DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.003 Page 98 of 118 2023-11-08 Radiated Emissions Limits 1. LTE Cat 1bis Band 12. * FCC §27.53 (g): (g) For operations in the 600 MHz band and the 698–746 MHz band, the power of any emission outside a licensee's frequency band(s) of operation shall be attenuated below the transmitter power (P) within the licensed band(s) of operation, measured in watts, by at least 43 + 10 log (P) dB. Compliance with this provision is based on the use of measurement instrumentation employing a resolution bandwidth of 100 kilohertz or greater. However, in the 100 kilohertz bands immediately outside and adjacent to a licensee's frequency block, a resolution bandwidth of at least 30 kHz may be employed. * RSS-130, 4.7: 4.7.1 General unwanted emissions limits: The unwanted emissions in any 100 kHz bandwidth on any frequency outside the low frequency edge and the high frequency edge of each frequency block range(s), shall be attenuated below the transmitter power, P (dBW), by at least 43 + 10 log10 p (watts), dB. However, in the 100 kHz band immediately outside of the equipment's frequency block range, a resolution bandwidth of 30 kHz may be employed. 4.7.2 Additional unwanted emissions limits: In addition to the limit outlined in section 4.7.1 above, equipment operating in the frequency bands 746-756 MHz and 777-787 MHz shall also comply with the following restrictions: a. the power of any unwanted emissions in any 6.25 kHz bandwidth for all frequencies between 763-775 MHz and 793-806 MHz shall be attenuated below the transmitter power, P (dBW), by at least: i. 76 + 10 log10 p (watts), dB, for base and fixed equipment and ii. 65 + 10 log10 p (watts), dB, for mobile and portable equipment b. the e.i.r.p. in the band 1559-1610 MHz shall not exceed −70 dBW/MHz for wideband signal and −80 dBW for discrete emission with bandwidth less than 700 Hz. 2. LTE Cat 1bis Band 13. * FCC §27.53 (c) & (f): (c) For operations in the 746-758 MHz band and the 776-788 MHz band, the power of any emission outside the licensee's frequency band(s) of operation shall be attenuated below the transmitter power (P) within the licensed band(s) of operation, measured in watts, in accordance with the following: (1) On any frequency outside the 746–758 MHz band, the power of any emission shall be attenuated outside the band below the transmitter power (P) by at least 43 + 10 log (P) dB; (2) On any frequency outside the 776-788 MHz band, the power of any emission shall be attenuated outside the band below the transmitter power (P) by at least 43 + 10 log (P) dB; (3) On all frequencies between 763–775 MHz and 793–805 MHz, by a factor not less than 76 + 10 log (P) dB in a 6.25 kHz band segment, for base and fixed stations; (4) On all frequencies between 763–775 MHz and 793–805 MHz, by a factor not less than 65 + 10 log (P) dB in a 6.25 kHz band segment, for mobile and portable stations; DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.003 Page 99 of 118 2023-11-08 (5) Compliance with the provisions of paragraphs (c)(1) and (c)(2) of this section is based on the use of measurement instrumentation employing a resolution bandwidth of 100 kHz or greater. However, in the 100 kHz bands immediately outside and adjacent to the frequency block, a resolution bandwidth of at least 30 kHz may be employed; (6) Compliance with the provisions of paragraphs (c)(3) and (c)(4) of this section is based on the use of measurement instrumentation such that the reading taken with any resolution bandwidth setting should be adjusted to indicate spectral energy in a 6.25 kHz segment. (f) For operations in the 746–758 MHz, 775–788 MHz, and 805–806 MHz bands, emissions in the band 1559–1610 MHz shall be limited to −70 dBW/MHz equivalent isotropically radiated power (EIRP) for wideband signals, and −80 dBW EIRP for discrete emissions of less than 700 Hz bandwidth. For the purpose of equipment authorization, a transmitter shall be tested with an antenna that is representative of the type that will be used with the equipment in normal operation. * RSS-130, 4.7: 4.7.1 General unwanted emissions limits: The unwanted emissions in any 100 kHz bandwidth on any frequency outside the low frequency edge and the high frequency edge of each frequency block range(s), shall be attenuated below the transmitter power, P (dBW), by at least 43 + 10 log10 p (watts), dB. However, in the 100 kHz band immediately outside of the equipment's frequency block range, a resolution bandwidth of 30 kHz may be employed. 4.7.2 Additional unwanted emissions limits: In addition to the limit outlined in section 4.7.1 above, equipment operating in the frequency bands 746-756 MHz and 777-787 MHz shall also comply with the following restrictions: a. the power of any unwanted emissions in any 6.25 kHz bandwidth for all frequencies between 763-775 MHz and 793-806 MHz shall be attenuated below the transmitter power, P (dBW), by at least: i. 76 + 10 log10 p (watts), dB, for base and fixed equipment and ii. 65 + 10 log10 p (watts), dB, for mobile and portable equipment b. the e.i.r.p. in the band 1559-1610 MHz shall not exceed −70 dBW/MHz for wideband signal and −80 dBW for discrete emission with bandwidth less than 700 Hz. 3. LTE Cat 1bis Band 66. * FCC §27.53 (h): AWS emission limits: (1) General protection levels. Except as otherwise specified below, for operations in the 1695–1710 MHz, 1710–1755 MHz, 1755–1780 MHz, 1915–1920 MHz, 1995–2000 MHz, 2000–2020 MHz, 2110–2155 MHz, 2155–2180 MHz, and 2180–2200 bands, the power of any emission outside a licensee's frequency block shall be attenuated below the transmitter power (P) in watts by at least 43 + 10 log10 (P) dB. (3) Measurement procedure. (i) Compliance with this provision is …

