2AVE3SHD2-75ASeura Outdoor Entertainment

PAN International (USA)
Seura Outdoor Entertainment - FCC ID 2AVE3SHD2-75A - PAN International (USA)
Click to zoom

Application Details

Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Date of Grant
Jul 28, 2020
Application Purpose
Original Equipment
Date of Application
Jul 27, 2020
Equipment Note
Seura Outdoor Entertainment
Frequency Range
2402.00000000 - 2480.00000000
Company
PAN International (USA)
Country
United States

Documents & Files

Select a file to view

Users Manual

↗
↗
↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

FCC supplier’s Declaration of Conformity SĂ©ura Outdoor Entertainment / SHD2-43, SHD2-55, SHD2-65, SHD2-75 This device complies with part 15 of the FCC Rules. Operation is subject to the follow two conditions: (1) This device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation. PAN International Address: 48008 Fremont Blvd, Fremont, CA 94538 United States Phone number: 510-623-3810

Users Manual

WELCOME GUIDE Shade Series ℱ SHD2-43 SHD2-55 SHD2-65 SHD2-75 2 3 A warning that an apparatus with class I construction shall be connected to a MAINS socket outlet with a protective earthing connection WARNING To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions. Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable; The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus. To reduce the risk of fire or electric shock, do not expose the inside of this apparatus to rain or moisture. The inside of this apparatus shall not be exposed to dripping or splashing. Un avertissement qu’un appareil de construction de CLASSE I doit ĂȘtre connecte Ă  un socle du rĂ©seau d’alimentation muni d’une connexion Ă  la terre de protection. ATTENTION Pour Ă©viter tout accident, cet appareil doit ĂȘtre fixe de façon sure au sol ou au mur conformĂ©ment aux instructions d’installation. Lorsque la prise du RESEAU D’ALIMENTATION ou une prise placĂ©e sur l’appareil est utilisĂ©e comme dispositif de dĂ©connexion, ce dispositif doit demeure aisĂ©ment accessible; Le mode d’emploi doit stipuler que l’appareil ne doit pas ĂȘtre expose Ă  des Ă©gouttements d’eau ou des Ă©claboussures et de plus qu’aucun objet rempli de liquide tel que des vases ne doit ĂȘtre place sur l’appareil. Pour rĂ©duire le risque d’incendie ou de choc Ă©lectrique, ne pas exposer l’intĂ©rieur de cet appareil Ă  la pluie ou Ă  l’humiditĂ©. L’intĂ©rieur de cet appareil ne doit pas ĂȘtre exposĂ© Ă  des gouttes ou des Ă©claboussures. WARNINGS AVERTISSEMENTS 4 This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. This symbol is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the appliance. WARNING: READ ALL INSTRUCTIONS BEFORE ATTEMPTING TO INSTALL OR SERVICE THIS PRODUCT. Warnings: Do not handle or remove your outdoor display from the packaging until it is ready to be installed. To avoid damage to the outdoor display, only transport it in a vertical position. It is highly recommended that at least two (2) persons assist in the installation of the outdoor display. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT OPEN BACK PANEL, NO USER-SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Do not submerge SĂ©ura Âź Outdoor Display in water: The SĂ©ura Âź Outdoor Display will resist water exposure from normal rain, sprinklers, snow, etc.; however, it is not designed to be submerged in water. Do not wash with garden hose or pressure-wash: SĂ©ura Âź Outdoor Display will resist water exposure from normal rain, sprinklers, snow etc.; however, it is not designed to withstand pressure washers, high-pressure water jets, projected snow from a blower, or hurricane-type weather. Do not let metal pieces or objects of any kind fall into the display. High voltage flows in the product, and inserting an object can cause electric shock and/or short internal parts. To prevent fire, never place any type of candle or flames on the top or near the display. To prevent fire or shock hazard, do not place the AC cord under the display or other heavy items. Power Lines An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal. Accessories Do not use accessories not specifically recommended by the manufacturer. Use of improper attachments can result in accidents. 5 Ce symbole est destinĂ© Ă  alerter l’utilisateur de la prĂ©sence d’une «tension dangereuse» non isolĂ©e Ă  l’intĂ©rieur de l’enceinte du produit qui peut ĂȘtre d’une amplitude suffisante pour constituer un risque de choc Ă©lectrique pour les personnes. Ce symbole est destinĂ© Ă  alerter l’utilisateur de la prĂ©sence d’instructions importantes d’utilisation et de maintenance dans la documentation accompagnant l’appareil. AVERTISSEMENT: LIRE TOUTES LES INSTRUCTIONS AVANT D’INSTALLER OU SERVICE CE PRODUIT. Avertissements: Ne pas manipuler ou supprimer votre moniteur extĂ©rieure de l’emballage jusqu’ Ă  ce qu’ il soit prĂȘt Ă  ĂȘtre installĂ©. Pour Ă©viter d’endommager la moniteur en plein air, seul le transporter dans une position verticale. Il est fortement recommandĂ© qu’au moins deux (2) personnes aident Ă  l’ installation de la moniteur en plein air. CAUTION RISQUE DE CHOC ELECTRIQUE. NE PAS OUVRIR. ATTENTION: POUR RÉDUIRE LE RISQUE DE CHOC ÉLECTRIQUE, NE RETIREZ PAS LE CAPOT (NI L’ARRIÈRE), AUCUNE PIÈCE RÉPARABLE PAR L’UTILISATEUR, RÉFÉREZ L’ENTRETIEN AU PERSONNEL DE SERVICE QUALIFIÉ. N’ immergez pas le SĂ©uraÂź Outdoor moniteur dans l’eau: le moniteur SĂ©uraÂź Outdoor rĂ©sistera Ă  l’exposition Ă  l’eau causĂ©e par la pluie, les gicleurs, la neige, etc. Cependant, il n’est pas conçu pour ĂȘtre immergĂ© dans l’eau. Ne lavez pas avec un tuyau d’arrosage ou avec un nettoyeur haute pression: SĂ©uraÂź Outdoor moniteur rĂ©sistera Ă  l’exposition Ă  l’eau causĂ©e par la pluie, les sprinklers, la neige, etc. Cependant, il n’est pas conçu pour rĂ©sister aux laveuses Ă  pression, aux jets d’eau Ă  haute pression, aux projections de neige d’un ventilateur ou aux intempĂ©ries de type ouragan. Ne laissez pas de morceaux de mĂ©tal ou d’objets de toute sorte tomber dans la moniteur. Une tension Ă©levĂ©e circule dans le produit et l’ insertion d’un objet peut provoquer un choc Ă©lectrique et / ou un court-circuit des piĂšces internes. Pour Ă©viter les incendies, ne placez jamais de bougies ni de fl


