETAPA POR ETAPA 1 ABC DE F Sealant Scellant Sellante Screwdriver Tournevis 2 Destornillador WHAT YOU WILL NEED VOUS AUREZ BESOIN LO QUE NECESITARÁ 4 CAUTION ATTENTION ATENCIÓN WARNING: Risk of electrical shock. Turn off breaker at the panel. Switch off the main electrical supply from the fuse box/circuit breaker before installing the unit or doing any maintenance. AVERTISSEMENT: Risque de décharge électrique. Éteindre le disjoncteur sur le panneau électrique. Il est important de couper l’alimentation électrique du disjoncteur avant de procéder à l’installation ou à l’entretien. ADVERTENCIA: Riesgo de descarga eléctrica. Desconectar la corriente eléctrica del panel (disyuntor). Desconecte la instalación eléctrica en la caja de circuitos/disyuntor antes de instalar esta unidad o realizar tareas de mantenimiento en ella. CAUTION If using a dimmer, it must be LED compatible. IMPORTANT The installer and/or user must read, understand and follow these instructions before installing the product. This product must be properly installed before it is used. If instructions are not followed, the manufacturer will not be held responsible for any problems or product malfunction. Failure to follow installation and/or operating instructions voids the warranty. We recommend that this product be installed by a certified electrician. In some states or provinces, it is a legal requirement for this type of product to be installed by a certified electrician, according to the electrical and building codes effective in the region where the unit is used. Indoor / Outdoor use ATTENTION Si un gradateur est utilisé, celui-ci doit être compatible avec les lumières à DEL. IMPORTANT Avant l’installation de ce produit, l’utilisateur et/ou l’installateur doit avoir lu et compris ces instructions. Cet appareil doit être installé convenablement avant usage. Si ces instructions ne sont pas respectées, le fabricant ne pourra être tenu responsable d’aucun problème ou de dysfonctionnement du produit. Le non-respect des instructions d’installation et/ou d’utilisation annulera la garantie en vigueur. Nous recommandons que ce produit soit installé par un électricien certifié. Dans certains États ou provinces, il est légalement requis que ce type de produit soit installé par un électricien certifié conformément aux codes de l’électricité et du bâtiment en vigueur. Utilisation intérieure/extérieure ATENCIÓN Si utiliza un regulador, debe asegurarse de que es compatible con las luces LED. IMPORTANTE El instalador o usuario debe leer detenidamente las instrucciones antes de instalar el producto y seguirlas fielmente. El producto debe estar correctamente instalado antes de su utilización. Si no siguen las instrucciones, el fabricante no se hará responsable de problemas o de un funcionamiento incorrecto del producto. Si no sigue las instrucciones de instalación o de uso, se anulará la garantía. Le recomendamos que el producto sea instalado por un electricista certificado. En algunos estados o provincias, se requiere por ley que este tipo de producto sea conectado por un electricista certificado siguiendo los códigos eléctricos y arquitectónicos de la región. Uso interior/exterior 5 MINIMUM CLEARANCE ESPACE MINIMUM ESPACIO MÍNIMO 1 Plan the desired height Planifier la hauteur désirée Alcanzar la altura deseada F ! Minimum Height 120 cm (48 in/po/pulg) 6 MOUNTING BRACKET INSTALLATION INSTALLATION DU SUPPORT DE MONTAGE INSTALACIÓN DEL SOPORTE DE MONTAJE 2 AC 7 TUNABLE WHITE TECHNOLOGY (CCT) TECHNOLOGIE DE BLANC AJUSTABLE (CCT) TECHNOLOGÍA BLANCO AJUSTABLE (CCT) 3 3000K 4000K 5000K RETIRER DESPEGAR PEEL OFF F 8 WIRE CONNECTION AND FINAL INSTALLATION CONNECTION DES FILS ET INSTALLATION FINALE CONEXIÓN DE CABLES E INSTALACIÓN FINAL 4 Ground wire (GND) Fil de mise à la terre (GND) Cable de tierra (GND) C White (N) Blanc (N) Blanco (N) Black (L) Noir (L) Negro (L) F DE 9 5 APPLY SEALANT APPLIQUER LE SCELLANT APLICAR SELLANTE NOTE: We recommend keeping the bottom unsealed. To maintain a drainage area in case of water infiltration. NOTE: Nous vous recommandons de garder le fond non scellé. Afin de maintenir une aire de drainage en cas d'infiltration d'eau.. NOTA: Recomendamos mantener la parte inferior abierta. Para mantener una zona de drenaje en caso de infiltración de agua. F 10 Operation is subject to the following two conditions: 1. this device may not cause interference, and 2. this device must accept any inteference, including inteference that may cause undesired operation of the device. L’exploitation est autorisée aux deux conditions suivantes : 1. l’appareil ne doit pas produire de brouillage; et 2. l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. La operación está sujeta a las dos condiciones siguientes: 1. este dispositivo no puede c…

Text truncated - open the document above for the full version.

