2AUXCCWHUBVehicle detection notification device

CW-HUB WIRELESS HYBRID DRIVEWAY SYSTEM 1. WHAT’S IN THE BOX There is a barcode serial number on the back of HUB, bottom of puck, and on product box. When calling to talk about your product, please have one of these numbers handy. PRODUCT CODE YEAR MADE SERIAL NUMBER 2. SERIAL NUMBER 1. SENSOR “PUCK” 2. HUB 3. AUGER SCREWS (2) 4. USB-C POWER SUPPLY & CABLE 5. CR123A BATTERIES (2) 3. LOW BATTERY INDICATION (see #9 below) 6. TESTING RANGE Your system has a radio range of at least 350 feet or over 1000’ line-of- sight. To determine range in your application, test before final installation. Radio range depends on several variables: • How the puck is installed (in ground or above ground on post) • Obstacles blocking radio signal, such as soil, trees, foilage, buildings, concrete, etc. To test range: 1. Put HUB near its final installation place in the home. 2. You will need to confirm the HUB is receiving the sensor’s signal. 3. Put sensor in test range mode (see #5 above). 4. Look on App or wait for push notification from sensor. If you don’t receive a notification, move sensor closer until you do. 5. Be sure to test again with puck installed in ground. 5. TEST MODE FOR SENSOR PUCK Test mode allows the sensor puck to be tripped without a vehicle. This is useful when testing radio range (see #6 below) and solo installations. 1. Press and HOLD button on sensor puck for 5 seconds 2. The red LED will be solid and dim while waiting the 5 seconds 3. Once the 5 seconds has expired, the LED will be bright red 4. Test mode is activated when the button is released 5. The sensor will trip itself every 15 seconds 6. Test mode will be exited when button is pressed again 7. Test mode will automatically be exited after 30 minutes 8. INSTALLING SENSOR PUCK 7. SETTING SENSITIVITY 1 2 3 4 5 NOTE: SENSOR PUCK AND LID ARE KEYED. WIPE SENSOR LID, LID GASKET, AND SENSOR BRIM WITH CLEAN CLOTH AND KEY CORRECTLY BEFORE ATTACHING. Battery status is displayed in the Cartell App under each sensor. Full power is indicated by a green color (see right). Lack of power is indicated by a red color (see far right). Replace batteries. VERSION 2 - JULY 2026 ON AN OBJECTIN THE GROUNDIN THE DRIVEWAY LOOP SEALANT Don’t allow sealant to touch lid or bosses Fill line Use 4.5” masonry hole saw Pour sealant in hole, then install puck. Do not cover lid or bosses with sealant. • Put logo parallel to drive • Put just below surface • Auger screws secure puck • Do not cover puck lid • Pack dirt/grass around puck • Keep puck lid clean min. 6"- 8" • Use stable object • Use 4 deck screws for fastening Bore hole 4.5" x 2.75" deep 0.25”- 0.50” The sensor puck can be installed in the driveway, in the ground, or on an immovable object (post, tree, etc.). NOTE: SENSOR PUCK DETECTS A VEHICLE GOING 5 MPH AFTER IT PASSES. ON AN OBJECT (see illustration bottom left) 1. Test range (#6 above), then seat lid securely on puck with screws provided, leaving no gap between lid and puck. Do not over-tighten or strip screws. 2. Find a tree, post, or other object directly beside the driveway. 3. Make sure the object is IMMOVABLE or false alarms will occur. 4. Use the holes on the bottom tabs to screw puck to the object. IN THE GROUND (see illustration bottom left) 1. When range has been tested (see #6 above), seat lid securely on puck with screws provided. Be careful not to strip screws with screw gun. There should be no gap between lid and puck. 2. Find a spot directly beside driveway. 3. Dig a hole big enough for puck and auger screws, allowing puck’s lid to be level with surface of dirt. 4. Secure puck in ground with auger screws, overlapping bottom tabs of puck. If you fail to secure puck, lawn mowers, etc. will pull/suck it up. 5. Pack and tamp dirt around puck, ensuring lid is clean of dirt and all debris. IN THE DRIVEWAY (see illustration bottom left) 1. When range has been tested (see #6 above), seat lid securely on puck with screws provided. Be careful not to strip screws with screw gun. There should be no gap between lid and puck. Note: If close to cross traffic, consider turning sensitivity down (see #7 above) 2. Use a 4.5" diameter masonry hole saw to bore a hole for puck. Bore at least 2.75” deep so puck lid will be 0.25”- 0.50” below driveway surface (so it can’t be pulled up by snow plows, graters, etc.). 3. Pour loop sealant in hole, careful not to overfill, and put puck in hole. 4. Hold puck down with weight until sealant becomes firm. 5. DO NOT pour sealant over puck lid or bosses to gain access to batteries. WARNING: WIPE CLEAN & DRY THE SENSOR BRIM, LID, and LID GASKET BEFORE SCREWING LID TO HOUSING. REPLACE BOTH BATTERIES AT THE SAME TIME. DO NOT USE RECHARGEABLE BATTERIES! Push & hold button FOR 5 SECONDS to put in test mode ONLY ADJUST (LOWER) SENSITIVITY IF PUTTING IN MIDDLE OF DRIVEWAY (see #8 below). IN ALL OTHER CASES USE DEFAULT. HIGHEST SENSITIVITY IS DEFAULT When a vehicle is detected, a notification will be pushed to the App. This notification will be followed by a second low battery notifica- tion (see left). 4. INSTALLING BATTERIES 1. Use CR123A batteries and match polarity with battery terminal in puck. 2. If batteries are put in backwards, they will not power the unit. 3. Push batteries in place fully to make contact. 4. Sensor will power up automatically when batteries are installed. Note: Puck lid will keep batteries in place. SENSITIVITY ADJUSTMENT HIGH (Default) Detects vehicle at 5 MPH 12-14’ Jumper on #1 MEDIUM Detects vehicle at 5 MPH 6-8’ Jumper on #1&2 LOW Detects vehicle at 5 MPH 2-4’ Jumper on #2&3 NOTE: JUMPER COLOR IS USUALLY RED, BUT MAY DIFFER. Copyright © 2026 by Cartell CONTACT INFORMATION TECH SUPPORT717-532-0033, option 1 [email protected] ORDERING (Distributors only)Email POs to: [email protected] ADDRESS510 W King Street, Shippensburg, PA 17257 WEBSITEwww.cartell.com CONSUMER: Contact your installer. INSTALLER: CALL BEFORE DIGGING UP OR UNINSTALLING Call (717) 532-0033, option 1 to troubleshoot and r…

