2AVCI-QYS-05WIRELESS HEADPHONE

User manual QYS‐05 Product Features: 1.Power consumption:≤40mW 2.Working voltage: DC 3.7V 3.Charge Voltage: DC5V/500mA 4.Battery capacity: Rechargeable 200mAh 5.Frequency range:20Hz‐20Khz 6.Charging time:1‐2hours 7.Play time：3‐5 hours 8.BT version: 5.0 9.Microphone sensitivity: ‐32db 10.Working range: 10 meters 11.Support HSP/HFP/A2DP/AVRCP Introduction: Thank you for purchasing the QYS‐05.Please read the manual fully before using this device.Keep the manual for your further reference. IMPORTANT SAFEGUARDS When using electrical appliances, basic safety should always be followed. Read and familiarity yourself with all operating instructions before using your Bluetooth Headphones. Before using your Bluetooth Headphones, visually check that the unit is intact and has not suffered any transit damage. Only charge the headphones from a suitable USB outlet, any other power source may cause permanent damage to the headphones. The headphones must be fully charged via the USB port before use. Never allow children to play with the headphones. Small parts may be a choking hazard. Do not allow the USB charging cable to hang over sharp edges or come in contact with hot surfaces. These headphones are intended for household use only and should not be used for industrial purposes. Do not use these headphones for anything other than its intended use. Do not immerse the headphones in water or any other liquids. Do not expose the headphones to moisture, rain or humidity, as it is not waterproof. Before cleaning, ensure the earphones are not connected to the USB supply. Never clean the headphones with solvents or harsh or abrasive cleaners. Do not attempt to dismantle the earphones, it does not contain any user serviceable parts. Whilst not in use, store the earphones in a cool dry place free from extreme temperatures, humidity or dust. Operation Fully chargers the headphone battery for the first time using.To charge,insert the micro usb Cable into the charging port,and connect to a power source.When it is charging,the indicator light will glow red.After it had finished charging,the indicator light will go off.It takes 2‐3 hours to charge. When the headphone is running out of battery ,an alarm sound will be heard.Pls charge the battery immediately.If the headphone are used after this warning,the will automatically turn off after 3‐5 minutes. POWER ON/OFF 1.Power on :Press and hold the “PHONE/POWER “button for 3 seconds then release to turn on the headphone, the indicator light will flash blue and red. It is to indicate that the headphone is get ready to connect. 2.Power off:Press and hold the “PHONE/POWER” button for 3 seconds to turn the headphone off,then the indicator light will go off. HOW TO PAIR THE HEADPHONE. 1. Turn on the headphone.The headphone’s indicator light will flash blue and red.Then the headphone is get ready to pair. 2. Turn on the Bluetooth function on your cellphone 3. Search the Device name”QYS‐05” to connect it,if required,enter the code’0000”. 4. The indicator will keep blue after successfully paired. 5. The indicator will flash blue alternately while is working. NOTE: once the headphone is paired with your cellphone ,you can stream audio and answer/made the call freely . BLUETOOTH MODE 1. ANSWER/END A CALL 1.When a call comes in ,Quick press the “PHONE” button once to answer,press again to end the call. 2.Adjusting the volume: Press and hold the (+)or(‐) button to adjust the level you want to be.While the volume goes to max, an alarm sound will be heard. 3.To make the call :While the headphone is in Bluetooth mode , double quick press the “PHONE” button to make a call which the last number you dial list on your phone. 3.Reject a call Press and hold the” PHONE” button for 2 seconds then release it. to reject a call Playing Audio 2.In Bluetooth mode, connect your device to the headphone,then could listen the music easily . 3.Press next track and previous track button once to select the song you desired. 4.Press and hold the (+) or (‐) button to adjust the level you want to be. 5.While the volume goes to max, an alarm sound will be heard. 6.Press the play/pause button once to play the music,press again to stop playing. Playing Music from a TF Card 1. Insert a TF card (pre‐loaded with audio tracks – Mp3, WAV, files etc.) into the TF Card slot ( support 32GB capacity max) 2. The tracks on the card will begin to play automatically. 3. Press the Play/Pause button to start playing music, press the button again to pause playing music. 4. Press and hold down “+”to increase the volume level. 7.Press and hold down the “‐” button to decrease the volume level. 6. Briefly Press the Next Track button to next track. 7. Briefly Press the Previous Track button to the previous track. FM MODE 1. Press and hold the PLAY/PAUSE button for 2 second until enter into the FM mode,then press the play/pause button again to scan and memorize the FM radio stations. 2.Press the next track /previous track button to select the desired channels.Press and hold the (+)or(‐) button to adjust the volume. NOTE: If you want to change the playing mode. Press and hold the PLAY/PAUSE button for 2 second ,it will return to TF/FM/Bluetooth mode automatically. WIRED HEADPHONE 1.Plug the 3.5mm cable to “line in “port and plug the other side to the computer or other music device then could work as a wired headphone. 2.When using the headphones in AUX mode, only the source device could control the play/pause and output volume. 3.While in AUX mode , Bluetooth function/FM/ TF will not work. FCC Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designe…

