2AUN9-T2automatic pet feeder

Packing List 1* Feeder 1* Dog Bowl 1* Charger 1* Data Cable 1* Suction Cup 5* Desiccant Packs 4* Double-sided Adhesive Strips Open your mobile app store, search for the "Smart Life" app, and download and install it. Or scan the QR code to download the app. Smart Life (iOS System) Smart Life (Android System) How to Connect the Feeder to the App: 1. Turn on the Bluetooth and Wi-Fi on your phone, ensuring that the Wi-Fi (2.4 GHz) is connected and the network is functioning properly. 2. Connect the feeder to a power source, then press and hold the power button for about 3 seconds until the machine beeps and the green light starts blinking rapidly. (The feeder must be connected to a power source, otherwise, it cannot be paired.) 3. Open the "Smart Life" app. How to Manually Feed: As shown in the left image, press "Feed" at this time, and it will dispense 12 portions of food (approximately 10 grams per portion). The maximum amount dispensed at one time is 12 portions. Choose the time and number of portions for dispensing the food, then simply save the settings. How to Use the Suction Cup: Wipe the surface where the suction cup will be attached and the suction cup itself with a damp cloth. Dry the surface and the suction cup with a dry towel or paper towel. Stick the double-sided adhesive about 1 centimeter from the center of the suction cup, towards the edge. Attach the suction cup to the surface, pressing down around the edges. Place the machine on top of the suction cup. If you're unsure, you can watch a video or ask customer service for assistance. Precautions: 1. The feeder must be plugged into a power source for remote control via the smartphone. If not plugged in, and running purely on battery mode, it will dispense food automatically according to the pre-set schedule. 2. If it dispenses food as scheduled, it will be shown in the feeding record. If there is no record, it means no food was dispensed at the scheduled time. This way, you can know whether the machine is dispensing food properly when you're away. 3. If the machine experiences a blockage, the app interface will display "Dispensing Port Blocked" until the next successful dispensing. This allows you to monitor the machine's functionality remotely. 4. If the suction cup isn't strong enough, please ensure the surface is smooth. Clean the suction cup and the surface with a damp cloth and follow the video instructions again. 5. After the machine is plugged in and paired successfully, the indicator light will stay red. When the built-in battery is fully charged, the green light will blink slowly. 6. The machine automatically powers on when plugged in. It cannot be turned off while plugged in. To turn it off, unplug the charger and press the power button twice quickly. A "beep-beep" sound indicates successful shutdown. To turn it on again, press the power button lightly. 7. When not plugged in, if you remove and then re-insert the battery, the machine will need to be re-paired for the scheduled feeding plan to function. 8. Upon plugging in, the machine will start charging, indicated by a constant red light. When fully charged, the green light will blink. 9. In pure battery mode, when the battery is low, the red light will blink rapidly. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. The equipment complies with FCC Radiation exposure limit set forth for uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

Shenzhen shi yuehuanyu Technology Co.,Ltd. Covered Equipment Certification Attestation Letter DATE: 2024-4-8 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AUN9-T2 Shenzhen shi yuehuanyu Technology Co.,Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List , the applicant should include an explanation on why the equipment is not “covered” equipment. Shenzhen shi yuehuanyu Technology Co.,Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. <Signature> Name:Fuliang Dong Title:manager Company: Shenzhen shi yuehuanyu Technology Co.,Ltd.

* the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. Shenzhen shi yuehuanyu Technology Co.,Ltd. U.S. Agent Designation for Service of Process -Certification Attestation Letter DATE: 2024-4-16 TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTN.: Reviewing Engineer FCC ID: 2AUN9-T2 FRN of applicant: 0028834075 Per section 2.911(d)(7) of the FCC rules, Shenzhen shi yuehuanyu Technology Co.,Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company name: REP America LLC Address: 6510 S Academy Blvd, Ste A #523, Colorado Springs, CO 80906 FRN Number: 0034192500 Contact Name: Ben XU Telephone No: (719) 201-3314 Email: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Signed: Printed name: Fuliang Dong Title: manager Company Name: Shenzhen shi yuehuanyu Technology Co.,Ltd. Date: 2024-4-16 Signed: Printed name: Ben XU Title: manager Company Name: REP America LLC Date: 2024-4-16 Agent Signed (if different from Applicant):

DATE: 2024/04/08 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen POCE Technology Co., Ltd. Address:101-102 Building H5 & 1/F., Building H, Hongfa Science & Technology Park, Tangtou, Shiyan, Bao'an District, Shenzhen, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Shenzhen shi yuehuanyu Technology Co.,Ltd. Address: 601, No. 14-2 Zhengcheng 1st Road, Xintian Community, Fuhai Street, Bao'an District, Shenzhen (Applicant Name and address) <Signature> Name:Fuliang Dong Title:manager Company: Shenzhen shi yuehuanyu Technology Co.,Ltd.