Text truncated - open the document above for the full version.

Users Manual

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and any part of your body.

External Photos

UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. Appendix I External Photographs Page 2 of 6 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. . . All View of EUT Front View of EUT Page 3 of 6 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. . . Back View of EUT-1 Back View of EUT-2 Page 4 of 6 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. . . Back View of EUT-3 Back View of EUT-4 Page 5 of 6 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. . . Top View of EUT Bottom View of EUT Page 6 of 6 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. . . Left View of EUT Right View of EUT

ID Label/Location Info

Dec 25,2019 Produce Date 90106-36280

Internal Photos

Appendix II Internal Photographs Page 2 of 9 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. . Open View of EUT-1 Open View of EUT-2 Page 3 of 9 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. . Open View of EUT-3 Open View of EUT-4 Page 4 of 9 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. . Open View of EUT-4 Internal View of EUT-1 Page 5 of 9 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. . Internal View of EUT-2 Internal View of EUT-3 Page 6 of 9 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. . Internal View of EUT-4 Internal View of EUT-5 Page 7 of 9 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. . Internal View of EUT-6 Internal View of EUT-7 Page 8 of 9 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. . Antenna location RF Module location-1 Page 9 of 9 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. . RF Module location-2 RF Module location-3

RF Exposure Info

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. This report does not imply that the product(s) has met the criteria for certification. FFCC RF EXPOSURE REPORT For SĂ©ura Outdoor Entertainment MODEL NUMBER: SHD2-75 FCC ID: 2AVE3SHD2-75A PROJECT NUMBER: 4789257350 REPORT NUMBER: 4789257350-12 ISSUE DATE: Feb. 26, 2020 Prepared for K-tronics (Su Zhou) Technology Co., LTD Prepared by UL-CCIC COMPANY LIMITED No. 2, Chengwan Road, Suzhou Industrial Park, People’s Republic of China Tel: +86 512 6808 6400 Fax: +86 512 6808 4099 Website: www.ul.com REPORT No.: 4789257350-12 Page 2 of 6 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED.. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................. 3 2. TEST METHODOLOGY ..................................................................................................... 4 3. FACILITIES AND ACCREDITATION ................................................................................. 4 4. REQUIREMENT ................................................................................................................. 5 REPORT No.: 4789257350-12 Page 3 of 6 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED.. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: K-tronics (Su Zhou) Technology Co., LTD Address: No.1088, Dajing Road, Economic and Technological Development Zone Wujiang District, Suzhou, Jiangsu, China Manufacturer Information Company Name: K-tronics (Su Zhou) Technology Co., LTD Address: No.1088, Dajing Road, Economic and Technological Development Zone Wujiang District, Suzhou, Jiangsu, China EUT Description EUT Name: SĂ©ura Outdoor Entertainment Model: SHD2-75 Sample Status: Normal Sample Received Date: Dec. 25, 2019 Date of Tested: Dec. 26, 2019 ~ Jan 14, 2020 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Guidelines for Human Exposure IEEE C95.1 Complies Prepared By: Reviewed By: Tom Tang Chris Zhong Engineer Project Associate Senior Project Engineer Authorized By: Scholl Zhang Laboratory Leader REPORT No.: 4789257350-12 Page 4 of 6 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED.. 2. TEST METHODOLOGY The tests documented in this report were performed in accordance with KDB 447498 D01 General RF Exposure Guidance v06 and FCC Guidelines for Human Exposure IEEE C95.1. 3. FACILITIES AND ACCREDITATION Accreditation Certificate A2LA (Certificate No.: 4829.01) UL-CCIC COMPANY LIMITED has been assessed and proved to be in compliance with A2LA. FCC (FCC Designation No.: CN1247) UL-CCIC COMPANY LIMITED has been recognized to perform compliance testing on equipment subject to the Commission's Declaration of Conformity (DoC) and Certification rules. IC (IC Designation No.: 25056) UL-CCIC COMPANY LIMITED has been recognized to perform compliance testing on equipment subject to the Commission's Declaration of Conformity (DoC) and Certification rules. Note 1: All tests measurement facilities use to collect the measurement data are located at No. 2, Chengwan Road, Suzhou Industrial Park, Suzhou 215122, People’s Republic of China Note 2: For below 30MHz, lab had performed measurements at test anechoic chamber and comparing to measurements obtained on an open field site. These measurements below 30MHz had been correlated to measurements performed on an OATS. Note 3: The test anechoic chamber in UL-CCIC COMPANY LIMITED had been calibrated and compared to the open field sites and the test anechoic chamber is shown to be equivalent to or worst case from the open field site. REPORT No.: 4789257350-12 Page 5 of 6 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED.. 4. REQUIREMENT LIMIT Limits for General Population/Uncontrolled Exposure Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Time |E| 2 , |H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f2)* 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- f/150 30 1500-100,000 -- -- 1.0 30 Note 1: f = frequency in MHz, * means Plane-wave equivalent power density Note 2: General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or cannot exercise control over their exposure. Note 3: The limit value 1.0mW/cm 2 is available for this EUT. MPE CALCULATION METHOD S =PG/(4πR 2 ) where: S = power density (in appropriate units, e.g. mW/ cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) REPORT No.: 4789257350-12 Page 6 of 6 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED.. CALCULATED RESULTS Radio Frequency Radiation Exposure Evaluation 1) For BLE BLE (Worst case) Output Power to Antenna Antenna Gain Power Density Limit Test Result (dBm) (mW) (dBi) (Numeric) (mW/cm2) (mW/cm2) -- 2.5 1.78 2.99 1.99 0.0007 1 Complies 2) For BT BT (Worst case) Output Power to Antenna Antenna Gain Power Density


Text truncated - open the document above for the full version.

