2AVHG-344344INFLATABLE FLOATING BLUETOOTH SPEAKER

1 FLOATING TUNES Inflatable Floating Bluetooth Speakers SKU: 344344 INSTRUCTION MANUAL PLEASE READ ALL INSTRUCTIONS CAREFULLY AND RETAIN FOR FUTURE USE 2 Getting Started ƒ Remove the product from the box. ƒ Please retain all packaging after you have chec ked and counted all the parts and the contents against the list. Package Contents ƒ Inflatable Floating Bluetooth Speaker ƒ USB charging cable ƒ Air pump ƒ Instruction Manual Key Features ƒ Inflatable Floating Bluetooth Speaker ƒ Rechargeable floating speaker, pair it with any Bluetooth device and play your favorite tunes to enjoy your party ƒ Canbeusedasfloatingspeakeratbeachorpoolortub ƒ Wireless speaker can be removed to make it a cup-holder ƒ Air pump & micro USB cable included ƒ IP67 rated Safety Instructions ƒ Keep the unit away from heat sources. ƒ Do not use the unit if it has been dropped or damaged in any way. ƒ Repairs to electrical equipment should only be p erformed by a qualified electrician. Improper repairs may place the user at serio us risk. ƒ Do not put objects into any of the openings. ƒ Keep the unit free from dust, lint etc. ƒ Do not use this unit for anything other than its intended use. ƒ Dry your hands and speaker before charging. 3 Description of Parts Number Description 1 Charging Port (inside) 2 Rubber Cover (for water resistant) 3 Power ON/OFF/Play/Pause/Phone Button 4 LED Indicator 5 Speaker/Built-in Microphone INSTRUCTIONS FOR USEInflating the Plastic HugInflate the Plastic Hug completely by the included air pump.Charging the Bluetooth SpeakerFor best results, fully charge the unit before use. 1. Plug the Micro USB end of the included USB charging cable into the charging port of the speaker. Plug the other end into a USB port on your computer or suitable USB power source. 4 2. LED Indicator turns RED while charging, and turns off when fully charged Note: Before using the unit for the first time, please charge it for around 1-2 hours or until the LED Indicator turns off. Turn On/Off the SpeakerPress and hold the Power ON/OFF button for 2-3 seconds to turn on/off the unit.Pairing your device with the Speaker – Your Bluetooth Speaker can stream wireless audio from any Bluetooth enabled device within the range of up to 10 meters. Simply follow the bel ow steps. 1. Press and hold the Power ON/OFF button for 2-3 seconds to turn on/off the unit. 2. An indication tone would be heard, and the LED will flash blue rapidly, indicating that the speaker is now in pairing mode. 3. Turn on the Bluetooth on your Mobile Phone or Tablet or Computer.4. It will search for available Bluetooth devices. 5. Bluetooth Speaker would appear as “ Floating Fun ”, in the list of searched devices. Select it from the available list of devices. 6. If required , enter the password ‘0000’ to confirm pairing. 7. Once paired successfully, another indication t one would be heard, and blue LED light will stay on. 8. If you fail to pair it within a few seconds or you want to pair it with a new device, please repeat above steps. Play your favorite song on the Bluetooth source device and music would now stream through the speaker. Listening to Wireless MusicPlease ensure that your device (iPhone, Tablet or Other Smart Phone) is paired with the speaker to stream wireless music. Once it is paired, play music from your device. Function Operation Button Increase / Decrease Volume Playing music Adjust volu mefromthesourcedevice. Pause Playing music Short press Play/Pause button once to pause music Play Pause Short press Play/Pause button once to resume music 5 Please Note Not all mobile phones support all the functions listed above. Please refer to your cell phone’s user’s manual for further information. Certain functions and indication tone maybe vary depending on your mobile phone. Do’s and Don’tsDo not play music at excessive levels as damage to hearing and/or equipment may result.Care and maintenanceClean the unit with a soft, dry cloth. Never use chemicals or hard abrasives. Keep this unit away from wet or damp surroun dings. Product Specifications:Bluetooth version: 4.2 Speaker size: Dia. 74.6mm x 53mm H Speaker weight: ~138g Power input: DC 5V Charging time: 1-2 hoursPlay time: up to 2 hours (moderate volume) Bluetooth range: 10m Built-In Rechargeable Lithium Battery: 3.7V 400mAh (Note: Battery life & charging time may vary based on usage, types of devices connected & wirelessdistance.) TROUBLESHOOTINGProblem Possible Cause Solution Low sound level Source (Tablet, Mobile Pho ne, Laptop, etc.) volume too low. Battery dead Adjust source volume.Charge battery. Sound distortion Volume level too high Decrease the volume. 6 InformationonDisposalforUsersofWEEEThe wheelie bin symbol on the product(s) and / or accompanying documents means that used electrical and electronic equipment (WEEE) should not be mixed with general household waste. For proper treatment, recovery and recycling, please take this product(s) to designated collection points where it will be accepted free of charge. Alternatively, in some countries, you may be able t oreturnyourproductstoyourlocalretailerupo n purchase of an equivalent new product. Disposing of this product correctly will help save valuable resources and prevent any potential negative effects on human health and the environment, which could otherwise arise from inappropriate waste handling.Please contact your local authority for further det ails of your nearest designated collection point Produced in PRC for The RangePlymouth PL6 5ZD FCC ID: 2AVHG-344344FCC StatementThis equipment has been tested and found to comply with the limits for a Class B digital device, ƉƵƌƐƵĂŶƚƚŽWĂƌƚϭρŽĨƚŚĞ&ZƵůĞƐ͘dŚĞƐĞůŝŵŝƚƐĂƌĞĚĞƐŝŐŶĞĚ ƚŽƉƌŽǀŝĚĞƌĞĂƐŽŶĂďůĞƉƌŽƚĞĐƟŽŶ ĂŐĂŝŶƐƚŚĂƌŵĨƵůŝŶƚĞƌĨĞƌĞŶĐĞŝŶĂƌĞƐŝĚĞŶƟĂůŝŶƐƚĂůůĂƟŽŶ͘dŚŝƐ ĞƋƵŝƉŵĞŶƚŐĞŶĞƌĂƚĞƐƵƐĞƐĂŶĚĐĂŶ ƌĂĚŝĂƚĞƌĂĚŝŽĨƌĞƋƵĞŶĐLJĞŶĞƌŐLJĂŶĚ͕ŝĨŶŽƚŝŶƐƚĂůůĞĚĂŶĚƵƐĞĚŝ ŶĂĐĐŽƌĚĂŶĐĞǁŝƚŚƚŚĞŝŶƐƚƌƵĐƟŽŶƐ͕ ŵĂLJĐĂƵƐĞŚĂƌŵĨƵůŝŶƚĞƌĨĞƌĞŶĐĞƚŽƌĂĚŝŽĐŽŵŵƵŶŝĐĂƟŽŶƐ͘,ŽǁĞǀĞƌ͕ ƚŚ…

