2AUYFRMA2010realme Buds Q2

Enter pairing mode Open up the charging case and keep both earbuds in the case, and press button on both earbuds for more than 5s. realme Buds Q2 User Guide 1 Connect earbuds Turn on Bluetooth on smartphone, search and connect to "realme Buds Q2" 2 80g哑粉 单黑 双面印刷/风琴折/规格：92*80mm Bluetooth Available equipment realme Buds Q2 realme Buds Q2 Connection Touch operation Single click: Answer calls Double click: Play/Pause; Hang up Triple click: Next song Press and hold both earbuds for 2s: Enter/Exit game mode Game mode Buttons of right earbud Use with realme Link Users can download realme Link to install additional features for realme Buds Q2 Search realme Link in APP Store, or scan the following QR code to download Basic Parameters Product name realme Buds Q2 Product model DA2002 Bluetooth version Bluetooth 5.0 Bluetooth protocol HFP/A2DP/AVRCP Bluetooth code SBC，AAC Charging interface Micro-USB Endurance (music) About 5h (earbuds) About 20h (use with charging case) Packing List 1、realme Buds Q2 *1 2、Ear tips *6 (two of them have been mounted) 3、User Guide *1 Buttons of left earbud Double click Triple click Long press Pause/Play > Next song > Double click Triple click Long press Pause/Play > Next song > Charging time Bluetooth communication distance Working frequency Max power rate About 2h ≤10m 2.4GHz~2.4835 GHz ≤8dBm REV.1.0 Realme Chongqing Mobile Telecommunications Corp., Ltd. No.178 Yulong Avenue, Yufengshan, Yubei District, Chongqing, China 0303002775 Battery warning The built-in lithium battery of the product is forbidden to be disassembled, impacted, extruded or put into fire. The battery under the very low air pressure may result in explosion or flammable liquid or gas leakage. Avoid the battery in a high-temperature environment or being exposed to strong sunlight to avert explosion. Don't use the battery continuously in case of serious ballooning. The battery shall be handled pursuant to the local regulations and shall not be disposed as household garbage. Don't try to repair, remove or refit the battery. The explosion may happen if the battery is replaced by the one subject to incorrect model. Don't compress or puncture the battery with hard object. The battery leakage, overheating or outbreak of a fire may occur if the battery is destroyed. This symbol means that aocorcing to looal laws and regulations your product and/or its battery shall be disposed of separately from household waste. When this product reaches its end of life, user has the choice to give his product to a competent recycling organization. Proper recycling of your product will protect human health and the environmerrt. Hereby, realme, declares that this device is in compliance with the essential requirements and other relevant provisions of Radio Equipment Directive 2014/53/EU. The declaration of conformity may be consulted at http://www.realme.com/global/support/eu-declaration. RF exposure information: The EIRP power of the device at maximal case is below the exempt condition, 20mW specified in EN 50663:2017. RF exposure assessment has been performed to prove that this unit will not generate the harmful EM emission above the reference level as specified in EC Council Recommendation (1999/519/EC). Operation temperature: 0~45 Operation frequency (Max power)Bluetooth: 2402-2480MHz Max. RF power transmitted: 8.41dBm for left ear, 7.50dBm for right ear input: DC5.0V, 0.5A EU Declaration of Conformity DOC )) FCC Warranty Matters Needing Attention: Non-warranty situation: Thank you for purchasing realme products. If any manufacturing defect problems occur within 12 months from the date of purchase, user can enjoy our company's warranty service. This warranty does not cover the following cases: 1. Out of warranty period. 2. Damage caused by use not in accordance with the instructions. 3. Damage caused by man-made causes. 4. Failure caused by unauthorized disassembly, maintenance, or modification of the product. 5. Damage caused by force majeure factors (such as floods, earthquakes, lightning, etc.). 6. There is no warranty card, invoice, or warranty card that does not match the invoice information. 7. The product wears naturally. 8. Other failures and damages that are not caused by the quality of the product itself. Website: www.realme.com 1. When you buy the product, the sales unit will issue a valid proof of purchase. 2. The warranty card and the proof of purchase should be kept by the user properly, and it will not be replaced if lost. 3. If the product fails due to non-human factors, the user can present the warranty card and proof of purchase to the realme customer service center for free maintenance during the warranty period. Dear user, thank you for using the product of our company. Please read and keep properly the w arranty card after purchasing the product so that we can provide better services to you. Warranty Card (Stub Copy) User Information User's name Phone Number Address Email Product Information Product Model Product Serial Number Sales Information Purchase Date Invoice Number Sales Unit Phone Number Address Warranty Card (Customer Copy) Dear user, thank you for using the product of our company. Please read and keep properly the warranty card after purchasing the product so that we can provide better services to you. User Information User's name Phone Number Address Email Product Information Product Model Product Serial Number Sales Information Purchase Date Invoice Number Sales Unit Phone Number Address FCC Compliance Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee t…

Text truncated - open the document above for the full version.

