2AV96NM-WCH302WIRELESS CHARGER CUP HOLDER

Car wireless charging cup holder manual Thank you for purchasing our product, this item is a car multi-function wireless charging cup holder, using WPC QI standard wireless charging technology, compatible with QI standard wireless charging mobile phone use, while extending 2 USB interface output, can be given to multiple mobile phones.It is used for charging, and has a cup holder storage device, which is simple and easy to use. Product description: 1. Product Description: Product exploded view + product description 2. Specifications: Product name: Car wireless cup holder Input size: DC-5V / 2A Wireless power: 10w USB output: 5V / 1A Material: ABS Applicable mobile phones: Iphone11, XS, X, 8, Samsung Glaxy Note 8, S8, S9, S10, HUAWEI Mate30, P30, etc 3. Installation instructions: 1. Installation Instructions: Assemble the on-board wireless charging cup holder, insert the bracket in the front passenger seat slot and fix it, the Type-c data cable is connected to the on-board power supply, and the normal charging indicator lights up in green. 2. Instructions for use (Please remove the shell of your phone before using the charging function to avoid unsuccessful charging): 1. Wireless output: The wireless charging function is only applicable to mobile phones with wireless charging function 2. USB output: Match the correct USB cable to charge the device 3. Wireless cup holder: Cup holder storage 4. Matters needing attention: 1. When the current of the input power supply is insufficient, it does not support the use of USB and wireless charging at the same time 2. Do not squeeze, bump or pull the power cord to avoid damage to electronic products 3. Do not cancel or take fire and water to avoid short circuit 4. Do not use it under severe distortion or harsh environment to avoid damage to the internal circuit of the device 5. Do not place the magnetic or magnetic card (visa, etc.) too close to avoid demagnetization of the magnetic card 6. Do not let children or pets play with the equipment, the brakes will cause additional accidents 7. Do not use approved or incompatible power adapters to avoid damage to the device or other hazards 8. Please dispose of the equipment in accordance with local regulations, and do not treat the equipment as domestic waste FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum 20cm distance between the radiator your body: Use only the supp lied antenna.

(Ningbo Oceanspring Fitness Equipment Co., Ltd. ) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AV96NM-WCH302 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description Block Diagram Schematics Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ( Jason Zhu) Rev 11/20/07

(Ningbo Oceanspring Fitness Equipment Co., Ltd.) Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: SUBJECT: FCC Application for FCC ID: ZAV96NM-WCH302 To Whom It May Concern: We, the undersigned, hereby authorize Andy Yuan at Shenzhen BCTC Testing Co., Ltd. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Andy Yuan of Shenzhen BCTC Testing Co., Ltd. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, ( Jason Zhu)

