2AUYFRMX3741Mobile Phone with GSM, WCDMA, LTE, 5G NR, WiFi, Bluetooth and NFC

Realme Chongqing Mobile Telecommunications Corp., Ltd.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: May 13, 2023
Application Purpose: Original Equipment
Date of Application: May 11, 2023
Equipment Note: Mobile Phone with GSM, WCDMA, LTE, 5G NR, WiFi, Bluetooth and NFC
Frequency Range: 816.50000000 - 821.50000000
Company: Realme Chongqing Mobile Telecommunications Corp., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

This user manual provides the product safety information. Before using the phone, please read the Safety Guide carefully. Statement 'The Safety Guide' contains information regarding safety, operation and customer service. Before using the realme smartphone, please read all the instructions and the security information below, and keep it for backup. More detailed instructions are kept in this product as an electronic le. Please read the built-in instructions on the realme smartphone. For the latest information, please visit https://www.realme.com. Safety & security information Read all information before using the device to ensure safe and proper use. This mobile phone is suitable for working in an environment of 0°C to 35°C. Temperature for storage should be between -20°C and 45°C. Excessively high or low temperatures may damage the mobile phone or reduce the battery's lifespan. When charging, please keep the device in a well-ventilated area. Please charge this mobile phone in an environment between 5°C and 35°C. If the phone has a ash charging function, it may not be able to enter the ash charging mode when the temperature is below 15°C or over 35°C. Do not charge the battery over 12 hours. Do not replace, disassemble, modify, mechanically crush or cut the battery, as it may cause battery leakage, overheating, explosion or e. The adapter, as the disconnect device from the mains, shall be installed near the device and easily accessible. Use manufacturer-approved chargers, data cables, batteries and other accessories to prevent potential electric shock, re, explosion or other hazards. Back cover can't be removed. To prevent damage to your device's parts or internal circuits, do not use it in dusty, smoky, damp or dirty environments or near magnetic elds. Do not place the phone or battery directly in sunlight, near/inside sources of heat or in a low air pressure location, which may lead to an explosion or battery leakage. If any part of the product is cracked or damaged, discontinue use immediately and contact the realme Service Center. Power o your device in any area with a potentially explosive atmosphere, and comply with all signs and instructions. The battery can be charged and discharged hundreds of times at least, but it will eventually wear out. Precautions for using the device: Observe all safety instructions for any places, especially in hospital/health care facilities, service stations, schools, professional garages and in an aircraft. Do not use your device and adhere to all safety warnings/regulations regarding mobile device usage while driving. Persons with electronic implants (pacemakers, insulin pumps, neurostimulators, etc.) are recommended to place the mobile telephone 15 cm away from the implant or on the opposite side of the implant. To prevent hearing damage by high sound pressure, do not listen at high volume levels for long periods. Listening to a portable device at high volume may damage the user's ears and cause auditory disorders (temporary or permanent deafness, buzzing in the ears, tinnitus or hyperacusis). It is therefore strongly recommended not to use the portable device at full volume or more than one hour a day at medium volume. Recommendations for use: 1. No danger relating to the use of a mobile telephone has been observed and this is purely a preventive measure. The operating system of this product supports ocial system updates. If the user rooted the ROM system of any third party or modied the system le by cracking, it may lead to security risks of the system. realme will not provide any support nor take any responsibility for the nal use in these cases. To better understand how we protect your personal information, please see the privacy policy at realme ocial website. For more information, please check the User Guide on your device. All personal information may be removed during or after the product software upgrade. Please back up your personal information before upgrading. 2. To reduce the level of exposure to radiation, you should use the mobile telephone: A. In good reception conditions: when the signal indicator displays a full signal on the signal reception bar. B. With a hands-free kit or speaker. C. Giving priority to the use of data, SMS and MMS messages rather than calls. 3. Pregnant women should keep the mobile phone away from their abdomen and teenagers should keep the mobile phone away from their lower abdomen. 4. It is recommended to make reasonable use of the mobile phone by children and adolescents, for example by limiting the number of calls and their durations or by limiting the night use of the device. Do not leave your phone and its accessories within the reach of small children or allow them to play with it. They could hurt themselves or others, or may accidentally damage the phone. Your phone contains small parts with sharp edges that may cause an injury or which could become detached and create a choking hazard. Waste Electrical and Electronic Equipment (WEEE) realme Mobiles will seek shared responsibility and cooperation from customers in reducing the environmental impact of their products. realme Mobiles will comply with all the applicable laws related to WEEE management. This symbol (with or without a solid bar) means that according to local laws and regulations your product and/or its battery shall be disposed of separately from household waste. When this product reaches its end of life, user has the choice to give his product to a competent recycling organization. Proper recycling of your product will protect human health and the environment. FCC Regulatory Conformance FCC Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference; (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limi…

Text truncated - open the document above for the full version.

