2AUUE-3000Smart LED Light Bulb

INSTRUCTION GUIDE SMART LED LIGHT BULB Product Introduction Remote switch Group control State feedback Dimming Adjust atmosphere Voice control Specification Name Color System Support Power Working environment Characteristics Input parameters Material Size Smart LED Light Bulb White light + colorful AndroidiOS 10W Home, office Free toning, Remote control 100~250V AC, 50-60Hz PC+ABS 62x62x114mm Install the light bulb Install the bulb as shown in the picture and turn on the power switch. Note: 1. When installing, removing or inspecting the lamp. Please make sure the power is off . 2.Do not use fixtures to be dimmered to avoid damaging the product. 3.Do not use in damp environments. 4.Not recommended for use in narrow sealed barrel shades to avoid signal or heat dissipation problems. 1 2 3 Mobile APP download 1. Scan your QR code with your phone, Or in the APP store, application market; 2. Search for “ELFstorm APP” Download and install; 3. Sign up and log in to the“ELFstorm APP”. Pairing operationPairing operationPairing operation 4. Click "Setup" after entering the APP. 5. Select product category "LED Bulb" and click to enter its interface. Note: the product can only be used after connecting to 2.4g network. The 2.4g network can be set on the router. Scanning download ELFstorm APP Support Android iOS 6. Connect the LED bulb to the power supply, and power the product/power off for 3 cycles (when the light is on, the power will be quickly cut off and then power will be restored). The light will flash quickly, indicating that the LED bulb has entered the distribution network state. 7. Return to the mobile APP interface and click "Next" to enter the interface of connecting to Wi-Fi. 8. Enter the Wi-Fi password for the connection and click "Start configuration". 8. Display the device network connection is successful and click "Done" to enter the main page. 9. Click "My Devices" on the main page to enter, and the currently connected products are displayed on the interface. Pairing operation 10. Click the connected product icon, and you can control the corresponding functions of the product after entering. 11. In order to facilitate voice search of products and voice control in amazon APP, first modify the product name (for example: smart light), click the icon " "in the upper right corner of the product main interface.Enter the modify screen. Voice interaction skill authorizationVoice interaction skill authorizationVoice interaction skill authorizationVoice interaction skill authorization 1. Download Amazon Alex APP, register and log in. Enter Amazon Alex APP and click the menu button in the upper left corner . 2. Click "skills & Games". Note: in order to realize voice control, smart speaker must be equipped and voice authorization must be carried out: menu 3. Click the search icon “ ” 4. Input the name of the skill (such as ELFSTORM), search for ELFSTORM, and click "ELFSTORM". search 5. Click "ENABLE TO USE" 6. Enter the account and password of ELFSTORM App. 7. Close the page after the successful skill link, and the page of "Discover Devices" will appear and click enter (after the skill activation, you can also control the Echo speaker to search the device) 8. Alexa App searches for currently connected smart products. 9. Found products appear in the "Lights" page of Alexa App's "Devices" page, which can be controlled by voice, such as "turn on smat light, or turn off smart light". Click the control switch for three loops FCC Warning Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Statement The contents of this manual are subject to change due to product version upgrade or other reasons. Our company reserves the right to modify the contents of this manual without any notice or prompt. This manual is intended as a guide only. We do our best to provide accurate information in this manual. However, we do not ensure that the contents of this manual are completely error-free. All statements, information and recommenda- tions in this manual do not constitute any express or implied. guarantee. Items list •WiFi Smart LED Bulb x 1 • Operations Guide x 1 Warranty Explain Thank you for purchasing this product. In order to protect your rights, please read the following items carefully: According to national policy standards, our company's product warranty period is 1 year (Calculated from the date of purchase, Unable to verify the date of purchase, subject to the date of manufacture). Within warranty period, Our company will give a free warranty for any malfunction caused by the quality of the product itself under normal circumstances. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer o…

Text truncated - open the document above for the full version.

QA-FR-17 1-A IDEAL TECHNOLOGY COMPANY LIMITED Add: NO.12 Xiangrong Road, Song mu Shan Dalang Town, Dongguan City, Guangdong, China Tel: 0769-39011818 Fax: 0769-39000289 Email: [email protected] FCC Confidential Authorization Date: 2020- 04-29 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID:2AUUE-3000 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, IDEAL TECHNOLOGY COMPANY LIMITED hereby requests long-term confidential treatment of information accompanying this application as outlined below: Block Diagra m Schematics Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Printed Name: Carrie Tang Title: RD Manager

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS

Label and location Label

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS

FCC PART 15B TEST REPORT For IDEAL TECHNOLOGY COMPANY LIMITED NO.12 Xiangrong Road, Song mu Shan Dalang Town,Dongguan City, Guangdong, China. FCC ID: 2AUUE-3000 Report Type: Original Report Product Type: Smart LED Light Bulb Report Number: RDG200324006-00 Report Date: 2020-04-28 Reviewed By: Redick Zhang EMC Engineer Test Laboratory: Bay Area Compliance Laboratories Corp. (Dongguan) No.69 Pulongcun, Puxinhu Industry Area, Tangxia, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200324006-00 Page 2 of 18 TABLE OF CONTENTS General Information ..................................................................................................................................................... 3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 3 OBJECTIVE ................................................................................................................................................................... 3 TEST METHODOLOGY .................................................................................................................................................. 3 MEASUREMENT UNCERTAINTY ................................................................................................................................... 4 TEST FACILITY............................................................................................................................................................. 4 DECLARATIONS ........................................................................................................................................................... 4 System Test Configuration ........................................................................................................................................... 5 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 5 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 5 EUT EXERCISE SOFTWARE .......................................................................................................................................... 5 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 5 TEST EQUIPMENT LIST ................................................................................................................................................. 6 ENVIRONMENTAL CONDITIONS .................................................................................................................................... 7 Summary of Test Results .............................................................................................................................................. 8 1 – Conducted emissions ............................................................................................................................................... 9 EUT SETUP .................................................................................................................................................................. 9 EMI TEST RECEIVER SETUP ........................................................................................................................................ 9 TEST PROCEDURE ...................................................................................................................................................... 10 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................. 10 TEST DATA ................................................................................................................................................................ 11 2 – Radiated emissions ................................................................................................................................................ 13 EUT SETUP ................................................................................................................................................................ 13 EMI TEST RECEIVER SETUP ...................................................................................................................................... 13 TEST PROCEDURE ...................................................................................................................................................... 13 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................. 14 TEST DATA ................................................................................................................................................................ 15 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200324006-00 Page 3 of 18 GENERAL INFORMATION Product Description for Equipment under Test (EUT) EUT Name: Smart LED Light Bulb EUT Model: N7 Multiple Models: N/A Rated Input Voltage: 100-250Vac 50/60Hz The Highest Operating Frequency: 2480MHz I/O Ports: N/A EUT Function: Light Bulb Serial Number: 200324006 EUT Received Date: 2020.03.25 EUT Received Status: Good Objective This report is prepared on behalf of IDEAL TECHNOLOGY COMPANY LIMITED in accordance with Part 2, Part J, and Part 15, Subpart A and B of the Federal Communications Commission’s rules.. The objective is to determine the compliance of EUT with: FCC Part 15B. Test Methodology All measurements contained in this report were conducted with ANSI C63.4-2014 American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipme…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emissions Front View Conducted Emissions Side View Radiated Emission Below 1GHz Front View Radiated Emission Below 1GHz Side View Radiated Emission Above 1GHz Front View Radiated Emission Above 1GHz Side View