External Photos

Model: NM-WCH302 FCC ID:2AV96NM-WCH302 Label Location

Internal Photos Antenna

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-1E RF EXPOSURE REPORT For FCC ID: 2AV96NM-WCH302 Product Name: WIRELESS CHARGER CUP HOLDER Trademark: N/A Model Number: NM-WCH302 Prepared For : Ningbo Oceanspring Fitness Equipment Co., Ltd. Address : No. 290, Zhenxing South Road, Simen Town, Yuyao City, Zhejiang province, China Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Apr. 16, 2020 to Apr. 22, 2020 Date of Report : Apr. 22, 2020 Report No.: BCTC2004001010-1E Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 09 Ver.：A.0 Page 1 of 12 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-1E TEST RESULT CERTIFICATION Applicant’s name ................. : Ningbo Oceanspring Fitness Equipment Co., Ltd. Address ................................. : No. 290, Zhenxing South Road, Simen Town, Yuyao City, Zhejiang province, China Manufacture's Name ............ : Ningbo Oceanspring Fitness Equipment Co., Ltd. Address ................................. : No. 290, Zhenxing South Road, Simen Town, Yuyao City, Zhejiang province, China Product description Product name ............................ : WIRELESS CHARGER CUP HOLDER Trademark ........................... : N/A Model and/or type reference : NM-WCH302 Serial Model : N/A Power Supply : AC120/60Hz Standards ............................. : FCC CFR 47 part1, 1.1307(b), 1.1310 This device described above has been tested by BCTC, and the test results show that the equipment under And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Prepared by(Engineer): Cai Fangzhong Reviewer(Supervisor): Eric Yang Approved(Manager): Zero Zhou Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 09 Ver.：A.0 Page 2 of 12 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-1E Table of Contents Page 1 . GENERAL INFORMATION 4 1.1 . Independent Operation Mode 4 1.2 . Test Supporting System 4 2 .LIST OF TEST AND MEASUREMENT INSTRUMENTS 5 2.1 . For conducted emission at the mains terminals test 5 3. METHOD OF MEASUREMENT 6 3. 1.Applicable Standard 6 3. 2. Test Modes 6 3. 3. MAXIMUM PERMISSIBLE EXPOSURE 6 4. TEST RESULT 7 4.1. Conducted Emission at the Mains Terminals Test 7 4.2. Equipment Approval Considerations: 8 4.3. E and H field Strength 9 5. Photographs of test set-up 10 Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 09 Ver.：A.0 Page 3 of 12 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-1E 1. GENERAL INFORMATION 1.1. Independent Operation Mode The basic operation mode is: 1.1.1. Charging 1.2. Test Supporting System Adapter Description : Adapter Model No. : BCTC-002 Power Input : AC 100-240V~50/60Hz Output: 5V 2A DC Line : Unshielded, Detachable 1m Mobile phone Model No. : iphone8P Model No. : iphone Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 09 Ver.：A.0 Page 4 of 12 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-1E 2.LIST OF TEST AND MEASUREMENT INSTRUMENTS 2.1. For conducted emission at the mains terminals test Equipment Manufacturer Model No. Serial No. Last Cal. Next Cal. Exposure Level Tester Narda ELT-400 N-0231 Jul. 15, 2019 Jul. 14, 2020 Magnetic field probe 100cm2 Narda B-Field Probe 100cm2 M0675 Jul. 15, 2019 Jul. 14, 2020 843 Chamber ETS 843 84301 Aug. 27, 2018 Aug. 26, 2021 Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 09 Ver.：A.0 Page 5 of 12 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-1E 3. METHOD OF MEASUREMENT 3. 1.Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure is calculated. According KDB680106 D01v03: RF Exposure Wireless Charging Apps v02. 3. 2. Test Modes Test Modes keeping TX+Charging mode 3. 3. MAXIMUM PERMISSIBLE EXPOSURE Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 09 Ver.：A.0 Page 6 of 12 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-1E 4. TEST RESULT 4.1. Conducted Emission at the Mains Terminals Test Note: Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device Test Procedure: a) The RF exposure test was performed on 360 degree turn table in anechoic chamber. b) The measurement probe was placed at test distance (15cm) which is between the edge of the charger and the geometric centre of probe. c) The turn table was rotated 360d degree to search of highest strength. d) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E) were completed. e) The EUT were measured according to the dictates of KDB 680106D01v03. Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 09 Ver.：A.0 Page 7 of 12 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-1E 4.2. Equipment Approval Considerations: The EUT does comply with item 5(b) of KDB 680106 D01v03 1) Power transfer frequency is less than 1MHz Ye s , the device operate in the frequency range from 120KHz to 220 KHz 2) Output power from each primary coil is less than or equal to 15 watts. Ye s , the maximum output power of the primary coil is 15W. 3) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that able to detect and allow coupling only…