Attestation Statements

Rev1/26/2023 RealmeChongqingMobileTelecommunicationsCorp.,Ltd. No.178YulongAvenue,Yufengshan,YubeiDistrict,Chongqing,China FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:04-07-2023 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID: 2AUYFRMX3741 RealmeChongqingMobileTelecommunicationsCorp.,Ltd.certifiesthattheequipmentforwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceivinganequipment authorizationpursuanttosection2.903oftheFCCrules. Sincerely, ContactPerson: E-mail:[email protected] Rev1/26/2023 RealmeChongqingMobileTelecommunicationsCorp.,Ltd. No.178YulongAvenue,Yufengshan,YubeiDistrict,Chongqing,China FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:04-07-2023 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID:2AUYFRMX3741 RealmeChongqingMobileTelecommunicationsCorp.,Ltd.certifiesthat,asofthedateofthefilingof theapplication,theapplicantisnotidentifiedontheCoveredListasanentityproducing“covered” equipment. Sincerely, ContactPerson: E-mail:[email protected]

Attestation Statements

realme U.S. Agent Designation for Service of Process TO:Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Innopeak Technology, Inc. FRN ： 0033456872 Contact Name: Richard Wahng Physical U.S. address: 2479 E Bayshore Rd #120, Palo Alto, CA 94303 Email: [email protected] This letter is to confirm that weInnopeak Technology, Inc.have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of theApplicantnoted below. U.S. Agent Signature: Date:February 15, 2023 Signed by (Printed Name/Title):Richard Wahng /General Counsel The applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Realme Chongqing Mobile Telecommunications Corp., Ltd. Grantee Code: 2AUYF FRN: 0028939957 Contact Name: YangLiangping Address: No.178 Yulong Avenue, Yufengshan, Yubei District, Chongqing, P.R. China. Email: [email protected] Applicant Signature: Date: February 15, 2023 Signed by (Printed Name/Title): YangLiangping / Compliance Manager

Cover Letter(s)

RealmeChongqingMobileTelecommunicationsCorp.,Ltd. No.178YulongAvenue,Yufengshan,YubeiDistrict,Chongqing,China To:FederalCommunicationsCommission, Authorization&EvaluationDivision, 7435OaklandMillsRoad, Columbia,MD21046 RE: RealmeChongqingMobileTelecommunicationsCorp.,Ltd. FCCID: 2AUYFRMX3741 FCCCertificationConfidentialityRequest Gentlemen: Thisletteristocomplywith47CFR0.457and0.459pertainingtoconfidentialitymaterial. RealmeChongqingMobileTelecommunicationsCorp.,Ltd. requeststhatthefollowing documentsregardingthissubmissionforFCCID: 2AUYFRMX3741 bekeptLong-Term confidential: ExhibitTypeFileName BlockDiagramBlockDiagram.pdf SchematicsSchematics.pdf OperationalDescriptionOperationalDescription.pdf PartlistBOM.pdf Tune-Up-ProcedureTuneupprocedure.pdf Andbelowexhibitkeptshort-termconfidential(180days): ExhibitTypeFileName ExternalPhotos ExternalPhotos.pdf InternalPhotos InternalPhotos.pdf TestSetupPhotos TestSetupPhotos.pdf UsersManuals UsersManual.pdf Thosedocumentscontaindetailedsystemandequipmentdescriptionandrelated informationabouttheproductwhich RealmeChongqingMobileTelecommunicationsCorp.,Ltd. considerstobeconfidentialproprietary,acustomdesignand,otherwise,notreleasableto thegeneralpublic.Sincethisdesignisabasisformwhichfuturetechnologicalproductswill evolve, RealmeChongqingMobileTelecommunicationsCorp.,Ltd. considersthisinformation wouldbeofbenefittoitscompetitors,andthatthedisclosureoftheinformationinthese documentswouldgivecompetitorsanunfairadvantageinthemarket. Thankyouforyourattentiontothismatter. YoursSincerely,NameoftheManager: E-mail:[email protected] Date: 2023/04/07 Signature:

Cover Letter(s)

