2AUYCCD8Smart Display

Center Display Unit - QSG CONFIDENTIAL V2_07092021 Page | 1 NOT APPROVED FOR RELEASE Center Display Unit Quick Start Guide (QSG) Center Display Unit - QSG CONFIDENTIAL V2_07092021 Page | 2 Revision History Date Description Approval Function 07/09/2021 Rev 2_QSG Preliminary Release B. Weidemann Project Manager 07/08/2021 Rev 1_QSG Preliminary Release B. Weidemann Project Manager Center Display Unit - QSG CONFIDENTIAL V2_07092021 Page | 3 Table of Contents Page A. Overview............................................................................................................................................................4 B. Product Dimensions..........................................................................................................................................5 C. Location of Markings.........................................................................................................................................5 D. Disposal and Recycling......................................................................................................................................5 E. Regulatory Compliance.....................................................................................................................................6 F. Manufacturer Details........................................................................................................................................6 Center Display Unit - QSG CONFIDENTIAL V2_07092021 Page | 4 A. Overview • This Quick Start Guide (QSG) is intended for users of the Center Display Unit. The QSG provides a step-based approach that is easy to follow and focused on helping the user quickly get familiar with the Center Display Unit’s features and functions. Carefully read the QSG before operating the E-Bike. A.1 Product Image A.2 Main Features & Specifications Main Features • Large 2” QVGA (240 x 320) IPS panel • Wide 160 o /160 o viewing angle • Super bright 1,400cd/m 2 (Typical) backlit display • 1P65 rating protection • USB-C port for charging and service Specifications Item Definition Display Technology Type Backlit TFT (IPS Panel) Panel Size 2.0” Native Resolution QVGA (240 x 320) Pixels Brightness (Typical) 1,400cd/m2 Viewing Angle (H/V) 160° (80°/80°)/160° (80°/80°) Orientation Portrait Memory 256M Interface CAN/CANopen, UART, RS-485, RS-232, LIN Light Sensor Yes Power (Wide VIN Range) 7 - 55V Max Current W/USB Charging: 80mA - 440mA W/O USB Charging: 30mA - 150mA USB USB Type C, Max. 1.5A (For Charging) Mounting Three options: Y-Mount, Forward Mount, One-Arm Mount IP Level IP65 Storage/Operating Temperature -20° to +60°C (-4° to +140°F)/-10° to +50°C (14° to +122°F) Connector AVS 6-Pin x2 (Drive/Remote Cable) Dimensions (W x D x H) (Estimated) 46mm x 19mm x 62mm (1.8” x 0.7” x 2.4”) Weight (Estimated) 35g (1.2oz) Color Housing: Pantone Black Center Display Unit - QSG CONFIDENTIAL V2_07092021 Page | 5 B.1 Product Dimensions C.1 Location of Markings D.1 Disposal and Recycling This product may contain other electronic waste that can be hazardous if not disposed of properly. Recycle or dispose in accordance with local, state, or federal Laws. For more information, contact the Electronic Industries Alliance at www.eiae.org. DISPOSAL: Do not use household or municipal waste collection services for disposal of electrical and electronic equipment. EU countries require the use of separate recycling collection services. E.1 Regulatory Compliance Center Display Unit - QSG CONFIDENTIAL V2_07092021 Page | 6 FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. Hower, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experience radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party. Responsible for compliance could void the user’s authority to operate this equipment. .(Example: use only shielded- interface cables when connecting to a computer or peripheral devices). This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.This device maybe not cause harmful interference, and 2.This device must accept any interference received, including interference that may cause undesired operation. FCC Radiation Exposure Statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction F.1 Manufacturer Details (Center Display Unit) AVS Electronics (HK) Ltd 16D Hollywood Centre, 77-91 Queens Road West, Sheung Wan, Hong Kong S.A.R.

AVS Electronics (HK) Ltd. U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: 02-21-2023 Ref: Attestation Statement – Part2.911(d)(7) filing FCC ID: 2AUYCCD8 AVS Electronics (HK) Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, THREE STONES MEDIA LLC(“the agent”) is our designated U.S. agent for service of process for the abovereference FCC ID. The applicant accepts to maintain an agent for service of process in the United States forno less than one year after either the grantee has permanently terminated all marketing and importation of theapplicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicialproceeding involving the equipment, whichever is later. The applicant further acknowledges it is ourresponsibility to inform the FCC whenever the agent information changes. THREE STONES MEDIA LLC ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: THREE STONES MEDIA LLC FRN: 0033401761 GC: 2A99E Address: 1200 Broadway St. APT 329, Los Angeles, CA90015 Signature: Contact Person: Sijie Zhang Tel: +1 267 909 3692 Email: [email protected] Applicant Company Name: AVS Electronics (HK) Ltd. Address: 16D Hollywood Centre, 77-91 Queens Road West, Sheung Wan, Hong Kong S.A.R. Signature: Contact Person: Andreas Hoffmann Tel: 00852 2369 4308 Email: [email protected]

