2AV7N-HUSH-IPROAcoustic Guitar

HUSH-I PRO User Manual Manuel d'Instructions Bedienungsanleitung Manuale d'Uso Manual de Usuario 取扱説明書 使用说明书 CONTENTS English Français Deutsch Italiano Español 日 本 語 中 文 1~9 10~18 19~27 28~36 37~45 46~54 55~63 1 NOTE If you abide by the following simple rules, Donner HUSH-I PRO guitar will provide you with reliable service all year round: Where to store the guitar ● In order to avoid deformation, discoloration, or more serious damage, do not store it in the following environments. - Direct sunlight (e.g. near a window) - High temperature (e.g. close to the heat source, outdoors, or in a car during the daytime). - Excessive humidity. - Excessive dust. - Strong vibration. ● In order to avoid damaging the guitar and other connected equipment (such as the audio system), please turn off the power switch of all relevant equipment before connecting or disconnecting the audio cable. Handling and transportation - Never apply excessive force to the controls, connectors, or other instrument parts. - Grab the plug firmly while unplugging the cables, never pull the audio cables with force. - Disconnect all cables before moving the instrument. - Shocks caused by dropping, bumping the instrument, or placing heavy objects on top of it, can result in scratches and even more severe damages. Cleaning - Clean the guitar body with a dry and soft cloth - Spots or dirt that are difficult to remove can be wiped off with a slightly water-dampened cloth. - Do not use thinners and alcohol for cleaning the unit. Built-In Multi-Function Effects - Do not change the batteries without the professional. - Please use the special charging cable to power the product. - To avoid the battery from draining quickly, turn off the power after playing. - When the product is not used for a long time, please turn off the power and disconnect the USB power cord. - Make sure the power is off when connecting or disconnecting the power cord. - Do not place the product near electrical equipment in order to avoid interfering with other products such as televisions, radios, etc. - Do not disassemble or modify the product to avoid fire and electric shock hazards. - Do not place it in direct sunlight, high temperatures, excessive humidity, dust, or strong vibration. - Do not clean the product with thinner, alcohol or similar chemicals to avoid discoloration. - When the product is turned on, pressing the power button quickly and continuously may cause unsuccessful reboot, if you want to reboot the product, please turn it on after turning off the power for 2 seconds. - It’s normal that HUSH-I PRO may experience distortion and overdrive in the following situations. You should know this in advance and follow our recommendations to adjust: 1. We cannot guarantee that all third-party IRs will load successfully. If you import a third-party IR, there may exist distortion or overdrive in the output of HUSH-I PRO because of an abnormal parameter specification of the IR file. You can first try to adjust the value of the upper computer's Level setting when importing to achieve the desired effect, or try to replace the other third-party IR; 2. The there exist impedance mismatch in the output device or headphone, then you can try to replace it with a suitable matching one. 3. There may exist the phenomena of distortion or overdrive because of the superposition of different effects and the excessive levels of the Air Boost/Tone Boost/EQ parameters/Preset Level/Master Level. At this time, control reasonably the the parameters according to their real aural feeling; Warning - Do not mechanically squeeze or cut the battery to avoid explosion! - Do not place products or batteries with batteries in extremely low pressure environments, as this may cause explosions or flammable liquids or gas leaks! - The product's operating environment temperature is 0°C to 35°C, and the product's transportation/storage environment temperature is -10°C to 45°C. - We recommend an operating air pressure range of 860hPa to 1060hPa for the electric guitar. Additionally, please note that high-altitude areas may have unpredictable effects on related electronic components. DONNER is not responsible for any damage caused by improper handling or operation. ENGLISH Thank you for purchasing the Donner HUSH-I PRO Guitar. In order to get the best performance and enjoy more fun with our product, it is strongly recommended that you read this guide before using it. Please store it in a safe place for future reference. USER MANUAL 2 ACCESSORIES PARTS OF THE GUITAR BODY ① ② ③ ④ ⑤ Body Left Guitar Stand * 1 Right Guitar Stand * 1 Guitar Gig Bag * 1 USB Cable * 1 Nut Fretboard Truss Rod Right Stand (Removable) Saddle(The pickup is under the saddle) 6.35mm Line out jack Left Stand Built-In Multi-Function Effects (Detailed functions are listed on the next page) Bridge Tuning pegs Allen Wrench ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ Guitar Pick * 3 Clean Cloth * 1 Allen Wrench * 1 Wrench for Truss Rod * 1 Strap * 2 Earphones * 1 6.35mm(1/4”) connecting cable * 1 User Manual * 1 3 ASSEMBLE THE STAND This stand is not assembled to the guitar body when shipping from the manufacturer Before using the instrument, please correctly assemble the stand using the procedure described below. 1. Make sure the direction of the stand is aligned with the guitar body. Put the end of the rod fully inserted into the corresponding bracket, then release it. 2. First, insert the rod of the lower stand (the shorter one) fully into the bracket hole on the guitar's main body. Next, insert the lower rod of the upper stand (the longer one) fully into the bracket hole, and the upper rod fully into the bracket hole. ● Make sure that the upper rod and lower rod of the stand are not reversed. ● Make sure not to press down the rod firmly or it may be damaged. Reverse the procedures of the above steps if you need to disassemble the stands. ● Make sure to check whether the rods are fully inserted prior to use. The …