RealmeChongqingMobileTelecommunicationsCorp.,Ltd. No.178YulongAvenue,Yufengshan,YubeiDistrict,Chongqing,China Date:May5,2023 PowerofAttorney Towhomitmayconcern, PleasebenotifiedthatI,YangLiangping,havedesignatedSamuelPenginShenzhenBalun TechnologyCo.,Ltd.asthepersonbeingresponsibleforthisprojectandtosigntheform731and otherdocumentation. AnyandallactscarriedoutbySamuelPenginShenzhenBalunTechnologyCo.,Ltd.onthe mattersofrelatingtoallprocessesrequiredintheFCCapprovalandanycommunicationneeded withthenationalauthority,shallhavethesamelegalauthorityasactsonourownbehalf. Wefurthercertifiesthatneithertheapplicantnoranypartytothisapplication,asdefinedin47CFR Ch.1.2002(b),issubjecttoadenialtoFederalbenefits,thatincludeFCCbenefits,pursuantto section5301oftheAnti-DrugAbuseActof1998,21U.S.C862. Thisauthorizationislimitedtotheproductofasfollowing: FCCID:2AUYFRMX3741 Ifyouhaveanyacknowledgementandresponse,pleasesendittoShenzhenBalunTechnologyCo., Ltd.directly. Shouldyouhaveanyquestionsorcommentsregardingthismatter,pleasehavemybestattention. Sincerelyyours, ____ ContactPerson: E-mail:[email protected]

Cover Letter(s)

RealmeChongqingMobileTelecommunications Corp.,Ltd. No.178YulongAvenue,Yufengshan,YubeiDistrict,Chongqing,China Statement We,RealmeChongqingMobileTelecommunicationsCorp.,Ltd.,statesthatour device: FCCID:2AUYFRMX3741 ThehardwaresupportsLTEband40butitwillbedisabledbysoftwareandarenot availableinUSmarket. ContactPerson: E-mail:[email protected]

Cover Letter(s)

UNIIDeclarationLetter WehavedeclaredbelowfeaturedforFCCequipmentauthorization,deviceFCCID:2AUYFRMX3741, (1)DFSDevice-- Master,ClientwithRadardetectioncapability, Clientwithoutradardetectioncapability,N/A (2)Active/PassiveScanning,adhocmodeaccesspointcapability FrequencyBand (MHz) ActiveScanning (thedevicecan transmitaprobe (beacon)) passivescanning (wherethedevice is canlistenonly withno probes) AdHocMode capability Accesspoint capability 2412–2462MHz Yes,NoYes,NoYes,NoYes,No 5150–5250MHzYes,NoYes,NoYes,NoYes,No 5250–5350MHzYes,NoYes,NoYes,NoYes,No 5470–5725MHzYes,NoYes,NoYes,NoYes,No 5725–5850MHzYes,NoYes,NoYes,NoYes,No (3)Countrycodeselectionability-Yes,No Ifno,plsexplainhowwasimplemented:useMicrosoftnetworkutility (4)Meet15.202requirement- Yes,No, plscheckbelow: Amasterdeviceisdefinedasadeviceoperatinginamodeinwhichithasthecapabilityto transmitwithoutreceivinganenablingsignal.Inthismodeitisabletoselectachannelandinitiatea networkbysendingenablingsignalstootherdevices Aclientdeviceisdefinedasadeviceoperatinginamodeinwhichthetransmissionsofthedevice areundercontrolofthemaster.Adeviceinclientmodeisnotabletoinitiateanetwork. (5)Forclientdevicesthathavesoftwareconfigurationcontroltooperateindifferentmodes(active scanninginsomeandpassivescanninginothers)indifferentbands(deviceswithmultipleequipment classesorthosethatoperateonnon-DFSfrequencies)ormodulardeviceswhichconfigurethemodes ofoperationsthroughsoftware,theapplicationmustprovidesoftwareandoperationsdescriptionon howthesoftwareand/orhardwareisimplementedtoensurethatproperoperationsmodescannot bemodifiedbyenduseroraninstaller. Apply,NoApply, (Ifapply,plshelptoprovideexplanationonhowitwasimplement(Byhardwareorsoftware,andhowsoftwarewascontrolled) Theactiveorpassivemodewascontrolledbysoftware.Fornon-DFSfrequencyusedactivescanning,forDFSfrequencywas switchedtopassivescanningbysoftwareMechanism Ifyouhaveanyquestions,pleasefeelfreetocontactmeattheaddressshownbelow. Yourssincerely, Signatory ContactPerson: E-mail:[email protected]

