2AUZW-6C101-Channel 4-20mA/1-5V Interface Node

Wuxi Wisen Innovation Co., Ltd.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Apr 29, 2026
Application Purpose: Original Equipment
Equipment Note: 1-Channel 4-20mA/1-5V Interface Node
Frequency Range: 905.00000000 - 925.00000000
Company: Wuxi Wisen Innovation Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Wisen Innovation Technical Doc. No.2026 WiSenMeshWAN® 1-Channel 4-20mA/1-5V Interface Node - User Manual www.wisencn.com Page - 1 - of 14 WisenMeshWAN® 1-Channel 4-20mA/1-5V Interface Node User Manual 6C10 Wuxi Wisen Innovation Co., Ltd. April 2026 Wisen Innovation Technical Doc. No.2026 WiSenMeshWAN® 1-Channel 4-20mA/1-5V Interface Node - User Manual www.wisencn.com Page - 2 - of 14 Revision History and Clarification Rev. Issue Date Revisions Written By Revised By V1.0 10/04/2026 1st issue Xinhu Nie Dr. Yan Wu Document Definition: It defines the specifications (i.e., introduction, technical features, deployment and maintenance methods) of the WiSenMeshWAN® 1-Channel 4-20mA/1-5V Interface Node, which is one of the key components in WiSenMeshWAN® Low Power, Intelligent, Wireless Sensor Network (WSN) system. It is responsible to:  Sample data from 4-20mA or 1-5V analogue sensors, such as displacement, soil moisture, temperature, etc.;  Form a time-synchronised W ireless Sensor Network with other nodes in the system;  Transmit the data packet to a gateway. Scope： Customer Site Project Managers and Engineers, W isen Service Engineers, etc. Wisen Innovation Technical Doc. No.2026 WiSenMeshWAN® 1-Channel 4-20mA/1-5V Interface Node - User Manual www.wisencn.com Page - 3 - of 14 Table of Contents 1. Product Introduction ..............................................................................................................................................- 4 - 2. System Structure Layout .........................................................................................................................................- 5 - 3. Node & Radio Features ...........................................................................................................................................- 6 - 4. Terminologies .........................................................................................................................................................- 8 - 5. Operation Procedures .............................................................................................................................................- 8 - 5.1．System Deployment Notifications ..............................................................................................................- 8 - 5.2．Deployment Procedures .............................................................................................................................- 9 - 5.3．Mounting Options .................................................................................................................................... - 11 - 6. General Maintenance and Notification ................................................................................................................. - 11 - 7. Package and Accessories ....................................................................................................................................... - 12 - 8. Safety and Warning............................................................................................................................................... - 13 - 9. Contact ................................................................................................................................................................. - 14 - Wisen Innovation Technical Doc. No.2026 WiSenMeshWAN® 1-Channel 4-20mA/1-5V Interface Node - User Manual www.wisencn.com Page - 4 - of 14 1. Product Introduction The W iSenMeshWAN® 1-Channel 4-20mA/1-5V Interface Node is one of the key products in our patented WiSenMeshWAN® geotechnical safety monitoring system. Working together with the WiSenMeshWAN® gateway product and the specified 4-20mA or 1-5V analogue sensors, it intelligently delivers real-time sensor data to the information centre. The WiSenMeshWAN® 1-Channel 4-20mA/1-5V Interface Node operates using our core technology, i.e., the WiSenMeshWAN^®^ Low Power, Intelligent, W ireless Sensor Network protocol, together with its internal high precision analogue sample module and power unit. This product satisfies the three fundamental identities of the system: A. Network Life Span: to maximise battery life across the mesh network as a whole; B. Network Data Arrival Rate: to minimise data packet loss; C. Single Node Environmental Coverage: to maximise radio coverage. Our product has IP68 and is designed to work in a tough environment. It is small in size, reliable in performance, easy for maintenance, has high precision during sampling, and has strong immunity to radio-interference. The node supports 4-20mA, 1-5V, and resistive ratio type sensors (e.g., LVDT displacement sensors). Figure 1. 4-20mA/1-5V Interface Node (From left to right: EC-5 Soil Moisture in %, Displacement in mm, Noise Level in dB). Wisen Innovation Technical Doc. No.2026 WiSenMeshWAN® 1-Channel 4-20mA/1-5V Interface Node - User Manual www.wisencn.com Page - 5 - of 14 2. System Structure Layout Figure 2. System Structure Layout. Wisen Innovation Technical Doc. No.2026 WiSenMeshWAN® 1-Channel 4-20mA/1-5V Interface Node - User Manual www.wisencn.com Page - 6 - of 14 3. Node & Radio Features Node Features: Basics Battery Power Qty. x 1 (3.6V Lithium primary D-Cell ER34615) Mesh Stop Voltage 2.1VDC Battery Connection Standard Aluminium Battery Holder Output Current / Voltage Max. 50mA @ 2.5V / 5.0V / 9.0V / 12.0V ± 0.2V (Default @ 12V, Output Voltage Switch on board) Local Storage Min. 1500 Messages during Meshing at Mesh3.0 Protocol Dimension (L x W x H) Interface Node: 100 x 100 x 60mm Node Weight 0.6kg Cable Gland Qty. 1 x EMC-CMA14 for external sensor connection (through cable diameter, 4-8mm) Wire Connection Spring type wiring terminal Primary Sensor Sensor Type A. 4-20mA Analogue Type; B. 1-5V Analogue Type; C. Resistive Ratio Type (e.g., LVDT Displacement Sensor) [Note: Must use 2.5V Power Output Voltage]. No. of Inputs 1 Channel Hosting: single 4-20mA sensor, single 1-5V sensor, or single Resistive Ratio…