C5266091_X8_Ed.1 1/1 LetterofAuthorization RealmeChongqingMobileTelecommunicationsCorp.,Ltd. No.178YulongAvenue,Yufengshan,YubeiDistrict,Chongqing,China Company:RealmeChongqingMobileTelecommunicationsCorp.,Ltd. Address:No.178YulongAvenue,Yufengshan,YubeiDistrict,Chongqing,China ProductName:realmeBudsQ2 ModelNumber:RMA2010 FCCIdentifier:2AUYFRMA2010 WeauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdelCarme,s/n, 08193Bellaterra,Spain,toactonourbehalfonallmattersconcerningthe abovenamedequipment. AnyindividualwithinLGAITechnologicalCenterS.A.isauthorizedtoactonour behalfandtakeactionontheapplication. WedeclarethatauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdel Carme,s/n,08193Bellaterra,Spain,isallowedtoforwardallinformation relatedtotheapprovalprojecttotheFederalCommunicationCommissionand todiscussanyissuesconcerningtheapprovalapplication.Anyandallacts carriedoutbyLGAITechnologicalCenterS.A.onourbehalfshallhavethe sameeffectasactsofourown. Name:LiangPingYangDate:2020.12.18 Title:Manager Signatureofapplicant:

C5266091_X10_Ed.2 1/1 RealmeChongqingMobileTelecommunicationsCorp.,Ltd. No.178YulongAvenue,Yufengshan,YubeiDistrict,Chongqing,China OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 Date:2020.12.18 Subject:RequestforConfidentiality FCCID:2AUYFRMA2010 ToWhomItMayConcern, PursuanttotheprovisionsofSections0.457and0.459ofCommission'srules (47CFR0.457,0.459),wearerequestingtheCommissiontowithholdthefollowing attachment(s)asconfidentialdocumentfrompublicdisclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality NOTE2 IDLabel/LocationNoNo AttestationStatementNoNo ExternalPhotosNo ☐ BlockDiagram ☒☐ Schematics ☒☐ TestReportNoNo TestSetupPhotosNo ☒ User’sManual ☐ NOTE 1 ☒ InternalPhotos ☐ NOTE 1 ☒ PartsList/TuneUp ☐ RFExposureInfoNoNo OperationalDescription ☒☐ CoverLetter(s)NoNo SDRSoftware/SecurityInfoNo NOTE1:Long-TermConfidentialitymaybepermittedunderspecialconditions(SeeII.LONG-TERMCONFIDENTIALITY,Section3of KDB726920,uselastinforce) NOTE2:Short-TermConfidentialitycanberequestedforamaximumof180daysfromthedateofthegrant. Abovementioneddocumentcontainsdetailedsystemandequipmentdescriptionare consideredasproprietaryinformationinoperationoftheequipment.Thepublic disclosureofabovedocumentsmightbeharmfultoourcompanyandwouldgive competitoranunfairadvantageinthemarket. Incaseofshort-termConfidentiality,theapplicantrequeststheexhibitsselected abovearewithheldfrompublicviewforaperiodof______daysfromthedateofthe GrantofEquipmentAuthorizationandpriortomarketing. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondentduringcertificationreviewprocesscannotbegrantedasconfidential ☐ ☐ 180 ☒ C5266091_X10_Ed.2 1/1 documentsandthoseinformationwillbeavailableforpublicreviewoncethegrantof equipmentauthorizationisissued. Sincerely, Signature: Name: LiangPingYang Title:Manager

