2AVBL-VC1SXLoRa Mesh Wireless Transceiver Module

第 1 页 19页 File name: vc1sx-1276b-g4 wireless module used Documentation Date: 2017.10.27 Document Number: vc-qw-0a-2017-10 Implementation date: 2017.10.27 vc1sx-1276b-g4 wireless module Use document v1.1 Preparation / Date: 2017-07- 10 Audit / Date: 2017-07-11 Approval / Date: 2017-07-12 Shanghai Entropy Internet of Things Technology Co., Ltd. 第 2 页 19页 File name: vc1sx-1276b-g4 wireless module used Documentation Date: 2017.10.27 Document Number: vc-qw-0a-2017-10 Implementation date: 2017.10.27 Version v1.1 version number editor time instruction manual V1.0 Li Teng 2016-08-02 Initial version, all functions are implemented V1.1 Pei Liqun 2017-03-25 Add test bit error rate Version v1.1 ......................................................................................................................................................... 2 1.Description ....................................................................................................................................................... 4 Application field ................................................................................................................................................ 4 3.Technical characteristics ................................................................ ............................................................. 5 4.Technical parameters ................................................................ ...................................................................... 6 5.Interface definition ................................................................ ...................................................................... 7 6.Serial communication protocol ...................................................................................................................... 8 6.1. Data Frame ........................................................................................................................................................ 9 6.1.1. Delivery (module serial port receiving) .......................................................................................... 9 6.1.2. Data frame upload (wireless data reception completion triggers module serial port transmission) .............................................................................................................................................................. 9 6.1.3. About address ........................................................................................................................................... 10 6.1.4. Recommended minimum interval for serial port transmission .................................................... 10 6.2. Command frame ................................................................................................................................................ 10 6.3. Parameter settings are not read ............................................................................................................ 13 6.4. set_a, aux, set_b foot definition ........................................................................................................ 15 6.5. Configuration Tool ...................................................................................................................................... 15 7. Precautions for RF frequency point selection ........................................................................................ 16 8. Transmit power and receiving sensitivity test ...................................................................................... 16 9, attached: ....................................................................................................................................................... 17 9.1, version information ...................................................................................................................................... 17 9.2. Command frame crc16 algorithm .................................................................................................................. 17 File name: vc1sx-1276b-g4 wireless module used Documentation Date: 2017.10.27 Document Number: vc-qw-0a-2017-10 Implementation date: 2017.10.27 9.3. Examples ............................................................................................................................................................ 18 9.4 、 Parameter setting packing instruction ............................................................................................... 19 10. Technical support and after-sales service .......................................................................................... 19 第 3 页 File name: vc1sx-1276b-g4 wireless module used Documentation Date: 2017.10.27 Document Number: vc-qw-0a-2017-10 Implementation date: 2017.10.27 1.Description VC1SX-1276B type wireless communication module is highly integrated with ultra-low- power half-duplex micro-power wireless data transmission module, using LORA chip SX1276, embedded with high-speed single-chip microcomputer and high-performance radio frequency chip. LoRa TM spread spectrum modulation frequency hopping technology, communication The distance and receiving sensitivity are far beyond the current FSK and GFSK modulation. Multiple transmission signals occupy the same channel and are not affected. It has strong anti-interference. VC1SX-1276B wireless communication series modules provide flexible channels. Various parameters such as settings, transmit power, frequency, etc. At the same time, the module has a low-power sleep function, and the sleep current is less than 2.5uA; the module supports the low-power carrier sensing protocol, and the module can automatically exit from sleep at regular intervals to listen to air data, It automatically sleeps after data transmission, which is convenient for various battery-powered systems, especially gas meters and water meters. The VC1SX-1276B-G4 module has a built-in LoraMesh protocol independently develop…

Text truncated - open the document above for the full version.

SingleModular approval Declaration letter We ，Zhejiang Eastron Electronic Co.,Ltd. apply Single modular approval for Product Name: LoRa Mesh Wireless Transceiver Module Model: VC1SX-1276B-G4 FCC ID: 2AVBL-VC1SX According to 996369 D01 Module Equip Auth Guide v01r04 and 15.212 requirement: 1) The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly; Answer ：Yes. The modular equip with own RFshielding. 2) The module must have buffered modulation/data inputs to ensure that the device willcomply with Part 15 requirements with any type of input signal; Answer ：Yes ；All inputs to the modules are buffered through logic or microprocessor inputs. 3)The modular transmitter must have its own power supply regulation. Answer ：Yes ；A low drop out regulator is used for modular power supply regulation. 4) The module must contain a permanently attached antenna, or contain a unique antennaconnector, and be marketed and operated only with specific antenna(s), per Sections15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b); Answer ：Yes ；Device is equipped with integral antenna. (5) The module must demonstrate compliance in a stand-alone configuration; Answer ：Yes，EUT was test stand alone ，refer to setup photo. (6) The module must be labeled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labeling requirements); Answer ：Yes ；The modular has a permanent fixed label, and below statement was listed in the User Manual;The host device must be labeled to display the FCCID of the module “Contains FCC ID: 2AVBL-VC1SX” (7) The module must comply with all specific rules applicable to the transmitter includingall the conditions provided in the integration instructions by the grantee; Answer ：Yes ；The module comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee, Refer to test report and user manual . (8) The module must comply with RF exposure requirements Answer ：Yes ；The module meets the minimum requirements of RF exposure. Please contact me if you have any further questions. Thanks for your attention. Best Regards, Signature: Name: Eason Gu Title: sales manager Company: Zhejiang Eastron Electronic Co.,Ltd.