Text truncated - open the document above for the full version.

Attestation Statements

AOGES CO., LIMITED 2.911 (d)(7)USA Agent v1.5 Section 2.911(d)(7) USA Agent for Service of Process Company Name: Wuxi Wisen Innovation Co., Ltd. Address: Floor 12, Building 1, Phase III, International Life Science Innovation Park, 6-2 Shensi Road, Xinwu District, Wuxi, Jiangsu, China Product Name: 1-Channel 4-20mA/1-5V Interface Node FCC ID: 2AUZW-6C10 Model(s): 6C10, 6C1X, Where X can be 0-7( Hexadecimal). Product Description: 1-Channel 4-20mA/1-5V Interface Node 2.911(d)(7) USA Designated Agent for Service of Process We, [Wuxi Wisen Innovation Co., Ltd.] (“the applicant”) designate [AOGES CO., LIMITED] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either we the grantee have permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: AOGES CO., LIMITED USA Address: 1624 Market St, Ste 226, #30327 Denver CO, 80202 USA FRN Number：0033947847 Contact Name: XIAOYAN LAl Telephone No: +1 303 623 1940 Email: [email protected] Applicant Company name: Wuxi Wisen Innovation Co., Ltd. Address: Floor 12, Building 1, Phase III, International Life Science Innovation Park, 6-2 Shensi Road, Xinwu District, Wuxi, Jiangsu, China Grantee FRN Number：0028951184 FCC Grantee Code: 2AUZW Contact Name: Xinhu Nie AOGES CO., LIMITED 2.911 (d)(7)USA Agent v1.5 Telephone No: 18762672069 Email: [email protected] Signature: Title: CEO Signature: Title: C Hardware Engineer Date: 2026.04.24 Date: 2026.04.24 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

Attestation Statements

Wuxi Wisen Innovation Co., Ltd. 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company Name: Wuxi Wisen Innovation Co., Ltd. Address: Floor 12, Building 1, Phase III, International Life Science Innovation Park, 6-2 Shensi Road, Xinwu District, Wuxi, Jiangsu, China Product Name: 1-Channel 4-20mA/1-5V Interface Node FCC ID: 2AUZW-6C10 Model(s): 6C10, 6C1X, Where X can be 0-7( Hexadecimal). Product Description: 1-Channel 4-20mA/1-5V Interface Node 2.911(d)(5)(i) Equipment Type We, [Wuxi Wisen Innovation Co., Ltd.] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Xinhu Nie Date: 2026.04.24 Title and Company name: Hardware Engineer / Wuxi Wisen Innovation Co., Ltd. NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Attestation Statements

