2AUSP-BABY8GMCBaby Monitor

• Please read this instruction manual carefully before using, and keep it for future reference. • Functions and features are subject to change without further notice. Baby Monitor with Bluetooth, Wi-Fi and SRD function V1.1.1 1. Meet the camera • The camera needs to be plugged in to a power source before it can be used. • Please use the original AC adapter and power cord to power on the camera. Status LED indicator Camera lens Microphone SD card slot Reset hole Call/Pair button Speaker USB Type-C power port Power adapter & cable 1 2. Mee t the monitor 5-inch LCD display Reset key Type-C charging port On/off switch Status indicator Microphone Direction keys OK Return Menu Intercom Zoom Internal antenna Speaker Foldable stand Memory card slot Type-C charging port Reset key 2 3. Charge Your Monitor 1. The monitor comes with a built-in battery that can last up to 6 hours of continuous use after a full charge. When the battery is low, it will pop-up low power alert. 2. Please use the original AC adapter and power cord(1M) for battery recharge. It takes about 5 hours to fully charge the monitor. 3. Do not use this product on a sloping or unstable surface, keep it away from heat sources to avoid possible damage, and do not place it near or on any electrical appliances. 4. Do not allow children to use this product as a toy without supervision. 1.5 meter Power Cable AC Adapter 3 4. App Download Search 'CloudEdge' in the App stores or scanbelow QR codes to download the App. 5. Connect the Camera to the APP The camera can be connected both to the monitor and the App.Generally, it is connected to the monitor by default. Follow the steps below to connect the camera to the App. 1. Make sure the Wi-Fi network is a 2.45GHz network. 2. Download the 'CloudEdge' App on your phone. Register a new account to log in or log in directly. 3. Press the Reset button for five seconds until you hear the "BOOGU" which means the camera has been reset, after 10-20 seconds, you will hear another beep and the red light of the camera blinks slowly. 4 Most routers typically have a 2.4GHz Wi-Fi network, with some routers also having a 5GHz Wi-Fi network. When connectingto the app, please make sure you are connected to the 2.4GHz Wi-Fi network to ensure stable signal transmission. 4. Follow the step instructions on your smart phone to add the camera, and scan the QR code with your camera. LED STATUSINDICATION Device is abnormal.Solid red Ready for Wi-Fi configuration. Connecting to Wi-Fi Device is onlineSolid blue Firmware upgradingFlash blue (twice/sec) Flash red (once/sec) Flash red (twice/sec) • Make sure your phone's Bluetooth is turned on. • Make sure your phone is connecting to a 2.4GHz Wi-Fi . • Open 'CloudEdge', reset the camera, click "+" in the upper right corner, select Add Device, "Device Found" will pop up at the bottom of the page, click to enter, select 2.4GHz Wi-Fi network andenter the password to connect. 5 6. Installation 6.1. Insert memory card for camera(not included). 6.2. Insert memory card for monitor(not included). • The memory cards are sold separately. • Check SD card status: For camera: In the CloudEdge App, tap the Recording Management in the Settings to check the SD card status. For monitor, check the memrory card status in monitor Settings --> SD card. • If the memory card status displays as Uninitialized, tap to format the SD card. 6 7. Pair with Monitor The camera is pre-paired with its monitor to work as a system. The transmission range is limited by distance. Make sure the distance between them is within 200m (656 ft). 6.3. Mount your camera (Optional) The camera can be placed horizontally or mounted on the ceiling. Here we take ceiling mounting as an example. • Make sure the ceiling is strong enough to withstand three times the weight of the camera. • Avoid positioning the camera to strong light source. • (For cement wall/ceiling only) Drill screw holes accordingly and insert three anchors. • Screw in the metal screws to fix the camera mount. Mount the camera to the base, and turn it clockwise until it is fixed. 7 7.1. Steps to unpair the camera: Press power key to light up screen. Press menu button. Select Settings, and press OK. Select Camera and press OK. Press and hold OK to unpair your camera. Camer a S uccessfull y P air ed Press a nd hold O K to unpair your camera. Camera management Power Menu Settings Camera Sleep ModeDate and Time Camera Light SD Card Feeding Reminder Temperature and humiduty Smar t Car e Camera OK 8 Camera Sleep ModeDate and Time Camera Light SD Card Feeding Reminder Temperature and humiduty Smar t Car e 7.2. Steps to reconnect your camera to monitor: The monitor support adding 2 cameras, follow suit to add another camera to your monitor. Press and hold the PAIR button on the camera till you hear a prompt tone. Select Camera in monitor settings, click OK. Click OK button to start pairing. Pairing succeeds. Pair Camera OK Camera management Camera Not Paired 1. Pr ess and hold the pairing button on the camera untill you hear the tone. 2. Pr ess the OK button on the monitor to finalize pairing your camera. 3. Binding is expected to take 20 seconds 9 Camera Sleep ModeDate and Time Camera Light SD Card Feeding Reminder Temperature and humiduty Smar t Car e Wallpaper Language Safty Protection Factory Reset Device Infor 8.Monitor Setting Menu Camera: To pair or unpair a camera. Feeding Reminder: Make feeding schedules and get alert alarms. Smart Care: Set motion detection and noise detection alarm. Sleep Mode: Customize screen timeout settings. Date & Time: Set system date and time. Camera Light: To turn on/off camera indicator light. SD Card: Check the memory card status. Wallpaper: Customize your wallpaper on your monitor. Language: Operating language setting. Factory Reset: To restore factory defaults. Device information: Check camera and monitor information here. Safety Protection: ➊ Choose to cut off Wi-Fi, and block the remote view access. ➋ Remote access history w…

Text truncated - open the document above for the full version.