Test Report

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. This report does not imply that the product(s) has met the criteria for certification. FCC 47 CFR PART 15 SUBPART C CERTIFICATION TEST REPORT For SĂ©ura Outdoor Entertainment MODEL NUMBER: SHD2-75 FCC ID: 2AVE3SHD3-75A PROJECT NUMBER: 4789257350 REPORT NUMBER: 4789257350-11 ISSUE DATE: Feb. 26, 2020 Prepared for K-tronics (Su Zhou) Technology Co., LTD Prepared by UL-CCIC COMPANY LIMITED No. 2, Chengwan Road, Suzhou Industrial Park, People’s Republic of China Tel: +86 512 6808 6400 Fax: +86 512 6808 4099 Website: www.ul.com REPORT NO: 4789257350-11 Page 2 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. Revision History Rev. Issue Date Revisions Revised By V0 01/26/2020 Initial Issue REPORT NO: 4789257350-11 Page 3 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. Summary of Test Results Clause Test Items FCC Rules Test Results 1 20dB Bandwidth FCC 15.247 (a) (1) Complied 2 Peak Conducted Output Power FCC 15.247 (b) (1) Complied 3 Carrier Hopping Channel Separation FCC 15.247 (a) (1) Complied 4 Number of Hopping Frequency 15.247 (a) (1) III Complied 5 Time of Occupancy (Dwell Time) 15.247 (a) (1) III Complied 6 Conducted Bandedge FCC 15.247 (d) Complied 7 Radiated Bandedge and Spurious FCC 15.247 (d) FCC 15.209 FCC 15.205 Complied 8 Conducted Emission Test for AC Power Port FCC 15.207 N/A 9 Antenna Requirement FCC 15.203 Complied Remark: The measurement result for the sample received is <Pass> according to < ANSI C63.10-2013, FCC CFR 47 Part 2, FCC CFR 47 Part 15C> when <Accuracy Method> decision rule is applied. REPORT NO: 4789257350-11 Page 4 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. TABLE OF CONTENTS 1. ATTESTATION OF TESCT RESULTS ............................................................................... 6 2. TEST METHODOLOGY ..................................................................................................... 7 3. FACILITIES AND ACCREDITATION ................................................................................. 7 4. CALIBRATION AND UNCERTAINTY ................................................................................ 8 4.1. MEASURING INSTRUMENT CALIBRATION .............................................................. 8 4.2. MEASUREMENT UNCERTAINTY ............................................................................... 8 5. EQUIPMENT UNDER TEST ............................................................................................... 9 5.1. DESCRIPTION OF EUT .............................................................................................. 9 5.2. MAXIMUM OUTPUT POWER...................................................................................... 9 5.3. PACKET TYPE CONFIGURATION ............................................................................. 9 5.4. CHANNEL LIST ..........................................................................................................10 5.5. TEST CHANNEL CONFIGURATION ..........................................................................10 5.6. THE WORSE CASE POWER SETTING PARAMETER ..............................................10 5.7. DESCRIPTION OF AVAILABLE ANTENNAS .............................................................11 5.8. WORST-CASE CONFIGURATIONS...........................................................................12 5.9. TEST ENVIRONMENT ...............................................................................................12 5.10. DESCRIPTION OF TEST SETUP ...........................................................................13 5.11. MEASURING INSTRUMENT AND SOFTWARE USED ..........................................14 6. ANTENNA PORT TEST RESULTS ...................................................................................15 6.1. ON TIME AND DUTY CYCLE .....................................................................................15 6.2. 20 dB BANDWIDTH ....................................................................................................17 6.2.1. GFSK MODE .......................................................................................................18 6.2.2. 8DPSK MODE .....................................................................................................20 6.3. PEAK CONDUCTED OUTPUT POWER .....................................................................22 6.3.1. GFSK MODE .......................................................................................................23 6.3.2. 8DPSK MODE .....................................................................................................25 6.4. CARRIER HOPPING CHANNEL SEPARATION .........................................................27 6.4.1. GFSK MODE .......................................................................................................28 6.4.2. 8DPSK MODE .....................................................................................................29 6.5. NUMBER OF HOPPING FREQUENCY ......................................................................30 6.5.1. GFSK MODE .......................................................................................................31 6.5.2. 8DPSK MODE .....................................................................................................32 6.6. TIME OF OCCUPANCY (DWELL TIME) ..........


Text truncated - open the document above for the full version.