AVS Electronics (HK) Ltd. The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2/27/2023 To whom it may concern: We, [AVS Electronics (HK) Ltd.], hereby certify that the equipment for which authorization is sought (FCC ID: 2AUYCCD8) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List ( https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). Sincerely, Signature [Name] Andreas Hoffmann [Title]Manager [Company] AVS Electronics (HK) Ltd. 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V02

Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8

©Copyright 2021. AVS Electronics (HK) LTD & AVE Mobility (TW) LTD. All Rights Reserved . AVS CD8 –Rating Label Placement Location Rating Label goes here

Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 ANT Photo 7 Photo 8 Photo 9

version01 AVS Electronics (HK) Ltd. Declaration concerning Antenna Specification It is hereby declared that the product Model No.: CD8 FCC ID: 2AUYCCD8 fulfills the requirement in FCC test relating to the antenna type. Gain of the antenna: Frequency range: 1.3 dBi 2400-2500 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: AVS Electronics (HK) Ltd. Address: 16D Hollywood Centre, 77-91 Queens Road West, Sheung Wan, Hong Kong S.A.R. City: Hong Kong SAR ZIP / Postal code: Country: China Name: Andreas Hoffmann Date: 09/02/2023 Signature: The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Model No. of antenna: UPB2400-1051B-O Type of antenna:Dipole for E mbedded Type

ULTRA Electronic Corp. Approval Sheet Customer Approved ULTRA Approved Leon.Lee AVS Electronics (HK) Customer : Project Name : Customer P/N : Model: UPB2400-1051B-O Product Description : UPB 2.4G PCB +1.13黑 L=51mm open Issue Date :2023 / 22 /16 version : A ULTRA Electronics Corp. 昂創電子有限公司 9F No. 168 Ruiguang Rd, Neihu Dist. Taipei City 11491 Taiwan TEL: 886-2-77550883 FAX: 886-2-87518367 E-mail: [email protected] Content 1. Product Photos and Configuration 2. Specification 3. Reliability Characteristics 4. S Parameter Test 4.1 Test Cable Setup 4.2 S.W.R. Test Data 5. Antenna Gain Test 5.1 Chamber Setup and Angle Definition 5.2 Antenna Radiation Pattern 5.3 Gain and Efficiency Test Data 6. Packaging Information 7. Mechanical Drawing / Dimension / Layout 1. Product Photos and Configuration . Product Number : . Version : X1 Electrical Characteristics . Frequency (MHz) : 2400-2500 MHz . S.W.R. : < 3.0 * S.W.R. tested within whole device * . Peak Gain : 1.3 dBi . Efficiency : 20~30 % * peak gain and efficiency data depended on whole device installation environments* . Antenna Type : Dipole for Embedded Type . Radiation Pattern : Omni-Directional . Polarization : Linear . Impedance : 50 ohm . Input Power : 5W Max. Mechanical Characteristics . Antenna Material : PCB . Cable : O.D. 1.13 mm / 50 Ohm Coaxial Cable . Material : RoHS Compliant Environmental Condition . Operation Temperature : -40 ~ +80 ºC . Storage Temperature : -40 ~ +80 ºC . Moisture Sensitivity Levels (MSL) : N/A . ESD Limit : N/A . Vibration Limit : N/A 2. Specification 3. Reliability Characteristics R1. Soldering Ability Condition: the dipped surface of the terminal should be over 95% covered with solder after dipped in soldering material of 260 +/- 5°C for 3 +/- 1 seconds. Requirement: no apparent damage R2. Soldering Heat Condition: .solder bath temperature : 260 +/- 5°C .bathing time : 10+/-1 seconds Requirement: no apparent damage R3. Thermal Shock Condition: 30 minutes @ -40 +/- 5°C and 5 minutes to 90°C ; 30 minutes @ 90 +/- 5°C and 5 minutes to -40°C ; 96 continuous cycles Requirement: no apparent damage / electrical test pass R4. Humidity Condition: R.H. 85% ; 85 +/- 5°C ; 96 Hours Requirement: no apparent damage / electrical test pass R5. High Temperature Condition: 90 +/- 5°C ; 96 Hours Requirement: no apparent damage / electrical test pass R6. Low Temperature Condition: -40 +/- 5°C ; 96 Hours Requirement: no apparent damage / electrical test pass 4.2 S Parameter Test S.W.R. Test Data (on Plastic Case) 5. Antenna Gain Test 5.1 Chamber Setup and Angle Definition X Y Z 5. Antenna Gain Test 5.2 Antenna Radiation Pattern 5. Antenna Gain Test 5.2 Antenna Radiation Pattern 5. Antenna Gain Test 5.3 Gain and Efficiency Test Data 昂創電子有限公司 UPB2400-1051B-O