ReportNo.:MTEB26080064-R1Page 38 of 83 NT/NV_Antenna0 IEEE802.11ac_Channel165_20MHz IEEE802.11ac_40 NT/NV_Antenna0 IEEE802.11ac_Channel151_40MHz NT/NV_Antenna0 IEEE802.11ac_Channel159_40MHz IEEE802.11ax_20 NT/NV_Antenna0 IEEE802.11ax_Channel149_20MHz NT/NV_Antenna0 IEEE802.11ax_Channel157_20MHz NT/NV_Antenna0 IEEE802.11ax_Channel165_20MHz ReportNo.:MTEB26080064-R1Page 39 of 83 IEEE802.11ax_40 NT/NV_Antenna0 IEEE802.11ax_Channel151_40MHz NT/NV_Antenna0 IEEE802.11ax_Channel159_40MHz ReportNo.:MTEB26080064-R1Page 40 of 83 APPENDIXII.ConductedOutputPower U-NII1: Conductedoutputpower ModeChannelRU&Index Ant.0 (dBm) Corr'dValue Ant.0 (dBm) Limit (dBm) Result IEEE802.11a 36 N/A 13.1215.25≤24PASS 4013.7115.84≤24PASS 4813.7115.84≤24PASS IEEE 802.11n_20 3612.7815.29≤24PASS 4013.1815.68≤24PASS 4813.4615.96≤24PASS IEEE 802.11n_40 386.9611.53≤24PASS 4611.4716.04≤24PASS IEEE 802.11ac_20 3612.7115.05≤24PASS 4013.5015.84≤24PASS 4813.5515.89≤24PASS IEEE 802.11ac_40 387.2611.72≤24PASS 4611.7616.23≤24PASS IEEE 802.11ax_20 36 SU 12.6815.14≤24PASS 4013.5015.96≤24PASS 4813.4715.93≤24PASS IEEE 802.11ax_40 387.2211.56≤24PASS 4611.6215.96≤24PASS Note:CorrectedValue=AntennaPower+DutyCycleFactor. U-NII3: Conductedoutputpower ModeChannelRU&Index Ant.0 (dBm) Corr'dValue Ant.0 (dBm) Limit (dBm) Result IEEE802.11a 149 N/A 14.3816.54≤30PASS 15713.9716.12≤30PASS 16512.4514.61≤30PASS IEEE 802.11n_20 14914.1016.62≤30PASS 15713.6316.15≤30PASS 16512.1514.67≤30PASS IEEE 802.11n_40 15112.0516.64≤30PASS 1598.2712.86≤30PASS IEEE 802.11ac_20 14914.2216.69≤30PASS 15713.7516.23≤30PASS 16512.2714.74≤30PASS IEEE 802.11ac_40 15112.9817.51≤30PASS 1598.5013.02≤30PASS IEEE 802.11ax_20 149 SU 14.2916.89≤30PASS 15713.8716.47≤30PASS 16512.3014.9≤30PASS IEEE 802.11ax_40 15112.2216.74≤30PASS 1598.6113.13≤30PASS Note:CorrectedValue=AntennaPower+DutyCycleFactor. ReportNo.:MTEB26080064-R1Page 41 of 83 APPENDIXIII.99%Bandwidth U-NII1: TestResult ModeChannelRU&IndexAnt. Center Frequency(MHz) 99%BW(MHz) IEEE802.11a 36 N/A 0 518016.460 40520016.439 48524016.475 IEEE802.11n_20 36518017.623 40520017.555 48524017.609 IEEE802.11n_40 38519035.910 46523036.024 IEEE802.11ac_20 36518017.572 40520017.565 48524017.594 IEEE802.11ac_40 38519035.882 46523036.001 IEEE802.11ax_20 36 SU 518017.597 40520017.573 48524017.606 IEEE802.11ax_40 38519035.894 46523036.016 TestGraphs IEEE802.11a_Channel36_20MHz_Antenna0IEEE802.11a_Channel40_20MHz_Antenna0 IEEE802.11a_Channel48_20MHz_Antenna0IEEE802.11n_Channel36_20MHz_Antenna0 ReportNo.:MTEB26080064-R1Page 42 of 83 IEEE802.11n_Channel40_20MHz_Antenna0IEEE802.11n_Channel48_20MHz_Antenna0 IEEE802.11n_Channel38_40MHz_Antenna0IEEE802.11n_Channel46_40MHz_Antenna0 IEEE802.11ac_Channel36_20MHz_Antenna0IEEE802.11ac_Channel40_20MHz_Antenna0 IEEE802.11ac_Channel48_20MHz_Antenna0IEEE802.11ac_Channel38_40MHz_Antenna0 ReportNo.:MTEB26080064-R1Page 43 of 83 IEEE802.11ac_Channel46_40MHz_Antenna0 IEEE802.11ax_Channel36_20MHz_Antenna 0_RU&IndexSU IEEE802.11ax_Channel40_20MHz_Antenna 0_RU&IndexSU IEEE802.11ax_Channel48_20MHz_Antenna 0_RU&IndexSU IEEE802.11ax_Channel38_40MHz_Antenna 0_RU&IndexSU IEEE802.11ax_Channel46_40MHz_Antenna 0_RU&IndexSU ReportNo.:MTEB26080064-R1Page 44 of 83 U-NII3: TestResult ModeChannelRU&IndexAnt. Center Frequency(MHz) 99%BW(MHz) IEEE802.11a 149 N/A 0 574516.512 157578516.486 165582516.490 IEEE802.11n_20 149574517.607 157578517.623 165582517.607 IEEE802.11n_40 151575535.987 159579535.854 