V1第一次发行12/29 V2 取消NEO 1/5 FCC ID : 2AUYFRMA2010

Guangzhou GRG Metrology & Test Co., Ltd. Address:No.163 Pingyun Road, West of Huangpu Avenue, Guangzhou GuangdongChina Tel:+86-20-38699960 Fax:+86-20-38695185 Email: [email protected] http://www.grgtest.com TEST REPORT Verified Code: Report No.: E202012093384-3-G1 Application No.: E202012093384 Client: Realme Chongqing Mobile Telecommunications Corp., Ltd. Address: No.178 Yulong Avenue, Yufengshan, Yubei District, Chongqing，China. Sample Description: realme Buds Q2 Model: RMA2010 Test Specification: IEEE Std. 1528:2013 47 CFR FCC Part 2.1093:2013 IEEE Std. C95.1:2019 Receipt Date: 2020-12-11 Test Date: 2021-01-12 to 2021-01-12 Issue Date: Test Result: Pass Prepared By: Test Engineer Reviewed By: Technical Manager Approved By: Manager Other Aspects: Note: This report instead the report E202012093384-3, and from the date of issuance of this report, the report which being replaced become invalid. Abbreviations: ok / P = passed; fail / F = failed; n.a. / N = not applicable; The test result in this test report refers exclusively to the presented test sample. This report shall not be reproduced except in full, without the written approval of GRGT. 061325 2021-01-22 Report No.: E202012093384-3-G1 Application No.: E202012093384 Page 1 of 61 DIRECTIONS OF TEST 1. This station carries out test task according to the national regulation of verifications which can be traced to National Primary Standards and BIPM. 2. The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. 3. If there is any objection concerning the test, the client should inform the laboratory within 15 days from the date of receiving the test report. Report No.: E202012093384-3-G1 Application No.: E202012093384 Page 2 of 61 TABLE OF CONTENTS 1. GENERAL INFORMATION ...................................................................................................................... 3 2. GENERAL INFORMATION OF EUT .......................................................................................................... 4 2.1 STATEMENT OF COMPLIANCE ......................................................................................................................... 4 2.2 GENERAL DESCRIPTION .................................................................................................................................... 5 2.3 LABORATORY ENVIRONMENT ........................................................................................................................ 6 3. LABORATORY AND ACCREDITATIONS .................................................................................................... 7 3.1 LABORATORY ...................................................................................................................................................... 7 3.2 ACCREDITATIONS ............................................................................................................................................... 7 3.3 MEASUREMENT UNCERTAINTY ...................................................................................................................... 7 4. SAR MEASUREMENTS SYSTEM .............................................................................................................. 8 4.1 DEFINITION OF SPECIFIC ABSORPTION RATE (SAR) .................................................................................. 8 4.2 SAR SYSTEM ......................................................................................................................................................... 9 4.3 E-FIELD PROBE .................................................................................................................................................. 10 4.4 DATA ACQUISITION ELECTRONICS (DAE) .................................................................................................. 11 4.5 ROBOT.................................................................................................................................................................. 12 4.6 MEASUREMENT SERVER ................................................................................................................................. 13 4.7 PHANTOM ........................................................................................................................................................... 14 4.8 DEVICE HOLDER ............................................................................................................................................... 15 4.9 DATA STORAGE AND EVALUATION ............................................................................................................. 16 5. TEST EQUIPMENT LIST ......................................................................................................................... 18 6. SYSTEM VERIFICATION PROCEDURE ..................................................................................................... 19 6.1 TISSUE VERIFICATION ..................................................................................................................................... 19 6.2 SYSTEM CHECK PROCEDURE ........................................................................................................................ 20 7. SAR MEASUREMENT VARIABILITY AND UNCERTAINTY ......................................................................... 22 7.1 SAR MEASUREMENT VARIABILITY .............................................................................................................. 22 7.2 MEASUREMENT UNCERTAINTY .................................................................................................................... 22 8. EUT TESTING POSITION ........................................................................................................................ 23 8.1 BODY WORN POSITION ................................................…

Text truncated - open the document above for the full version.