DATE：2024-04-08 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AUN9-T2 Product Name:automatic pet feeder Request for Confidentiality Pursuant t o Sections 0.457 and 0.459 of the commissions rules, we hereby request that th e following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) Schematics Block diagram Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name:Fuliang Dong Title:manager Company: Shenzhen shi yuehuanyu Technology Co.,Ltd.

FCC ID: 2AUN9-T2 External FCC ID: 2AUN9-T2 FCC ID: 2AUN9-T2 FCC ID: 2AUN9-T2

FCC ID: 2AUN9-T2 Label place SIZE: 20*40mm Automatic pet feeder Model: T2 FCC ID: 2AUN9-T2 INPUT: DC5.0V 2A Max

FCC ID: 2AUN9-T2 Internal FCC ID: 2AUN9-T2 FCC ID: 2AUN9-T2 ANT

Page 1 of 1 RF Exposure Evaluation Report 1 RF EXPOSURE Product Name: automatic pet feeder Model No.: T2 FCC ID: 2AUN9-T2 2. RF Exposure Evaluation FCC KDB447498 D01 General RF Exposure Guidance v06: Mobile and Portable Device, RF Exposure, Equipment Authorization Procedures. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices. 2.1 LIMITS According to FCC Part1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in part1.1307(b) F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4* Pi * R 2) Where Page 1 of 1 Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 2.2 EUT RF EXPOSURE EVALUATION BT and WIFI ANT: 2.54dBi The Max Conducted Peak Output Power data refer to report Report No.: POCE240314009RL001& POCE240314009RL002 BT mode and channel: Test channel Conducted Power(dBm) Tune-up Power (dbm) Maximum tune-up Power (dbm) Maximum tune-up Power (mW) Calculated value (mW/cm2) Limit (mW/cm2) Result 2402.00 3.32 3.0±1 4.0 2.512 0.0009 1.0 Pass 2440.00 3.53 3.0±1 4.0 2.512 0.0009 1.0 Pass 2480.00 2.96 3.0±1 4.0 2.512 0.0009 1.0 Pass Remark: Pd = (Pout*G)/(4* Pi * R 2 )=( 2.512*1.7947)/(4*3.1415*20*20)= 0.0009 , G=10 gain/10 =1.7947 2.4GWIFI worst mode and channel: Test channel Conducted Power(dBm) Tune- up Power (dbm) Maximum tune-up Power (dbm) Maximum tune-up Power (mW) Calculated value (mW/cm2) Limit (mW/cm2) Result 802.11b- 2412MHz 18.75 18.0±1 19.0 79.4328 0.0284 1.0 Pass 802.11b- 2437MHz 18.05 18.0±1 19.0 79.4328 0.0284 1.0 Pass 802.11b- 2462MHz 18.67 18.0±1 19.0 79.4328 0.0284 1.0 Pass Remark: Pd = (Pout*G)/(4* Pi * R 2 )=( 79.4328*1.7947)/(4*3.1415*20*20)= 0.0284, G=10 gain/10 =1.7947 EUT RF Exposure Evaluation simultaneous transmission operations According to 865664D02 2.2 d) 1): The sum of the ratios of the spatially averaged results to the applicable frequency dependent MPE limits : Simultaneous transmission mode The sum of the ratios SUM Limit 2.4G WIFI + BT 0.0009+ 0.0284 0.0293 1.0 Conclusion: 0.0293 < 1.0, So there is no sar requirement NOTE:1. EUT RF module is more than 20cm away from the human body. 2.The sum of the ratios(2.4GWIFI + BT) is less than the limit value of 1.0, so there is no sar requirement. Antenna Gain: The maximum Gain measured in fully anechoic chamber is 1.7947 in linear scale.

