1 English This guide will show you how to use the phone and its important functions. You may also visit realme ocial website to get more information about the phone. Greetings from realme mobile Warning Do not place the phone or battery near or inside heating equipment, cooking equipments, high pressure vessels (such as microwave ovens, induction cooker, electric oven, heater, pressure cooker, water heater, gas stove, etc.) to prevent the battery overheating which may lead to an explosion. Back cover can’t be removed. The original charger, data cable and battery shall be used. Unapproved chargers, data cables, or batteries that are not certied by the manufacturer may result in electric shock, re, explosion, or other hazards. Standard accessories 1 Phone, 1 Charger, 1 USB data cable, 1 Safety Guide, 1 Quick Guide, 1 SIM Ejector Tool, 1 Protective Case . When charging, please place the device in an environment that has a normal room temperature and good ventilation. It is recommended to charge the device in an environment with temperature ranging from 5 °C ~35 °C . How to reboot the phone Press and hold the Power Button and Volume Up Button at the same time until the realme boot animation is displayed to reboot the phone. How to Transfer Old Mobile Content to a New Mobile You can use realme Clone Phone to easily transfer photos, videos, music, contacts, messages, apps, etc from your old phone to the new one. 1. If you have an old Android phone, rst scan the QR code below, then download and install Clone Phone, next open Clone Phone on both the new and old phones, and follow the on-screen instructions to complete the operation. 2. If you have an old iPhone, open Clone Phone on the new phone directly, and follow on-screen instructions to sign in to iCloud account and sync the les. https://i.clonephone.coloros.com/download / Fingerprint Scanner 2 RMX2001 16.5cm(6.5’’) 162.1×74.8×9.6 16 648 22 4210mAh/16.29Wh(Min) 4300mAh/16.64Wh(Typ) Radio Waves Specications WCDMA LTE TDD Bluetooth 2.4G Wi-Fi LTE FDD GSM 5G Wi-Fi 32.5±0.8dBm 29.5±0.8dBm 23.2±0.8dBm 23.5±0.8dBm 23±0.8dBm 23±0.8dBm 23.3±0.8dBm 22.8±0.8dBm 8±2dBm(EIRP) 15±2dBm(EIRP) Radio Max. Output PowerFrequency Bands 5/8/20/28 Band 7 Bands 1/2/4 Bands 5/8 Bands 1/2/3/4 Bands 38/40 22.8±0.8dBmBand 41 850MHz/900MHz 1800MHz/1900MHz 2.4-2.4835GHz 2.4-2.4835GHz 0.831W/kg(Head) 0.723W/kg(Body) 12.5±1.5dBm(EIRP) 12.5±2dBm(EIRP) 5.15-5.35GHz 5.47-5.725GHz 5.725-5.85GHz RCM SAR X.XXXW/kg(Head) X.XXXW/kg(Body) 13.56MHz ≤42dBuAm 10m @ NFC The N-Mark is a trademark or registered trademark of NFC Forum, Inc. in the United States and in other countries. V0.15211637 RMX2001 Statement Security information The operating system of this product supports official system updates. If the user rooted the ROM system of any third party or modified the system file by cracking, it may lead to security risks of the system. realme will not provide any support nor take any responsibility for the final use in these cases. 'The Important Information Guide and Warranty Card' contains information regarding safety, operation and customer service. Before using the realme smartphone, please read all the instructions and the security information below, and keep it for backup. More detailed instructions are kept in this product as an electronic file. Please read the built-in instructions on the realme smartphone. For the latest information, please visit http://www.realme.com. This mobile phone is suitable for working in an environment of 0°C to 35°C. Temperature for storage should be between -20°C and 45°C. Excessively high or low temperatures can affect the use of mobile phones and even damage the mobile phone and battery. When using this mobile phone, please avoid places near telephone, television, radio, and office automation machines. Please charge this mobile phone in an environment between 5°C and 35°C, so as not to reduce battery performance and standby time. If the phone has a flash charging function, it may not be able to enter the flash charging mode when the temperature is below 15°C or over 35°C. Battery precautions in use Please do not weld battery terminals. Otherwise, it may cause battery leakage, overheat, explosion and fire. Please do not press or pierce the battery with hard objects (for example needle or other sharp objects), to avoid damage, battery leak, overheating or fire. Battery liquid may be harmful if contacted with skin or clothes, your skin might be hurt. Please immediately wash it with water, or go to hospital at once to seek medical help if necessary. If there are any abnormalities like high temperature, discoloration, distortion, bulging, leakage, etc. during operation, charging or preservation, please cease to use the device. Do not expose the battery liquid to eyes. It might cause potential blindness. When happens, wash your eyes immediately or go to the hospital if serious. Do not disassemble or modify the battery, as it may cause battery leakage, overheating, explosion or fire. Do not place or use the battery near fire, heater or other high temperature places. Otherwise, it may cause battery leakage, overheat, explosion or fire. If there is battery leakage or strange smell, please immediately move it from open flame in order to avoid fire or explosion. Please keep the battery away from moist or wet areas from moisture. Otherwise, it may cause battery overheat, fuming and corrosion. Do not place the battery directly in sunlight, or other high temperature areas. Otherwise, battery leakage and overheating may make battery performance descend and service life affected. Keep the battery in a well-ventilated area. Other matters of attention Adapter shall be installed near the equipment and shall be easily accessible. To prevent possible hearing damage, do not listen at high volume levels for long periods. Warning: Please do not charge the battery over 12 hours. Caution: Risk of explosion if battery is replaced by an incorrect type. Dispose of u…