Text truncated - open the document above for the full version.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-2E FCC TEST REPORT FCC ID: 2AV96NM-WCH302 Product Name: WIRELESS CHARGER CUP HOLDER Trademark: N/A Model Number: NM-WCH302 Prepared For : Ningbo Oceanspring Fitness Equipment Co., Ltd. Address : No. 290, Zhenxing South Road, Simen Town, Yuyao City, Zhejiang province, China Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Apr. 16, 2020 to Apr. 22, 2020 Date of Report : Apr. 22, 2020 Report No.: BCTC2004001010-2E Test Report Tel: 400-788-9558 We b : https://www.bctc-lab.com BCTC/RF-EMC-0 13 Ve r.：A.0 Page 1 of 23 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-2E TABLE OF CONTENTS TEST REPORT DECLARATION .................................................................................................. 3 1. GENERAL INFORMATION ........................................................................................................ 4 1.1. Report information .......................................................................................................................... 4 1.2. Measurement Uncertainty .............................................................................................................. 4 1.3. Test Facility ...................................................................................................................................... 4 1.4. Test Uncertainty .............................................................................................................................. 4 2. PRODUCT DESCRIPTION ......................................................................................................... 5 2.1. EUT Description .............................................................................................................................. 5 2.2. Test mode ........................................................................................................................................ 5 2.3. Block Diagram of EUT Configuration ........................................................................................... 5 2.4. Test Conditions ................................................................................................................................ 5 2.5. Description Of Support Units (Conducted Mode) ....................................................................... 6 3. TEST RESULTS SUMMARY ..................................................................................................... 6 4. TEST EQUIPMENT USED.......................................................................................................... 7 4.1. For Conducted Emission Test ....................................................................................................... 7 4.2. For Radiated Emission Measurement ......................................................................................... 7 5. CONDUCTED EMISSION TEST ................................................................................................ 9 5.1. Block Diagram of Test Setup ......................................................................................................... 9 5.2. Test Standard .................................................................................................................................. 9 5.3. Conducted Emission Limit ............................................................................................................. 9 5.4. EUT Configuration on Test ............................................................................................................ 9 5.5. Operating Condition of EUT ........................................................................................................ 10 5.6. Test Procedure .............................................................................................................................. 10 5.7. Test Result ..................................................................................................................................... 10 6. RADIATED EMISSION MEASUREMENT ............................................................................. 13 6.1. Block Diagram of Test Setup ....................................................................................................... 13 6.2. Test Standard and Limit ............................................................................................................... 14 6.3. EMI Test Receiver Setup ............................................................................................................. 15 6.4. Test Procedure .............................................................................................................................. 15 6.5. Test Result ..................................................................................................................................... 15 7. BANDWIDTH TEST ................................................................................................................... 19 8. EUT TEST PHOTOS .................................................................................................................. 21 9. EUT PHOTOS ............................................................................................................................. 23 Test Report Tel: 400-788-9558 We b : https://www.bctc-lab.com BCTC/RF-EMC-0 13 Ve r.：A.0 Page 2 of 23 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-2E TEST REPORT DECLARATION Applicant : Ningbo Oceanspring Fitness Equipment Co., Ltd. Address : No. 290, Zhenxing South Road, Simen Town, Yuyao City, Zhejiang province, China EUT Description : WIRELESS CHARGER CUP HOLDER Model Number : NM-WCH302 Test Standards: FCC Part 15 C This device described above has been tested by BCTC, and the test results show that the equipment under An…

Text truncated - open the document above for the full version.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-1E 5. Photographs of test set-up Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 10 of 12 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-1E Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 11 of 12 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-1E ※※※※※ END OF REPORT ※※※※※ Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 12 of 12 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-2E 8. EUT TEST PHOTOS Conducted Measurement Photos Test Report Tel: 400-788-9558 We b : https://www.bctc-lab.com BCTC/RF-EMC-0 13 Ve r.：A.0 Page 21 of 23 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2004001010-2E Radiated Measurement Photos 9KHz-30MHz 30MHz-1GHz Test Report Tel: 400-788-9558 We b : https://www.bctc-lab.com BCTC/RF-EMC-0 13 Ve r.：A.0 Page 22 of 23