External Photos

Report No.: BL-SZ2320162-AW 1 / 8 EUT EXTERNAL PHOTOS FRONT VIEW OF EUT (Plate Material) BACK VIEW OF EUT (Plate Material) Report No.: BL-SZ2320162-AW 2 / 8 LEFT SIDE VIEW OF EUT (Plate Material) RIGHT SIDE OF EUT (Plate Material) Report No.: BL-SZ2320162-AW 3 / 8 TOP VIEW OF EUT (Plate Material) BOTTOM VIEW OF EUT (Plate Material) Report No.: BL-SZ2320162-AW 4 / 8 FRONT VIEW OF EUT (Leather) BACK VIEW OF EUT (Leather) Report No.: BL-SZ2320162-AW 5 / 8 LEFT SIDE VIEW OF EUT (Leather) RIGHT SIDE OF EUT (Leather) Report No.: BL-SZ2320162-AW 6 / 8 TOP VIEW OF EUT (Leather) BOTTOM VIEW OF EUT (Leather) Report No.: BL-SZ2320162-AW 7 / 8 Accessory-Power Supply Unit 1 (VCBAJAUH US Plug) CLOSE-UP Report No.: BL-SZ2320162-AW 8 / 8 USB Cable Headset --BLANK BELOW--

ID Label/Location Info

Label Location Back To p Label IMEI2: xxxxxxxxxxxxxxxx IMEI1: xxxxxxxxxxxxxxxx S/N: xxxxxxxx Model: RMX3741 FCC ID: 2AUYFRMX3741 Mobile Phone Designed by realmeAssembled in China Realme Chongqing Mobile Telecommunications Corp., Ltd. IMEI2: xxxxxxxxxxxxxxxx IMEI1: xxxxxxxxxxxxxxxx S/N: xxxxxxxx Model: RMX3741 FCC ID: 2AUYFRMX3741 Mobile Phone Designed by realmeMade in China Realme Chongqing Mobile Telecommunications Corp., Ltd.

Internal Photos

Report No.: BL-SZ2320162-AI 1 / 7 EUT INTERNAL PHOTOS EUT UNCOVER VIEW EUT UNCOVER VIEW Antenna 1： GSM 850 WCDMA Band 5 LTE Band 5/12/13/17/26 SA n5 NSA n5 8 Antenna 0： GSM 850 WCDMA Band 5 LTE Band 5/12/13/17/26 SA n5 NSA n5 Antenna 3： GSM 1900 WCDMA Band 2/4 LTE Band 2/4/7/66/38/41 SA n7/38/41/66 NSA n7/41/66 Antenna 4： GSM 1900 WCDMA Band 2/4 LTE Band 2/4/7/66/38/41 SA n7/38/41/66 NSA n7/41/66 Antenna 7： 5G CH1 Antenna 8： WIFI2.4G CH0/BT Antenna 6： LTE：B4/B7/B38/B41/B66 DRX MIMO SA: N7/38/41/66 DRX MIMO SA: N77/78 PRX MIMO Antenna 2： WIFI2.4G CH1/5G CH0 Report No.: BL-SZ2320162-AI 2 / 7 EUT UNCOVER VIEW MAIN BOARD TOP VIEW (WITH SHIELDING) Report No.: BL-SZ2320162-AI 3 / 7 MAIN BOARD REAR VIEW (WITH SHIELDING) MAIN BOARD TOP VIEW (WITHOUT SHIELDING) Report No.: BL-SZ2320162-AI 4 / 7 MAIN BOARD REAR VIEW (WITHOUT SHIELDING) SUB BOARD TOP VIEW (WITH SHIELDING) Report No.: BL-SZ2320162-AI 5 / 7 SUB BOARD REAR VIEW (WITH SHIELDING) SUB BOARD TOP VIEW (WITHOUT SHIELDING) Report No.: BL-SZ2320162-AI 6 / 7 SUB BOARD REAR VIEW ((WITHOUT SHIELDING) Battery Photo (TOP) 0 Report No.: BL-SZ2320162-AI 7 / 7 Battery Photo (REAR) --BLANK BELOW--