Text truncated - open the document above for the full version.

Realme Chongqing Mobile Telecommunications Corp., Ltd. Agent Authorization Company: Realme Chongqing Mobile Telecommunications Corp., Ltd. Address: No.178 Yulong Avenue, Yufengshan Yubei District, Chongqing, China. Product Name: Mobile Phone Model Number(s): RMX2001 Product Description: Mobile Phone We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Jan. 10, 2020 Name: Yang Liangping Title: Manager Company: Realme Chongqing Mobile Telecommunications Corp., Ltd.

RealMe重庆移动通信有限公司Realme Chongqing Mobile Telecommunications Corp., Ltd. 重庆市渝北区回兴街道霓裳大道24号2幢 No.2 Building, No.24 Nichang Boulevard, Huixing Block, Yubei District, Chongqing, China Date: Jan. 10, 2020 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Realme Chongqing Mobile Telecommunications Corp., Ltd., the undersigned, hereby authorizes Mr. Wu Xuewen from Shenzhen BALUN Technology Co., Ltd., to act on the behalf of the Realme Chongqing Mobile Telecommunications Corp., Ltd. solely in matters relating to the application for an FCC equipment authorization for FCC ID: 2AUYFRMX2001 including the signing of documents in connection with this Application. Necessary acts carried out by Shenzhen BALUN Technology Co., Ltd. in connection with the Application shall have the same effect as acts of the Realme Chongqing Mobile Telecommunications Corp., Ltd.. The Realme Chongqing Mobile Telecommunications Corp., Ltd. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. Section 862. Yours Sincerely, Name of the Manager: Yang Liangping Position: Manager Date: Jan. 10, 2020 Signature:

Annex No.: BL-SZ19C0360-AW 1 / 7 EUT EXTERNAL PHOTOS FRONT VIEW OF EUT REAR VIEW OF EUT Annex No.: BL-SZ19C0360-AW 2 / 7 LEFT SIDE VIEW OF EUT RIGHT SIDE OF EUT Annex No.: BL-SZ19C0360-AW 3 / 7 TOP VIEW OF EUT c BOTTOM VIEW OF EUT Annex No.: BL-SZ19C0360-AW 4 / 7 Accessory-Power Adapter (VC56HAUH US Plug) CLOSE-UP Annex No.: BL-SZ19C0360-AW 5 / 7 Accessory-Power Adapter (VC56JAUH US Plug) CLOSE-UP Annex No.: BL-SZ19C0360-AW 6 / 7 Accessory-Power Adapter (VC56GAUH US Plug) CLOSE-UP Annex No.: BL-SZ19C0360-AW 7 / 7 Accessory-USB Cable

35x25mm Label Label location(device back side) IMEI2: 864987040000088 IMEI1: 864987040000096 S/N: E42C7715 Model: RMX2001Mobile Phone Designed by realmeAssembled in China Realme Chongqing Mobile Telecommunications Corp., Ltd. FCC ID:2AUYFRMX2001