< Zhejiang Eastron Electronic Co.,Ltd.> Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD21046 Date:12-20-2019 Subject; Request for Long Term Confidentiality FCC ID: 2AVBL-VC1SX To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Eason Gu Title: sales manager

Zhejiang Eastron Electronic Co.,Ltd. Letter of Authorization Company: Zhejiang Eastron Electronic Co.,Ltd. Address: No.1369, Chengnan Road, Economic and technological development District, Jiaxing, Zhejiang, China Product Name: LoRa Mesh Wireless Transceiver Module Model Number(s): VC1SX-1276B-G4 Product Description: LoRa Mesh Wireless Transceiver Module We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2019-12-20 Name: Eason Gu Title: sales manager Company: Zhejiang Eastron Electronic Co.,Ltd.

Size: 15*5mm Label location

Global United Technology Services Co., Ltd. Report No.: GTS201912000164F01 Test Report Applicant: Zhejiang Eastron Electronic Co.,Ltd. Address of Applicant: No.1369, Chengnan Road, Economic and technological development District, Jiaxing, Zhejiang, China Manufacturer: Shanghai Shangquan IoT Co., Ltd. Address of Manufacturer: Room 501, Building 1, No. 615, Ningqiao Road, Pudong New District, Shanghai, China Equipment Under Test (EUT) Product Name: LoRa Mesh Wireless Transceiver Module Model No.: VC1SX-1276B-G4 Trade Mark: Shangquan FCC ID: 2AVBL-VC1SX Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249 Date of sample receipt: December 17, 2019 Date of Test: December 17-20, 2019 Date of report issued: December 20, 2019 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Authorized Signature: Robinson Lo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 30 Report No.: GTS201912000164F01 2 Version Version No. Date Description 00 December 20, 2019 Original Prepared By: Date: December 20, 2019 Project Engineer Check By: Date: December 20, 2019 Reviewer Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 30 Report No.: GTS201912000164F01 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 4.1 MEASUREMENT UNCERTAINTY ............................................................................................................ 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 TEST MODE ........................................................................................................................................ 6 5.3 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 6 5.4 DEVIATION FROM STANDARDS ............................................................................................................. 6 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................... 6 5.6 TEST FACILITY .................................................................................................................................... 6 5.7 TEST LOCATION ................................................................................................................................. 6 6 TEST INSTRUMENTS LIST ..................................................................................................................... 7 7 TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 9 7.1 ANTENNA REQUIREMENT ..................................................................................................................... 9 7.2 CONDUCTED EMISSIONS ................................................................................................................... 10 7.3 RADIATED EMISSION METHOD ........................................................................................................... 13 7.3.1 Field Strength of The Fundamental Signal ................................................................................ 15 7.3.2 Spurious emissions .................................................................................................................... 16 7.4 20DB OCCUPY BANDWIDTH .............................................................................................................. 28 8 TEST SETUP PHOTO ............................................................................................................................ 30 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 30 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 30 Report No.: GTS201912000164F01 4 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203 Pass AC Power Line Conducted Emission 15.207 Pass Field strength of the fundamental signal 15.249 (a) Pass Spurious emissions 15.249 (a) (d)/15.209 Pass Band edge 15.249 (d)/15.205 Pass 20dB Occupied Bandwidth 15.215 (c) Pass Remarks： 1. Pass: The EUT complies with the essential requirements in the standard. 2. Test according to ANSI C63.10:2013. 4.1 Measurement Uncertainty Test Item Frequency Range Measurement Uncertainty Notes Radiated Emission 30MHz-200MHz 3.8039dB (1) Radiated Emission 200MHz-1GHz 3.9679dB (1) Radiated Emission 1GHz-18GHz 4.29dB (1) Radiated Emission 18GHz-40GHz 3.30dB (1) AC Power Line…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
