2AUXUECLIPSE-S1Eclipse

www.rollashade.comRev: 02.4.2020 Page 1 of 2© Copyright 2020 Roll-A-Shade Inc., All rights reserved. - Contractor #916075 RAS - Installation Instructions for Sun Sensor Eclipse-S1 Hardware IncludedTools Required Phillips Head Drill 12101 Madera Way Riverside, CA 92503 Phone: 888-245-5077 Fax: 951-245-5075 www.rollashade.com Sun Sensor #8-18 x 3/4” Screws #8-18 x 1-1/2” Screws x2 x2 Sun Sensor Bracket 1. Install Bracket Install Sun Sensor bracket into mullion vertically or horizontally. Note: Must be at least two screws in every bracket. SIDE INSTALL ATION TOP INSTALL ATION BOT TOM INSTALL ATION 2. Install Sun Sensor Install Sun Sensor into bracket. Note: Must be at least two screws installed into Sun Sensor. Note2: Make sure screen and buttons are facing you. www.rollashade.comRev: 02.4.2020 Page 2 of 2© Copyright 2020 Roll-A-Shade Inc., All rights reserved. - Contractor #916075 3. Sun Sensor Installation Check Make sure all screws are securely fastened into the bracket and Sun Sensor. Note: Device is designed for interior installations only. 4. Sun Sensor Testing Correct - Perfect Placement Correct - Sensor location clear of obstructing shadows Incorrect - Sensor obstruction by shadows Incorrect - Sensor obstruction by shadows Faces outside SUN SENSOR SUN SENSOR SUN SENSOR SUN SENSOR BACK Roll-A-Shade Eclipse FCC ID: 2AUXUECLIPSE-S1 Contains FCC ID: QOQMGM12P3 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Faces into room FRONT

February 25, 2020 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Dear Sir/Madam: Enclosed please find an application for original equipment certification of Model Eclipse/Pippin; FCC ID: 2AUXUECLIPSE- S1 under Rule Part FCC 15.231 The device is a sun sensor product. Further details and supporting documents are attached. Sincerely, Ty Pereira CEO

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 1/29/2020 Re: Request for confidentiality FCC ID: 2AUXUECLIPSE‐S1 To Whom It May Concern, We hereby respectfully request that under the provision of 47 CFR 0.459 and 0.457(d) the documents listed below and attached with this application for certification be provided with confidential status.  Schematics.pdf  Operational Description.pdf  Frequency Block Diagrams.pdf Any exhibit / information for which we have requested confidentiality, but which may not be accorded such treatment by the FCC, should be returned to us. The documents listed above contain trade secrets that are treated as confidential by us. Substantial competitive harm to us could result should they be made available to the public. Sincerely, Ty Pereira CEO

Label Sample Note: Since we have an integrated display we have opted to do e-labeling of FCC ID numbers, warning statements etc. To access the FCC information, please see below instructions: Starting from Home Screen: Step 1 – Right click uni-button to access Main Menu Step 2 – access submenu “Configuration” Step 3 – access submenu “FCC” BOX LABEL

ROLL-A-SHADE INFORMATION PIPPIN ANTENNA INFORMATION Document Revision: 1.1 Issue Date: Roll-A-Shade Information Pippin is a Trademark of Roll-A-Shade All other trademarks are the property of the respective owner. Pippin Antenna Information 3 ROLL-A-SHADE Information Specification Document 1 Pippin Antenna Information In the Pippin product there is one 433MHz printed meander-line antenna on an FR4 substrate. The printed circuit board and soldered components are enclosed in a plastic enclosure. This antenna is only used to transmit an ASK signal. With the antenna printed on the printed circuit board and inside the plastic enclosure, it is not possible to attach another antenna. Thus, compliance to 15.203 is covered. Peak Antenna Gain is -2dBi Pictures of the antenna: Front side Back side – entire pcb Specification Document Pippin Antenna Information ROLL-A-SHADE Information 4 Back side – antenna only