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.003 Page 61 of 118 2023-11-08 LTE Cat 1bis Band 66. BW=15 MHz. QPSK. RB Size All. Low Channel: Middle Channel: DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.003 Page 62 of 118 2023-11-08 High Channel: DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.003 Page 63 of 118 2023-11-08 LTE Cat 1bis Band 66. BW=15 MHz. 16QAM. RB Size All. Low Channel: Middle Channel: DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.003 Page 64 of 118 2023-11-08 High Channel: DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.003 Page 65 of 118 2023-11-08 LTE Cat 1bis Band 66. BW=20 MHz. QPSK. RB Size All. Low Channel: Middle Channel: DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.003 Page 66 of 118 2023-11-08 High Channel: DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.003 Page 67 of 118 2023-11-08 LTE Cat 1bis Band 66. BW=20 MHz. 16QAM. RB Size All. Low Channel: Middle Channel: DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.003 Page 68 of 118 2023-11-08 High Channel: DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.003 Page 69 of 118 2023-11-08 Spurious Emissions at Antenna Terminals Limits 1. LTE Cat 1bis Band 12. * FCC §27.53 (g): (g) For operations in the 600 MHz band and the 698–746 MHz band, the power of any emission outside a licensee's frequency band(s) of operation shall be attenuated below the transmitter power (P) within the licensed band(s) of operation, measured in watts, by at least 43 + 10 log (P) dB. Compliance with this provision is based on the use of measurement instrumentation employing a resolution bandwidth of 100 kilohertz or greater. However, in the 100 kilohertz bands immediately outside and adjacent to a licensee's frequency block, a resolution bandwidth of at least 30 kHz may be employed. * RSS-130, 4.7: 4.7.1 General unwanted emissions limits: The unwanted emissions in any 100 kHz bandwidth on any frequency outside the low frequency edge and the high frequency edge of each frequency block range(s), shall be attenuated below the transmitter power, P (dBW), by at least 43 + 10 log10 p (watts), dB. However, in the 100 kHz band immediately outside of the equipment's frequency block range, a resolution bandwidth of 30 kHz may be employed. 4.7.2 Additional unwanted emissions limits: In addition to the limit outlined in section 4.7.1 above, equipment operating in the frequency bands 746-756 MHz and 777-787 MHz shall also comply with the following restrictions: a. the power of any unwanted emissions in any 6.25 kHz bandwidth for all frequencies between 763-775 MHz and 793-806 MHz shall be attenuated below the transmitter power, P (dBW), by at least: i. 76 + 10 log10 p (watts), dB, for base and fixed equipment and ii. 65 + 10 log10 p (watts), dB, for mobile and portable equipment b. the e.i.r.p. in the band 1559-1610 MHz shall not exceed −70 dBW/MHz for wideband signal and −80 dBW for discrete emission with bandwidth less than 700 Hz. 2. LTE Cat 1bis Band 13. * FCC §27.53 (c): (c) For operations in the 746-758 MHz band and the 776-788 MHz band, the power of any emission outside the licensee's frequency band(s) of operation shall be attenuated below the transmitter power (P) within the licensed band(s) of operation, measured in watts, in accordance with the following: (1) On any frequency outside the 746–758 MHz band, the power of any emission shall be attenuated outside the band below the transmitter power (P) by at least 43 + 10 log (P) dB; (2) On any frequency outside the 776-788 MHz band, the power of any emission shall be attenuated outside the band below the transmitter power (P) by at least 43 + 10 log (P) dB; (3) On all frequencies between 763–775 MHz and 793–805 MHz, by a factor not less than 76 + 10 log (P) dB in a 6.25 kHz band segment, for base and fixed stations; (4) On all frequencies between 763–775 MHz and 793–805 MHz, by a factor not less than 65 + 10 log (P) dB in a 6.25 kHz band segment, for mobile and portable stations; DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.003 Page 70 of 118 2023-11-08 (5) Compliance with the provisions of paragraphs (c)(1) and (c)(2) of this section is based on the use of measurement instrumentation employing a resolution bandwidth of 100 kHz or greater. However, in the 100 kHz bands immediately outside and adjacent to the frequency block, a resolution bandwidth of at least 30 kHz may be employed; (6) Compliance with the provisions of paragraphs (c)(3) and (c)(4) of this section is based on the use of measurement instrumentation such that the reading taken with any resolution bandwidth setting should be adjusted to indicate spectral energy in a 6.25 kHz segment. * RSS-130, 4.7: 4.7.1 General unwanted emissions limits: The unwanted emissions in any 100 kHz bandwidth on any frequency outside the low frequency edge and the hig…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.003 2023-11-08 ISED CABid: ES1909 Lab. Company Number: 4621A Test Report No: 75461RRF.003 Test Report USA FCC Part 27 CANADA RSS-130, RSS-139 (*) Identification of item tested LTE Cat 1bis module (*) Trademark Sequans Communications (*) Model and /or type reference GC02S1-NA2 Other identification of the product FCC ID: 2AAGMGC02SA IC: 12732A-GC02SA (*) Features 4G LTE module HW version: Rev1 SW version: LR9.0.1.1-59215 Applicant SEQUANS COMMUNICATIONS 55 Boulevard Charles de Gaulle, 92700 Colombes, France Test method requested, standard USA FCC Part 27 (10-1-21 Edition). CANADA RSS-130 Issue 2, February 2019. CANADA RSS-139 Issue 4 September 2022, Amendment October 2022. CANADA RSS-Gen Issue 5, April 2018. ANSI C63.26-2015. KDB 971168 D01 Power Meas License Digital Systems v03r01, April 2018. Summary IN COMPLIANCE Approved by (name / position & signature) José Manuel Gómez Galván EMC Consumer & RF Lab. Manager Date of issue 2023-11-08 Report template No. FDT08_24 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.003 Page 2 of 118 2023-11-08 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Uncertainty ................................................................................................................................. 3 Data provided by the client .......................................................................................................... 3 Usage of samples ....................................................................................................................... 4 Test sample description .............................................................................................................. 4 Identification of the client............................................................................................................. 5 Testing period and place ............................................................................................................. 5 Document history ........................................................................................................................ 5 Environmental conditions ............................................................................................................ 5 Remarks and comments ............................................................................................................. 6 Testing verdicts ........................................................................................................................... 8 Summary .................................................................................................................................... 8 Appendix A: Test results for FCC 27 / RSS-130, RSS-139, RSS-Gen: LTE Cat 1bis Bands 4, 12, 13, 17, 66 .................................................................................................................................... 9 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.003 Page 3 of 118 2023-11-08 Competences and guarantees DEKRA Testing and Certification S.A.U. is a testing laboratory accredited by the National Accreditation Body (ENAC - Entidad Nacional de Acreditación), to perform the tests indicated in the Certificate No. 51/LE 147. DEKRA Testing and Certification is an FCC-recognized accredited testing laboratory with appropriate scope of accreditation that include testing performed in this test report. DEKRA Testing and Certification is an ISED-recognized accredited testing laboratory, CABid: ES1909, Company Number: 4621A, with the appropriate scope of accreditation that covers the performed tests in this report. In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification S.A.U. has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification S.A.U. guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Testing and Certification S.A.U. at the time of performance of the test. DEKRA Testing and Certification S.A.U. is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Test Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Testing and Certification S.A.U. General conditions 1. This report is only referred to the item that has undergone the test. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Testing and Certification S.A.U. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Testing and Certification S.A.U. and the Accreditation Bodies. Uncertainty Uncertainty (factor k=2) was calculated…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.002 Page 55 of 58 2023-11-09 - Middle Channel: The peak above the limit is the carrier frequency. - High Channel: The peak above the limit is the carrier frequency. Level in dBm Level in dBm DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.002 Page 56 of 58 2023-11-09 FREQUENCY RANGE 3 - 18 GHz: - Low Channel: - Middle Channel: Level in dBm Level in dBm DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.002 Page 57 of 58 2023-11-09 - High Channel: FREQUENCY RANGE 18 - 20 GHz: - Low Channel: Level in dBm Level in dBm DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.002 Page 58 of 58 2023-11-09 - Middle Channel: - High Channel: Level in dBm Level in dBm

