2AUI4-E73FACE RECOGNITION TERMINAL

Introduction Uface 7 is an enhanced all-in-one recognition terminal updated by the latest technology, which notably offers the best fit for different scenario needs with incomparable merits such as rich interfaces and enables quicker facial automatic detection when a target enters its detection distance from 0.3m to 2m. Powered by the dual- core CPU for running the intellectualized Uni- Ubi® robust algorithm, the live detection has been optimized in producing the best biometric recognition accuracy and anti-spoofing ability, with greatly boosted security performance. Features  Industrial design, stable performance, and smooth outline  Anti-backlight  7-inch IPS touch screen with 550 lux, offering high visibility against intense, direct light  1920*1080 IR, RGB camera sensor, supporting facial recognition in a dark state  Live detection algorithm against spoofing attacks  Recognition accuracy 99.99% (99.77% recognition rate at 1% FAR; 99.27% recognition rate at 0.1% FAR), with under 1s fast detection  IP65 (Outdoor solution)  EM 125KHz & MIFARE 13.56MHz  Face capacity up to 1:N-30,000 facial templates E73-1711-OS-V Versatile AI FACE RECOGNITION TERMINAL With its IP65-rated waterproof structure and low- temperature running module, Uface 7 features excellent durability in harsh conditions such as outdoor envir Access Control AI Dual Camera IP65 Waterproof -40°C Running Touch Screen E73-1711-OS-V Versatile AI FACE RECOGNITION TERMINAL Specifications Model Name E73-1711-OS-V Capacity Faces 30,000 Cards 30,000 Logs Max. 150,000 (including 50,000 logs with photos) Interfaces Communication Modes TCP/IP, WIFI, Bluetooth I/O Relay, Wiegand input/output, RS232, RS485, Door sensor, Exit button, 2 Type-A USB, MIC Functions Face Recognition Live detection Upgrade Modes Online, USB Supported Software Standalone, Ustar, Ustar Cloud, Ustar Mobile, Ustar Access, Web Server Multi-verification Modes Face, Card, Face + Card, Card + Password, User ID + Password Hardware Memory 8GB ROM + 1GB RAM CPU Dual-core ARM Cortex-A7@900MHz, Linux NPU 1.2 Tops Screen 7-inch TN LCD touch screen Cameras IR, RGB dual-lens camera, Recognition distance (0.3m-2m) Card Modules Standard EM & MIFARE Card, NFC General Working Temperature -40°C~40°C Storage Temperature -20°C~60°C Working Humidity 10%~90% IP Rate IP65 Power Supply DC 12V/2A Power Consumption Max. 15W Dimensions 219mm*113mm*23mm Certificates CE, FCC Universal Ubiquitous Al Co., Ltd. Floor 24-26 Building 3, Fashion Vantone City, Cangqian Street, Yuhang District, Hangzhou, Zhejiang, China E-mail: [email protected] www.uni-ubi.com/en Follow us on Facebook / Twitter / YouTube / LinkedIn /Instagram @UniUbiGlobal E73-1711-OS-V Versatile AI FACE RECOGNITION TERMINAL Caution: Intended for sale and application in a business environment. Use the Product in the environment with the temperature Between -40°C and 40°C; Otherwise, it may damage your product. Products can only be used below 2000m altitude For the following equipment: Product Name: FACE RECOGNITION TERMINAL Brand Name: / Model No.: E73-1711-OS-V, E73-1701-V, E73-1711-V, E73-1701-OS-V, E73-1701, E73-1711, E73- 1701-OS, E73-1711-OS Universal Ubiquitous Al Co., Ltd. E-mail: [email protected] Hereby declares that this [Name: FACE RECOGNITION TERMINAL, Model: E73-1711-OS-V, E73-1701-V, E73-1711-V, E73-1701-OS-V, E73-1701, E73-1711, E73-1701-OS, E73-1711-OS] is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. This product is intended for sale and application in a business environment. RED Article 10 2 -This product can be used across EU member states RED Article 10 10 -The product is class 1 product, No restrictions The RF distance between body and product is 20mm Technical Characteristics Bluetooth Bluetooth Version: Bluetooth V4.2 Frequency Range: 2402-2480MHz Max.RF Output Power: 0.24dBm (EIRP) Wi-Fi (2.4GHz) Support Standards: 802.11b, 802.11g, 802.11n-HT20/40 Frequency Range: 2412-2472MHz for 802.11b/g/n(HT20) 2422-2462MHz for 802.11n(HT40) Max.RF Output Power: 17.48dBm (EIRP) NFC-13.56MHz Frequency Range: 13.56MHz Radiated H-Field: 25.84dBuA/m(@3m) NFC-125kHz E73-1711-OS-V Versatile AI FACE RECOGNITION TERMINAL Frequency Range: 125KHz Radiated H-Field: 1.0dBuA/m(@3m) FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for complia…

Text truncated - open the document above for the full version.

