2AUV4SATCUBEKU

Satcube AB

Satcube Ku band satellite terminal

Click to zoom

Application Details

Equipment Class: TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant: Nov 16, 2020
Application Purpose: Original Equipment
Date of Application: Nov 13, 2020
Equipment Note: Satcube Ku band satellite terminal
Frequency Range: 13750.00000000 - 14500.00000000
Company: Satcube AB
Country: Sweden

Documents & Files

Select a file to view

Users Manual

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

Parts List/Tune Up Info

RF Exposure Info

Test Report

Test Setup Photos

Contact Information

Applicant

Jakob Kallmer(CEO)

[email protected]+46709588188Fax: +46317010500

Test Firm

Nemko Canada Inc. (Ottawa)Charles Neal

[email protected]613-737-9680Fax: 613-737-9691

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
4	25	13.75 GHz - 14.50 GHz	40.7 W	2M20D7W	0.04 ppm

Confidentiality

Long Term

Grant Notes

Output power listed is EIRP per 4 kHz. This device must be installed to provide a separation distance of at least 19 m from all persons located directly in front of the antenna and 20 cm behind the antenna as documented in this filing. This antenna must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. End-users must be provided with transmitter operating conditions for satisfying RF exposure compliance.