IEEE802.11ac_20 149574517.615 157578517.598 165582517.599 IEEE802.11ac_40 151575536.152 159579535.855 IEEE802.11ax_20 149 SU 574517.619 157578517.574 165582517.627 IEEE802.11ax_40 151575535.976 159579535.900 TestGraphs IEEE802.11a_Channel149_20MHz_Antenna0IEEE802.11a_Channel157_20MHz_Antenna0 IEEE802.11a_Channel165_20MHz_Antenna0IEEE802.11n_Channel149_20MHz_Antenna0 ReportNo.:MTEB26080064-R1Page 45 of 83 IEEE802.11n_Channel157_20MHz_Antenna0IEEE802.11n_Channel165_20MHz_Antenna0 IEEE802.11n_Channel151_40MHz_Antenna0IEEE802.11n_Channel159_40MHz_Antenna0 IEEE802.11ac_Channel149_20MHz_Antenna0IEEE802.11ac_Channel157_20MHz_Antenna0 IEEE802.11ac_Channel165_20MHz_Antenna0IEEE802.11ac_Channel151_40MHz_Antenna0

ModelNo.:Baby8GM CETESTSETUP RETESTSETUP ModelNo.:Baby8GM RETESTSETUP

SPECIFICATION Shenzhen Strongpower Communication Co., Ltd 深圳市瑞强通信有限公司 Shenzhen Strongpower Communication Co.,Ltd. baby3G 天线产品规格书 baby3G Antenna Product Specification 客 户 Customer 卓悦 Zhuoyue 频 段 Frequency Band WIFI: 2400MHz-2500MHz 5150MHz-5850MHz 项目名称 Project Name baby3G 天线类型 Antenna Type FPC+ 焊线 FPC with soldered wire 天线料号 Antenna P/N RQ03B161875B-WIFI 颜 色 Coloer 黑 色 Black RF 设计 RF Design 贺一柏 HeYibai 结 构 Structure Designer 彭耀辉 PengYaohui 技术总监 Technical Director 傅以成 Fu Yicheng 日 期 Date 2026-07-07 客户确认 Customer Confirmation ： Confidential Information 保 密 要 求 深圳市瑞强通信有限公司已拥有专有技术所提供的资料，这些专有资料应严加保密，在未经深圳市瑞强通信技术有限公司事 先书面同意的时不允许透露给任何人或公司。 Page 2 Table of Contents 1 ． TheEquipmentofActive&PassiveTest..........................................................................................................3 2 ． PassiveTestData..................................................................................................................................................4 1.S-Parameters (Free Space).........................................................................................................................................4 3.Efficiency and Gain (Free Space)..............................................................................................................................5 4.Passive Radiation Pattern (Free Space)..................................................................................................................... 5 3 ． ActiveTestData......................................................................................................................................................6 1.TRP&TIS(Free Space ） ............................................................................................................................................ 6 OTA （ Free Space ） .....................................................................................................................................................6 TRP................................................................................................................................................................................6 TIS.................................................................................................................................................................................6 4 ． MatchingCircuit.....................................................................................................................................................7 5 ． Engineeringdrawing.............................................................................................................................................7 Confidential Information 保 密 要 求 深圳市瑞强通信有限公司已拥有专有技术所提供的资料，这些专有资料应严加保密，在未经深圳市瑞强通信技术有限公司事 先书面同意的时不允许透露给任何人或公司。 