Reference No.: WTX23X10221080W001/002/003/004/005 Page 2 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTX23X10221080W001/002/003/004/005 Page 3 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTX23X10221080W001/002/003/004/005 Page 4 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTX23X10221080W001/002/003/004/005 Page 5 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 7 EUT View 8

Reference No.: WTX23X10221080W001/002/003/004/005 Page 6 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 EUT Housing and Board View 2 Reference No.: WTX23X10221080W001/002/003/004/005 Page 7 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 1 Solder Board-Component View 2 Reference No.: WTX23X10221080W001/002/003/004/005 Page 8 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 3 Solder Board-Component View 4 Reference No.: WTX23X10221080W001/002/003/004/005 Page 9 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Antenna View 1 13.56MHz Antenna 125 KHz Antenna Wi-Fi and BT Antenna

1. RF Exposure Requirements 1.1 General Information Client Information Applicant: Universal Ubiquitous AI Co., Ltd. Address of applicant: Floor 24-26 Building 3,Fashion Vantone City, Cangqian Street,Yuhang District, Hangzhou,Zhejiang,China Manufacturer: Universal Ubiquitous AI Co., Ltd. Address of manufacturer: Floor 24-26 Building 3,Fashion Vantone City, Cangqian Street,Yuhang District, Hangzhou,Zhejiang,China General Description of EUT: Product Name: FACE RECOGNITION TERMINAL Trade Name: Model No.: E73-1711-OS-V Adding Model(s): E73-1701-V, E73-1711-V, E73-1701-OS-V, E73-1701, E73-1711, E73-1701-OS, E73-1711-OS Rated Voltage: DC 12V Power Adapter Model: / FCC ID: 2AUI4-E73 Equipment Type: Fixed device Technical Characteristics of EUT: Bluetooth(BLE mode) Bluetooth Version: V4.2 (BLE mode) Frequency Range: 2402-2480MHz RF Output Power: 4.98dBm (Conducted) Data Rate: 1Mbps Modulation: GFSK Quantity of Channels: 40 Channel Separation: 2MHz Type of Antenna: FPC Antenna Antenna Gain: 2.9dBi Bluetooth(BR/EDR mode) Bluetooth Version: V4.2 (BR/EDR mode) Frequency Range: 2402-2480MHz RF Output Power: 6.78dBm (Conducted) Data Rate: 1Mbps, 2Mbps, 3Mbps Modulation: GFSK, π/4 DQPSK, 8DPSK Quantity of Channels: 79 Channel Separation: 1MHz Type of Antenna: FPC Antenna Antenna Gain: 2.9dBi Wi-Fi(2.4GHz) Support Standards: 802.11b, 802.11g, 802.11n Frequency Range: 2412-2462MHz for 802.11b/g/n(HT20) 2422-2452MHz for 802.11n(HT40) RF Output Power: 19.70dBm (Conducted) Type of Modulation: CCK, OFDM, QPSK, BPSK, 16QAM, 64QAM Quantity of Channels: 11 for 802.11b/g/n(HT20); 7 for 802.11n(HT40) Channel Separation: 5MHz Type of Antenna: FPC Antenna Antenna Gain: 2.9dBi NFC(125KHz) Frequency Range: 125kHz Modulation Type: BPSK Max. Field Strength: 50.75dBuV/m (at 3m) Antenna Type: Coil Antenna Antenna Gain 0dBi NFC(13.56MHz) Frequency Range: 13.56MHz Modulation Type: ASK, BPSK Max. Field Strength: 39.52dBuV/m (at 3m) Antenna Type: FPC Antenna Antenna Gain 0dBi 1.2 RF Exposure Exemption According to §1.1307(b)(3) and KDB 447498 D04 Interim General RF Exposure Guidance v01, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Option A: FCC Rule Part 1.1307 (b)(3)(i)(A):The available maximum time-averaged power is no more than 1mW, regardless of separation distance. Option B: FCC Rule Part 1.1307 (b)(3)(i)(B): The available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. P th is given by: Option C: FCC Rule Part 1.1307 (b)(3)(i)(C): The minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. R must be at least λ/2π, where λ is the free-space operating wavelength in meters. Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 1.34-30 3,450 R 2 /f 2 30-300 3.83 R 2 300-1,500 0.0128 R 2 f 1,500-100,000 19.2R 2 For Multiple RF sources: FCC Rule Part 1.1307(b)(3)(ii): (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). (B) In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. 1.3 Calculated Result Radio Access Technology Prediction Frequency Output Power Antenna Gain Duty Cycle Tune-Up Time-Averaged Power ERP (MHz) (dBm) (dBi) (%) (dBm) (dBm) Bluetooth 2402 6.78 2.9 100 7.00 7.75 2.4G Wi-Fi 2412 19.70 2.9 100 20.75 20.00 NFC 13.56 -55.74 0 / -151.00 -153.15 Frequency Option Min. Distance Max. Power Exposure Limit Ratio Result (MHz) (cm) (dBm) (mW) (mW) Pass/Fail 2402 C 20.00 7.75 5.96 768.00 0.01 Pass 2412 C 20.00 20.75 118.85 768.00 0.15 Pass 13.56 B 20.00 -151.00 0.00 27.66 0.01 Pass Note: 1. a. Time-Averaged Power=Output Power * Duty Cycle; ERP= Time-Averaged Power+ Antenna gain-2.15dB; b. EIRP= E-104.8+20logD; Output Power=EIRP- Antenna Gain; ERP=EIRP-2.15dB 2. Option A, B and C refers as clause 1.2. 3. For option B, Max (time-averaged power, effective radiated power (ERP)) converts to Max. Power. For option C, ERP converts to Max. Power; 4. For option B, P th (mW) converts to Exposure Limit (mW); For option C, ERP (W) converts to Exposure Limit (mW). 5. Ratio= Tune-Up ERP (mW)/ Exposure Limit (mW) Mode for Simultaneous Multi-band Transmission: Radio Access Technology Ratio 1 Ratio 2 Simultaneous Ratio Limit Result Pass/Fail 2.4G Wi-Fi + NFC 0.15 0.01 0.16 1 Pass Note: WIFI and BT is the use the same antenna cannot simultaneous transmission. Result: Pass

样品承认书 SPECIFICATION FOR APPROVAL 样品编号（FILES NO.）： 1230110417-01 物料名称 （PART NAME）： 2.4G Antenna 物料编码 （PART NO.）： 1230110417 物料描述 （DESC.）： E73 新 RF 座-WiFi 天线-柔性 FPC-45.0*15.0mm-带 IPEX 接头-线长 192mm E73 NewRF-WiFi Antenna-FPC-45.0*15.0mm-First-Generation IPEX-Cable 192mm 供 应 商（SUPPLIER）： 东莞市一佳电子通讯科技有限公司 Dongguan YiJia Electronics Communication Technology Co.,Ltd. 型 号（MODEL）： YJH01.038.032.302A 2023/12/26 发样日期（ISSUE DATE）： NO . 1 承认书封面（Spec Cover） 11 2 承认书项目表（Spec Item ） 12 3 工程成品图（Drawing） 133 工程成品图（Drawing） 13 4 天线规格（Antenna Specification） 14 5 S参数测试（S Parameter ） 15 无源测试（） 6 无源测试（Passive Test ） 26 ~ 7 7 方向图（Radiation Pattern ） 38 ~ 10 8 天线装配图（Antenna Profile） 211 ~ 12 9N/AN/AN/A 10--- 11--- add：东莞市长安镇沙头社区木鱼路59号元富工业区Tel:0769-82586086 Fax:0769-82586086 12--- 13---   承认书项目表 & RQILUPDWLRQ/HWWHU3URMHFW7DEOH 页数 Number of pages 页 码 Page number 内容 content add: Yuanfu Industrial Zone, No. 59 Muyu Road, Shatou Community, Chang'an Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 c��,�1�I - 2 -3＿ 4 _5- - 6 CUSTOMER PART NO 詈 7 DESCRIPTION 百 DATE 2022-05-19 E E I D D I o l YJ-E73-WIFI-V02 匾 .. 45.0 \\ 悠＿ l e c l B B A l 3 FPCB 45.0*15.0MM FPCB FPC1000XA.P01 1 2 Coaxial Cable O.D.1.13 COA 1 OOOXA. P01 1 1 Mini Connector O.D .1.13 Black Au Plate d 1 Cu TER 1 OOOXA. P01 1 NO PART NAME DESCRIPTION Material Part Q. TY 2 I 3 也住东莞市 一 佳电子通讯科技有限公司 Tel ·0 76 9-825860 86 Dongguan YiJia Electronics Communication Technology Co.,Ltd. Fax:0 76 9-82586086 PART NAME: 2.4G Antenna PART NO.: Y JH01.038.032.302A DATE: 2022-05-19 E3- Tolerance A APPROVED BY CHECKED BY DESIGNED BY : mm x.x 士0.50 SCALE: 1/1 x.x 没0.1 REVISION: A x o 士 3 0 5 6 7 8 电气性能 Frequency（频率范围） 2.4-2.5GHz Impedance（输入阻抗） 50 Ohm Nominal V.S.W.R（电压驻波比） 2.5 Max Gain（总增益） 3.9 dBi Radiation（辐射方向） Omni-directional Polarization（极化方式） Linear Connector（接头类型） 1 IPEX Cable Type（线材类型） O.D.1.13mm Cable Length（线材长度） 192mm Cable Color（线材颜色） 黑色 black add：东莞市长安镇沙头社区木鱼路59号元富工业区Tel:0769-82586086 Fax:0769-82586086 Operating Temp.