2AUL7-03736Mini Remote Control, 4 Buttons

Technical parameters: 1. Working voltage: DC6V 2. Working current: ≤ 25mA 4. Launching distance: 20-50m (open space without interference) 5. Working frequency: 433MHz (optional) 6. Modulation mode: ASK 7. Chip type: EV1527, pt2260 8. Working temperature: - 20 °C ~ + 70 °C 9. Product size: 55 * 32 * 13.5mm Product features: Remote transmitter product description Model: 03736 pcb for Mini transmitter of Mini Remote Control, 4 Buttons High quality shell. The circuit design is stable, the key is no longer used as the power wire, and the high current triode is controlled separately to improve the power dynamic. Imported high-frequency triode is adopted no dead angle Learn to code: 1. In ching: Press the code matching k ey of the control board once, and the LED indicator light flashes once. When the LED indicator light is on, press the remote control that requires code matching Key , control panel LED indicator light flashes for 3 times. 2. Self-locking learning method: Press the code matching k ey of the control board for two consecutive times, and the LED indicator light flashes for 2 times. W hen the LED indicator light is on,press the button for code matching Key of controller, LED indicator light of control board flashes 3 times successively successfully. 3. Interlock learni ng method: Press the code matching button of the control board for 3 times continuously, and the LED indicator light flashes for 3 times. When the LED indicator light turns on, press the button to check the code Key of controller, LED indicator light of control board flashes 3 times successively successfully. 4. Two-way inching and two-way self-locking learning methods: Press the code matching button of the control board for 4 times continuously , and the LED indicator light flashes for 4 times. W hen the LED indicator light turns on, press the button to check the code Key of controller, LED indicator light of control board fl ashes 3 times successively successfully. 5. Learning method of tw o-wa y inching and two-way interlock: Press the code matching button of the control board for 5 consecutive times, and the LED indicator light flashes for 5 times. When the LED indicator light turns on, press the button to check the code Key of controller, LED indicator light of control board flashes 3 times successively successfully. 6. Two-way self-locking and two-way interlock learning methods: Press the code matching button of the control board for 6 times continuously, and the LED indicator light flashes for 6 times. When the LED indicator light turns on, press the button to check the code Key of controller, LED indicator light of control board flashes 3 times successively successfully. 7. Two-way interlocking and two-way interlocking learning methods: Press the code matching button of the control board for 7 times continuously , and the LED indicator light flashes for 7 times. When the LED indicator light is on, press the button to check the code Key of controller, LED indicator light of control board flashes 3 times successively successfully. Clear data: Press the code matching button of the control board for 8 consecutive times, and the LED indicator light flashes 8 times. At this time, the LED indicator light flashes 8 times automatically. Then code clearance is completed, clear all the remote control key codes learned before. Explanation of output mode: 1. self-lock: press the same remote control button, press once, the relay is on, press again, the relay is off. 2. Interlock: press the "A" k ey of the remote control to open the relay; press the "B" key of the remote control to close the relay. 3. Inching: press the "A" k ey of the remote control to open the relay, and release the "A" key of the remote control to close the relay. If you k eep pressing the "a" key of the remote control, the relay will be on all the time. When you release the remote control, w hen the relay will be off. Notes: 1. Do not operate with live power. The power should be turned off for operation. 2. W hen the voltage of the remote control is insufficient, please replace the battery in time (when the battery voltage of the re mote control is insufficient, the distance of the remote control generally becomes close). 3. When using wireless electronic products, it is necessary to avoid strong interference sources such as metal mask, large electronic equipment, electromagnetic field, etc., so as to avoid short distance between remote control and reception o r failure to work normally 4.Do not use this electronic product abnormally. Abnormal use will reduce the performance and life of the product, and serious damage to the product w ill also bring hidden dangers to your safety. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party. Responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded inter…

Text truncated - open the document above for the full version.

LALIZAS ITALIA SRL Agent Authorization Date: 17th December, 2019 Company: LALIZAS ITALIA SRL Address: Via Fontanelle 22, Busalla, 16012, Italy Product Description: Mini Remote Control, 4 Buttons FCC ID Number: FCC ID: 2AUL7-03736 Tested Model Number: 03736 pcb for Mini transmitter of Mini Remote Control ,4 Buttons We authorize Eurofins Product Service GmbH, Storkower Strasse 38c, D-15526 Reichenwalde, Germany, to act on our behalf on all matters concerning the certification of above mentioned equipment. We declare that Eurofins Product Service GmbH is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We, LALIZAS ITALIA SRL, the undersigned, hereby authorize Shenzhen Toby Technology Co., Ltd. (Ivan Su, Supervisor of EMC Dep.), Shenzhen Microwave Certification Services Co., Ltd. (Gilbert Lui, Marketing Manager) and Ka.Ma.S UG (Karin Schmidt, CEO) on our behalf, to apply to the Federal Communications Commission on our equipment. We, the undersigned, hereby authorize Shenzhen Toby Technology Co., Ltd. (Ivan Su, Supervisor of EMC Dep.) to act on our behalf in matters relating to the application for a FCC equipment authorization for mentioned FCC ID Number including the signing of Form 731, necessary forms and documents in connection with this application. Any and all acts carried out by Shenzhen Toby Technology Co., Ltd. (Ivan Su, Supervisor of EMC Dep.) on our behalf shall have the same effect as acts of our own. This authorization expires on 31th December, 2019. Yours Sincerely, LALIZAS ITALIA SRL <Signature of Magda Kartsonaki > ----------------------------------------------------------------------------------- Magda Kartsonaki (R&D Department Administrator) Via Fontanelle 22, Busalla, 16012, Italy Phone: +30 210 4226274+1326 Email: [email protected]