Text truncated - open the document above for the full version.

Ningbo Wiser Imp.& Exp.Co.,Ltd. DATE : 2019-12-27 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AVHG-344344 Product Name: INFLATABLE FLOATING BLUETOOTH SPEAKER Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name: JAMES XU Title: SALES Company: Ningbo Wiser Imp.& Exp.Co.,Ltd.

DATE : 2019-12-27 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Jason Wu of Global United Technology Services Co., Ltd.and No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Ningbo Wiser Imp.& Exp.Co.,Ltd. And 2Fl Unit.7 No.688 Jinda Road Yinzhou, Ningbo 315040, China Signature: Name: JAMES XU Title: SALES Company: Ningbo Wiser Imp.& Exp.Co.,Ltd.

FCC ID LABEL: Label sample:length*wide,50mm*20mm FCC ID LABEL LOCATION

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10- g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m Sopt = (EXd) 2 /30 x gt Ant gain= 0 dBi ; so Ant numeric gain= 1 Field strength =91.75 dBμ V/m @3m So Pt={ [10 (91.75 /20) /10 6 x3] 2 /30x1 }x1000 mW = 0.45 mW So (0.45 mW/5mm)x √2.480 GHz = 0.14 < 3 Then SAR evaluation is not required

Global United Technology Services Co., Ltd. Report No.: GTS201912000242F01 Authorized Signature: Robinson Lo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 27 TEST REPORT Applicant: Ningbo Wiser Imp.& Exp.Co.,Ltd. Address of Applicant: 2Fl Unit.7 No.688 Jinda Road Yinzhou, Ningbo 315040, China Manufacturer: Ningbo Wiser Imp.& Exp.Co.,Ltd. Address of Manufacturer: 2Fl Unit.7 No.688 Jinda Road Yinzhou, Ningbo 315040, China Equipment Under Test (EUT) Product Name: INFLATABLE FLOATING BLUETOOTH SPEAKER Model No.: 344344 FCC ID: 2AVHG-344344 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249 Date of sample receipt: December 25, 2019 Date of Test: December 25-27, 2019 Date of report issued: December 27, 2019 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS201912000242F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 27 2 Version Version No. Date Description 00 December 27, 2019 Original Prepared By: Date: December 27, 2019 Project Engineer Check By: Date: December 27, 2019 Reviewer Report No.: GTS201912000242F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 27 3 Contents Page 1 COVER PAGE .............................................................................................................................................1 2 VERSION ...................................................................................................................................................2 3 CONTENTS ...............................................................................................................................................3 4 TEST SUMMARY ......................................................................................................................................4 4.1 MEASUREMENT UNCERTAINTY .............................................................................................................4 5 GENERAL INFORMATION .......................................................................................................................5 5.1 GENERAL DESCRIPTION OF EUT ..........................................................................................................5 5.2 TEST MODE .........................................................................................................................................7 5.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................................7 5.4 DEVIATION FROM STANDARDS ..............................................................................................................7 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................7 5.6 TEST FACILITY ....................................................................................................................................8 5.7 TEST LOCATION ..................................................................................................................................8 6 TEST INSTRUMENTS LIST ......................................................................................................................9 7 TEST RESULTS AND MEASUREMENT DATA .....................................................................................11 7.1 ANTENNA REQUIREMENT ....................................................................................................................11 7.2 CONDUCTED EMISSIONS ....................................................................................................................12 7.3 RADIATED EMISSION METHOD ............................................................................................................15 7.3.1 Field Strength of The Fundamental Signal ..................................................................................17 7.3.2 Spurious emissions .....................................................................................................................18 7.3.3 Bandedge emissions ...................................................................................................................23 7.4 20DB BANDWIDTH .............................................................................................................................25 8 TEST SETUP PHOTO .............................................................................................................................27 9 EUT CONSTRUCTIONAL DETAILS .......................................................................................................27 Report No.: GTS201912000242F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 27 4 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203 Pass AC Power Line Conducted Emission 15.207 Pass Field strength of the fundamental signal 15.249 (a) Pass Spurious emissions 15.249 (a) (d)/15.209 Pass Band edge 15.249 (d)/15.205 Pass 20dB Bandwidth 15.215 (c) Pass Pass: The EUT complies with the essential requirements in the standard. Remark ：Test …

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
