2AV2WHZ-9457Bluetooth speakers

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Radiation Exposure Statement This device complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. FCC statement

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Dongguan Sogoode Computer System Co.,Ltd. Address: United Finance Building 20th floor KeJi Road NO.10 Songshan Lake High-tech Development Zone, Dongguan, Guangdong, China. Product Name: Bluetooth speakers Model Number: HZ-9457 FCC Identifier: 2AV2WHZ-9457 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Ren Shuang Date: Feb. 22, 2021 Title: Manager Signature of applicant:

C5266091_X10_Ed.1 1/1 Dongguan Sogoode Computer System Co.,Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: Feb. 22, 2021 Subject: Request for Confidentiality FCC ID: 2AV2WHZ-9457 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.1 1/1 Sincerely, Signature: Name: Ren Shuang Title: Manager

FCC ID:2AV2WHZ-9457

FCC ID Label Information 1. Label location: 2. FCC ID Label: FCC ID:2AV2WHZ-9457 FCCID Label Location

Bluetooth Antenna FCC ID:2AV2WHZ-9457 AC6926

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison pt=0.16dBm =1.038mW at 2480MHz So (1.038mW/5mm)x √2.480GHz =0.327<3 Then SAR evaluation is not required

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 E-mail: [email protected] TEST REPORT FCC PART 15.247 Report Reference No.: CTL2007314031-WF Compiled by: ( position+printed name+signature) Happy Guo (File administrators) Tested by: ( position+printed name+signature) Nice Nong (Test Engineer) Approved by: ( position+printed name+signature) Ivan Xie (Manager) Product Name ............................ : Bluetooth speakers Model/Type reference ................ : HZ-9457 List Model(s) ............................... : N/A Trade Mark .................................. : N/A FCC ID ......................................... : 2AV2WHZ-9457 Applicant’s name ....................... : Dongguan Sogoode Computer System Co.,Ltd. Address of applicant ................. : United Finance Building 20th floor KeJi Road NO.10 Songshan Lake High-tech Development Zone, Dongguan, Guangdong, China. Test Firm ..................................... : Shenzhen CTL Testing Technology Co., Ltd. Address of Test Firm ................. : Floor 1-A, Baisha Technology Park, No.3011, Shahexi Road, Nanshan District, Shenzhen, China 518055 Test specification ....................... : Standard ...................................... : FCC Part 15.247: Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz. TRF Originator ............................. : Shenzhen CTL Testing Technology Co., Ltd. Master TRF .................................. : Dated 2011-01 Date of receipt of test item ........ : Aug. 21, 2020 Date of sampling ........................ : Aug. 21, 2020 Date of Test Date ........................ : Aug. 21, 2020 - Sep. 11, 2020 Date of Issue .............................. : Sep. 12, 2020 Result .......................................... : Pass Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. V1.0 Page 2 of 34 Report No.: CTL2007314031-WF TEST REPORT Test Report No. : CTL2007314031-WF Sep. 12, 2020 Date of issue Equipment under Test : Bluetooth speakers Sample No. CTL200731403-1-S001 Model /Type : HZ-9457 Listed Models : N/A Applicant : Dongguan Sogoode Computer System Co.,Ltd. Address : United Finance Building 20th floor KeJi Road NO.10 Songshan Lake High-tech Development Zone, Dongguan, Guangdong, China. Manufacturer : Dongguan Sogoode Computer System Co.,Ltd. Address : United Finance Building 20th floor KeJi Road NO.10 Songshan Lake High-tech Development Zone, Dongguan, Guangdong, China. Test result Pass * *In the configuration tested, the EUT complied with the standards specified page 5. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the issuing testing laboratory. V1.0 Page 3 of 34 Report No.: CTL2007314031-WF ** Modified History ** Revisions Description Issued Data Report No. Remark Version 1.0 Initial Test Report Release 2020-09-12 CTL2007314031-WF Tracy Qi V1.0 Page 4 of 34 Report No.: CTL2007314031-WF Table of Contents Page 1. SUMMARY ............................................................................................................................................................... 5 1.1. TEST STANDARDS ..................................................................................................................................................... 5 1.2. TEST DESCRIPTION ........................................................................................................................................................ 5 1.3. TEST FACILITY .............................................................................................................................................................. 6 1.4. STATEMENT OF THE MEASUREMENT UNCERTAINTY ............................................................................................................... 6 2. GENERAL INFORMATION .......................................................................................................................................... 8 2.1. ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 8 2.2. GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 8 2.3. DESCRIPTION OF TEST MODES AND TEST FREQUENCY .......................................................................................................... 8 2.4. EQUIPMENTS USED DURING THE TEST .............................................................................................................................. 9 2.5. RELATED SUBMITTAL(S) / GRANT (S) ................................................................................................................................ 9 2.6. MODIFICATIONS ......................................................................................................................................................... 10 3. TEST CONDITIONS AND RESULTS ............................................................................................................................ 11 3.1. CONDUCTED EMISSIONS TEST ....................................................................................................................................... 11 3.2. RADIATED EMISSIONS AND BAND EDGE .......................................................................................................................... 14 3.3. MAXIMUM PEAK OUTPUT POWER............…

Text truncated - open the document above for the full version.