Page 3 1 、测试环境 The Equipment ofActive&Passive Test 1. 测试系统 Test System Confidential Information 保 密 要 求 深圳市瑞强通信有限公司已拥有专有技术所提供的资料，这些专有资料应严加保密，在未经深圳市瑞强通信技术有限公司事 先书面同意的时不允许透露给任何人或公司。 Page 4 2. 测试仪器 Test Equipment Confidential Information 保 密 要 求 深圳市瑞强通信有限公司已拥有专有技术所提供的资料，这些专有资料应严加保密，在未经深圳市瑞强通信技术有限公司事 先书面同意的时不允许透露给任何人或公司。 Page 5 2 、无源测试数据 Passive Test Data 1.S 参数 S-Parameters 2. 无源效率及增益 Efficiency&Gain Freque ncy/M hz Efficien cy/dB Efficienc y/% MaxGain /dBi 2400-2.8651.763.46 2410-2.7253.463.82 2420-2.654.953.82 2430-2.3558.214.19 2440-2.2659.434.38 2450-2.2559.574.28 2460-2.3158.754.25 2470-2.1560.954.26 2480-2.161.664.32 2490-2.0861.944.06 2500-2.1261.383.99 5150-3.9340.461.47 5160-3.8741.021.64 5170-3.9140.641.53 5180-3.8741.021.61 Confidential Information 保 密 要 求 深圳市瑞强通信有限公司已拥有专有技术所提供的资料，这些专有资料应严加保密，在未经深圳市瑞强通信技术有限公司事 先书面同意的时不允许透露给任何人或公司。 Page 6 5190-3.8940.831.73 5200-3.9640.181.71 5210-3.9440.361.83 5220-3.7142.561.94 5230-3.7542.172.31 5240-3.7542.172.35 5250-3.8840.932.61 5260-3.7941.782.62 5270-3.940.742.83 5280-3.6243.453.01 5290-3.4944.773.22 5300-3.2647.213.31 5310-3.346.773.39 5320-3.2747.13.38 5330-3.4145.63.53 5340-3.445.713.47 5350-3.4744.983.51 5360-3.2647.213.48 5370-3.346.773.67 5380-3.2447.423.65 5390-3.2647.213.64 5400-3.2147.753.78 5410-3.3146.673.67 5420-3.1947.973.6 5430-3.1947.973.55 5440-3.1947.973.48 5450-3.2647.213.29 5460-3.2347.533.32 5470-3.4744.983.25 5480-3.3945.813.1 5490-3.5544.163 5500-3.2447.423.06 5510-3.4145.63.05 5520-3.1848.083.12 5530-3.4345.393.12 5540-3.2647.213.11 5550-3.4944.773.01 5560-3.3446.342.94 5570-3.3845.922.94 5580-3.2247.642.84 5590-3.4245.52.66 Confidential Information 保 密 要 求 深圳市瑞强通信有限公司已拥有专有技术所提供的资料，这些专有资料应严加保密，在未经深圳市瑞强通信技术有限公司事 先书面同意的时不允许透露给任何人或公司。 Page 7 5600-3.2747.12.57 5610-3.5943.752.25 5620-3.5743.952.07 5630-3.6343.351.99 5640-3.4145.62.17 5650-3.5244.462.15 5660-3.5843.852.13 5670-3.7342.362.19 5680-3.8441.32.1 5690-4.0439.452.07 5700-3.9440.362.18 5710-4.0139.722.33 5720-3.8741.022.42 5730-4.1138.822.45 5740-4.0539.362.51 5750-4.2337.762.58 5760-4.2437.672.49 5770-4.2737.412.69 5780-3.9839.992.94 5790-4.138.93.1 5800-4.0938.993.1 5810-4.238.023.24 5820-4.2337.763.2 5830-4.4236.143.21 5840-4.0839.083.5 5850-4.1438.553.69 Confidential Information 保 密 要 求 深圳市瑞强通信有限公司已拥有专有技术所提供的资料，这些专有资料应严加保密，在未经深圳市瑞强通信技术有限公司事 先书面同意的时不允许透露给任何人或公司。 Page 8 3. 无源方向图 Passive Radiation Pattern WiFi 2.4G Pin 0Pin 90Theta 90 WiFi 5.8G Pin 0Pin 90Theta 90 3、有源测试数据 Active Test Data 4 、匹配电路 Matching Circuit 无 None 5 、工程图 Engineering Drawing （见下页 See next page ） Shenzhen Strongpower Communication Co., Ltd. 由 Autodesk 教育版产品制作 由 Autodesk 教育版产品制作 由 Autodesk 教育版产品制作 由 Autodesk 教育版产品制作

ReportNo.:MTEB26080064-R1Page 82 of 83 IEEE802.11n_Channel157_20MHz_Antenna0IEEE802.11n_Channel165_20MHz_Antenna0 IEEE802.11n_Channel151_40MHz_Antenna0IEEE802.11n_Channel159_40MHz_Antenna0 IEEE802.11ac_Channel149_20MHz_Antenna0IEEE802.11ac_Channel157_20MHz_Antenna0 IEEE802.11ac_Channel165_20MHz_Antenna0IEEE802.11ac_Channel151_40MHz_Antenna0 ReportNo.:MTEB26080064-R1Page 83 of 83 IEEE802.11ac_Channel159_40MHz_Antenna0 IEEE802.11ax_Channel149_20MHz_Antenna 0_RU&IndexSU IEEE802.11ax_Channel157_20MHz_Antenna 0_RU&IndexSU IEEE802.11ax_Channel165_20MHz_Antenna 0_RU&IndexSU IEEE802.11ax_Channel151_40MHz_Antenna 0_RU&IndexSU IEEE802.11ax_Channel159_40MHz_Antenna 0_RU&IndexSU **********************EndofReport**********************

