2AUYX-P3MINI4G Bonding Encoder

P3 mini 4G Bonding Video Encoder 4G+ H.265 Bonding Video Encoder （V1.0） Trailblazers in AV over IP Quick Start Guide The Kiloview P3 mini is a new generation wireless bonded encoder developed by Kiloview based on Kilolink transmission technology. It supports multiple simultaneous wireless bonding connections, including 3x 4G cellular networks, WiFi (2.4G/5G dual-band), and Gigabit Ethernet. The device supports PD and DC charging and can be powered by a power bank through the TYPE-C port, ensuring round-the-clock operation. The P3mini uses H.265/H.264 encoding technology, equipped with dual interface inputs of 3G-SDI and HDMI, and supports resolutions up to 1080p60. When used with the KiloLink Server Pro software, it provides remote management and all-protocol streaming forwarding services, and supports cross-Internet voice intercom functionality, fully meeting various application needs. Contents ◼ Packing List ◼ Device interfaces ◼ Device installation ◼ Device connection, login and use guide ◼ Device upgrade and restore factory setting Before you start using this product, it is recommended that you carefully read the user manual. To ensure your personal safety and to avoid physical or electrical damage to the device, please strictly follow the guidance in this manual or install and use the product under the supervision of a professional. Incorrect electrical connections or physical installation may cause permanent damage to the device and even pose a threat to personal safety. P3 5G Wireless Bonding Encoder.USER MANUAL 1 1 Packing List (1) P3 mini Encoder ×1 (2) Wi-Fi antenna ×1 (3) 4G antenna ×3 (4) Power bank Bracket x1 (5) Cold boot screw x1 (6) Power Adapter x1 (7) Bracket screw mount x1 (8) Warranty Card ×1 (9) Quick Start Guide ×1 [文档标题] 2 Device Interface (1) Wi-Fi SMA Interface (2) USB TYPE-A (3) HDMI Input (4) SDI Input (5) Power Port (6) 3.5mm LINE IN (7) USB TYPE-C（PD charging supported） (8) USB TYPE-A (9) 1000M Ethernet (10) Quick Stream Switch (11) Power Switch (12) SIM card slot (13) 4G SMA Interface (14) 4G SMA Interface (15) SIM card slot (16) SIM card slot (17) 4G SMA Interface (18) 1/4 inch screw mount 3 Battery indicator light After the battery is installed, the P3 mini battery indicator light can help users understand the current device power usage. The colors of the indicator light correspond to different states are as follows: Indicator light Explanation The device has five indicator lights, labeled as LOW, 25%, 50%, 75%, and 100%. Each light indicates the current battery level. When the battery level drops below 25%, the LOW light will illuminate with a red warning to indicate low battery. When the battery level is between 25% and 100%, the corresponding indicator light for that battery level range will stay on. During charging, the lights corresponding to the battery levels will flash according to the charging progress. When all the battery level indicators are constantly on, it means the battery is fully charged. [文档标题] 4 Device installation The P3 mini supports simultaneous multi-path wireless bonding connections, including 3 channels of 4G cellular network, Wi-Fi (2.4G/5G dual-band), and Gigabit Ethernet. It also supports PD charging, allowing it to be powered by a portable power bank for round-the-clock operation.Before using the multi-bonding feature of the P3mini device, ensure that SIM cards, antennas, and other external accessories are correctly installed. The specific installation method is as follows: 4.1 Installation of 4G SIM Card To use the 4G feature of the P3 mini, a Nano-SIM card must be installed. The installation procedure is as follows: The three Nano-SIM card slots shown in the left image can be used for installing SIM cards. The installation steps are as follows: As shown in the left image, align the notch on the SIM card with the slot where it will be inserted. Push the SIM card all the way in to ensure it is securely fixed in the slot. After installation, insert the SIM card and wait for about 1 minute. The device will automatically detect the signal from the inserted slot. If the signal is normal, it indicates that the SIM card has been successfully installed. Remove the SIM card: Please use a pin as shown in the left image to gently push the SIM card inward until it pops out, then you can remove it. [文档标题] 4.2 Antennas Installation The P3 mini requires antennas for the 3 channels of 4G cellular network and Wi-Fi. The installation procedure is as follows: The P3 mini has two types of external antennas: the Wi-Fi antenna and the 4G antenna. The installation method is as follows: As shown in the left image, align the SMA connector of the antenna with the corresponding antenna port on the device. Screw in the antenna securely to ensure it is firmly connected. Note: The Wi-Fi antenna and 4G antenna should not be interchanged. Mixing them can cause abnormal antenna signals. Please carefully check the markings on the antennas when connecting them to ensure proper installation. Note ⚫ Please use the device’s standard power adapter or a compliant PD charger to power the device. Other non-standard power sources may damage the device. ⚫ Ensure that the Wi-Fi antenna and 4G antenna ports are not confused. Incorrectly installing the antennas can significantly affect the device's signal quality and performance. 5 5 Viewing the Device's IP Address On the LCD screen, you can easily view the device's IP address. Click "Settings" on the main interface of the LCD screen and then click "Network" to view the corresponding IP address of the current network connection. Login to the device management page In addition to using the LCD display to quickly set up and operate the device, this device also supports operating and managing the device through the WEB management system. If you need to log in to the device management page, just open the web browser and enter: http://device IP address/ in the address bar to access the device management system. Note ⚫ The user…

Text truncated - open the document above for the full version.

JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 1 of 5 EUT External Photos JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 5 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 5 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 4 of 5 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 5 of 5 ------End------

JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 1 of 7 EUT Internal Photos JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 7 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 7 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 4 of 7 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 5 of 7 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 6 of 7 JianYan Testing Group Shenzhen Co., Ltd. JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 7 of 7 ------End------

JianYan Testing Group Shenzhen Co., Ltd. Report No.: JYTSZ-R12-2400927 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in above the application standard version. Test results reported herein relate only to the item(s) tested. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. Cover Page RF Exposure Evaluation Report Report No.: JYTSZ-R12-2400927 Applicant: ChangSha Kiloview Electronics Co., Ltd. Address of Applicant: B4-106/109, Jiahua Intelligence Valley Industrial Park, 877 Huijin Road, Yuhua District, Changsha, China Equipment Under Test (EUT) Product Name: 4G Bonding Encoder Model No.: P3 mini Trade mark: KILOVIEW FCC ID: 2AUYX-P3MINI Applicable standards: FCC CFR Title 47 Part 2 (§2.1091) Date of sample receipt: 08 Aug., 2024 Date of Test: 09 Aug., to 26 Aug., 2024 Date of report issue: 27 Aug., 2024 Test Result: PASS Project by: Date: 27 Aug., 2024 Project Engineer Reviewed by: Date: 27 Aug., 2024 Senior Engineer Approved by: Date: 27 Aug., 2024 Manager Report No.: JYTSZ-R12-2400927 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-177-C Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 8 Version 1 Version No. Date Description 00 27 Aug., 2024 Original Report No.: JYTSZ-R12-2400927 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-177-C Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 8 Contents 2 Page Cover Page ............................................................................................................................................................. 1 Version ........................................................................................................................................................... 2 1 Contents ......................................................................................................................................................... 3 2 General Information ...................................................................................................................................... 4 3 Client Information ................................................................................................................................... 4 3.1 General Description of E.U.T. ................................................................................................................ 4 3.2 Operating Modes .................................................................................................................................... 5 3.3 Additions to, deviations, or exclusions from the method ........................................................................ 5 3.4 Laboratory Facility .................................................................................................................................. 6 3.5 Laboratory Location ................................................................................................................................ 6 3.6 Technical Requirements Specification ....................................................................................................... 7 4 Limits ...................................................................................................................................................... 7 4.1 Test Procedure ....................................................................................................................................... 7 4.2 Result ..................................................................................................................................................... 8 4.3 Conclusion .............................................................................................................................................. 8 4.4 Report No.: JYTSZ-R12-2400927 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-177-C Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 4 of 8 General Information 3 Client Information 3.1 Applicant: ChangSha Kiloview Electronics Co., Ltd. Address: B4-106/109, Jiahua Intelligence Valley Industrial Park, 877 Huijin Road, Yuhua District, Changsha, China Manufacturer: ChangSha Kiloview Electronics Co., Ltd. Address: B4-106/109, Jiahua Intelligence Valley Industrial Park, 877 Huijin Road, Yuhua District, Changsha, China Factory: ChangSha Kiloview Electronics Co., Ltd. Address: B4-106/109, Jiahua Intelligence Valley Industrial Park, 877 Huijin Road, Yuhua District, Changsha, China General Description of E.U.T. 3.2 Product Name: 4G Bonding Encoder Model No.: P3 mini Test Sample Condition: The test samples were provided in good working order with no visible defects. 2.4GWi-Fi Specification Operation Frequency: 2412 MHz - 2462 MHz (802.11b, g, n-HT20) Channel Numbers: 11 (802.11b, g, n-HT20) Channel Separation: 5MHz Modulation Technology: (IEEE 802.11b) DSSS-DBPSK, DQPSK, CCK Modulation Technology: (IEEE 802.11g/n/…

Text truncated - open the document above for the full version.