1 / 39 Annex for Bluetooth BR&EDR Part 15.247 Test Report No. : CTL2007314031-WF 1. Bandwidth 1.1 Test Result Test Mode Frequency (MHz) TX Type ANT No. 20dB Bandwidth Verdict Test Result (MHz) GFSK 2402 SISO 1 0.952 PASS 2441 SISO 1 0.951 PASS 2480 SISO 1 0.941 PASS Pi/4DQPSK 2402 SISO 1 1.318 PASS 2441 SISO 1 1.305 PASS 2480 SISO 1 1.317 PASS 8DPSK 2402 SISO 1 1.336 PASS 2441 SISO 1 1.308 PASS 2480 SISO 1 1.312 PASS Test Mode Frequency (MHz) TX Type ANT No. 99% Occupied Bandwidth Test Result (MHz) GFSK 2402 SISO 1 0.857 Only for Report Use 2441 SISO 1 0.844 Only for Report Use 2480 SISO 1 0.843 Only for Report Use Pi/4DQPSK 2402 SISO 1 1.180 Only for Report Use 2441 SISO 1 1.176 Only for Report Use 2480 SISO 1 1.193 Only for Report Use 8DPSK 2402 SISO 1 1.183 Only for Report Use 2441 SISO 1 1.179 Only for Report Use 2480 SISO 1 1.184 Only for Report Use 1.2 Test Graph - 20dB Bandwidth 2 / 39 3 / 39 4 / 39 5 / 39 1.3 Test Graph - 99% Occupied Bandwidth 6 / 39 7 / 39 8 / 39 9 / 39 10 / 39 2. Maximum Conducted Output Power 2.1 Test Result Test Mode Frequency (MHz) Tx Type Measured Peak Output Power (dBm) Limits (dBm) Verdict Ant 1 GFSK 2402 SISO -2.45 30 PASS 2441 SISO -1.28 30 PASS 2480 SISO -0.59 30 PASS Pi/4DQPSK 2402 SISO -1.76 20.97 PASS 2441 SISO -0.55 20.97 PASS 2480 SISO 0.16 20.97 PASS 8DPSK 2402 SISO -1.75 20.97 PASS 2441 SISO -0.52 20.97 PASS 2480 SISO 0.16 20.97 PASS 2.2 Test Graph 11 / 39 12 / 39 13 / 39 14 / 39 15 / 39 3. Carrier frequency separation 3.1 Test Result Test Mode TX Type ANT No. Channel Separation (MHz) 20dB Bandwidth (MHz) Limits (MHz) Verdict GFSK SISO 1 0.977 0.952 ≥0.635 PASS Pi/4DQPSK SISO 1 0.999 1.318 ≥0.879 PASS 8DPSK SISO 1 0.999 1.336 ≥0.891 PASS 3.2 Test Graph 16 / 39 4. Number of hopping frequencies 4.1 Test Result Test Mode TX Type ANT No. Num of Hopping Frequencies Limits Verdict GFSK SISO 1 79 ≥15 PASS Pi/4DQPS K SISO 1 79 ≥15 PASS 8DPSK SISO 1 79 ≥15 PASS 4.2 Test Graph 17 / 39 18 / 39 5. Time of Occupancy (Dwell Time) 5.1 Test Result Test Mode Packet Type TX Type ANT No. Duration of Single Pulse (ms) Obeser vation Period (s) Num of Pulse in Observation Period Dwell Time (ms) Limits (ms) Verdict GFSK DH1 SISO 1 0.378 31.6 317 119.826 ≤400 PASS DH3 SISO 1 1.633 31.6 98 160.034 ≤400 PASS DH5 SISO 1 2.880 31.6 72 207.360 ≤400 PASS Pi/4D QPS K 2DH1 SISO 1 0.387 31.6 317 122.679 ≤400 PASS 2DH3 SISO 1 1.639 31.6 119 195.041 ≤400 PASS 2DH5 SISO 1 2.888 31.6 72 207.936 ≤400 PASS 8DPS K 3DH1 SISO 1 0.387 31.6 321 124.227 ≤400 PASS 3DH3 SISO 1 1.640 31.6 110 180.400 ≤400 PASS 3DH5 SISO 1 2.888 31.6 58 167.504 ≤400 PASS 5.2 Test Graph 19 / 39 20 / 39 21 / 39 22 / 39 23 / 39 24 / 39 25 / 39 26 / 39 27 / 39 6. Unwanted Emissions in Non-restricted Frequency Bands 6.1 Test Result Test Mode Frequency (MHz) TX Type ANT No. Spurious Conducted Emission (dBm) Limits (dBm) Verdict GFSK 2402 SISO 1 Refer to test graph -20.67 PASS 2441 SISO 1 Refer to test graph -20.67 PASS 2480 SISO 1 Refer to test graph -20.67 PASS Hopping SISO 1 Refer to test graph -20.67 PASS Pi/4DQPSK 2402 SISO 1 Refer to test graph -20.78 PASS 2441 SISO 1 Refer to test graph -20.78 PASS 2480 SISO 1 Refer to test graph -20.78 PASS Hopping SISO 1 Refer to test graph -20.78 PASS 8DPSK 2402 SISO 1 Refer to test graph -20.73 PASS 28 / 39 2441 SISO 1 Refer to test graph -20.73 PASS 2480 SISO 1 Refer to test graph -20.73 PASS Hopping SISO 1 Refer to test graph -20.73 PASS 6.2 Test Graph 29 / 39 30 / 39 31 / 39 32 / 39 33 / 39 34 / 39 35 / 39 36 / 39 37 / 39 38 / 39 39 / 39

FCC ID:2AV2WHZ-9457