ReportNo.:MTEB26080064-R1Page 76 of 83 IEEE802.11n_20MHz_Channel157IEEE802.11n_20MHz_Channel165 IEEE802.11n_40MHz_Channel151IEEE802.11n_40MHz_Channel159 IEEE802.11ac_20MHz_Channel149IEEE802.11ac_20MHz_Channel157 IEEE802.11ac_20MHz_Channel165IEEE802.11ac_40MHz_Channel151 ReportNo.:MTEB26080064-R1Page 77 of 83 IEEE802.11ac_40MHz_Channel159IEEE802.11ax_20MHz_Channel149 IEEE802.11ax_20MHz_Channel157IEEE802.11ax_20MHz_Channel165 IEEE802.11ax_40MHz_Channel151IEEE802.11ax_40MHz_Channel159 ReportNo.:MTEB26080064-R1Page 78 of 83 APPENDIXVIII.PowerSpectralDensity U-NII1: TestResult ModeChannelRU&Index Ant.0 MeasPSD (dBm/MHz) Ant.0 Corr'dPSD (dBm/MHz) Limit (dBm/MHz) Result IEEE802.11a 36 N/A 3.7705.901 11 PASS 404.6316.762PASS 484.6646.795PASS IEEE 802.11n_20 363.1025.605PASS 404.0856.588PASS 484.3796.882PASS IEEE 802.11n_40 38-5.194-0.622PASS 46-0.8153.757PASS IEEE 802.11ac_20 363.0195.362PASS 404.0026.345PASS 484.2646.607PASS IEEE 802.11ac_40 38-4.917-0.451PASS 46-0.6743.792PASS IEEE 802.11ax_20 36 SU 3.4975.956PASS 404.0106.469PASS 483.9036.362PASS IEEE 802.11ax_40 38-5.289-0.955PASS 46-0.8403.494PASS TestGraphs IEEE802.11a_Channel36_20MHz_Antenna0IEEE802.11a_Channel40_20MHz_Antenna0 IEEE802.11a_Channel48_20MHz_Antenna0IEEE802.11n_Channel36_20MHz_Antenna0 ReportNo.:MTEB26080064-R1Page 79 of 83 IEEE802.11n_Channel40_20MHz_Antenna0IEEE802.11n_Channel48_20MHz_Antenna0 IEEE802.11n_Channel38_40MHz_Antenna0IEEE802.11n_Channel46_40MHz_Antenna0 IEEE802.11ac_Channel36_20MHz_Antenna0IEEE802.11ac_Channel40_20MHz_Antenna0 IEEE802.11ac_Channel48_20MHz_Antenna0IEEE802.11ac_Channel38_40MHz_Antenna0 ReportNo.:MTEB26080064-R1Page 80 of 83 IEEE802.11ac_Channel46_40MHz_Antenna0 IEEE802.11ax_Channel36_20MHz_Antenna 0_RU&IndexSU IEEE802.11ax_Channel40_20MHz_Antenna 0_RU&IndexSU IEEE802.11ax_Channel48_20MHz_Antenna 0_RU&IndexSU IEEE802.11ax_Channel38_40MHz_Antenna 0_RU&IndexSU IEEE802.11ax_Channel46_40MHz_Antenna 0_RU&IndexSU ReportNo.:MTEB26080064-R1Page 81 of 83 U-NII3: TestResult ModeChannelRU&Index Ant.0 MeasPSD (dBm/500kHz) Ant.0 Corr'dPSD (dBm/500kHz) Limit (dBm/500kHz) Result IEEE802.11a 149 N/A 1.8944.048 30 PASS 1571.7713.925PASS 1650.3312.485PASS IEEE 802.11n_20 1491.5374.055PASS 1571.2123.73PASS 165-0.1962.322PASS IEEE 802.11n_40 151-3.4091.178PASS 159-6.330-1.743PASS IEEE 802.11ac_20 1491.9004.373PASS 1571.2183.691PASS 165-0.2122.261PASS IEEE 802.11ac_40 151-2.1872.337PASS 159-6.276-1.752PASS IEEE 802.11ax_20 149 SU 1.9574.557PASS 1571.2613.861PASS 165-0.0592.541PASS IEEE 802.11ax_40 151-3.1771.347PASS 159-6.724-2.2PASS TestGraphs IEEE802.11a_Channel149_20MHz_Antenna0IEEE802.11a_Channel157_20MHz_Antenna0 IEEE802.11a_Channel165_20MHz_Antenna0IEEE802.11n_Channel149_20MHz_Antenna0

ReportNo.:MTEB26080064-R1Page 71 of 83 OutOfBandEmission IEEE802.11ax_Channel151_40MHz_Antenna 0_RU&IndexSU SpuriousEmission:30.0~5650MHz IEEE802.11ax_Channel151_40MHz_Antenna 0_RU&IndexSU SpuriousEmission:5925~25000.0MHz IEEE802.11ax_Channel151_40MHz_Antenna 0_RU&IndexSU OutOfBandEmission IEEE802.11ax_Channel159_40MHz_Antenna 0_RU&IndexSU SpuriousEmission:30.0~5650MHz IEEE802.11ax_Channel159_40MHz_Antenna 0_RU&IndexSU SpuriousEmission:5925~25000.0MHz IEEE802.11ax_Channel159_40MHz_Antenna 0_RU&IndexSU ReportNo.:MTEB26080064-R1Page 72 of 83 APPENDIXVII.DutyCycle U-NII1: TestResult Mode Data rates Channel RU& Index Antenna On