FCC ID:2AUYCCD8 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. BLE: Antenna Type: Dipole for Embedded Type Antenna Gain: 1.3dBi Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n 1g SAR Exclusion threshold SAR test exclusion 2.402 0.24 1.0571±121.585<50.491273.00YES 2.44 1.39 1.3771±121.585<50.495143.00YES 2.480 0.49 1.1191±121.585<50.499183.00YES GFSK Conclusion: For the max result :0.49918≤ 3.0 for 1-g SAR, No SAR is required. Signature: Date: 2023-02-23 NAME AND TITLE (Please print or type): Alex /Manager COMPANY (Please print or type): Shenzhen NTEK Testing Technology Co., Ltd./ 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China

Report No.: S22070502202001 Version.1.3 Page 1 of 46 RADIO TEST REPORT FCC ID: 2AUYCCD8 Product: Smart Display Trade Mark: AVS Model No.: CD8 Family Model: N/A Report No.: S22070502202001 Issue Date: Dec 07. 2022 Prepared for AVS Electronics (HK) Ltd. 16D Hollywood Centre, 77-91 Queens Road West, Sheung Wan, Hong Kong S.A.R. Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website: http://www.ntek.org.cn Report No.: S22070502202001 Version.1.3 Page 2 of 46 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ...................................................................................................................... 3 2 SUMMARY OF TEST RESULTS ......................................................................................................................... 4 3 FACILITIES AND ACCREDITATIONS ............................................................................................................. 5 3.1 FACILITIES..................................................................................................................................................... 5 3.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................................. 5 3.3 MEASUREMENT UNCERTAINTY ............................................................................................................... 5 4 GENERAL DESCRIPTION OF EUT .................................................................................................................. 6 5 DESCRIPTION OF TEST MODES ..................................................................................................................... 8 6 SETUP OF EQUIPMENT UNDER TEST ........................................................................................................... 9 6.1 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ....................................................................... 9 6.2 SUPPORT EQUIPMENT............................................................................................................................... 10 6.3 EQUIPMENTS LIST FOR ALL TEST ITEMS .............................................................................................. 11 7 TEST REQUIREMENTS .................................................................................................................................... 13 7.1 CONDUCTED EMISSIONS TEST ............................................................................................................... 13 7.2 RADIATED SPURIOUS EMISSION ............................................................................................................ 16 7.3 6DB BANDWIDTH ....................................................................................................................................... 25 7.4 DUTY CYCLE ............................................................................................................................................... 26 7.5 PEAK OUTPUT POWER .............................................................................................................................. 28 7.6 POWER SPECTRAL DENSITY ................................................................................................................... 29 7.7 CONDUCTED BAND EDGE MEASUREMENT......................................................................................... 31 7.8 SPURIOUS RF CONDUCTED EMISSIONS................................................................................................ 32 7.9 ANTENNA APPLICATION .......................................................................................................................... 33 8 TEST RESULTS ................................................................................................................................................... 34 Report No.: S22070502202001 Version.1.3 Page 3 of 46 1 TEST RESULT CERTIFICATION Applicant’s name ......................... : AVS Electronics (HK) Ltd. Address ....................................... : 16D Hollywood Centre, 77-91 Queens Road West, Sheung Wan, Hong Kong S.A.R. Manufacturer's Name .................. : geruibang technology co. LTD Address ....................................... : 5F，C-building of SOGOOD Park in Sanwei Village of Xixiang, Baoan district in Shenzhen Product description Product name .............................. : Smart Display Model and/or type reference ...... : CD8 Family Model ............................... : N/A Test Sample Number ................... : S220705022001 Measurement Procedure Used: APPLICABLE STANDARDS APPLICABLE STANDARD/ TEST PROCEDURE TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 Complied This device described above has been tested by Shenzhen NTEK Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of Shenzhen NTEK Testing Technology Co., Ltd., this document may be altered or revised by Shenzhen NTEK Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. The test results of this report relate only to the tested sample identified in this report. Date of Test : Nov 21. 2022 ~ Dec 07. 2022 Testing Engineer : (Mary Hu) Authorized Signatory : (Alex Li) Report No.: S22070502202001 Version.1.3 Page 4 of 46 2 SUMMARY OF TEST RESULTS FCC Part15 (15.247), Subpart C Standard Section Test Item Verdict Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.209 (a) 15.205 (a) Radiated Spurious Emission PASS…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