RF Exposure Info

8 CONDUCTED RF OUPUT POWER 8.1 GSM Output Power 8.2 WCDMA Output Power 8.3 LTE Output Power 8.3.1 LTE Band2 Output Power 8.3.2 LTE Band4 Output Power 8.3.3 LTE Band5 Output Power 8.3.4 LTE Band7 Output Power 8.3.5 LTE Band12 Output Power 8.3.6 LTE Band13 Output Power 8.3.7 LTE Band17 Output Power 8.3.8 LTE Band26 Output Power 8.3.9 LTE Band66 Output Power 8.3.10 LTE Band38 Output Power 8.3.11 LTE Band41 Output Power 8.4 NR-SA Output Power 8.4.1 NR Band5 Output Power 8.4.2 NR Band7 Output Power 8.4.3 NR Band38 Output Power 8.4.4 NR Band40 Output Power 8.4.5 NR Band41 Output Power 8.4.6 NR Band66 Output Power 8.5 LTE-ENDC Output Power 8.5.1 LTE Band2 Output Power 8.5.2 LTE Band5 Output Power 8.5.3 LTE Band7 Output Power 8.5.4 LTE Band26 Output Power 8.5.5 LTE Band66 Output Power 8.6 NR-NSA Output Power 8.6.1 NR Band5 Output Power 8.6.2 NR Band7 Output Power 8.6.3 NR Band41 Output Power 8.6.4 NR Band66 Output Power BL-SZ2320162-701 1 8.1GSM Output Power GSM-Full Power-Ant.1&4 GSM850 Band Burst Average Power(dBm)Tune-up Power(dBm) Frame-Averaged power Tune-up Power(dBm） Channel128190251128190251 GSM (GMSK, 1-Slot) 32.70 32.58 32.49 33.50 23.51 23.39 23.30 24.31 GPRS (GMSK, 1-Slot) 32.64 32.52 32.43 33.50 23.45 23.33 23.24 24.31 GPRS (GMSK, 2-Slots) 31.94 31.77 31.65 32.00 25.81 25.64 25.52 25.87 GPRS (GMSK, 3-Slots) 29.95 30.19 29.85 30.50 25.53 25.77 25.43 26.08 GPRS (GMSK, 4-Slots) 28.98 28.93 28.78 29.00 25.80 25.75 25.60 25.82 EGPRS (8PSK, 1-Slot) 27.38 27.18 26.72 28.50 18.19 17.99 17.53 19.31 EGPRS (8PSK, 2-Slots) 25.71 25.70 25.53 26.50 19.58 19.57 19.40 20.37 EGPRS (8PSK, 3-Slots) 23.62 23.51 23.33 24.50 19.20 19.09 18.91 20.08 EGPRS (8PSK, 4-Slots) 22.42 22.25 22.17 23.50 19.24 19.07 18.99 20.32 GSM1900 Band Burst Average Power(dBm)Tune-up Power(dBm) Frame-Averaged Tune-up Power(dBm） Channel512661810512661810 GSM (GMSK, 1-Slot) 29.57 29.68 29.75 30.50 20.38 20.49 20.56 21.31 GPRS (GMSK, 1-Slot) 29.53 29.64 29.72 30.50 20.34 20.45 20.53 21.31 GPRS (GMSK, 2-Slots) 28.35 28.38 28.38 28.50 22.22 22.25 22.25 22.37 GPRS (GMSK, 3-Slots) 26.71 26.90 27.08 27.50 22.29 22.48 22.66 23.08 GPRS (GMSK, 4-Slots) 25.19 25.40 25.40 25.50 22.01 22.22 22.22 22.32 EGPRS (8PSK, 1-Slot) 26.44 26.35 26.39 28.00 17.25 17.16 17.20 18.81 EGPRS (8PSK, 2-Slots) 24.75 24.71 24.84 25.00 18.62 18.58 18.71 18.87 EGPRS (8PSK, 3-Slots) 22.72 22.68 22.71 23.00 18.30 18.26 18.29 18.58 EGPRS (8PSK, 4-Slots) 21.65 21.68 21.68 22.50 18.47 18.50 18.50 19.32 BL-SZ2320162-701 2 GSM-State1-Ant.1&4 GSM850 Band Burst Average Power(dBm)Tune-up Power(dBm) Frame-Averaged power Tune-up Power(dBm） Channel128190251128190251 GSM (GMSK, 1-Slot) 32.70 32.58 32.49 33.50 23.51 23.39 23.30 24.31 GPRS (GMSK, 1-Slot) 32.64 32.52 32.43 33.50 23.45 23.33 23.24 24.31 GPRS (GMSK, 2-Slots) 31.94 31.77 31.65 32.00 25.81 25.64 25.52 25.87 GPRS (GMSK, 3-Slots) 29.95 30.19 29.85 30.50 25.53 25.77 25.43 26.08 GPRS (GMSK, 4-Slots) 28.98 28.93 28.78 29.00 25.80 25.75 25.60 25.82 EGPRS (8PSK, 1-Slot) 27.38 