（工作温度） -40 ~ +85 ̊C Storage Temp / Humidity（储存 温度/湿度） 25±5 ̊C / <70% 天线规格 Antenna specifications Electrical performance 物理性能 physical property add: Yuanfu Industrial Zone, No. 59 Muyu Road, Shatou Community, Chang'an Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 S参数测试 Agilent S参数测试 Agilent E5071B S11S11 Parameter Test // 2.4G Antenna add：东莞市长安镇沙头社区木鱼路59号元富工业区Tel:0769-82586086 Fax:0769-82586086 add: Yuanfu Industrial Zone, No. 59 Muyu Road, Shatou Community, Chang'an Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 Parameter tes ting ZZ Y XX Y X Z add：东莞市长安镇沙头社区木鱼路59号元富工业区Tel:0769-82586086 Fax:0769-82586086 Y add: Yuanfu Industrial Zone, No. 59 Muyu Road, Shatou Community, Chang'an Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 Passive Test For 2.4GAntenna FreqEffiEffiGain (MHz)(%)(dB)(dBi) 2400 30.7-5.11.8 2410 32.7-4.91.8 2420 33.1-4.82.3 2430 35.1-4.52.7 2440 34.9-4.62.9 2450 33.9-4.72.8 2460 32.5-4.92.8 2470 32.8-4.82.3 2480 33.2-4.82.9 add：东莞市长安镇沙头社区木鱼路59号元富工业区Tel:0769-82586086 Fax:0769-82586086 2490 34.2-4.73.0 2500 33.2-4.83.9 add: Yuanfu Industrial Zone, No. 59 Muyu Road, Shatou Community, Chang'an Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For 2.4G Antenna(2400MHz) add：东莞市长安镇沙头社区木鱼路59号元富工业区Tel:0769-82586086 Fax:0769-82586086 add: Yuanfu Industrial Zone, No. 59 Muyu Road, Shatou Community, Chang'an Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For 2.4G Antenna(2450MHz) add：东莞市长安镇沙头社区木鱼路59号元富工业区Tel:0769-82586086 Fax:0769-82586086 add: Yuanfu Industrial Zone, No. 59 Muyu Road, Shatou Community, Chang'an Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For 2.4G Antenna(2500MHz) add：东莞市长安镇沙头社区木鱼路59号元富工业区Tel:0769-82586086 Fax:0769-82586086 add: Yuanfu Industrial Zone, No. 59 Muyu Road, Shatou Community, Chang'an Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 64 TEST REPORT Reference No. ....................: WTX23X10221080W002 FCC ID ............................... .: 2AUI4-E73 Applicant .......................... .: Universal Ubiquitous AI Co., Ltd. Address ............................ .: Floor 24-26 Building 3,Fashion Vantone City, Cangqian Street,Yuhang District, Hangzhou,Zhejiang,China Manufacturer .................... .: The same as Applicant Address ............................ .: The same as Applicant Product Name .................. .: FACE RECOGNITION TERMINAL Model No... ........................ .: E73-1711-OS-V Standards ......................... .: FCC Part 15.247 Date of Receipt sample ... .: 2023-10-16 Date of Test....................... .: 2023-10-16 to 2023-12-19 Date of Issue .................... .: 2023-12-19 Test Report Form No. ...... . : WTX_Part 15_247W Test Result ........................ .: Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Gala Wang Silin Chen Reference No.: WTX23X10221080W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 64 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................................................... 5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ......................................................................... 5 1.2 TEST STANDARDS ................................................................................................................................................. 6 1.3 TEST METHODOLOGY ........................................................................................................................................... 6 1.4 TEST FACILITY ...................................................................................................................................................... 6 1.5 EUT SETUP AND TEST MODE .............................................................................................................................. 