Page 1 SHANGHAI DEMAN INFORMATION TECHNOLOGY CO.,LTD. MANUFACTURER: TUYA PRODUCT NAME:WBR3 ANTENNA ANTENNA TYPE:PCB WRITED: Long Wang DATE:20190520 VERSIONS:A Page 2 Measurement data Frequency (MHz) 240024502500 Return Loss-8.73-11.76-11.21 VSWR 2.161.711.77 Page 3 Antenna Size Test SetupAntenna Size Page 4 Directivity Diagram 2D YZ XY XZ Page 5 Radiation pattern 3D Page 6 Freq.（MHz）Effi(%)Gain (dBi) 2400 52.29 1.62 2410 52.17 1.71 2420 53.14 1.93 2430 54.16 1.98 2440 57.62 2.00 2450 59.64 2.17 2460 61.55 2.45 2470 60.64 2.38 2480 62.86 2.54 2490 59.85 2.30 2500 60.41 2.49 Efficiency&Gain

V1.0 Report No.: POCE240314009RL001 101-102 Building H5 & 1/F., Building H,Hongfa Science & Technology Park,Tangtou, Shiyan, Bao’an District, Shenzhen, Guangdong, China Web:http://www. poce-cert.com Tel: 86-755-29113252 E-mail: [email protected] Page 1 of 55 RF TEST REPORT For Shenzhen shi yuehuanyu Technology Co.,Ltd. Product Name: automatic pet feeder Test Model(s): T2 Report Reference No. : POCE240314009RL001 FCC ID : 2AUN9-T2 Applicant’s Name : Shenzhen shi yuehuanyu Technology Co.,Ltd. Address : 601, No. 14-2 Zhengcheng 1st Road, Xintian Community, Fuhai Street, Bao'an District, Shenzhen Testing Laboratory : Shenzhen POCE Technology Co., Ltd. Address : 101-102 Building H5 & 1/F., Building H, Hongfa Science & Technology Park, Tangtou, Shiyan, Bao'an District, Shenzhen, Guangdong, China Test Specification Standard : 47 CFR Part 15.247 & KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10-2013 Date of Receipt : March 14, 2024 Date of Test : March 14, 2024 to March 22, 2024 Data of Issue : March 22, 2024 Result : Pass Note: This report shall not be reproduced except in full, without the written approval of Shenzhen POCE Technology Co., Ltd. This document may be altered or revised by Shenzhen POCE Technology Co., Ltd. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. V1.0 Report No.: POCE240314009RL001 101-102 Building H5 & 1/F., Building H,Hongfa Science & Technology Park,Tangtou, Shiyan, Bao’an District, Shenzhen, Guangdong, China Web:http://www. poce-cert.com Tel: 86-755-29113252 E-mail: [email protected] Page 2 of 55 Revision History Of Report Version Description REPORT No. Issue Date V1.0 Original POCE240314009RL001 March 22, 2024 NOTE1: The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Compiled by: Supervised by: Approved by: Keren Huang / Test Engineer Stone Yin / Project Engineer Tom Chen / Manager V1.0 Report No.: POCE240314009RL001 101-102 Building H5 & 1/F., Building H,Hongfa Science & Technology Park,Tangtou, Shiyan, Bao’an District, Shenzhen, Guangdong, China Web:http://www. poce-cert.com Tel: 86-755-29113252 E-mail: [email protected] Page 3 of 55 CONTENTS 1 TEST SUMMARY ........................................................................................................................................... 5 1.1 TEST STANDARDS .................................................................................................................................. 5 1.2 SUMMARY OF TEST RESULT .................................................................................................................... 5 2 GENERAL INFORMATION ............................................................................................................................ 6 2.1 CLIENT INFORMATION ............................................................................................................................. 6 2.2 DESCRIPTION OF DEVICE (EUT) .............................................................................................................. 6 2.3 DESCRIPTION OF TEST MODES ................................................................................................................ 7 2.4 DESCRIPTION OF SUPPORT UNITS ........................................................................................................... 7 2.5 EQUIPMENTS USED DURING THE TEST .................................................................................................... 8 2.6 STATEMENT OF THE MEASUREMENT UNCERTAINTY ................................................................................. 9 2.7 AUTHORIZATIONS ................................................................................................................................... 9 2.8 ANNOUNCEMENT .................................................................................................................................. 10 3 EVALUATION RESULTS (EVALUATION) .................................................................................................... 11 3.1 ANTENNA REQUIREMENT ........................................................................................................................ 11 3.1.1 Conclusion: .............................................................................................................................. 11 4 RADIO SPECTRUM MATTER TEST RESULTS (RF) ................................................................................. 12 4.1 CONDUCTED EMISSION AT AC POWER LINE ........................................................................................... 12 4.1.1 E.U.T. Operation: .................................................................................................................... 12 4.1.2 Test Setup Diagram: ............................................................................................................... 12 4.1.3 Test Data: ............................................................................................................................... 13 4.2 OCCUPIED BANDWIDTH ........................................................................................................................ 15 4.2.1 E.U.T. Operation: .................................................................................................................... 15 4.2.2 Test Setup Diagram: ............................................................................................................... 15 4.2.3 Test Data: ............................................................................................................................... 15 4.3 MAXIMUM CONDUCTED OUTPUT POWER .................…