Text truncated - open the document above for the full version.

Preferred Security Components, Inc. of PA 510 W King Street  Shippensburg, PA 17257  717-532-0033  [email protected] Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 05-27-2026 Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47 CFR parts §2.903 and §2.911(d)(5)(i)(ii) of the FCC rules Applicant: Preferred Security Components Inc. of Pa DAB Cartell FCC ID: 2AUXCCWHUB To whom it may concern, Preferred Security Components Inc. of Pa DAB Cartell (“Applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant is not identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. Applicant further certifies that no Cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software is installed in the equipment being certified. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Compliance Testing LLC if there is any change in the status identified above. Joel Bohannon President/CEO Preferred Security Components, Inc. of PA DBA Cartell 05-27-2026

Preferred Security Components, Inc. of PA 510 W King Street  Shippensburg, PA 17257  717-532-0033  [email protected] Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 05-27-2026 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2AUXCCWHUB Preferred Security Components Inc. of Pa DAB Cartell (“the applicant”) certifies that, as of the date of the filing of the application, we designate ourselves as the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Preferred Security Components Inc. of Pa DAB Cartell FRN: 0026206201 Address: 510 W. King Street, Shippensburg, PA 17257 Contact Person: Joel Bohannon Email: [email protected] Sincerely, Preferred Security Components, Inc of PA DBA Cartell Joel Bohannon