Differences Declaration To whom concern, We company ARTIKA FOR LIVING INC hereby declares: The product models OUT-LPC-XXXXX (The suffix “XXXXX” can be two to five character denotes product color or customer code.) are identical in the same PCB layout, interior structure and electrical circuits, The differences are product color and model name for commercial purpose. Authorized signature: Date: 2022-11-03

ARTIKA FOR LIVING INC DATE : 2022-11-03 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AUHG-OUT-LPC Product Name: OUTDOOR LIGHT Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name: Mathieu Seguin Title: Engineering & QC Director Company: ARTIKA FOR LIVING INC

DATE:2022-11-03 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act asAgent On our behalf, I appoint Jason Wu of Global United Technology Services Co., Ltd.and No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with ARTIKA FOR LIVING INC and 1756 50th avenue, Lachine Quebec, Canada H8T 2V5 Signature: Name: Mathieu Seguin Title: Engineering & QC Director Company: ARTIKA FOR LIVING INC

FCC Label and Location Sivler base black words: 50*30 Sivler base black words: 80*25 Proposed Label Location on EUT Label location

Global United Technology Services Co., Ltd. Report No.: GTS2022110000007F01 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 19 TEST REPORT Applicant: ARTIKA FOR LIVING INC Address of Applicant: 1756 50th avenue, Lachine, Quebec, CanadaH8T 2V5 Manufacturer/ Factory: ZHONGSHAN WEIHUA LIGHTING TECHNOLGY CO .,LTD. Address of Manufacturer/ Factory: No.13 YOUNG YI 2RD HENGLAN TOWN ZHONGSHAN CITY GUANGDONG PROVINCE CHINA Equipment Under Test (EUT) Product Name: OUTDOOR LIGHT Model No.: OUT-LPC-XXXXX (The suffix “XXXXX” can be two to five character denotes product color or customer code.) FCC ID: 2AUHG-OUT-LPC Applicable standards: FCC CFR Title 47 Part 15 Subpart B Date of sample receipt: November 02, 2022 Date of Test: November 02-03, 2022 Date of report issued: November 03, 2022 Test Result : Pass * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS202211000007F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 19 2 Version Version No. Date Description 00 November 03, 2022 Original Prepared by: Date: November 03, 2022 Project Engineer Reviewed by: Date: November 03, 2022 Reviewer Report No.: GTS202211000007F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 19 3 Contents 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 TEST MODE AND TEST VOLTAGE .......................................................................................................... 5 5.3 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 5 5.4 DEVIATION FROM STANDARDS ............................................................................................................. 5 5.5 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................... 5 5.6 TEST FACILITY .................................................................................................................................... 5 5.7 TEST LOCATION .................................................................................................................................. 5 6 TEST INSTRUMENTS LIST ..................................................................................................................... 6 7 TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 8 7.1 RADIATED EMISSION ........................................................................................................................... 8 7.2 CONDUCTED EMISSIONS ................................................................................................................... 11 8 TEST SETUP PHOTO ............................................................................................................................ 14 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 15 Report No.: GTS202211000007F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 19 4 Test Summary Test Item Test Requirement Test Method Class / Severity Result Conducted Emission FCC Part15.107 ANSI C63.4a Class B PASS Radiated Emissions # FCC Part15.109 ANSI C63.4a Class B PASS Remark: 1. Pass: The EUT complies with the essential requirements in the standard. 2. # Refer to FCC Part 15.33 (b)(1) conditional testing procedure : Highest frequency generated or used in the device or on which the device operates or tunes (MHz) Upper frequency of measurement range (MHz) Below 1.705 30 1.705-108 1000 108-500 2000 500-1000 5000 Above 1000 5th harmonic of the highest frequency or 40 GHz, whichever is lower. Measurement Uncertainty Test Item Frequency Range Measurement Uncertainty Notes Radiated Emission 30MHz-200MHz 3.8039dB (1) Radiated Emission 200MHz-1GHz 3.9679dB (1) Radiated Emission 1GHz-18GHz 4.29dB (1) AC Power Line Conducted Emission 0.15MHz ~ 30MHz 3.44dB (1) Note (1): The measurement uncertainty is for coverage factor of k=2 and a level of confidence of 95%. Report No.: GTS202211000007F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zon…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
