2AUMIDDCMC20101CONTROL BOX

CONTROL BOX User Manual programming port LED port USB chargingport syncport Powersupply port headmotor port footmotor port Programming Port：Enter the program through this port. SyncPort: Two beds can be synchronized through this port. USB ChargingPort: Connect USB charger through this port. LED Port: Connect LED through this port. PowerSupplyPort: Input power through this port. HeadMotorPort: Connect the head motor through this port. FootMotorPort: Connect the foot motor through this port. Remote control pairing Unplug the control box from the power source. Then press and hold the Button and Button si multaneously for about 5 seconds till the backlights of the remote control (model: K07012BK, FCC ID: 2AUMIDDCK07012BK) are off. Plug the control box, two sounds from the buzzer, means the pairing is successful. Operation Instructionof APP 1. Controlthe Adjustable Bed by APP, Cheers APP shallbedownloadedfrom A pplestoreor 360 software, searching with “Cheers adjustable bed” (when using this function, make sure the Bluetooth is activated). 2. Or scan the QR code below to download APP. FCC Warning： Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .This equipment should be installed and operated with minimum distance 20cm between the radiator& your body.