Preferred Security Components, Inc. of PA 510 W King Street  Shippensburg, PA 17257  717-532-0033  [email protected] Date 5/27/2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, Joel Bohannon President/CEO Preferred Security Components, Inc. of PA DBA Cartell

Preferred Security Components, Inc. of PA 510 W King Street  Shippensburg, PA 17257  717-532-0033  [email protected] Date 05-27-2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: Long-Term Confidentiality Request for CW HUB 2AUXCCWHUB To Whom It May Concern: This letter serves as an official request for confidentiality under § 0.457(d) and § 0.459 of CFR 47. We have requested that the following documents required to be submitted with this application be permanently withheld from public review. • Block Diagram • Schematics • Theory of Operation These documents contain detailed system and equipment descriptions and related information about the product, which manufacturer/applicant considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, manufacturer/applicant feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Joel Bohannon President/CEO Preferred Security Components, Inc. of PA DBA Cartell

HUB External Photos

FCC Label Artwork with Location •The FCC ID is located on the bottom of the product.

HUB Internal Photos LORA Antenna Wi-Fi Antenna

P2640011_FCC_MPE_Rev 1.0 Page 1 of 8 Test Report Prepared for: Preferred Security Components Inc. of PA DBA Cartell Model: CW-HUB Project No: p2640011 Serial Number: 260101-00808 FCC ID: 2AUXCCWHUB To FCC Part 1.1310 FCC Part 1.1307 447498 D04 Interim General RF Exposure Guidance v01 Date of Issue: May 28, 2026 On behalf of the applicant: Attention of: Prepared By: Preferred Security Components Inc. of PA DBA Cartell 510 W King St Shippensburg, PA 17257 Troy Wenger Ph: 717-535-0033 ext. 9327 E-mail: [email protected] Compliance Testing, LLC Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com ANAB Cert #: AT-2901 FCC Site Reg. #750616 ISED Site Reg. #2044A-2 Reviewed / Authorized By: Harshith Devaraja EMC Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing All results contained herein relate only to the sample tested P2640011_FCC_MPE_Rev 1.0 Page 2 of 8 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 May 28, 2026 Harshith Devaraja Original Document Current revision of the test report replaces any prior versions. Only the current version of the test report is valid. P2640011_FCC_MPE_Rev 1.0 Page 3 of 8 EUT Description Model: CW-HUB Serial: 260101-00808 Firmware: 1032/5019 Description: Works with Cartell's wired and wireless device to enable notifications to the Cartell app. Additional Information: 1. EUT can simultaneously transmit BLE and LoRa DTS 2. EUT can simultaneously transmit Wi-Fi 802.11b/g/n and LoRa DTS BLE Radio Frequency Range and Operational Info: 2402 – 2480 