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.002 2023-11-09 ISED CABid: ES1909 Lab. Company Number: 4621A Test Report No: 75461RRF.002 Test Report USA FCC Part 24 CANADA RSS-133 (*) Identification of item tested LTE Cat 1bis module (*) Trademark Sequans Communications (*) Model and /or type reference GC02S1-NA2 Other identification of the product FCC ID: 2AAGMGC02SA IC: 12732A-GC02SA (*) Features 4G LTE module HW version: Rev1 SW version: LR9.0.1.1-59215 Applicant SEQUANS COMMUNICATIONS 55 Boulevard Charles de Gaulle, 92700 Colombes Test method requested, standard USA FCC Part 24 (10-1-21 Edition). CANADA RSS-133 Issue 6, Jan. 2018 Amendment 1. ANSI C63.26-2015. KDB 971168 D01 Power Meas License Digital Systems v03r01, April. 2018. Summary IN COMPLIANCE Approved by (name / position & signature) José Manuel Gómez Galván EMC Consumer & RF Lab. Manager Date of issue 2023-11-09 Report template No FDT08_24 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.002 Page 2 of 58 2023-11-09 Index Competences and guarantees ...................................................................................................................... 3 General conditions ......................................................................................................................................... 3 Uncertainty ..................................................................................................................................................... 3 Data provided by the client ............................................................................................................................ 3 Usage of samples .......................................................................................................................................... 4 Test sample description ................................................................................................................................. 4 Identification of the client ............................................................................................................................... 5 Testing period and place ............................................................................................................................... 5 Document history ........................................................................................................................................... 5 Environmental conditions .............................................................................................................................. 5 Remarks and comments ................................................................................................................................ 6 Testing verdicts .............................................................................................................................................. 7 Summary ....................................................................................................................................................... 7 Appendix A: Test results for FCC 24 / RSS-133 ........................................................................................... 8 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29507456 Report No: 75461RRF.002 Page 3 of 58 2023-11-09 Competences and guarantees DEKRA Testing and Certification is a testing laboratory accredited by the National Accreditation Body (ENAC - Entidad Nacional de Acreditación) to perform the tests indicated in the Certificate No. 51/LE 147. DEKRA Testing and Certification is an FCC-recognized accredited testing laboratory with appropriate scope of accreditation that covers the performed tests in this report. DEKRA Testing and Certification is an ISED-recognized accredited testing laboratory, CABid: ES1909, Company Number: 4621A, with the appropriate scope of accreditation that covers the performed tests in this report. In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and it is based on the knowledge and technical facilities available at DEKRA Testing and Certification at the time of performance of the test. DEKRA Testing and Certification is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Test Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Testing and Certification. General conditions 1. This report is only referred to the item that has undergone the test. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Testing and Certification S.A.U. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Testing and Certification S.A.U. and the Accreditation Bodies. Uncertainty Uncertainty (factor k=2) was calculated accordi…

Text truncated - open the document above for the full version.