JianYan Testing Group Shenzhen Co., Ltd. Report No.: JYTSZ-R12-2400924 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in above the application standard version. Test results reported herein relate only to the item(s) tested. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. Cover Page FCC RF Test Report (2.4G Wi-Fi) Report No.: JYTSZ-R12-2400924 Applicant: ChangSha Kiloview Electronics Co., Ltd. Address of Applicant: B4-106/109, Jiahua Intelligence Valley Industrial Park, 877 Huijin Road, Yuhua District, Changsha, China Equipment Under Test (EUT) Product Name: 4G Bonding Encoder Model No.: P3 mini Trade Mark: KILOVIEW FCC ID: 2AUYX-P3MINI Applicable Standards: FCC CFR Title 47 Part 15C (§15.247) Date of Sample Receipt: 08 Aug., 2024 Date of Test: 09 Aug., to 26 Aug., 2024 Date of Report Issued: 27 Aug., 2024 Test Result: PASS Project by: Date: 27 Aug., 2024 Project Engineer Reviewed by: Date: 27 Aug., 2024 Senior Engineer Approved by: Date: 27 Aug., 2024 Manager Report No.: JYTSZ-R12-2400924 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-145-C1 Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 33 Version 1 Version No. Date Description 00 27 Aug., 2024 Original Report No.: JYTSZ-R12-2400924 JianYan Testing Group Shenzhen Co., Ltd. Report Template No.: JYTSZ4b-145-C1 Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 33 Contents 2 Page Cover Page ............................................................................................................................................................. 1 Version ........................................................................................................................................................... 2 1 Contents ......................................................................................................................................................... 3 2 General Information ...................................................................................................................................... 4 3 Client Information ................................................................................................................................... 4 3.1 General Description of E.U.T. ................................................................................................................ 4 3.2 Test Mode and Environment .................................................................................................................. 5 3.3 Description of Test Auxiliary Equipment ................................................................................................ 5 3.4 Measurement Uncertainty ...................................................................................................................... 5 3.5 Additions to, Deviations, or Exclusions from the Method ....................................................................... 5 3.6 Laboratory Facility .................................................................................................................................. 6 3.7 Laboratory Location ................................................................................................................................ 6 3.8 Test Instruments List .............................................................................................................................. 6 3.9 Measurement Setup and Procedure ........................................................................................................... 9 4 Test Channel .......................................................................................................................................... 9 4.1 Test Setup .............................................................................................................................................. 9 4.2 Test Procedure ..................................................................................................................................... 11 4.3 Test Results ................................................................................................................................................. 12 5 Summary .............................................................................................................................................. 12 5.1 Clause and Data Summary .............................................................................................................. 12 5.1.1 Test Limit .......................................................................................................................................... 13 5.1.2 Antenna Requirement .......................................................................................................................... 14 5.2 AC Power Line Conducted Emission ................................................................................................... 15 5.3 Emissions in Restricted Frequency Bands ........................................................................................... 17 5.4 Emissio…

Text truncated - open the document above for the full version.