Report No.: E202012093384-3-G1 Application No.: E202012093384 Page 50 of 61 Report No.: E202012093384-3-G1 Application No.: E202012093384 Page 51 of 61 Report No.: E202012093384-3-G1 Application No.: E202012093384 Page 52 of 61 Report No.: E202012093384-3-G1 Application No.: E202012093384 Page 53 of 61 Report No.: E202012093384-3-G1 Application No.: E202012093384 Page 54 of 61 Report No.: E202012093384-3-G1 Application No.: E202012093384 Page 55 of 61 Report No.: E202012093384-3-G1 Application No.: E202012093384 Page 56 of 61 APPENDIX D: PHOTOGRAPH OF SET UP Left Ear-Front Face Left Ear-Rear Face Report No.: E202012093384-3-G1 Application No.: E202012093384 Page 57 of 61 Left Ear-Left Side Left Ear-Right Side Report No.: E202012093384-3-G1 Application No.: E202012093384 Page 58 of 61 Left Ear-Top Side Left Ear-Bottom Side Report No.: E202012093384-3-G1 Application No.: E202012093384 Page 59 of 61 Right Ear-Front Face Right Ear-Rear Face Report No.: E202012093384-3-G1 Application No.: E202012093384 Page 60 of 61 Right Ear-Left Side Right Ear-Right Side Report No.: E202012093384-3-G1 Application No.: E202012093384 Page 61 of 61 Right Ear-Top Side Right Ear-Bottom Side --------------------This is the last page of the report. -----------------------

Guangzhou GRG Metrology & Test Co., Ltd. Address:No.163 Pingyun Road, West of Huangpu Avenue, Guangzhou GuangdongChina Tel:+86-20-38699960 Fax:+86-20-38695185 Email: [email protected] http://www.grgtest.com TEST REPORT Verified Code: Report No.: E202012093384-2 Application No.: E202012093384 Client: Realme Chongqing Mobile Telecommunications Corp., Ltd. Address: No.178 Yulong Avenue, Yufengshan, Yubei District, Chongqing，China. Sample Description: realme Buds Q2 Model: RMA2010 Test Specification: FCC 47 CFR Part 15 Subpart C Receipt Date: 2020-12-11 Test Date: 2020-12-16 to 2021-01-06 Issue Date: Test Result: Pass Prepared By: Test Engineer Reviewed By: Technical Manager Approved By: Manager Other Aspects: Note: Note Abbreviations: ok / P = passed; fail / F = failed; n.a. / N = not applicable; The test result in this test report refers exclusively to the presented test sample. This report shall not be reproduced except in full, without the written approval of GRGT. 743912 2021-01-15 Report No.: E202012093384-2 Application No.: E202012093384 Page 1 of 116 DIRECTIONS OF TEST 1. This station carries out test task according to the national regulation of verifications which can be traced to National Primary Standards and BIPM. 2. The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. 3. If there is any objection concerning the test, the client should inform the laboratory within 15 days from the date of receiving the test report. Report No.: E202012093384-2 Application No.: E202012093384 Page 2 of 116 TABLE OF CONTENTS 1. TEST RESULT SUMMARY ............................................................................................................................ 4 2. GENERAL DESCRIPTION OF EUT ................................................................................................................. 5 2.1. APPLICANT .............................................................................................................................................. 5 2.2. MANUFACTURER ................................................................................................................................... 5 2.3. FACTORY ................................................................................................................................................. 5 2.4. BASIC DESCRIPTION OF EQUIPMENT UNDER TEST ....................................................................... 5 2.5. TEST OPERATION MODE ....................................................................................................................... 6 2.6. LOCAL SUPPORTIVE .............................................................................................................................. 6 3. LABORATORY AND ACCREDITATIONS ........................................................................................................ 7 3.1. LABORATORY ......................................................................................................................................... 7 3.2. ACCREDITATIONS ................................................................................................................................. 7 3.3. MEASUREMENT UNCERTAINTY ......................................................................................................... 7 4. LIST OF USED TEST EQUIPMENT AT GRGT .................................................................................................. 8 5. TEST RESULTS ............................................................................................................................................ 9 5.1. E.U.T. TEST CONDITIONS ...................................................................................................................... 9 5.2. 20DB BANDWIDTH ................................................................................................................................ 11 5.2.1. LIMITS ................................................................................................................................................. 11 5.2.2. TEST PROCEDURES .......................................................................................................................... 11 5.2.3. TEST SETUP ....................................................................................................................................... 11 5.2.4. TEST RESULTS ................................................................................................................................... 12 5.3. CARRIER FREQUENCIES SEPARATED ............................................................................................. 23 5.3.1. LIMITS ................................................................................................................................................. 23 5.3.2. TEST PROCEDURES .......................................................................................................................... 23 5.3.3. TEST SETUP ....................................................................................................................................... 23 5.3.4. TEST RESULTS ................................................................................................................................... 24 5.4. HOPPING CHANNEL NUMBER ........................................................................................................... 31 5.4.1. LIMITS ................................................................................................................................................. 31 5.4.2. TEST PROCEDURES .......................................................................................................................... 31 5.4.3. TEST SETUP .............................................................................................................................…

Text truncated - open the document above for the full version.