MHz BLE GFSK (1 Mbps) BLE GFSK (2 Mbps) LoRa Radio Frequency Range and Operational Info: 903 – 927 MHz LoRa DTS – CSS Modulation (Spread factor 12) Wi-Fi 802.11 Radio Frequency Range and Operational Info: 2412 – 2462 MHz 802.11b: DSSS 802.11g: OFDM 802.11n: OFDM Usage: Fixed/Mobile Receipt of Sample(s): May 8, 2026 EUT Condition: Visual Damage No State of Development Production/Production Equivalent P2640011_FCC_MPE_Rev 1.0 Page 4 of 8 Maximum Conducted Output Power and Antenna Gain Table Worst case data collected from the following reports in each band. 1. p2640011 BLE_FCC_247_RSS_247_Rev 1.0 2. p2640011 WiFi_FCC_247_RSS_247_Rev 1.0 3. p2640011 LoRa_FCC_247_RSS_247_Rev 1.0 Band Maximum Conducted Output Power (dBm) Maximum Conducted Output Power (mW) Antenna gain (dBi) BLE (1 Mbps) 2440 MHz 7.35 5.4 3.96 802.11b (1 Mbps) 2437 MHz 18.69 74 3.96 LoRa (SF12) 915 MHz 19.47 88.5 2 P2640011_FCC_MPE_Rev 1.0 Page 5 of 8 MPE Evaluation This is a fixed/mobile device used in Uncontrolled Exposure environment. Limits Controlled Exposure 47 CFR 1.1310 Table 1, (A) 0.3-3.0 MHz: Limit [mW/cm²] = 100 3.0-30 MHz: Limit [mW/cm²] = (900/f²) 30-300 MHz: Limit [mW/cm²] = 1.0 300-1500 MHz: Limit [mW/cm²] = f/300 1500-100,000 MHz Limit [mW/cm²] = 5 Limits Uncontrolled Exposure 47 CFR 1.1310 Table 1, (B) 0.3-1.234 MHz: Limit [mW/cm²] = 100 1.34-30 MHz: Limit [mW/cm²] = (180/f²) 30-300 MHz: Limit [mW/cm²] = 0.2 300-1500 MHz: Limit [mW/cm²] = f/1500 1500-100,000 MHz Limit [mW/cm²] = 1.0 Test Data BLE 1 Mbps Test Frequency, MHz 2440 Conducted peak Power, mW (P) 5.4 Antenna Gain Isotropic 3.96 dBi Antenna Gain Numeric (G) 2.49 Distance (R) 20 cm 푆= 푃∗퐺 4휋푟 2 Power Density (S) mW/cm 2 Power Density (S) = 0.00267 mW/cm 2 Limit = (from above table) = 1.0 mW/cm 2 Wi-Fi 802.11b 1 Mbps Test Frequency, MHz 2437 Conducted peak Power, mW (P) 74 Antenna Gain Isotropic 3.96 dBi Antenna Gain Numeric (G) 2.49 Distance (R) 20 cm 푆= 푃∗퐺 4휋푟 2 Power Density (S) mW/cm 2 Power Density (S) = 0.03665 mW/cm 2 Limit = (from above table) = 1.0 mW/cm 2 P2640011_FCC_MPE_Rev 1.0 Page 6 of 8 LoRa DTS (CSS SF12) Test Frequency, MHz 915 Conducted peak Power, mW (P) 88.5 Antenna Gain Isotropic 2 dBi Antenna Gain Numeric (G) 1.58 Distance (R) 20 cm 푆= 푃∗퐺 4휋푟 2 Power Density (S) mW/cm 2 Power Density (S) = 0.0278 mW/cm 2 Limit = (from above table) = 0.610 mW/cm 2 Band Power Density (mW/cm 2 ) Limit (mW/cm 2 ) Result BLE (1 Mbps) 2440 MHz 0.00267 1 Pass 802.11b (1 Mbps) 2437 MHz 0.03665 1 Pass LoRa (SF12) 915 MHz 0.0278 0.610 Pass P2640011_FCC_MPE_Rev 1.0 Page 7 of 8 P2640011_FCC_MPE_Rev 1.0 Page 8 of 8 BLE and LoRa Simultaneous Transmission ( 0.00267 1 )+( 0.0278 0.610 )<1 0.0482 < 1 Wi-Fi and LoRa Simultaneous Transmission ( 0.03665 1 )+( 0.0278 0.610 )<1 0.0822 < 1 EUT is MPE-based simultaneous transmission exposure compliant. END OF TEST REPORT