Text truncated - open the document above for the full version.

HUIZHOU YESONG TECHNOLOGY CO.,LTD 3-4/F NO.146 XI KENG INDUSTRIAL ZONE,HUIHUAN STREET, ZHONGKAI HIGH TECH AREA,HUIZHOU CITY, GUANGDONG, CHINA Tel: +86-13760443407 Email: [email protected] Series Models Description Date: 2019/12/10 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD FCC ID: 2AVCI-QYS-05 Dear Sir/Madam, We, HUIZHOU YESONG TECHNOLOGY CO.,LTD Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only color and model number is different for these model: Product name: WIRELESS HEADPHONE Model no.: QYS-05, LaBoca, FON-6710, ET-A4324B Sincerely, Name: Xiankui Yin Company: HUIZHOU YESONG TECHNOLOGY CO.,LTD Address: 3-4/F NO.146 XI KENG INDUSTRIAL ZONE,HUIHUAN STREET, ZHONGKAI HIGH TECH AREA,HUIZHOU CITY, GUANGDONG, CHINA Phone: +86-13760443407 Fax: N/A E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: Dec.10, 2019 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AVCI-QYS-05 QYS-05, LaBoca, FON-6710, ET-A4324B For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Xiankui Yin Company: HUIZHOU YESONG TECHNOLOGY CO.,LTD Address: 3-4/F NO.146 XI KENG INDUSTRIAL ZONE,HUIHUAN STREET, ZHONGKAI HIGH TECH AREA,HUIZHOU CITY, GUANGDONG, CHINA Phone: +86-13760443407 Fax: N/A E-Mail: [email protected]

HUIZHOU YESONG TECHNOLOGY CO.,LTD 3-4/F NO.146 XI KENG INDUSTRIAL ZONE,HUIHUAN STREET, ZHONGKAI HIGH TECH AREA,HUIZHOU CITY, GUANGDONG, CHINA Tel: +86-13760443407 Email: [email protected] Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 1/6/2020 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AVCI-QYS-05 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name: Xiankui Yin Company: HUIZHOU YESONG TECHNOLOGY CO.,LTD Address: 3-4/F NO.146 XI KENG INDUSTRIAL ZONE,HUIHUAN STREET, ZHONGKAI HIGH TECH AREA,HUIZHOU CITY, GUANGDONG, CHINA Phone: +86-13760443407 Fax: N/A E-Mail: [email protected]

FCC ID: 2AVCI-QYS-05

BT antenna

RF Exposure evaluation FCC ID: 2AVCI-QYS-05 Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.1. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.2. Manufacturing tolerance GFSK Channel Channel 00 Channel 39 Channel 78 Target (dBm) 1.0 1.0 1.0 Tolerance ±(dB) 1.0 1.0 1.0 π/4DQPSK Channel Channel 00 Channel 39 Channel 78 Target (dBm) 1.0 1.0 1.0 Tolerance ±(dB) 1.0 1.0 1.0 8DPSK Channel Channel 00 Channel 39 Channel 78 Target (dBm) 1.0 1.0 1.0 Tolerance ±(dB) 1.0 1.0 1.0 2. Evaluation Result Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BT 2.480 5 0 1.585 0.5<3.0 Yes 3. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06, No SAR is required. .....................End.........................