Report No.: E202012093384-2 Application No.: E202012093384 Page 70 of 116 Left earphone Hopping On GFSK CH Low (2.31GHz ~2.5GHz) /4-DQPSK CH Low (2.31GHz ~2.5GHz ) Report No.: E202012093384-2 Application No.: E202012093384 Page 71 of 116 8DPSK CH Low (2.31GHz ~2.5GHz ) Report No.: E202012093384-2 Application No.: E202012093384 Page 72 of 116 Right earphone Hopping On GFSK CH Low (2.31GHz ~2.5GHz) /4-DQPSK CH Low (2.31GHz ~2.5GHz ) Report No.: E202012093384-2 Application No.: E202012093384 Page 73 of 116 8DPSK CH Low (2.31GHz ~2.5GHz ) Report No.: E202012093384-2 Application No.: E202012093384 Page 74 of 116 5.8. RADIATED SPURIOUS EMISSIONS 5.8.1. LIMITS In any 100 kHz bandwidth outside the frequency band in which the spread spectrum or digitally modulated intentional radiator is operating, the radio frequency power that is produced by the intentional radiator shall be at least 20 dB below that in the 100 kHz bandwidth within the band that contains the highest level of the desired power, based on either an RF conducted or a radiated measurement, provided the transmitter demonstrates compliance with the peak conducted power limits. If the transmitter complies with the conducted power limits based on the use of RMS averaging over a time interval, as permitted under paragraph (b)(3) of this section, the attenuation required under this paragraph shall be 30 dB instead of 20 dB. Attenuation below the general limits specified in §15.209(a) is not required. Frequency (MHz) Quasi-peak(μV/m) Measurement distance(m) Quasi-peak(dBμV/m)@distance 3m 0.009-0.490 2400/F(kHz) 300 53.8~88.5 0.490-1.705 24000/F(kHz) 30 43~53.8 1.705-30.0 30 30 49.5 30 ~ 88 100 3 40 88~216 150 3 43.5 216 ~ 960 200 3 46 Above 960 500 3 54 NOTE: (1) The lower limit shall apply at the transition frequencies. NOTE: (2) Above 18G Limit=74+20log(3/1)=83.54 (dBμV/m). 5.8.2. TEST PROCEDURES 1) The EUT was placed on the top of a rotating table 0.8 meters (for below 1GHz) / 1.5 meters (for above 1GHz) above the ground at a 3 meters semi-anechoic chamber. The table was rotated 360 degrees to determine the position of the highest radiation. 2) The EUT was set 3 meters away from the interference-receiving antenna, which was mounted on the top of a variable-height antenna tower. 3) Height of receiving antenna is varied from one meter to four meters above the ground to determine the maximum value of the field strength. Both horizontal and vertical polarizations of the antenna are set to make the measurement. 4) The test-receiver system was set to Peak Detect Function and Specified Bandwidth with Maximum Hold Mode. 5) The test-receiver system was set to Peak Detect Function and Specified Bandwidth with Maximum Hold Mode. 6) If the emission level of the EUT in peak mode was lower than the limit specified, then testing could be stopped and the peak values of the EUT would be reported. Otherwise the emissions would be re-tested one by one using peak, quasi-peak or average method as specified and then reported in a data sheet. Report No.: E202012093384-2 Application No.: E202012093384 Page 75 of 116 5.8.3. TEST SETUP Figure 1. 9 KHz to 30MHz radiated emissions test configuration Figure 2. 