P2640011_WiFi_FCC_15.247_RSS_247_Rev 2.0 Page 1 of 91 Test Report Prepared for: Preferred Security Components Inc. of PA DBA Cartell Model: CW-HUB Serial Number: 260101-00808, 260101-00807 Project No: p2640011 FCC ID: 2AUXCCWHUB IC ID: 25651-CWHUB Test Results: Pass To FCC Part 15.247 & RSS Gen Issue 5 (April 2018) RSS-247 Issue 4 (July 2025) Date of Issue: May 28, 2026 On behalf of the applicant: Preferred Security Components Inc. of PA DBA Cartell 510 W King St Shippensburg, PA 17257 Attention of: Troy Wenger Ph: 717-535-0033 ext. 9327 E-mail: [email protected] Prepared By: Compliance Testing, LLC Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com ANAB Cert#: AT-2901 FCC Site Reg. #750616 ISED Site Reg. #2044A-2 CAB US-ID: US0122 Reviewed / Authorized By: Harshith Devaraja, EMC Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing. All results contained herein relate only to the sample tested. All samples were selected by the customer. P2640011_WiFi_FCC_15.247_RSS_247_Rev 2.0 Page 2 of 91 Test Results Summary Test Date Range: May 12, 2026 – May 28, 2026 Specification Test Name Pass, Fail, N/A Comments FCC RSS 15.247(a)(2) RSS Gen 6.7 RSS 247 6.3.1(a) Occupied Bandwidth Pass 15.247(b)(3) RSS 247 6.3.2 Transmitter Output Power Pass 15.247(d) RSS 247 6.6 Conducted Spurious Emissions Pass 15.247(d), 15.209(a), 15.205 RSS Gen 8.9/8.10 RSS 247 6.6 Spurious Emissions Pass 15.247(e) RSS 247 6.3.1(b) Power Spectral density Pass 15.207 RSS Gen 8.8 A/C Powerline Conducted Emissions Pass 15.203 RSS Gen 6.8 Antenna Requirement Pass Method Deviations/Additions: No Statements of conformity are reported as: • Pass - the measured value is below the acceptance limit, acceptance limit = test limit. • Fail - the measured value is above the acceptance limit, acceptance limit = test limit. References/Methods Description ANSI C63.4-2014 Method and Measurements of Radio-Noise Emissions from low-Voltage Electrical and Electronic Equipment in the range 9kHz to 40GHz. ANSI C63.10:2020+ Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024 American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices 558074 D01 15.247 Meas Guidance v05r02 Guidance for Compliance Measurements on DTS, FHSS, and Hybrid System Devices Operating Under Section 15.247 of the FCC Rules ISO/IEC 17025:2017 General requirements for the Competence of Testing and Calibrations Laboratories P2640011_WiFi_FCC_15.247_RSS_247_Rev 2.0 Page 3 of 91 Table of Contents Description Page Test Results Summary ........................................................................................................................ 2 Test Report Revision History .............................................................................................................. 4 EUT Description .................................................................................................................................. 5 Test and Measurement Data ............................................................................................................... 7 Test Setup and Modes of Operation ................................................................................................... 8 Transmitter Output Power ................................................................................................................. 10 15.209/15.205 Spurious Emissions ................................................................................................... 16 Occupied Bandwidth ......................................................................................................................... 66 Power Spectral Density ..................................................................................................................... 71 Conducted Spurious Emissions ........................................................................................................ 76 A/C Powerline Conducted Emissions ................................................................................................ 82 Test Equipment Utilized .................................................................................................................... 91 Measurement Uncertainty ................................................................................................................. 91 P2640011_WiFi_FCC_15.247_RSS_247_Rev 2.0 Page 4 of 91 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 May 28, 2026 Harshith Devaraja Original Document 2.0 July 2, 2026 Harshith Devaraja CAB US-ID updated Reference method updated IC HVIN, PMN updated Added EIRP table Current revision of the test report replaces any prior versions. Only the current version of the test report is valid. P2640011_WiFi_FCC_15.247_RSS_247_Rev 2.0 Page 5 of 91 EUT Description Model: CW-HUB IC HVIN: CWHUB IC PMN: CWHUB Serial: 260101-00808 Simultaneous transmission sample: 260101-00807 Firmware: 1032/5019 Description: Works with Cartell's wired and wireless device to enable notifications to the Cartell app. Additional Information: Radio Frequency Range and Operational Info: 2.412 – 2.462 GHz 802.11b: DSSS 802.11g: OFDM 802.11n: OFDM EUT can simultaneously transmit Wi-Fi and LoRa DTS LoRa Radio Frequency Range and Operational Info: 903 – 927 MHz LoRa DTS – CSS Modulation (Spread factor 12) Usage: Fixed/Mobile Receipt of Sample(s): May 8, 2026 EUT Condition: Visual Damage No State of Development Production/Production Equivalent P2640011_WiFi_FCC_15.247_RSS_247_Rev 2.0 Page 6 of 91 The applicant has been cautioned as to the following 15.21 - Information to User The user’s manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 15.27(a) - Special Accessories Equipment marked to a consum…

Text truncated - open the document above for the full version.