7 1.6 MEASUREMENT UNCERTAINTY ............................................................................................................................. 9 1.7 TEST EQUIPMENT LIST AND DETAILS ................................................................................................................. 10 2. SUMMARY OF TEST RESULTS ......................................................................................................................... 13 3. ANTENNA REQUIREMENT ................................................................................................................................. 14 3.1 STANDARD APPLICABLE ..................................................................................................................................... 14 3.2 EVALUATION INFORMATION ................................................................................................................................ 14 4. FREQUENCY HOPPING SYSTEM REQUIREMENTS .................................................................................... 15 4.1 STANDARD APPLICABLE ..................................................................................................................................... 15 4.2 FREQUENCY HOPPING SYSTEM ......................................................................................................................... 15 4.3 EUT PSEUDORANDOM FREQUENCY HOPPING SEQUENCE ............................................................................... 16 5. QUANTITY OF HOPPING CHANNELS AND CHANNEL SEPARATION .................................................... 17 5.1 STANDARD APPLICABLE ..................................................................................................................................... 17 5.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 17 5.3 TEST PROCEDURE .............................................................................................................................................. 17 5.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 18 6. DWELL TIME OF HOPPING CHANNEL ........................................................................................................... 19 6.1 STANDARD APPLICABLE ..................................................................................................................................... 19 6.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 19 6.3 TEST PROCEDURE .............................................................................................................................................. 19 6.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 20 7. 20DB BANDWIDTH ............................................................................................................................................... 21 7.1 STANDARD APPLICABLE ..................................................................................................................................... 21 7.2 TEST SETUP B…

Text truncated - open the document above for the full version.

Reference No.: WTX23X10221080W001/002/003/004/005 Page 10 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Conducted Emission Test Setup Radiation Emission Test Setup (Below 30MHz) Reference No.: WTX23X10221080W001/002/003/004/005 Page 11 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Radiation Emission Test Setup (30MHz to 1GHz) Radiation Emission Test Setup (1GHz to 18GHz) Reference No.: WTX23X10221080W001/002/003/004/005 Page 12 of 12 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Radiation Emission Test Setup (Above 18GHz) ***** END OF REPORT *****