This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S. Government. This Report shall not be reproduced, except in full without written approval of the laboratory. Roll-A-Shade Pippin FCC 15.231:2019 Low Power Radio Report # RODE0001 Rev. 1 NVLAP LAB CODE: 200676-0 CERTIFICATE OF TEST 2018-09-14 Product compliance is the responsibility of the client; therefore, the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. This report reflects only those tests from the referenced standards shown in the certificate of test. It does not include inspection or verification of labels, identification, marking or user information. As indicated in the Statement of Work sent with the quotation, Element’s standard process is to always use the latest published version of the test methods even when earlier versions are cited in the test specification. Issuance of a purchase order was de facto acceptance of this approach. Otherwise, the client would have advised Element in writing of the specific version of the test methods they wanted applied to the subject testing. Last Date of Test: December 20, 2019 Roll-A-Shade EUT: Pippin Radio Equipment Testing Standards Specification Method FCC 15.231:2019 ANSI C63.10:2013 Results Method Clause Test Description Applied Results Comments 6.2 Powerline Conducted Emissions (Transmitter) No N/A Not required for a battery powered EUT. 6.5, 6.6 Field Strength of Fundamental Yes Pass 6.5, 6.6 Spurious Radiated Emissions Yes Pass 6.9.2 Occupied Bandwidth Yes Pass 7.5 Duty Cycle Yes Pass Deviations From Test Standards None Approved By: Victor Ratinoff, Operations Manager Report No. RODE0001 Rev. 12/24 REVISION HISTORY 2018.07.17 Revision Number Description Date (yyyy-mm-dd) Page Number 01 Capitalized ‘h’ in MHz 2020-03-16 8 Revised range to 8 GHz 2020-03-16 13 Report No. RODE0001 Rev. 13/24 ACCREDITATIONS AND AUTHORIZATIONS 2019.03.08 United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Accredited by A2LA to ISO / IEC 17065 as a product certifier. This allows Element to certify transmitters to FCC and IC specifications. NVLAP - Each laboratory is accredited by NVLAP to ISO 17025 Canada ISED - Recognized by Innovation, Science and Economic Development Canada as a Certification Body (CB) and as a CAB for the acceptance of test data. European Union European Commission – Within Element, we have a EU Notified Body validated for the EMCD and RED Directives. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea MSIT / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Israel MOC – Recognized by MOC as a CAB for the acceptance of test data. Hong Kong OFCA – Recognized by OFCA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. SCOPE For details on the Scopes of our Accreditations, please visit: https://www.nwemc.com/emc-testing-accreditations Report No. RODE0001 Rev. 14/24 FACILITIES 2019.03.08 California Labs OC01-17 41 Tesla Irvine, CA 92618 (949) 861-8918 Minnesota Labs MN01-10 9349 W Broadway Ave. Brooklyn Park, MN 55445 (612)-638-5136 Oregon Labs EV01-12 6775 NE Evergreen Pkwy #400 Hillsboro, OR 97124 (503) 844-4066 Texas Labs TX01-09 3801 E Plano Pkwy Plano, TX 75074 (469) 304-5255 Washington Labs NC01-05 19201 120 th Ave NE Bothell, WA 98011 (425)984-6600 NVLAP NVLAP Lab Code: 200676-0 NVLAP Lab Code: 200881-0 NVLAP Lab Code: 200630-0 NVLAP Lab Code:201049-0 NVLAP Lab Code: 200629-0 Innovation, Science and Economic Development Canada 2834B-1, 2834B-3 2834E-1, 2834E-3 2834D-1 2834G-1 2834F-1 BSMI SL2-IN-E-1154R SL2-IN-E-1152R SL2-IN-E-1017 SL2-IN-E-1158R SL2-IN-E-1153R VCCI A-0029 A-0109 A-0108 A-0201 A-0110 Recognized Phase I CAB for ISED, ACMA, BSMI, IDA, KCC/RRA, MIC, MOC, NCC, OFCA US0158 US0175 US0017 US0191 US0157 Report No. RODE0001 Rev. 15/24 MEASUREMENT UNCERTAINTY TMU.2015.07.10 Measurement Uncertainty When a measurement is made, the result will be different from the true or theoretically correct value. The difference is the result of tolerances in the measurement system that cannot be completely eliminated. To the extent that technology allows us, it has been our aim to minimize this error. Measurement uncertainty is a statistical expression of measurement error qualified by a probability distribution. A measurement uncertainty estimation has been performed for each test per our internal quality document QM205.4.6. The estimation is used to compare the measured result with its "true" or theoretically correct value. The expanded measurement uncertainty (K=2) can be found included as part of the applicable test description page. Our measurement data meets or exceeds the measurement uncertainty requirements of the applicable specification; therefore, the test data can be compared directly to the specification limit to determine compliance. The calculations for estimating measurement uncertainty are based upon ETSI TR 100 028 (or CISPR 16-4-2 as applicable), and are available upon request. The following table represents the Measurement Uncertainty (MU) budgets for each of the tests that may be contained in this report. Test + MU - MU Frequency Accuracy 0.0007% -…

Text truncated - open the document above for the full version.

RADIATED TESTING photo PSA-ESCI 2019.05.10 photos PSA-ESCI 2019.05.10 FF and SE (1).JPG FF and SE (2).JPG and SE (2) RADIATED TESTING photo PSA-ESCI 2019.05.10 photos PSA-ESCI 2019.05.10 FF and SE (3).JPG FF and SE (4).JPG and SE (4) XMit 2019.09.05 Direct Connect (1).JPG Direct Connect (2).JPG DIRECT CONNECT