Report No.: JYTSZ-R12-2400924 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 1 of 42 Test Data Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) NVNT b 2412 Ant1 97.57 0.11 NVNT b 2437 Ant1 97.61 0.11 NVNT b 2462 Ant1 97.6 0.11 NVNT g 2412 Ant1 87.33 0.59 NVNT g 2437 Ant1 86.37 0.64 NVNT g 2462 Ant1 86.18 0.65 NVNT n20 2412 Ant1 85.45 0.68 NVNT n20 2437 Ant1 85.61 0.67 NVNT n20 2462 Ant1 85.44 0.68 Report No.: JYTSZ-R12-2400924 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 42 Test Graphs Duty Cycle NVNT b 2412MHz Ant1 Duty Cycle NVNT b 2437MHz Ant1 Duty Cycle NVNT b 2462MHz Ant1 Report No.: JYTSZ-R12-2400924 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 42 Duty Cycle NVNT g 2412MHz Ant1 Duty Cycle NVNT g 2437MHz Ant1 Report No.: JYTSZ-R12-2400924 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 4 of 42 Duty Cycle NVNT g 2462MHz Ant1 Duty Cycle NVNT n20 2412MHz Ant1 Report No.: JYTSZ-R12-2400924 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 5 of 42 Duty Cycle NVNT n20 2437MHz Ant1 Duty Cycle NVNT n20 2462MHz Ant1 Report No.: JYTSZ-R12-2400924 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 6 of 42 Report No.: JYTSZ-R12-2400924 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 7 of 42 Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT b 2412 Ant1 15.02 0 15.02 30 Pass NVNT b 2437 Ant1 14.59 0.11 14.7 30 Pass NVNT b 2462 Ant1 14.25 0.11 14.36 30 Pass NVNT g 2412 Ant1 14.4 0.59 14.99 30 Pass NVNT g 2437 Ant1 14.02 0.64 14.66 30 Pass NVNT g 2462 Ant1 13.67 0.65 14.32 30 Pass NVNT n20 2412 Ant1 13.54 0.68 14.22 30 Pass NVNT n20 2437 Ant1 13.1 0.67 13.77 30 Pass NVNT n20 2462 Ant1 12.85 0.68 13.53 30 Pass Report No.: JYTSZ-R12-2400924 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 8 of 42 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) limit Verdic NVNT b 2412 Ant1 8.409 0.5 Pass NVNT b 2437 Ant1 8.479 0.5 Pass NVNT b 2462 Ant1 8.414 0.5 Pass NVNT g 2412 Ant1 16.424 0.5 Pass NVNT g 2437 Ant1 16.427 0.5 Pass NVNT g 2462 Ant1 16.415 0.5 Pass NVNT n20 2412 Ant1 17.701 0.5 Pass NVNT n20 2437 Ant1 17.667 0.5 Pass NVNT n20 2462 Ant1 17.705 0.5 Pass Report No.: JYTSZ-R12-2400924 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 9 of 42 Test Graphs -6dB Bandwidth NVNT b 2412MHz Ant1 -6dB Bandwidth NVNT b 2437MHz Ant1 -6dB Bandwidth NVNT b 2462MHz Ant1 Report No.: JYTSZ-R12-2400924 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 10 of 42 -6dB Bandwidth NVNT g 2412MHz Ant1 -6dB Bandwidth NVNT g 2437MHz Ant1 Report No.: JYTSZ-R12-2400924 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 11 of 42 -6dB Bandwidth NVNT g 2462MHz Ant1 -6dB Bandwidth NVNT n20 2412MHz Ant1 Report No.: JYTSZ-R12-2400924 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, People's Republic of China. Tel: +86-755-23118282, Fax: +86-755-23116366 Page 12 of 42 -6dB Bandwidth NVNT n20 2437MHz Ant1 -6dB Bandwidth NVNT n20 2462MHz Ant1 Report No.: JYTSZ-R12-2400924 JianYan Testing Group Shenzhen Co., Ltd. Project No.: JYTSZR2408021 No.101, Building 8, Innovation Wisdom Port, No.155 Hongtian Road, Huangpu Community, Xinqiao Street, Bao'an District, Shenzh…

Text truncated - open the document above for the full version.

Tengxiang Technology.Inc Product Number: AN2450-15BC11SM-B Product Name: Antenna File No.: 201121001 Version: 1.0 Date: 2020.11.21 Specification For Approval Customer： Customer P/N： Tengxiang P/N：AN2450-15BC11SM-B Description : 2.4/5G ANTENNA BLACK Tengxiang Checked By: Customer Approved By: 工程：HC 射频：韦佳 工程课 Tengxiang Technology.Inc NO.53 Shatou ShaChong Road, ChangAn Town, Guangdong province, China TEL:86-769-81873082 FAX:86-769-82663788 http://www.tenxiang.cn Tengxiang Technology.Inc Product Number: AN2450-15BC11SM-B Product Name: Antenna Page 1 Version: 1.0 Issue Date: 2020.11.21 1. Specification Sample Photo A. Electrical Characteristics Frequency 2400-2500 / 5150-5850 MHz V.S.W.R. <= 2.0 Antenna Gain 4.54dBi Polarization Linear Impedance 50 Ohm B. Material & Mechanical Characteristics Material of Radiator PCB Material of Plastic ABS / POM Cable Type RG178 Connector Type SMA Plug C. Environmental Operation Temperature - 40 ̊C ~ + 80 ̊C Storage Temperature - 40 ̊C ~ + 80 ̊C 2. Characteristics and Reliability Test Test Items Test Condition and Procedure Requirements C1 V.S.W.R. Set DUT on Network Analyzer; make individual calibration to test Directive DUT specification Tengxiang Technology.Inc Product Number: AN2450-15BC11SM-B Product Name: Antenna Page 2 Version: 1.0 Issue Date: 2020.11.21 C2 Antenna Gain Set DUT on Antenna Chamber; make individual calibration to test Directive DUT specification M1 Vibration MIL-STD-202G, 201A Amplitude: 0.03 inch (0.76mm); Freq: 10 to 55 Hz 3 directions; 2 hours for each direction 1. No Visual Damage 2. Frequency Tol.<= 5% M2 Random Drop Height: 1.5 Meter; 3 directions; 1 time for each direction 1. No parts separated 2. Frequency Tol.<= 5% M3 Solderability MIL-STD-202G, 210F, cond. A Solder iron: 350±10°C; Duration: 5 seconds 1. Mounted on PCB 2. No Visual Damage M4 Terminal- Pull Test MIL-STD-202G, 211A, cond. A Holding with individual specification; force applied…

Text truncated - open the document above for the full version.