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : GTS20191205005-1-5 2AVCI-QYS-05 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Dec. 09, 2019 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : HUIZHOU YESONG TECHNOLOGY CO.,LTD Address ............................................ : 3-4/F NO.146 XI KENG INDUSTRIAL ZONE,HUIHUAN STREET, ZHONGKAI HIGH TECH AREA,HUIZHOU CITY, GUANGDONG, CHINA Test specification ...........................: Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: WIRELESS HEADPHONE Trade Mark ....................................... : N/A Manufacturer .................................... : HUIZHOU YESONG TECHNOLOGY CO.,LTD Model/Type reference....................... : QYS-05 Listed Models .................................. : LaBoca, FON-6710, ET-A4324B Modulation Type ............................... : GFSK, Π/4DQPSK, 8DPSK Operation Frequency ........................ : From 2402MHz to 2480MHz Rating ............................................... : DC 3.7V from battery Result................................................ : PASS Report No.: GTS20191205005-1-5 Page 2 of 48 T E S T R E P O R T Test Report No. : GTS20191205005-1-5 Dec. 09, 2019 ____________________________________________________________________________________ Date of issue Equipment under Test : WIRELESS HEADPHONE Model /Type : QYS-05 Listed Models : LaBoca, FON-6710, ET-A4324B Applicant : HUIZHOU YESONG TECHNOLOGY CO.,LTD Address : 3-4/F NO.146 XI KENG INDUSTRIAL ZONE,HUIHUAN STREET, ZHONGKAI HIGH TECH AREA,HUIZHOU CITY, GUANGDONG, CHINA Manufacturer : HUIZHOU YESONG TECHNOLOGY CO.,LTD Address : 3-4/F NO.146 XI KENG INDUSTRIAL ZONE,HUIHUAN STREET, ZHONGKAI HIGH TECH AREA,HUIZHOU CITY, GUANGDONG, CHINA Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20191205005-1-5 Page 3 of 48 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E NT .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 13 4.3 Maximum Peak Output Power 20 4.4 20dB Bandwidth 21 4.5 Frequency Separation 25 4.6 Number of hopping frequency 27 4.7 Time of Occupancy (Dwell Time) 29 4.8 Out-of-band Emissions 33 4.9 Pseudorandom Frequency Hopping Sequence 41 4.10 Antenna Requirement 42 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 43 6 P H O T O S O F TH E E U T ........................................................... 44 Report No.: GTS20191205005-1-5 Page 4 of 48 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices Report No.: GTS20191205005-1-5 Page 5 of 48 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Dec. 02, 2019 Testing commenced on : Dec. 03, 2019 Testing concluded on : Dec. 08, 2019 2.2 Product Description Product Name: WIRELESS HEADPHONE Model/Type reference: QYS-05 Power supply: DC 3.7V from battery Adapter(Auxiliary test Provided by the laborator) Mode:EP-TA20CBC Input:AC100-240V-50/60Hz，0.5A Output:DC 5V,2A Bluetooth : Supported Type: Bluetooth BR/EDR Modulation: GFSK, π/4DQPSK, 8DPSK Operation frequency: 2402MHz~2480MHz Channel number: 79 Channel separation: 1MHz Antenna type: PCB antenna Antenna gain: 0dBi 2.3 Equipment Under Test Power supply system utilised Power supply voltage : ○ 230V / 50 Hz ○ 120V / 60Hz ○ 12 V DC ○ 24…

Text truncated - open the document above for the full version.