P2640011_BLE_FCC_15.247_RSS_247_Rev 2.0 Page 1 of 63 Test Report Prepared for: Preferred Security Components Inc. of PA DBA Cartell Model: CW-HUB Serial Number: 260101-00808, 260101-00807 Project No: p2640011 FCC ID: 2AUXCCWHUB IC ID: 25651-CWHUB Test Results: Pass To FCC Part 15.247 & RSS Gen Issue 5 (April 2018) RSS-247 Issue 4 (July 2025) Date of Issue: May 28, 2026 On behalf of the applicant: Preferred Security Components Inc. of PA DBA Cartell 510 W King St Shippensburg, PA 17257 Attention of: Troy Wenger Ph: 717-535-0033 ext. 9327 E-mail: [email protected] Prepared By: Compliance Testing, LLC Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com ANAB Cert#: AT-2901 FCC Site Reg. #750616 ISED Site Reg. #2044A-2 CAB US-ID: US0122 Reviewed / Authorized By: Harshith Devaraja, EMC Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing. All results contained herein relate only to the sample tested. All samples were selected by the customer. P2640011_BLE_FCC_15.247_RSS_247_Rev 2.0 Page 2 of 63 Test Results Summary Test Date Range: May 12, 2026 – May 28, 2026 Specification Test Name Pass, Fail, N/A Comments FCC RSS 15.247(a)(2) RSS Gen 6.7 RSS 247 6.3.1(a) Occupied Bandwidth Pass 15.247(b)(3) RSS 247 6.3.2 Transmitter Output Power Pass 15.247(d) RSS 247 6.6 Conducted Spurious Emissions Pass 15.247(d), 15.209(a), 15.205 RSS Gen 8.9/8.10 RSS 247 6.6 Spurious Emissions Pass 15.247(e) RSS 247 6.3.1(b) Power Spectral density Pass 15.207 RSS Gen 8.8 A/C Powerline Conducted Emissions Pass 15.203 RSS Gen 6.8 Antenna Requirement Pass Method Deviations/Additions: No Statements of conformity are reported as: • Pass - the measured value is below the acceptance limit, acceptance limit = test limit. • Fail - the measured value is above the acceptance limit, acceptance limit = test limit. References/Methods Description ANSI C63.4-2014 Method and Measurements of Radio-Noise Emissions from low-Voltage Electrical and Electronic Equipment in the range 9kHz to 40GHz. ANSI C63.10:2020+ Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024 American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices 558074 D01 15.247 Meas Guidance v05r02 Guidance for Compliance Measurements on DTS, FHSS, and Hybrid System Devices Operating Under Section 15.247 of the FCC Rules ISO/IEC 17025:2017 General requirements for the Competence of Testing and Calibrations Laboratories P2640011_BLE_FCC_15.247_RSS_247_Rev 2.0 Page 3 of 63 Table of Contents Description Page Test Results Summary ........................................................................................................................ 2 Test Report Revision History .............................................................................................................. 4 EUT Description .................................................................................................................................. 5 Test and Measurement Data ............................................................................................................... 7 Test Setup and Modes of Operation ................................................................................................... 8 Transmitter Output Power ................................................................................................................. 10 15.209/15.205 Spurious Emissions ................................................................................................... 15 Occupied Bandwidth ......................................................................................................................... 41 Power Spectral Density ..................................................................................................................... 46 Conducted Spurious Emissions ........................................................................................................ 51 A/C Powerline Conducted Emissions ................................................................................................ 58 Test Equipment Utilized .................................................................................................................... 63 Measurement Uncertainty ................................................................................................................. 63 P2640011_BLE_FCC_15.247_RSS_247_Rev 2.0 Page 4 of 63 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 May 28, 2026 Harshith Devaraja Original Document 2.0 July 2, 2026 Harshith Devaraja CAB US-ID updated Reference method updated IC HVIN, PMN updated BLE operating frequency updated Added EIRP table Current revision of the test report replaces any prior versions. Only the current version of the test report is valid. P2640011_BLE_FCC_15.247_RSS_247_Rev 2.0 Page 5 of 63 EUT Description Model: CW-HUB IC HVIN: CWHUB IC PMN: CWHUB Serial: 260101-00808 Simultaneous Transmission Sample: 260101-00807 Firmware: 1032/5019 Description: Works with Cartell's wired and wireless device to enable notifications to the Cartell app. Additional Information: Radio Frequency Range and Operational Info: 2.402 – 2.48 GHz BLE GFSK (1 Mbps) BLE GFSK (2 Mbps) EUT can simultaneously transmit BLE and LoRa DTS LoRa Radio Frequency Range and Operational Info: 903 – 927 MHz LoRa DTS – CSS Modulation (Spread factor 12) Usage: Fixed/Mobile Receipt of Sample(s): May 8, 2026 EUT Condition: Visual Damage No State of Development Production/Production Equivalent P2640011_BLE_FCC_15.247_RSS_247_Rev 2.0 Page 6 of 63 The applicant has been cautioned as to the following 15.21 - Information to User The user’s manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 15.27(a) - Special Accessories Equipment m…