Wuxi Wisen Innovation Co., Ltd. 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company Name: Wuxi Wisen Innovation Co., Ltd. Address: Floor 12, Building 1, Phase III, International Life Science Innovation Park, 6-2 Shensi Road, Xinwu District, Wuxi, Jiangsu, China Product Name: 1-Channel 4-20mA/1-5V Interface Node FCC ID: 2AUZW-6C10 Model(s): 6C10, 6C1X, Where X can be 0-7( Hexadecimal). Product Description: 1-Channel 4-20mA/1-5V Interface Node 2.911(d)(5)(ii) Applicant filing We, [Wuxi Wisen Innovation Co., Ltd.] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Xinhu Nie Date: 2026.04.24 Title and Company name: Hardware Engineer / Wuxi Wisen Innovation Co., Ltd. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Cover Letter(s)

Differences Description We Wuxi Wisen Innovation Co., Ltd.state: Product： 1-Channel 4-20mA/1-5V Interface Node Model Name： 6C10, 6C1X, Where X can be 0-7( Hexadecimal). Brand Name： WisenMeshWAN® FCC ID： 2AUZW-6C10 Both of models have the same circuit schematic, construction, PCB Lavout and critical components. Only different in model names. Sincerely, Company: Wuxi Wisen Innovation Co., Ltd. Title: PM E-mail: [email protected] Name: Jiankuai Li Signature

Cover Letter(s)

Wuxi Wisen Innovation Co., Ltd. Authorization Letter We, (the approval holder) Company name Wuxi Wisen Innovation Co., Ltd. Address Floor 12, Building 1, Phase III, International Life Science Innovation Park, 6-2 Shensi Road, Xinwu District, Wuxi, Jiangsu, China declare that the following representative (agent): Name (person) Bovey Yang Company name SHENZHEN STS TEST SERVICES CO.,LTD. Addresss 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub- District, Bao’an District, Shenzhen, Guang Dong, China City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to Nemko for product certification below Product Description 1-Channel 4-20mA/1-5V Interface Node Type or Model(s) 6C10, 6C1X, Where X can be 0-7( Hexadecimal). Brand Name WisenMeshWAN® FCC ID 2AUZW-6C10 Attestation: Signature: Date: 2026.04.24 Name: Jiankuai Li Title: PM Company: Shenzhen STS Test Services Co., Ltd.

Cover Letter(s)

2026.04.21 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize SHENZHEN STS TEST SERVICES CO.,LTD./ A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District,Bao’an District, Shenzhen, Guang Dong, China/Jiankuai Li(Name of Agent company name and address, Name of Agent) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. Name: Jiankuai Li Title: PM E-mail:[email protected] This appointment is valid until further until Dec 31, 2026 Sincerely, Name: Xinhu Nie Title: Hardware Engineer E-mail: [email protected] Company: Wuxi Wisen Innovation Co., Ltd. Signature:

Cover Letter(s)

Wuxi Wisen Innovation Co., Ltd. Letter of Authorization Company Name: Wuxi Wisen Innovation Co., Ltd. Address: Floor 12, Building 1, Phase III, International Life Science Innovation Park, 6-2 Shensi Road, Xinwu District, Wuxi, Jiangsu, China Product Name: 1-Channel 4-20mA/1-5V Interface Node FCC ID: 2AUZW-6C10 Model(s): 6C10, 6C1X, Where X can be 0-7( Hexadecimal). Product Description: 1-Channel 4-20mA/1-5V Interface Node We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2026.04.24 Name: Jiankuai Li Title: PM Company: Shenzhen STS Test Services Co., Ltd.