27.18 26.72 28.50 18.19 17.99 17.53 19.31 EGPRS (8PSK, 2-Slots) 25.71 25.70 25.53 26.50 19.58 19.57 19.40 20.37 EGPRS (8PSK, 3-Slots) 23.62 23.51 23.33 24.50 19.20 19.09 18.91 20.08 EGPRS (8PSK, 4-Slots) 22.42 22.25 22.17 23.50 19.24 19.07 18.99 20.32 GSM1900 Band Burst Average Power(dBm)Tune-up Power(dBm) Frame-Averaged Tune-up Power(dBm） Channel512661810512661810 GSM (GMSK, 1-Slot) 27.49 27.66 27.85 29.00 18.30 18.47 18.66 19.81 GPRS (GMSK, 1-Slot) 27.46 27.64 27.81 29.00 18.27 18.45 18.62 19.81 GPRS (GMSK, 2-Slots) 26.45 26.65 26.82 27.00 20.32 20.52 20.69 20.87 GPRS (GMSK, 3-Slots) 24.76 24.98 25.21 26.00 20.34 20.56 20.79 21.58 GPRS (GMSK, 4-Slots) 23.72 23.95 23.87 24.00 20.54 20.77 20.69 20.82 EGPRS (8PSK, 1-Slot) 24.57 24.54 24.63 26.50 15.38 15.35 15.44 17.31 EGPRS (8PSK, 2-Slots) 23.11 22.67 22.78 23.50 16.98 16.54 16.65 17.37 EGPRS (8PSK, 3-Slots) 21.15 21.08 21.01 21.50 16.73 16.66 16.59 17.08 EGPRS (8PSK, 4-Slots) 19.90 19.83 19.86 21.00 16.72 16.65 16.68 17.82 BL-SZ2320162-701 3 GSM-State2&4-Ant.1&4 GSM850 Band Burst Average Power(dBm)Tune-up Power(dBm) Frame-Averaged power Tune-up Power(dBm） Channel128190251128190251 GSM (GMSK, 1-Slot) 32.70 32.58 32.49 33.50 23.51 23.39 23.30 24.31 GPRS (GMSK, 1-Slot) 32.64 32.52 32.43 33.50 23.45 23.33 23.24 24.31 GPRS (GMSK, 2-Slots) 31.94 31.77 31.65 32.00 25.81 25.64 25.52 25.87 GPRS (GMSK, 3-Slots) 29.95 30.19 29.85 30.50 25.53 25.77 25.43 26.08 GPRS (GMSK, 4-Slots) 28.98 28.93 28.78 29.00 25.80 25.75 25.60 25.82 EGPRS (8PSK, 1-Slot) 27.38 27.18 26.72 28.50 18.19 17.99 17.53 19.31 EGPRS (8PSK, 2-Slots) 25.71 25.70 25.53 26.50 19.58 19.57 19.40 20.37 EGPRS (8PSK, 3-Slots) 23.62 23.51 23.33 24.50 19.20 19.09 18.91 20.08 EGPRS (8PSK, 4-Slots) 22.42 22.25 22.17 23.50 19.24 19.07 18.99 20.32 GSM1900 Band Burst Average Power(dBm)Tune-up Power(dBm) Frame-Averaged Tune-up Power(dBm） Channel512661810512661810 GSM (GMSK, 1-Slot) 23.92 24.14 24.37 25.50 14.73 14.95 15.18 16.31 GPRS (GMSK, 1-Slot) 23.90 24.12 24.37 25.50 14.71 14.93 15.18 16.31 GPRS (GMSK, 2-Slots) 22.89 23.09 23.31 23.50 16.76 16.96 17.18 17.37 GPRS (GMSK, 3-Slots) 21.28 21.49 21.74 22.50 16.86 17.07 17.32 18.08 GPRS (GMSK, 4-Slots) 20.30 20.18 20.45 20.50 17.12 17.00 17.27 17.32 EGPRS (8PSK, 1-Slot) 21.15 21.21 21.12 23.00 11.96 12.02 11.93 13.81 EGPRS (8PSK, 2-Slots) 19.76 19.44 19.09 20.00 13.63 13.31 12.96 13.87 EGPRS (8PSK, 3-Slots) 17.51 17.53 17.42 18.00 13.09 13.11 13.00 13.58 EGPRS (8PSK, 4-Slots) 16.48 16.46 16.40 17.50 13.30 13.28 13.22 14.32 BL-SZ2320162-701 4 GSM-State3&5-Ant.1&4 GSM850 Band Burst Average Power(dBm)Tune-up Power(dBm) Frame-Averaged power Tune-up Power(dBm） Channel128190251128190251 GSM (GMSK, 1-Slot) 32.70 32.58 32.49 33.50 23.51 23.39 23.30 24.31 GPRS (GMSK, 1-Slot) 32.64 32.52 32.43 33.50 23.45 23.33 23.24 24.31 GPRS (GMSK, 2-Slots) 31.94 31.77 31.65 32.00 25.81 25.64 25.52 25.87 GPRS (GMSK, 3-Slots) 29.95 30.19 29.85 30.50 25.53 25.77 25.43 26.08 GPRS (GMSK, 4-Slots) 28.98 28.93 28.78 29.00 25.80 25.75 25.60 …