Time (ms) Period (ms) Duty Cycle (%) Duty Cycle (linear) Duty Cycle Factor (dB) 1/T IEEE 802.11a 54 36 N/A 1 0.1810.29461.560.61562.1075.5249 400.1800.29461.220.61222.13115.5556 480.1800.29461.220.61222.13115.5556 IEEE 802.11n_20 MCS7 360.1680.29157.730.57732.3865.9524 400.1670.30055.600.55602.54935.9880 480.1680.29956.190.56192.50345.9524 IEEE 802.11n_40 380.1040.29934.780.34784.58679.6154 460.1040.29834.900.34904.57179.6154 IEEE 802.11ac_20 MCS9 360.1730.29558.640.58642.31815.7803 400.1720.29558.310.58312.34265.8140 480.1720.29558.310.58312.34265.8140 IEEE 802.11ac_40 380.1080.37428.880.28885.3949.2593 460.1080.30235.760.35764.4669.2593 IEEE 802.11ax_20 MCS 11 36 SU 0.1720.29558.310.58312.34265.8140 400.1720.29558.310.58312.34265.8140 480.1720.30356.770.56772.45885.8140 IEEE 802.11ax_40 380.1080.29436.730.36734.34989.2593 460.1080.29336.860.36864.33449.2593 TestGraphs IEEE802.11a_20MHz_Channel36IEEE802.11a_20MHz_Channel40 IEEE802.11a_20MHz_Channel48IEEE802.11n_20MHz_Channel36 ReportNo.:MTEB26080064-R1Page 73 of 83 IEEE802.11n_20MHz_Channel40IEEE802.11n_20MHz_Channel48 IEEE802.11n_40MHz_Channel38IEEE802.11n_40MHz_Channel46 IEEE802.11ac_20MHz_Channel36IEEE802.11ac_20MHz_Channel40 IEEE802.11ac_20MHz_Channel48IEEE802.11ac_40MHz_Channel38 ReportNo.:MTEB26080064-R1Page 74 of 83 IEEE802.11ac_40MHz_Channel46IEEE802.11ax_20MHz_Channel36 IEEE802.11ax_20MHz_Channel40IEEE802.11ax_20MHz_Channel48 IEEE802.11ax_40MHz_Channel38IEEE802.11ax_40MHz_Channel46 ReportNo.:MTEB26080064-R1Page 75 of 83 U-NII3: TestResult Mode Data rates Channel RU& Index Antenna On Time (ms) Period (ms) Duty Cycle (%) Duty Cycle (linear) Duty Cycle Factor (dB) 1/T IEEE 802.11a 54 149 N/A 1 0.1800.29461.220.61222.13115.5556 1570.1800.29461.220.61222.13115.5556 1650.1790.29360.900.60902.15385.5866 IEEE 802.11n_20 MCS7 1490.1690.30056.330.56332.49265.9172 1570.1670.30055.820.55822.53215.9880 1650.1680.30056.000.56002.51815.9524 IEEE 802.11n_40 1510.1030.29834.510.34514.62069.7087 1590.1040.29934.780.34784.58679.6154 IEEE 802.11ac_20 MCS9 1490.1720.30456.580.56582.47345.8140 1570.1720.29558.310.58312.34265.8140 1650.1720.30456.580.56582.47345.8140 IEEE 802.11ac_40 1510.1080.29436.730.36734.34989.2593 1590.1070.30235.290.35294.52359.3458 IEEE 802.11ax_20 MCS 11 149 SU 0.1720.30456.580.56582.47345.8140 1570.1710.30456.180.56182.50425.8480 1650.1720.31354.950.54952.60035.8140 IEEE 802.11ax_40 1510.1080.29436.730.36734.34989.2593 1590.1070.30235.290.35294.52359.3458 TestGraphs IEEE802.11a_20MHz_Channel149IEEE802.11a_20MHz_Channel157 IEEE802.11a_20MHz_Channel165IEEE802.11n_20MHz_Channel149

ReportNo.:MTEB26080064-R1Page 67 of 83 SpuriousEmission:30.0~5650MHz IEEE802.11n_Channel165_20MHz_Antenna0 SpuriousEmission:5925~25000.0MHz IEEE802.11n_Channel165_20MHz_Antenna0 OutOfBandEmission IEEE802.11n_Channel151_40MHz_Antenna0 SpuriousEmission:30.0~5650MHz IEEE802.11n_Channel151_40MHz_Antenna0 SpuriousEmission:5925~25000.0MHz IEEE802.11n_Channel151_40MHz_Antenna0 OutOfBandEmission IEEE802.11n_Channel159_40MHz_Antenna0 SpuriousEmission:30.0~5650MHz IEEE802.11n_Channel159_40MHz_Antenna0 SpuriousEmission:5925~25000.0MHz IEEE802.11n_Channel159_40MHz_Antenna0 ReportNo.:MTEB26080064-R1Page 68 of 83 OutOfBandEmission IEEE802.11ac_Channel149_20MHz_Antenna0 SpuriousEmission:30.0~5650MHz IEEE802.11ac_Channel149_20MHz_Antenna0 SpuriousEmission:5925~25000.0MHz IEEE802.11ac_Channel149_20MHz_Antenna0 OutOfBandEmission