Cover Letter(s)

Wuxi Wisen Innovation Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026.04.24 Subject; Request for Confidentiality FCC ID: 2AUZW-6C10 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jiankuai Li Title: PM

External Photos

Page 1 of 4 Report No.: STS2604044 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: 6C10 Photo 1 Photo 2 Antenna Page 2 of 4 Report No.: STS2604044 Photo 3 Photo 4 Page 3 of 4 Report No.: STS2604044 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2604044 Photo 7 Photo 8

ID Label/Location Info

Label 1-Channel 4-20mA/1-5V Interface Node

RF Exposure Info

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. MPE Report Report No.:STS2604044H01 Issued for Wuxi Wisen Innovation Co., Ltd. Floor 12, Building 1, Phase III, International Life Science Innovation Park, 6-2 Shensi Road, Xinwu District, Wuxi, Jiangsu, China Product Name: 1-Channel 4-20mA/1-5V Interface Node Brand Name: WisenMeshWAN® Model Name: 6C10 Series Model(s): 6C1X, Where X can be 0-7( Hexadecimal). FCC ID: 2AUZW-6C10 Test Standards: FCC 47CFR §2.1091 Page 2 of 9 Report No.: STS2604044H01 TEST REPORT Applicant’s Name ................. : Wuxi Wisen Innovation Co., Ltd. Address ................................. : Floor 12, Building 1, Phase III, International Life Science Innovation Park, 6-2 Shensi Road, Xinwu District, Wuxi, Jiangsu, China Manufacturer's Name ........... : Wuxi Wisen Innovation Co., Ltd. Address ................................. : Floor 12, Building 1, Phase III, International Life Science Innovation Park, 6-2 Shensi Road, Xinwu District, Wuxi, Jiangsu, China Product Description Product Name ........................ : 1-Channel 4-20mA/1-5V Interface Node Brand ................................... : WisenMeshWAN® Model Number ....................... : .. : 6C10 Series Model(s) ...................... : 6C1X, Where X can be 0-7( Hexadecimal). Standards ............................. : FCC 47CFR §2.1091 447498 D04 Interim General RF Exposure Guidance v01 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 09 Apr. 2026 Date (s) of performance of tests ............. : 09 Apr. 2026~21 Apr. 2026 Date of Issue .......................................... : 21 Apr. 2026 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2604044H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2604044H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 21 Apr. 2026 STS2604044H01 ALL Initial Issue Page 5 of 9 Report No.: STS2604044H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name 1-Channel 4-20mA/1-5V Interface Node Brand WisenMeshWAN® Model Name 6C10 Series Model(s) 6C1X, Where X can be 0-7( Hexadecimal). Model Difference Only difference in model name. Product Description Operation Frequency: 902-928MHz Number Of Channel: 7CH Modulation Type: FSK/LoRa Antenna gain: 5dBi Antenna Designation: Omni-directional Power Rating Input: DC 3.6V/0.5A Adapter N/A Battery Model: ER34615 Brand: Forte Rated Voltage: 3.6 V Capacity: 19000mAh Hardware Version V1.1 Software Version V4785 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2604044H01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2604044H01 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . Page 8 of 9 Report No.: STS2604044H01 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the …

Text truncated - open the document above for the full version.