Text truncated - open the document above for the full version.

RF Exposure Info

Report No.: BL-SZ2320162-701 Tel: +86-755-66850100 E-mail: [email protected] Page No. 1 / 551 Web: www.titcgroup.com Template No.: TRP-FCC DASY-Body-2 (2023-01-30) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China TEST REPORT Applicant: Realme Chongqing Mobile Telecommunications Corp., Ltd. Address: No.178 Yulong Avenue, Yufengshan, Yubei District, Chongqing, China Equipment Type: Mobile Phone Model Name: RMX3741 Brand Name: realme FCC ID: 2AUYFRMX3741 Test Standard: FCC 47 CFR Part 2.1093 (refer section 3.1) Maximum SAR: Head (1 g@0mm): 1.08 W/kg Body-worn (1 g@15mm): 0.33 W/kg Hotspot (1 g@10mm): 0.96 W/kg Specific (10 g@0mm): 2.37 W/kg Sample Arrival Date: Feb. 28, 2023 Test Date: Mar. 02, 2023 - Apr. 16, 2023 Date of Issue: May 11, 2023 ISSUED BY: Shenzhen BALUN Technology Co., Ltd. Tested by: Ruan Zhaoyi Checked by: Xu Rui Approved by: Tolan Tu (Testing Director) _______________ _______________ _______________ Report No.: BL-SZ2320162-701 Tel: +86-755-66850100 E-mail: [email protected] Page No. 2 / 551 Web: www.titcgroup.com Template No.: TRP-FCC DASY-Body-2 (2023-01-30) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Revision History Version Issue Date Revisions Content Rev. 01 May 08, 2023 Initial Issue Rev. 02 May 11, 2023 Add 7C, 38C, 41C data in section 11.25 – 11.27. TABLE OF CONTENTS 1 GENERAL INFORMATION ........................................................................................................ 5 1.1 Test Laboratory ............................................................................................................ 5 1.2 Test Location ................................................................................................................ 5 1.3 Test Environment Condition .......................................................................................... 5 2 PRODUCT INFORMATION ....................................................................................................... 6 2.1 Applicant Information .................................................................................................... 6 2.2 Manufacturer Information .............................................................................................. 6 2.3 Factory Information ....................................................................................................... 6 2.4 General Description for Equipment under Test (EUT) ................................................... 6 2.5 Ancillary Equipment ...................................................................................................... 7 2.6 Technical Information ................................................................................................... 8 3 SUMMARY OF TEST RESULT ............................................................................................... 10 3.1 Test Standards ........................................................................................................... 10 3.2 Device Category and SAR Limit ................................................................................. 11 3.3 Test Result Summary ................................................................................................. 12 3.4 Test Uncertainty ......................................................................................................... 14 4 MEASUREMENT SYSTEM ..................................................................................................... 15 4.1 Specific Absorption Rate (SAR) Definition .................................................................. 15 4.2 DASY SAR System .................................................................................................... 16 5 SYSTEM VERIFICATION ........................................................................................................ 23 5.1 Purpose of System Check .......................................................................................... 23 5.2 System Check Setup .................................................................................................. 23 6 TEST POSITION CONFIGURATIONS .................................................................................... 24 6.1 Head Exposure Conditions ......................................................................................... 24 6.2 Body-worn Position Conditions ................................................................................... 26 Report No.: BL-SZ2320162-701 Tel: +86-755-66850100 E-mail: [email protected] Page No. 3 / 551 Web: www.titcgroup.com Template No.: TRP-FCC DASY-Body-2 (2023-01-30) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 6.3 Hotspot Mode Exposure Position Conditions .............................................................. 27 6.4 Product Specific 10g Exposure Consideration ............................................................ 28 7 MEASUREMENT PROCEDURE ............................................................................................. 29 7.1 Measurement Process Diagram ................................................................................. 29 7.2 SAR Scan General Requirement ................................................................................ 30 7.3 Measurement Procedure ............................................................................................ 31 7.4 Area & Zoom Scan Procedure .................................................................................... 31 8 UL duty cycle detection mechanism specification .................................................................... 32 8.1 General description of UL duty cycle detection mechanism. ....................................... 32 8.2 UL duty cycle detection mechanism clarifications ....…

Text truncated - open the document above for the full version.