LALIZAS ITALIA SRL CONFIDENTIALITY REQUEST for Certification under the FCC Rules Date: 17th December, 2019 Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the following product: FCC ID Number: FCC ID: 2AUL7-03736 Tested Model Number: 03736 pcb for Mini transmitter of Mini Remote Control ,4 Buttons For the product stated above, we request that the following information be held confidential: Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days Block Diagram Schematic Diagram/ Circuit Diagram Circuit Description/ Operational Description Parts List Tune Up Information User’s Manual External Photos Internal Photos Test Setup Photos The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. Please do not hesitate to contact me if you have any queries. Yours Sincerely, LALIZAS ITALIA SRL <Signature of Magda Kartsonaki > ----------------------------------------------------------------------------------- Magda Kartsonaki (R&D Department Administrator) Via Fontanelle 22, Busalla, 16012, Italy Phone: +30 210 4226274+1326 Email: [email protected]

Report No.: TB-FCC168678 Page: 3 of 7 FCC ID: 2AUL7-03736 TB-RF-075-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT Report No.: TB-FCC168678 Page: 4 of 7 FCC ID: 2AUL7-03736 TB-RF-075-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of EUT

Report No.: TB-FCC168678 Page: 1 of 7 FCC ID: 2AUL7-03736 TB-RF-074-1.0 Appendix IFCC ID Label FCC ID: 2AUL7-03736 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Model: 03736 pcb for Mini transmitter of Mini Remote Control, 4 Buttons 20mm 30mm Report No.: TB-FCC168678 Page: 2 of 7 FCC ID: 2AUL7-03736 TB-RF-075-1.0 Appendix II ID Label Location ID LOCATION

Report No.: TB-FCC168678 Page: 5 of 7 FCC ID: 2AUL7-03736 TB-RF-075-1.0 Appendix IV EUT Internal Photographs Photo 7 Internal of EUT Photo 8 Appearance of PCB 433MHz antenna Report No.: TB-FCC168678 Page: 6 of 7 FCC ID: 2AUL7-03736 TB-RF-075-1.0 Photo 9 Appearance of PCB Photo 10 Battery parameters

Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC168678 Page: 1 of 29 TB-RF-074-1.0 1A/F., Bldg.6, Yusheng Industrial Zone, The National Road No.107 Xixiang Section 467, Xixiang, Bao’an, Shenzhen, China Tel: +86 75526509301 Fax: +86 75526509195 FCC Radio Test Report FCC ID: 2AUL7-03736 Report No. : TB-FCC168678 Applicant : LALIZAS ITALIA SRL Equipment Under Test (EUT) EUT Name : Mini Remote Control, 4 Buttons Model No. : 03736 pcb for Mini transmitter of Mini Remote Control, 4 Buttons Serial No. : N/A Brand Name : Lofrans’ Receipt Date : 2019-08-31 Test Date : 2019-12-01 to 2019-12-15 Issue Date : 2019-12-16 Standards : FCC Part 15, Subpart C (15.231:2018) Test Method : ANSI C63.10:2013 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above, The EUT technically complies with the FCC requirements Test/Witness Engineer : Jack Deng Engineer Supervisor : Ivan Su Engineer Manager : Ray Lai This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TB-FCC168678 Page: 2 of 29 TB-RF-074-1.0 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 6 1.5 Description of Test Mode .................................................................................................... 6 Test Facility ................................................................................................................................. 7 2. TEST SUMMARY ....................................................................................................................... 8 3. CONDUCTED EMISSION TEST ............................................................................................. 9 3.1 Test Standard and Limit ...................................................................................................... 9 3.2 Test Setup ............................................................................................................................. 9 3.3 Test Procedure ..................................................................................................................... 9 3.4 Test Equipment Used ........................................................................................................ 10 3.5 Test Data ............................................................................................................................. 10 4. RADIATED EMISSION TEST ................................................................................................ 11 4.1 Test Standard and Limit .................................................................................................... 11 4.2 Test Setup ........................................................................................................................... 12 4.3 Test Procedure ................................................................................................................... 14 4.4 EUT Operating Condition ................................................................................................. 14 4.5 Test Equipment .................................................................................................................. 14 4.7 Test Data ............................................................................................................................. 15 Radiated Emission Bellow 1 GHz .......................................................................................... 15 5. BANDWIDTH ............................................................................................................................ 22 5.1 Test Standard and Limit .................................................................................................... 22 5.2 Test Setup ........................................................................................................................... 22 5.3 Test Procedure ................................................................................................................... 22 5.4 EUT Operating Condition ................................................................................................. 22 5.5 Test Equipment .................................................................................................................. 22 5.6 Test Condition .................................................................................................................... 22 5.7 Test Data ............................................................................................................................. 23 6. RELEASE TIME MEASUREMENT ....................................................................................... 24 6.1 Test Standard and Limit .................................................................................................... 24 6.2 Test Setup ........................................................................................................................... 24 6.3 Test Procedure ................................................................................................................... 24 6.4 EUT O…

Text truncated - open the document above for the full version.

Report No.: TB-FCC168678 Page: 7 of 7 FCC ID: 2AUL7-03736 TB-RF-075-1.0 Appendix V EUT Test Photographs 15C Test Setup Photo of Setup for Radiated Emission (Above 1 GHz) Photo of Setup for Radiated Emission (Below 1 GHz) -----END OF REPORT-----