Text truncated - open the document above for the full version.

P2640011_LORA_FCC_15.247_RSS_247_Rev 2.0 Page 1 of 57 Test Report Prepared for: Preferred Security Components Inc. of PA DBA Cartell Model: CW-HUB Serial Number: 260101-00808, 260101-00807 Project No: p2640011 FCC ID: 2AUXCCWHUB IC ID: 25651-CWHUB Test Results: Pass To FCC Part 15.247 & RSS Gen Issue 5 (April 2018) RSS-247 Issue 4 (July 2025) Date of Issue: May 28, 2026 On behalf of the applicant: Preferred Security Components Inc. of PA DBA Cartell 510 W King St Shippensburg, PA 17257 Attention of: Troy Wenger Ph: 717-535-0033 ext. 9327 E-mail: [email protected] Prepared By: Compliance Testing, LLC Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com ANAB Cert#: AT-2901 FCC Site Reg. #750616 ISED Site Reg. #2044A-2 CAB US-ID: US0122 Reviewed / Authorized By: Harshith Devaraja, EMC Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing. All results contained herein relate only to the sample tested. All samples were selected by the customer. P2640011_LORA_FCC_15.247_RSS_247_Rev 2.0 Page 2 of 57 Test Results Summary Test Date Range: May 22, 2026 – May 28, 2026 Specification Test Name Pass, Fail, N/A Comments FCC RSS 15.247(a)(2) RSS Gen 6.7 RSS 247 6.3.1(a) Occupied Bandwidth Pass 15.247(b)(3) RSS 247 6.3.2 Transmitter Output Power Pass 15.247(d) RSS 247 6.6 Conducted Spurious Emissions Pass 15.247(d), 15.209(a), 15.205 RSS Gen 8.9/8.10 RSS 247 6.6 Spurious Emissions Pass 15.247(e) RSS 247 6.3.1(b) Power Spectral density Pass 15.207 RSS Gen 8.8 A/C Powerline Conducted Emissions Pass 15.203 RSS Gen 6.8 Antenna Requirement Pass Method Deviations/Additions: No Statements of conformity are reported as: • Pass - the measured value is below the acceptance limit, acceptance limit = test limit. • Fail - the measured value is above the acceptance limit, acceptance limit = test limit. References/Methods Description ANSI C63.4-2014 Method and Measurements of Radio-Noise Emissions from low-Voltage Electrical and Electronic Equipment in the range 9kHz to 40GHz. ANSI C63.10:2020+ Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024 American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices 558074 D01 15.247 Meas Guidance v05r02 Guidance for Compliance Measurements on DTS, FHSS, and Hybrid System Devices Operating Under Section 15.247 of the FCC Rules ISO/IEC 17025:2017 General requirements for the Competence of Testing and Calibrat…

Text truncated - open the document above for the full version.