Test Report

REPORT NO: 4789257350-11 Page 51 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. 6.7.2. 8DPSK MODE SPURIOUS EMISSIONS, LOW CHANNEL LOW CH BANDEDGE REPORT NO: 4789257350-11 Page 52 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. LCH SPURIOUS EMISSION LCH SPURIOUS EMISSION_30MHz~3GHz REPORT NO: 4789257350-11 Page 53 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. LCH SPURIOUS EMISSION_3GHz~5GHz LCH SPURIOUS EMISSION_5GHz~10GHz REPORT NO: 4789257350-11 Page 54 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. LCH SPURIOUS EMISSION_10GHz~15GHz LCH SPURIOUS EMISSION_15GHz~25GHz REPORT NO: 4789257350-11 Page 55 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. SPURIOUS EMISSIONS, MID CHANNEL MCH SPURIOUS EMISSION MCH SPURIOUS EMISSION_30MHz~3GHz REPORT NO: 4789257350-11 Page 56 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. MCH SPURIOUS EMISSION_3GHz~5GHz MCH SPURIOUS EMISSION_5GHz~10GHz REPORT NO: 4789257350-11 Page 57 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. MCH SPURIOUS EMISSION_10GHz~15GHz MCH SPURIOUS EMISSION_15GHz~25GHz REPORT NO: 4789257350-11 Page 58 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. SPURIOUS EMISSIONS, HIGH CHANNEL HIGH CH BANDEDGE REPORT NO: 4789257350-11 Page 59 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. HCH SPURIOUS EMISSION HCH SPURIOUS EMISSION_30MHz~3GHz REPORT NO: 4789257350-11 Page 60 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. HCH SPURIOUS EMISSION_3GHz~5GHz HCH SPURIOUS EMISSION_5GHz~10GHz REPORT NO: 4789257350-11 Page 61 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. HCH SPURIOUS EMISSION_10GHz~15GHz HCH SPURIOUS EMISSION_15GHz~25GHz REPORT NO: 4789257350-11 Page 62 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. SPURIOUS BANDEDGE EMISSIONS WITH HOPPING ON LOW CH BANDEDGE WITH HOPPING ON HIGH CH BANDEDGE WITH HOPPING ON REPORT NO: 4789257350-11 Page 63 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. 7. RADIATED TEST RESULTS 7.1. LIMITS AND PROCEDURE LIMITS Please refer to FCC §15.205 and §15.209 Please refer to SS-GEN Clause 8.9 and Clause 8.10 Radiation Disturbance Test Limit for FCC (Class B)(9KHz-1GHz) Frequency (MHz) Field Strength (microvolts/meter) Measurement Distance (meters) 0.009~0.490 2400/F(KHz) 300 0.490~1.705 24000/F(KHz) 30 1.705~30.0 30 30 30~88 100 3 88~216 150 3 216~960 200 3 960~1000 500 3 Note: 1) At frequencies at or above 30 MHz, measurements may be performed at a distance other than what is specified provided: measurements are not made in the near field except where it can be shown that near field measurements are appropriate due to the characteristics of the device; and it can be demonstrated that the signal levels needed to be measured at the distance employed can be detected by the measurement equipment. Measurements shall not be performed at a distance greater than 30 meters unless it can be further demonstrated that measurements at a distance of 30 meters or less are impractical. When performing measurements at a distance other than that specified, the results shall be extrapolated to the specified distance using an extrapolation factor of 20 dB/decade (inverse linear-distance for field strength measurements; inverse-linear-distance-squared for power density measurements). (2) At frequencies below 30 MHz, measurements may be performed at a distance closer than that specified in the regulations; however, an attempt should be made to avoid making measurements in the near field. Pending the development of an appropriate measurement procedure for measurements performed below 30 MHz, when performing measurements at a closer distance than specified, the results shall be extrapolated to the specified distance by either making measurements at a minimum of two distances on at least one radial to determine the proper extrapolation factor or by using the square of an inverse linear distance extrapolation factor (40 dB/decade). This paragraph (f) shall not apply to Access BPL devices operating below 30 MHz. REPORT NO: 4789257350-11 Page 64 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. Radiation Disturbance Test Limit for FCC (Above 1G) Frequency (MHz) dB(uV/m) (at 3 meters) Peak Average Above 1000 74 54 Restricted bands of operation Note: 1 Until February 1, 1999, this restricted band shall be 0.490-0.510 MHz. 2 Above 38.6c REPORT NO: 4789257350-11 Page 65 of 99 UL-CCIC COMPANY LIMITED This report shall not be reproduced except in full, without the written approval of UL-CCIC COMPANY LIMITED. TEST SETUP AND PROCEDURE Below 30MHz The setting of the spectrum Analyzer RBW 200Hz (From 9kHz to 0.15MHz)/ 9KHz (From 0.15MHz to 30MHz) VBW 200Hz (From 9kHz to 0.15MHz)/ 9KHz (From 0.15MHz to 30MHz) Sweep Auto Trace Max hold 1. The testing follows the guidelines in ANSI C63.10-2013 2. The


Text truncated - open the document above for the full version.

Test Setup Photos

Page 1 of 3 Appendix III Setup Photographs Page 2 of 3 RADIATED RF MEASUREMENT SETUP (9KHz ~ 30 MHz) RADIATED RF MEASUREMENT SETUP (30MHz ~ 1 GHz) Page 3 of 3 RADIATED RF MEASUREMENT SETUP (ABOVE 1 GHz- Z axis) POWERLINE CONDUCTED EMISSIONS MEASUREMENT SETUP

Contact Information

Applicant

Hsinyu Wu(CEO)
[email protected]510-6233810Fax: 510-623-3899

Test Firm

UL-CCIC Company LimitedChris Zhong
[email protected]+86 512 68758596

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz7.00 mW
Confidentiality
Long Term
Grant Notes
Power Outputs listed are peak conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter evaluation procedures as documented in this filing. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