Test Report

Product Number: HN0900-9201SM Product Name: Antenna Page 1 Version: 1.0 Issue Date: 2017-01-03 Index: 1. Specification / Page 2 2. Characteristics and Reliability Test / Page 3 3. Antenna - S Parameter Test Data / Page 4 4. Antenna - Radiation Pattern Test Data / Page 5 5. Mechanical Drawing / Page 6 Product Number: HN0900-9201SM Product Name: Antenna Page 2 Version: 1.0 Issue Date: 2017-01-03 1. Specification Sample Photo A. Electrical Characteristics Frequency 868 ~ 930 MHz S.W.R. <= 2.0 @ 868-915 MHz Antenna Gain 5dbi Polarization Linear Impedance 50 Ohm B. Material & Mechanical Characteristics Material of Radiator Cu Material of Plastic Body: TPE Hinge: ABS Holder: PA+ABS Cable Type RG-178 Connector Type Non SMA Male Connector Pull Test >= 3Kg Connector Torque Test 200 ~500 g.cm C. Environmental Operation Temperature - 40 ̊C ~ + 60 ̊C Storage Temperature - 40 ̊C ~ + 85 ̊C Product Number: HN0900-9201SM Product Name: Antenna Page 3 Version: 1.0 Issue Date: 2017-01-03 2. Characteristics and Reliability Test Test Items Test Condition and Procedure Requirements C1 S.W.R. Set DUT on Network Analyzer; make individual calibration to test Directive DUT specification C2 Antenna Gain Set DUT on Antenna Chamber; make individual calibration to test Directive DUT specification M1 Vibration MIL-STD-202G, 201A Amplitude: 0.03 inch (0.76mm); Freq: 10 to 55 Hz 3 directions; 2 hours for each direction 1. No Visual Damage 2. Frequency Tol.<= 5% M2 Random Drop Height: 1.5 Meter; 3 directions; 1 time for each direction 1. No parts separated 2. Frequency Tol.<= 5% M3 Solderability MIL-STD-202G, 210F, cond. A Solder iron: 350±10°C; Duration: 5 seconds 1. Mounted on PCB 2. No Visual Damage M4 Terminal- Pull Test MIL-STD-202G, 211A, cond. A Holding with individual specification; force applied to axis of terminal 1. Directive DUT specification 2. Frequency Tol.<= 5% M5 Terminal- Torque Test MIL-STD-202G, 211A, cond. E Holding with individual specification; applied clockwise and counterclockwise to the axis of terminal 1. Directive DUT specification 2. Frequency Tol.<= 5% M6 Dimension Inspection of dimension, color, material, package, surface process Directive DUT specification E1 Salt Spray MIL-STD-202G, 101E, cond. B Temp: 35°C; RH: >= 95%; NaCl solution: >= 5%; Time: 48 hours After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<= 5% E2 Humidity MIL-STD-202G, 103B, cond. B Temp: 40°C; RH: >= 95%; Time: 48 hours After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<= 5% E3 Thermal Shock 1 Cycle: - 40°C (30 minutes) to + 80°C (30 minutes) Cycles: 24 After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<= 5% E4 Life (High Temp.) MIL-STD-202G, 108A, cond. A Temp: 85°C; Time: 96 hours After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<= 5% R1 RoHS With Reference to IEC 62321:2008 with flow chart Directive RoHS 2002/95/EC R2 PFOS With Reference to USA EPA 3540C:1996 by LC/MS Directive RoHS 2006/122/EC R3 PFOA With Reference to USA EPA 3540C:1996 by LC/MS Directive RoHS 2006/122/EC Product Number: HN0900-9201SM Product Name: Antenna Page 4 Version: 1.0 Issue Date: 2017-01-03 3. Antenna - S Parameter Test Data Product Number: HN0900-9201SM Product Name: Antenna Page 5 Version: 1.0 Issue Date: 2017-01-03 4. Antenna - Radiation Pattern Test Data Testing Equipment Specification: Antenna Anechoic Chamber Dimension: 8 x 4 x 4 m Quite Zone: 600mm @1 GHz Isolation: >100dB @ 1 MHz ~ 10 GHz Testing Equipment: Agilent 5071B Received Antenna: 0.7 ~ 6.0 GHz for Gain Calibration Double Ridged Horn Antenna 5. Mechanical Drawing See attached files

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Xinhu Nie(Hardware Engineer)

[email protected]Fax: 0755-36886277

Technical Contact

AOGES CO., LIMITEDXIAOYAN LAI

[email protected]

1624 Market St., Ste 226, #30327 Denver CO, 80202 · Denver CO, Colorado, 30327 · United States

Test Firm

SHENZHEN STS TEST SERVICES CO.,LTD.Bovey Yang

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	905 MHz - 925 MHz	15.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is the maximum conducted output power. The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance.
