BIVAROPERATIONMANUAL 1.AddGateway 1)Powersupply：USBor5V.Picture1 Noted:WhenyouadditinAPP,pleaserensure: i.poweronthegateway ii.4Gcardhasbeenputin iii.Twoantennasonthecircuitboard 2)Process LogininBivarApp,click“ADDDEV”，scanQRcode(ontheGateway).Afteradd successful,youcanrenamethedevice. 2.Addsub-device 1)ClickGatewaygotosub-deviceinterface,loginsub-deviceID(onthebackof 5VPower 4GCard devicecircuitboard).1-5devicescanbeaddedatatime. 2)Sub-deviceusing i.SmartHandle:HandlewassupplybyER14250(3.6V).Onceithasbeeninstalled,if thehandleswitchistriggered,thehandlewillsendamessagethroughtheRF 915Mhzfrequencybandtotellthegateway. ii.T/Hsensorusing:TemperatureandHumiditySensor(T&Hsensor)wassupplyby ER14250(3.6V).Onceithasbeeninstalled,itwillcollectsthetemperatureand humidityoftheenvironmentthroughthechipanduploadsthedatatotheclient throughthegatewaythroughtheRF915Mhzfrequencyband. 3.Sub-devicedevicestatus i.Clickonthesub-devicetoenterthedevicestatusinterface ii.Normalstate(temperature18-27°)Whenthetemperatureisdetectedto be>0.5°orthehumidityisgreaterthan1,theAPPwillpushamessage. Whenthetemperatureandhumiditydonotchange,thedeviceupdates thetemperatureandhumidityvaluesonceanhour.Abnormalstate (temperaturedetectedmorethan27°orbelow18°):Appwillpushan alarmmessageandreportthetemperatureandhumidityvalue.Atthe sametime,theredlightonthedevicelightsup5mins.ifthemiddlereturns tonormal,thegreenwilllightfor5mins,andtheAPPwillpushannormal message. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

External Photos ALL VIEW OF EUT Antenna TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

FCC ID Label Location FCC ID: 2AVK3THSENSOR

Internal Photos INTERNAL VIEW OF EUT VIEW OF BATTERY

Declaration concerning Antenna Specification It is hereby declared that the product FCC ID : 2AVK3THSENSOR Model Number: T/H Sensor, BWTHS-0101 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Type of antenna: FPC Antenna Gain of the antenna: 5 dBi Frequency range: 915MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: BIVAR INC. Address: 4 THOMAS, IRVINE, CA 92618 U.S.A. Place: IRVINE Date: 2020-01-13 Signature:

RF EXPOSURE EVALUATION 1. PRODUCT INFORMATION Product Description Bivar Wireless Temperature and Humidity Sensor Model Name T/H Sensor, BWTHS-0101 FCC ID 2AVK3THSENSOR 2. EVALUATION METHOD According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 3. CALCULATION According to the follow transmitter output power（P t ）formula： P t =（E x d） 2 /（30 x g t ） P t =transmitter output power in watts g t =numeric gain of the transmitting antenna (unitess) E=electric field strength in V/m d=measurement distance in meters (m) 915MHz: P t =0.089 mW The result for RF exposure evaluation SAR=(0.089mW /5mm) .[√0.9084(GHz)]= 0.0170<3.0 for 1-g SAR 4. CONCLUSION The SAR evaluation is not required.