IEEE802.11ac_Channel157_20MHz_Antenna0 SpuriousEmission:30.0~5650MHz IEEE802.11ac_Channel157_20MHz_Antenna0 SpuriousEmission:5925~25000.0MHz IEEE802.11ac_Channel157_20MHz_Antenna0 OutOfBandEmission IEEE802.11ac_Channel165_20MHz_Antenna0 SpuriousEmission:30.0~5650MHz IEEE802.11ac_Channel165_20MHz_Antenna0 ReportNo.:MTEB26080064-R1Page 69 of 83 SpuriousEmission:5925~25000.0MHz IEEE802.11ac_Channel165_20MHz_Antenna0 OutOfBandEmission IEEE802.11ac_Channel151_40MHz_Antenna0 SpuriousEmission:30.0~5650MHz IEEE802.11ac_Channel151_40MHz_Antenna0 SpuriousEmission:5925~25000.0MHz IEEE802.11ac_Channel151_40MHz_Antenna0 OutOfBandEmission IEEE802.11ac_Channel159_40MHz_Antenna0 SpuriousEmission:30.0~5650MHz IEEE802.11ac_Channel159_40MHz_Antenna0 SpuriousEmission:5925~25000.0MHz IEEE802.11ac_Channel159_40MHz_Antenna0 OutOfBandEmission IEEE802.11ax_Channel149_20MHz_Antenna 0_RU&IndexSU ReportNo.:MTEB26080064-R1Page 70 of 83 SpuriousEmission:30.0~5650MHz IEEE802.11ax_Channel149_20MHz_Antenna 0_RU&IndexSU SpuriousEmission:5925~25000.0MHz IEEE802.11ax_Channel149_20MHz_Antenna 0_RU&IndexSU OutOfBandEmission IEEE802.11ax_Channel157_20MHz_Antenna 0_RU&IndexSU SpuriousEmission:30.0~5650MHz IEEE802.11ax_Channel157_20MHz_Antenna 0_RU&IndexSU SpuriousEmission:5925~25000.0MHz IEEE802.11ax_Channel157_20MHz_Antenna 0_RU&IndexSU OutOfBandEmission IEEE802.11ax_Channel165_20MHz_Antenna 0_RU&IndexSU SpuriousEmission:30.0~5650MHz IEEE802.11ax_Channel165_20MHz_Antenna 0_RU&IndexSU SpuriousEmission:5925~25000.0MHz IEEE802.11ax_Channel165_20MHz_Antenna 0_RU&IndexSU

ReportNo.:MTEB26080064-R1Page 59 of 83 SpuriousEmission:30.0~5150MHz IEEE802.11ac_Channel38_40MHz_Antenna0 SpuriousEmission:5350~25000.0MHz IEEE802.11ac_Channel38_40MHz_Antenna0 OutOfBandEmission IEEE802.11ac_Channel46_40MHz_Antenna0 SpuriousEmission:30.0~5150MHz IEEE802.11ac_Channel46_40MHz_Antenna0 SpuriousEmission:5350~25000.0MHz IEEE802.11ac_Channel46_40MHz_Antenna0 OutOfBandEmission IEEE802.11ax_Channel36_20MHz_Antenna 0_RU&IndexSU SpuriousEmission:30.0~5150MHz IEEE802.11ax_Channel36_20MHz_Antenna 0_RU&IndexSU SpuriousEmission:5350~25000.0MHz IEEE802.11ax_Channel36_20MHz_Antenna 0_RU&IndexSU ReportNo.:MTEB26080064-R1Page 60 of 83 OutOfBandEmission IEEE802.11ax_Channel40_20MHz_Antenna 0_RU&IndexSU SpuriousEmission:30.0~5150MHz IEEE802.11ax_Channel40_20MHz_Antenna 0_RU&IndexSU SpuriousEmission:5350~25000.0MHz IEEE802.11ax_Channel40_20MHz_Antenna 0_RU&IndexSU OutOfBandEmission IEEE802.11ax_Channel48_20MHz_Antenna 0_RU&IndexSU SpuriousEmission:30.0~5150MHz IEEE802.11ax_Channel48_20MHz_Antenna 0_RU&IndexSU SpuriousEmission:5350~25000.0MHz IEEE802.11ax_Channel48_20MHz_Antenna 0_RU&IndexSU OutOfBandEmission IEEE802.11ax_Channel38_40MHz_Antenna 0_RU&IndexSU SpuriousEmission:30.0~5150MHz IEEE802.11ax_Channel38_40MHz_Antenna 0_RU&IndexSU ReportNo.:MTEB26080064-R1Page 61 of 83 SpuriousEmission:5350~25000.0MHz IEEE802.11ax_Channel38_40MHz_Antenna 0_RU&IndexSU OutOfBandEmission IEEE802.11ax_Channel46_40MHz_Antenna 0_RU&IndexSU SpuriousEmission:30.0~5150MHz IEEE802.11ax_Channel46_40MHz_Antenna 0_RU&IndexSU SpuriousEmission:5350~25000.0MHz IEEE802.11ax_Channel46_40MHz_Antenna 0_RU&IndexSU ReportNo.:MTEB26080064-R1Page 62 of 83 U-NII3: TestResult ModeChannel RU& Index Ant. OOB Emission Frequency (MHz) OOB Emission Level (dBm) Limit (dBm) Over Limit (dB) Result IEEE 802.11a 149 N/A0 5637.12-31.980-27.0-4.980PASS 5646.91-36.725-27-9.730PASS 5651.00-34.050-26.26-7.790PASS 