Annex No.: BL-SZ19C0360-AI 1 / 12 EUT INTERNAL PHOTOS EUT UNCOVER VIEW EUT UNCOVER VIEW 2/3/4G Antenna BT/WIFI Antenna GPS Antenna 2/3/4G Antenna NFC Antenna Annex No.: BL-SZ19C0360-AI 2 / 12 EUT UNCOVER VIEW EUT UNCOVER VIEW Annex No.: BL-SZ19C0360-AI 3 / 12 MAIN BOARD TOP VIEW (WITH SHIELDING) MAIN BOARD REAR VIEW (WITH SHIELDING) Annex No.: BL-SZ19C0360-AI 4 / 12 MAIN BOARD TOP VIEW (WITHOUT SHIELDING) c MAIN BOARD REAR VIEW (WITHOUT SHIELDING) RF Chip Annex No.: BL-SZ19C0360-AI 5 / 12 MAIN BOARD TOP VIEW (WITH SHIELDING) MAIN BOARD TOP VIEW (WITHOUT SHIELDING) Annex No.: BL-SZ19C0360-AI 6 / 12 MAIN BOARD REAR VIEW Battery Photo (Sunwoda Electronic Co., Ltd.) (FRONT) Annex No.: BL-SZ19C0360-AI 7 / 12 Battery Photo (Sunwoda Electronic Co., Ltd.) (REAR) Battery Photo (Dongguan NVT Technology Co., Ltd.) (FRONT) Annex No.: BL-SZ19C0360-AI 8 / 12 Battery Photo (Dongguan NVT Technology Co., Ltd.) (REAR) Battery Photo (TWS TECHNOLOGY (GUANGZHOU) LIMITED) (FRONT) Annex No.: BL-SZ19C0360-AI 9 / 12 Battery Photo (TWS TECHNOLOGY (GUANGZHOU) LIMITED) (REAR) Battery Photo (SUNWODA ELECTRONIC INDIA PRIVATE LIMITED) (FRONT) Annex No.: BL-SZ19C0360-AI 10 / 12 Battery Photo (SUNWODA ELECTRONIC INDIA PRIVATE LIMITED) (REAR) Battery Photo (Navitasys India Private Limited) (FRONT) Annex No.: BL-SZ19C0360-AI 11 / 12 Battery Photo (Navitasys India Private Limited) (REAR) Battery Photo (PT.BATTERY TECHNOLOGY INDONESIA) (FRONT) Annex No.: BL-SZ19C0360-AI 12 / 12 Battery Photo (PT.BATTERY TECHNOLOGY INDONESIA) (REAR)

Report No.: BL-SZ19C0360-701 2 / 174 Revision History Version Issue Date Revisions Content Rev. 01 Jan. 20, 2020 Initial Issue TABLE OF CONTENTS 1 GENERAL INFORMATION .................................................................................................................... 5 1.1 Identification of the Testing Laboratory ..................................................................................... 5 1.2 Identification of the Responsible Testing Location .................................................................... 5 1.3 Test Environment Condition ..................................................................................................... 5 1.4 Announce ................................................................................................................................. 6 2 PRODUCT INFORMATION ................................................................................................................... 7 2.1 Applicant Information ................................................................................................................ 7 2.2 Manufacturer Information .......................................................................................................... 7 2.3 Factory Information ................................................................................................................... 7 2.4 General Description for Equipment under Test (EUT) ............................................................... 7 2.5 Ancillary Equipment .................................................................................................................. 7 2.6 Technical Information ............................................................................................................. 10 2.7 Power Reduction Description.................................................................................................. 12 3 SUMMARY OF TEST RESULT ........................................................................................................... 14 3.1 Test Standards ....................................................................................................................... 14 3.2 Device Category and SAR Limit ............................................................................................. 15 3.3 Test Result Summary ............................................................................................................. 16 3.4 Test Uncertainty ..................................................................................................................... 18 4 MEASUREMENT SYSTEM ................................................................................................................. 19 4.1 Specific Absorption Rate (SAR) Definition .............................................................................. 19 4.2 DASY SAR System ................................................................................................................ 20 5 SYSTEM VERIFICATION .................................................................................................................... 27 5.1 Purpose of System Check ...................................................................................................... 27 5.2 System Check Setup .............................................................................................................. 27 6 TEST POSITION CONFIGURATIONS ................................................................................................ 28 6.1 Head Exposure Conditions ..................................................................................................... 28 Report No.: BL-SZ19C0360-701 3 / 174 6.2 Body-worn Position Conditions ............................................................................................... 30 6.3 Hotspot Mode Exposure Position Conditions .......................................................................... 31 6.4 Product Specific 10g Exposure Consideration ........................................................................ 31 7 MEASUREMENT PROCEDURE ......................................................................................................... 32 7.1 Measurement Process Diagram ............................................................................................. 32 7.2 SAR Scan General Requirement ............................................................................................ 33 7.3 Measurement Procedure ........................................................................................................ 34 7.4 Area & Zoom Scan Procedure ................................................................................................ 34 8 CONDUCTED RF OUPUT POWER .................................................................................................... 35 8.1 GSM ....................................................................................................................................... 35 8.2 WCDMA ................................................................................................................................. 36 8.3 LTE ......................................................................................................................................... 37 8.4 WIFI ........................................................................................................................................ 45 8.5 Bluetooth ................................................................................................................................ 47 8.6 Power Reduction List .............................................................................................................. 48 9 TEST EXCLUSION CONSIDERATION ............................................................................................... 69 9.1 SAR Test Exclusion Consideration Table .............................................................…
