CA310 Manual 1. Foreword: CA310 is a knife-type protective film cutting machine. Compared with laser protective film cutting machine, it has the following advantages: A. Environmental protection, does not produce soot and exhaust gas, can be used in any place, can be widely used in shopping malls, stores; B. The edges of the cutting protective film are fine and without burrs, and the customer experience is good; C. The machine is light and easy to carry, generally only 5 kg is conducive to carrying operations. 2. Instructions for use A. Plug in the matching power adapter and turn on the machine, the built-in APP will start automatically; B. After the machine is started, set WIFI to connect to the network (you can only cut the models that data have been downloaded if there is no network,); C. Put the matching membrane material into the designated position of the machine; D. Select the corresponding mobile phone or film model to be cut through the machine APP, and click to start cutting; E. At this time, the machine will move to cut the corresponding graphics, and the blade will return to the far left after finishing cutting. 3.FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC Radiation Exposure Statement The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located for operating in conjunction with any other antenna or transmitter.

SHENZHEN JINGWEIXIAN TECHNOLOGY CO.,LTD Statement We SHENZHEN JINGWEIXIAN TECHNOLOGY CO.,LTD Hereby Declare that The product cutting plotter, models no. CA310, C310, CN310, S310, SN310, CA370 are all identical in interior structure, electrical circuits and components, and just model names are different for the marketing requirement. Your assistance on this matter is highly appreciated. Yours sincerely, Signature: Company Name: SHENZHEN JINGWEIXIAN TECHNOLOGY CO.,LTD

C5266091_X8_Ed.1 1/1 Letter of Authorization SHENZHEN JINGWEIXIAN TECHNOLOGY CO.,LTD Company: SHENZHEN JINGWEIXIAN TECHNOLOGY CO.,LTD Address: Bbuilding, 4th floor, Hantian industrypark, Longgang, Shenzhen, China, 518110 Product Name: cutting plotter Model Number: CA310, C310, CN310, S310, SN310, CA370 FCC Identifier: 2AVGR-CA310 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Jianglin Li Date: January 06, 2020 Title: General Manager Signature of applicant:

1/1 Offic Fed e 7435 Colum Date Subj e FCC To W Purs u (47C attac Abo v cons discl o comp It is corr e docu equi p Sinc e Sign a Nam Title: SH e of Engine eral Commu 5 Oakland M mbia, MD 2 : January 0 ect: Reques ID: 2AVGR- Whom It May uant to th CFR0.457, 0 chment(s) a ve mentione idered as osure of ab petitor an u our under s espondent d uments and pment auth erely, ature: e: Jianglin : General M HENZHEN eering Techn nications Co Mills Road 21046 06, 2020 st for Confid -CA310 y Concern, he provisio 0.459), we as confident Exhibits ID Label/Loca Attestation St External Photo Block Diagram Schematics Test Report Test Setup Ph User’s Manua Internal Photo Parts List / Tu RF Exposure I Operational D Cover Letter(s SDR Software ed docume proprietar y bove docum nfair advan standing th during cert those infor orization is Li Manager N JINGWE nology ommission dentiality ns of Sec t are reques tial docume ation atement os m hotos l os une Up Info Description s) e / Security Inf nt contains y informatio ments migh ntage in the hat all meas tification rev rmation will issued. EIXIAN TE tions 0.457 sting the C nt from pub Lon Con fo s detailed s on in oper ht be harm e market. surement t view proce l be availab ECHNOLO 7 and 0.4 Commission blic disclosu ng-Term nfidentiality S C No No No No No No system and ration of th mful to our test reports ess cannot ble for publ C5 GY CO.,LT 59 of Com to withho ure. Short-Term Confidentiality No No No No No equipment he equipm company s, FCC ID la be granted ic review o 5266091_X10 TD mmission's old the follo y t descriptio ent. The p and would abel format d as confid nce the gr a 0_Ed.1 rules owing n are public give t and ential ant of

FCC ID: 2AVGR-CA310

Label Location Size: 60*40mm, Material: Dumb Silver Dragon Product Name: cutting plotter Model: CA310 FCC ID: 2AVGR-CA310 FCC warning：This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

FCC ID: 2AVGR-CA310

Maximum Permissible Exposure FCC ID: 2AVGR-CA310 Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. (a) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times ︱E︱ 2 , ︱H︱ 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100000 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times ︱E︱ 2 , ︱H︱ 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100000 1.0 30 Note: f=frequency in MHz; *Plane-wave equivalent power density MPE Calculation Method E (V/m) = (30*P*G) 0.5 /d Power Density: Pd (W/m 2 ) = E 2 /377 E = Electric Field (V/m) P = Peak RF output Power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = (30*P*G) / (377*d 2 ) From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Calculated Result and Limit Antenna Gain: 2.0dBi Antenna Gain (Numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 1.585 22.24 167.5 0.05 1 Compiles Note: the worse case was recorded.

Report No.: FCC 1912141-01 File Reference No.: 2019-12-30 Applicant: SHENZHEN JINGWEIXIAN TECHNOLOGY CO.,LTD Product: cutting plotter Model No.: CA310, C310, CN310, S310, SN310, CA370 Trademark: SKYCUT Test Standards: FCC Part 15.247 Test Result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.10, FCC Part 15.247 for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: December 30, 2019 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TESTING LABORATORIES Zone C, 1st Floor, Block B, Jun Xiang Da Building, Zhongshan Park Road West, Tong Le Village, Nanshan District, Shenzhen, China Tel (755) 83448688, Fax (755) 83442996, E-Mail:[email protected] Report No.: FCC1912141-01 Page 2 of 103 Date: 2019-12-30 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement： The testing quality ability of our laboratory meet with “Quality Law of People’s Republic of China” Clause 19. The testing quality system of our laboratory meet with ISO/IEC-17025 requirements, which is approved by CNAL. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAS-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAS-CL01 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:2005 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 744189 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 744189. Industry Canada (IC) —Registration No.:5205A The EMC Laboratory has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 5205A. A2LA (Certification Number:5013.01) The EMC Laboratory has been accredited by the American Association for Laboratory Accreditation (A2LA). Certification Number:5013.01 Report No.: FCC1912141-01 Page 3 of 103 Date: 2019-12-30 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details............................................................................................... 4 1.3 Description of EUT ........................................................................................... 4 1.4 Submitted Sample.............................................................................................. 5 1.5 Test Duration................................................................................................... 5 1.6 Test Uncertainty............................................................................................... 5 1.7 Test By.......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 6 3.0 Technical Details............................................................................................. 8 3.1 Summary of Test Results..................................................................................... 8 3.2 Test Standards.................................................................................................. 8 4.0 EUT Modification.............................................................................................8 5.0 Power Line Conducted Emission Test...................................................................... 9 5.1 Schematics of the Test........................................................................................ 9 5.2 Test Method and Test Procedure............................................................................ 9 5.3 Configuration of the EUT.................................................................................... …