5702.75-32.31010.77-43.080PASS 5720.38-34.02016.45-50.470PASS 5747.00-1.13027.0-28.130PASS 5854.25-34.27017.31-51.580PASS 5870.75-32.23011.19-43.420PASS 5924.75-34.050-26.82-7.230PASS 5938.25-33.230-27.0-6.230PASS 24938.0-39.985-27-12.980PASS 157 5603.00-32.900-27.0-5.900PASS 5649.44-37.868-27-10.870PASS 5650.62-31.450-26.53-4.920PASS 5705.38-31.00011.51-42.510PASS 5720.00-35.16015.6-50.760PASS 5782.25-2.00027.0-29.000PASS 5854.62-34.56016.45-51.010PASS 5874.88-34.39010.04-44.430PASS 5924.75-34.530-26.81-7.720PASS 5957.38-32.900-27.0-5.900PASS 24850.7-39.834-27-12.830PASS 165 5630.00-33.620-27.0-6.620PASS 5650.00-41.612-27-14.610PASS 5651.00-34.360-26.26-8.100PASS 5712.50-30.93013.5-44.430PASS 5720.00-33.20015.6-48.800PASS 5824.62-4.00027.0-31.000PASS 5854.62-34.64016.45-51.090PASS 5870.75-33.75011.19-44.940PASS 5924.75-34.700-26.82-7.880PASS 5937.88-40.234-27-13.230PASS 5972.00-32.580-27.0-5.580PASS IEEE 802.11n_20 149 5645.00-32.740-27.0-5.740PASS 5646.21-34.885-27-7.880PASS 5650.62-33.690-26.54-7.150PASS 5705.00-29.15011.4-40.550PASS 5720.38-30.97016.46-47.430PASS 5745.880.35027.0-26.650PASS 5854.62-35.22016.45-51.670PASS 5873.00-32.50010.56-43.060PASS 5924.75-34.100-26.81-7.290PASS 5973.12-32.760-27.0-5.760PASS 24890.3-40.113-27-13.110PASS 157 5619.88-33.110-27.0-6.110PASS 5647.61-39.253-27-12.250PASS 5650.62-34.460-26.54-7.920PASS 5701.62-33.31010.45-43.760PASS 5720.00-35.33015.6-50.930PASS 5787.12-3.25027.0-30.250PASS 5854.62-34.92016.45-51.370PASS 5871.12-32.96011.08-44.040PASS 5922.88-33.840-25.43-8.410PASS 5968.62-33.180-27.0-6.180PASS 24963.8-40.874-27-13.870PASS 165 5640.12-32.190-27.0-5.190PASS 5645.64-41.605-27-14.600PASS 5650.62-36.140-26.54-9.600PASS 5701.25-34.51010.35-44.860PASS 5720.38-33.37016.46-49.830PASS 5823.50-3.20027.0-30.200PASS 5854.62-33.63016.45-50.080PASS ReportNo.:MTEB26080064-R1Page 63 of 83 5873.00-33.94010.56-44.500PASS 5924.00-33.730-26.26-7.470PASS 5933.11-40.135-27-13.130PASS 5959.25-32.670-27.0-5.670PASS IEEE 802.11n_40 151 5643.12-31.260-27.0-4.260PASS 5648.88-35.224-27-8.220PASS 5650.25-32.520-26.81-5.710PASS 5700.12-32.90010.04-42.940PASS 5720.38-33.82016.45-50.270PASS 5753.38-2.39027.0-29.390PASS 5854.62-35.56016.45-52.010PASS 5874.12-33.32010.24-43.560PASS 5924.38-34.180-26.54-7.640PASS 5932.62-33.200-27.0-6.200PASS 24939.4-39.513-27-12.510PASS 159 5626.62-33.140-27.0-6.140PASS 5646.49-39.779-27-12.780PASS 5650.25-35.550-26.81-8.740PASS 5700.50-34.10010.14-44.240PASS 5720.00-33.26015.6-48.860PASS 5789.75-5.84027.0-32.840PASS 5854.62-34.82016.45-51.270PASS 5874.12-34.17010.25-44.420PASS 5924.38-35.280-26.53-8.750PASS 5969.00-32.550-27.0-5.550PASS 24939.4-40.588-27-13.590PASS IEEE 802.11ac_20 149 5643.12-31.790-27.0-4.790PASS 5648.88-34.941-27-7.940PASS 5650.62-34.530-26.54-7.990PASS 5700.88-30.50010.24-40.740PASS 5720.00-30.95015.6-46.550PASS 5741.000.42027.0-26.580PASS 5854.25-34.25017.31-51.560PASS 5874.50-34.37010.14-44.510PASS 5924.38-33.320-26.54-6.780PASS 5955.88-33.200-27.0-6.200PASS 24963.3-40.291-27-13.290PASS 157 5620.25-33.060-27.0-6.060PASS 5649.02-37.784-27-10.780PASS 5651.00-33.760-26.26-7.500PASS 5701.62-33.12010.46-43.580PASS 5720.00-32.99015.6-48.590PASS 5786.75-0.28027.0-27.280PASS 5854.62-34.73016.46-51.190PASS 5871.12-32.89011.08-43.970PASS 5923.25-34.870-25.71-9.160PASS 5966.75-32.850-27.0-5.850PASS 24912.7-39.024-27-12.020PASS 165 5644.38-42.772-27-15.770PASS 5647.62-32.190-27.0-5.190PASS 5651.00-34.390-26.2…