2440 Winston Park Drive Oakville, Ontario L6H 7V2, Canada +1 (416) 434 4309 www.geotab.com Dated: January 5 2026 Nemko North America, Inc. 303 River Road Ottawa ON K1V 1H2 Canada Covered Equipment Certification Attestation Letter Applicant: Geotab Inc. FCC ID: 2AV57GDSBA1 The applicant certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section §2.903 of the FCC rules. This includes certifying that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current FCC Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. The applicant certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature: Name: Benjamin Jull Title: Manager, Product Certification Company: Geotab Inc. Address: 2440 Winston Park Drive, Oakville ON Canada, L6H 7V2 Phone: +1 (877) 436-8221 Email: [email protected]

Dated: January 7, 2026 Nemko North America, Inc. 303 River Road Ottawa, ON K1V 1H2 Canada Test Data Attestation Letter – FCC FCC ID: 2AV57GDSBA1 This letter serves to confirm that Geotab Inc. is reusing test data for the LTE Cat1-bis module DLUS-WI01-NA (OEM: GC02S1-NA2), originally certified under FCC ID: NKR-DLUSWI01NA (OEM FCC ID: 2AAGMGC02SA) by WNC Corporation (OEM: Sequans Communications). The module is being integrated without modification into the end-product identified as GDSBA1. Please refer to the enclosed Operational Description exhibit for a comprehensive list of supported frequency bands. There have been no changes to the originally certified module, except for an alternative antenna use. The following test reports have been reviewed and are deemed valid, representative of the module’s performance within the GDSBA1 product, and compliant with current FCC requirements: Technology Report ID Issue date Rule Part LTE Band 5 75461RRF.001 November 9, 2023 22H LTE Band 2, 25 75461RRF.002 November 9, 2023 24E LTE Bands 4, 12, 13, 66 75461RRF.003 November 8, 2023 27 LTE Band 14 75461RRF.004 November 8, 2023 90R In addition, new radio testing with the new antenna has been conducted to demonstrate continued compliance of the integrated cellular module, which also includes a Bluetooth Low Energy (BLE) radio. Radiated Spurious Emissions (RSE) testing was performed for CAT1-bis module in conjunction with BLE to validate simultaneous transmission compliance. The GDSBA1 incorporates a custom antenna design to support the combined radio system of the product (see attached datasheet). From the cellular standpoint and the approved module: • The WNC Corporation (OEM: Sequans) module certification is based on the following antenna gains: 2 dBi (sub-1 GHz) and 2.4 dBi (above 1 GHz). • The GDSBA1 antenna design achieves the following antenna gains: 2.3 dBi (sub-1 GHz), and 2.8 dBi (above 1 GHz). An analysis of the antenna change has determined the following: • FCC Part 22H (B5 – 840 MHz): The new antenna gain is 0.3 dB higher, but there is sufficient ERP margin in the original report to accommodate increase of gain. ERP limit is 7 W (38.45 dBm) and the original assessment maximum level measured was 22.75 dBm (conducted). 22.75 dBm + 2.3 dBi (new antenna) = 25.05 dBm EIRP or 22.90 dBm ERP which is 15.55 dB margin below the limit. Radiated testing with new antenna demonstrate continued compliance. • FCC Part 24E (B2, B25 – 1900 MHz): The new antenna gain is slightly higher than the original, but there is sufficient EIRP margin in the original report to accommodate this. EIRP limit is 33 dBm and the original assessment maximum level measured was 22.65 dBm (conducted). 22.65 dBm + 2.8 dBi (new antenna) = 25.45 dBm = 7.55 dB margin below the limit. Radiated testing with new antenna demonstrate continued compliance. • FCC Part 27 (B4, B66 – 1700 MHz and B12, B13 – 700 MHz): Similarly, there is gain increase within acceptable limits based on the original report for above 1 GHz. EIRP limit is 30 dBm and the original assessment maximum level measured was 22.93 dBm (conducted). 22.93 dBm + 2.8 dBi (new antenna) = 25.73 dBm = 4.27 dB margin below the limit. The new antenna gain has 0.3 dB increase which is within acceptable limits bas…