30MHz to 1GHz radiated emissions test configuration 1m 30cm EUT Spectrum analyzer Horn antenna 3m 4m Turntable 1.5m Antenna tower Pre-amp Figure 3. Above 1GHz radiated emissions test configuration Report No.: E202012093384-2 Application No.: E202012093384 Page 76 of 116 1m 30cm EUT Spectrum analyzer Horn antenna 1m 4m Turntable 1.5m Antenna tower Pre-amp Figure 4. Above 18GHz radiated emissions test configuration 5.8.4. DATA SAMPLE 30MHz to 1GHz No. Frequency Reading Correct Result Limit Margin Remark Pole (MHz) (dBuV/m) Factor(dB/m) (dBuV/m) (dBuV/m) (dB) xxx xxx 37.06 -15.48 21.58 40.00 -18.42 QP Vertical Above 1 GHz No. Frequency Reading Correct Result Limit Margin Remark Pole (MHz) (dBuV/m) Factor(dB/m) (dBuV/m) (dBuV/m) (dB) xxx xxx 65.45 -11.12 54.33 74.00 -19.67 peak Vertical xxx xxx 63.00 -11.12 51.88 54.00 -2.12 AVG Vertical Frequency (MHz) = Emission frequency in MHz Ant.Pol. (H/V) = Antenna polarization Reading (dBuV) = Uncorrected Analyzer / Receiver reading Correction Factor (dB/m) = Antenna factor + Cable loss – Amplifier gain Result (dBuV/m) = Reading (dBuV) + Correction Factor (dB/m) Limit (dBuV/m) = Limit stated in standard Margin (dB) = Remark Result (dBuV/m) – Limit (dBuV/m) Peak = Peak Reading QP = Quasi-peak Reading AVG = Average Reading Report No.: E202012093384-2 Application No.: E202012093384 Page 77 of 116 5.8.5. TEST RESULTS 30MHz to 1GHz Left earphone Mode: TX Date: 2020/12/30 Polarity Vertical No. Frequency Reading Correct Result Limit Margin Height Degree Remark (MHz) (dBuV) Factor(dB/m) (dBuV/m) (dBuV/m) (dB) (cm) (deg) 1* 30.9700 35.70 -17.43 18.27 40.00 -21.73 299 358 QP 2 137.6700 36.85 -26.23 10.62 43.50 -32.88 299 0 QP 3 410.2400 36.79 -20.76 16.03 46.00 -29.97 299 75 QP 4 538.2800 37.16 -18.08 19.08 46.00 -26.92 299 357 QP 5 847.7100 37.25 -14.97 22.28 46.00 -23.72 397 0 QP 6 950.5300 37.97 -14.29 23.68 46.00 -22.32 226 0 QP Report No.: E202012093384-2 Application No.: E202012093384 Page 78 of 116 Mode: TX Date: 2020/12/30 Polarity Horizontal No. Frequency Reading Correct Result Limit Margin Height Degree Remark (MHz) (dBuV) Factor(dB/m) (dBuV/m) (dBuV/m) (dB) (cm) (deg) 1* 30.0000 35.54 -16.96 18.58 40.00 -21.42 158 360 QP 2 66.8600 47.90 -30.28 17.62 40.00 -22.38 100 330 QP 3 141.5500 37.55 -26.42 11.13 43.50 -32.37 301 360 QP 4 274.4400 37.37 -24.87 12.50 46.00 -33.50 199 189 QP 5 588.7200 37.78 -17.61 20.17 46.00 -25.83 199 101 QP 6 946.6500 37.98 -14.34 23.64 46.00 -22.36 397 79 QP Report No.: E202012093384-2 Application No.: E202012093384 Page 79 of 116 Right earphone Mode: TX Date: 2020/12/30 Polarity Vertical No. Frequency Reading Correct Result Limit Margin Height Degree Remark (MHz) (dBuV) Factor(dB/m) (dBuV/m) (dBuV/m) (dB) (cm) (deg) 1* 30.0000 35.23 -16.96 18.27 40.00 -21.73 101 360 QP 2 128.9400 36.89 -25.98…

Text truncated - open the document above for the full version.

Page 1 of 11 Conducted Emission on AC mains 0.15MHz to 30MHz Radiated emission Below 1G Mode 1 Page 2 of 11 Mode 2 Above 1G Mode 1 Page 3 of 11 Mode 2 Page 4 of 11 Radiated Spurious Emission Test（Below 1GHz） Radiated Spurious Emission Test（Above 1GHz） Page 5 of 11 Radiated Spurious Emission Test（Above 18GHz） SAR Left Ear-Front Face Page 6 of 11 Left Ear-Rear Face Left Ear-Left Side Page 7 of 11 Left Ear-Right Side Left Ear-Top Side Page 8 of 11 Left Ear-Bottom Side Right Ear-Front Face Page 9 of 11 Right Ear-Rear Face Right Ear-Left Side Page 10 of 11 Right Ear-Right Side Right Ear-Top Side Page 11 of 11 Right Ear-Bottom Side -------------------------------This is the last page of the report. -----------------------