RF Exposure Info

Report No.: BL-SZ2320162-701 Tel: +86-755-66850100 E-mail: [email protected] Page No. 321 / 551 Web: www.titcgroup.com Template No.: TRP-FCC DASY-Body-2 (2023-01-30) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Report No.: BL-SZ2320162-701 Tel: +86-755-66850100 E-mail: [email protected] Page No. 322 / 551 Web: www.titcgroup.com Template No.: TRP-FCC DASY-Body-2 (2023-01-30) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China System Performance Check Data (1900MHz) Device under Test Properties Model, Manufacturer Dimensions [mm] DUT Type D1900V2, SPEAG 10.0 x 10.0 x 3.0 Dipole Exposure Conditions Phanto m Section , TSL Positio n, Test Distanc e [mm] Band Grou p, UID Frequen cy [MHz], Channel Number Conversi on Factor TSL Conductivi ty [S/m] TSL Permittivi ty Ambient Temperatu re [°C] Liquid Temperatu re [°C] Flat, HSL D190 0 CW, 0-- 1900.0, 50 8.40 1.39 40.3 21.8 20.9 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V5.0 (30deg probe tilt) - 1859 HBBL-600-10000 2023-03- 14 EX3DV4 - SN7607, 2022-07- 04 DAE4 Sn878, 2022-06- 13 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 80.0 x 80.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 10.0 x 10.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Graded Grid Yes Yes Grading Ratio 1.5 1.5 MAIA N/A N/A Surface Detection VMS + 6p VMS + 6p Scan Method Measured Measured Measurement Results Area Scan Zoom Scan Date 2023-03-14 2023-03-14 psSAR1g [W/kg] 4.21 4.07 psSAR10g [W/kg] 2.24 2.11 Power Drift [dB] -0.16 -0.03 Power Scaling Disabled Disabled Scaling Factor [dB] TSL Correction No correction No correction M2/M1 [%] 81.6 Dist 3dB Peak [mm] 9.6 Report No.: BL-SZ2320162-701 Tel: +86-755-66850100 E-mail: [email protected] Page No. 323 / 551 Web: www.titcgroup.com Template No.: TRP-FCC DASY-Body-2 (2023-01-30) Add: Block B, 1/F, Baisha Science and Technology Park, S…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Mega Huang(Manager)

[email protected]18502096102Fax: 86 76986076999

Test Firm

Shenzhen BALUN Technology Co., Ltd.Hanson Lin

[email protected]86-755-66833830

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
68	9	816.5 MHz - 821.5 MHz	53.00 mW	4M50W7D	2.5 Hz

Confidentiality

Long Term

Grant Notes

Output power listed are maximum ERP for GSM 850, WCDMA Band 5, LTE Band 5/12/13/17/26, and 5G NR Band n5. Output power listed are maximum EIRP for PCS1900, WCDMA Band 2/4, LTE Band 2/4/7/38/41/66, and 5G NR Band n7/n38/n41/n66. It supports GSM, WCDMA, LTE (QPSK, 16QAM, 64QAM) and 5G NR Standalone and Non-standalone (CP-OFDM QPSK, 16QAM, 64QAM, 256QAM and DFT-s-OFDM BPSK, QPSK, 16QAM, 64QAM, 256QAM) LTE B2, B4, B5, B7, B12, B13, B17, B26, B38, B41, B66, 5G NR n5, n7, n38, n41, n66 Channel Bandwidth (5/10 MHz) for LTE B13, B17, Channel Bandwidth (1.4/3/5/10 MHz) for LTE B5, B12, Channel Bandwidth (1.4/3/5/10/15 MHz) for LTE B26, Channel Bandwidth (1.4/3/5/10/15/20 MHz) for LTE B2, B4, B66, Channel Bandwidth (5/10/15/20 MHz) for LTE B7, B38, B41; 5GNR n5, n7, n66, Channel Bandwidth (10/15/20 MHz) for 5GNR n38 Channel Bandwidth (20/40/50/60/80/90/100 MHz) for 5G NR n41; EUT supports Uplink Intra-band contiguous carrier aggregation CA_7C, CA_38C, CA_41C. 5G NR ENDC: DC_2A_n66A, DC_5A_n7A, DC_5A_n66A, DC_7A_n5A, DC_7_n66A, DC_26A_n41A, DC_66A_n5A, DC_66A_n7A; This device contains functions that are not operational in U.S. Territories; this filing is only applicable for U.S. operations. This device has integrated DXX, DSS, DTS, NII and PCE transmitters certified under the same FCC ID. SAR compliance for body-worn operating configurations is limited to the belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 15 mm separation between the device and the user's body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR values for head, body-worn accessory, hotspot and simultaneous transmission use conditions are 1.03 W/kg, 0.33 W/kg, 0.96 W/kg and 1.59 W/kg, respectively.
