2AVMJXMVBluetooth Connected Activity Tracker

XMOVE Bluetoot h connected activity tracker myxplora.com Xplora T echnologies AS Øvre Slottsgate 27, 0157 Oslo, Norway QUICK USER GUIDE • KURZE BEDIENUNGSANLEITUNG • GUIDE D’UTILISA TION RAPIDE • GUÍA DE USUARIO RÁPIDA • MANUALE BREVE EN 2 Xplora MOVE can be paired with: Android: using OS 5.0 and above iPhone: using OS 9.0 and above 1. The company r eserves the right to modify the contents of this manual without any further notification. It is normal that some functions may vary in certain versions of softwar e. 2. All information on XMOVE and APP is only for r eference purpose and maybe not accurate. 3. Please char ge this product with the configured char ger for no less than 2 hours befor e using it. 4. Please connect XMOVE with Xplora App and complete the configuration. When it is pair ed successfully, it displays the corr ect time. 5. Please use 5V, 1A for the charger. This pr oduct does not support fast charging. Do not char ge if the product is damp with sweat as this could cause the watch to short cir cuit and will damage the pr oduct. For mor e details and the full user guide, please visit https://support.myxplora.com 1. Pr oduct overview NOTES: 3 2.1 Please sear ch by “Xplora” in the A pp store 2.2 Connections for APP and XMOVE a) Open the APP and cr eate Xplora account if you don’ t have one. b) Ensur e your smartphone Bluetooth is on befor e adding the device. Notes: • For Apple iPhone users: If the watch is in standby or hiber nation mode for a long time (for example, for 2 hours or mor e), the APP may be closed by the phone’ s iOS system. If this happens the APP and XMOVE may be disconnected, and the featur es may not be available. You need to re- open the XMOVE to be automatically r econnected. • For Andr oid phone users: After installing the APP you need to enable the backgr ound application launch permission in the settings menu of your smartphone. c) In the available device list fr om the APP , select XMOVE. d) When it’ s successfully paired, it displays the information about the status. 2.3 APP settings (functions are only available if the watch and phone have been paired successfully): Call notification, Social Media notifications, Alarm clock, Time to move r eminder, Drink water reminder, DND mode (Do not disturb mode), Turn on screen when turning wrist, Heart rate monitoring, Remote camera control, Find device, Firmware update, Device version, Unbind. EN 2. APP download and connection EN 4 • Power ON: When XMOVE is tur ned off, long pr ess the side button for 3 seconds to power on. In the standby state, short pr ess the side button to wake it up. • Power OFF: When XMOVE is tur ned on, long pr ess the side button for 3 seconds, then pr ess Power Off button on the watch face. • Main scr een selection: Slide from right to left on the main scr een to display all the options to choose fr om, then slide up or down to choose the pr eferred menu. 3. Main functions EN 5 • XMOVE functions include: Pedometer, Sport mode, Sleep Monitor, Health, Messages, Alarm clock (only set via APP), Remote music player, Timer, Stopwatch, Find phone, Screen brightness setting, Remote camera control, Settings. • How to find the differ ent functions from the watch face: a) Slide from top to bottom on the main screen dial to see the status bar, which includes DND mode, brightness level, settings, connection icon, and battery. b) Slide from right to left on the main screen to enter the menu. c) Slide from left to right on the main screen to see step, heart rate, sleep, and QR code. d) Slide from bottom to top on the main screen to see the messages received. 6 This marking on the pr oduct, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take these items for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal. This product is RoHS compliant. 4. Corr ect disposal of this product EN For CE RED: TX/RX:2402-2480NHz Output power:-2.90dBm 77 DE 8 Xplora MOVE kann verbunden werden mit: Android: using OS 5.0 and above iPhone: using OS 9.0 and above 1. Das Unternehmen behält sich das Recht vor, den Inhalt dieses Handbuchs ohne weitere Benachrichtigung zu ändern. Es ist normal, dass einige Funktionen in bestimmten Softwar eversionen variieren können. 2. Alle Informationen zur XMOVE und APP dienen nur zu Referenzzwecken und sind möglicherweise nicht korrekt. 3. Bitte laden Sie dieses Produkt mindestens 2 Stunden lang mit dem mitgelieferten Ladegerät auf, bevor Sie es verwenden. 4. Bitte verbinden Sie XMOVE mit der Xplora APP und schließen Sie die Konfiguration ab. Sobald die Uhr erfolgr eich gekoppelt wurde, wird die richtige Zeit angezeigt. 5. Bitte verwenden Sie 5V , 1A für das Ladegerät. Dieses Pr odukt unterstützt kein schnelles Aufladen. Laden Sie nicht auf, wenn das Pr odukt Schweissreste aufweist, da dies zu einem Kurzschluss der Uhr führ en und das Pr odukt beschädigen kann. Weitere Informationen und das vollständige Benutzerhandbuch finden Sie unter https://support.myxplora.com 1. Produkt-Übersicht HINWEISE: Bildschirm- bereich Touchscreen Magnetischer Ladepunkt Taste Herzfrequenz- Sensor DE 9 2.1 Bitte suchen Sie nach ”Xplora” im APP Store 2.2 Verbindungen für APP und XMOVE a) Öffnen Sie die App und erstellen Sie ein Xplora-Konto, falls Sie noch Keines haben. b) Stellen Sie sicher, dass Bluetooth auf Ihrem…

Text truncated - open the document above for the full version.

XPLORA Technologies AS Add: Tangerudvegen 13 Fjerdingby 2008 Norway Tel: +447479553848 Fax: +442081236688 Email: [email protected] Date: 2021-05-19 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir/Madam, We, XPLORA Technologies AS, hereby authorize Bay Area Compliance Laboratories Corp. to act as a laboratory for testing and test report generation for the following project(s): (Product name: Bluetooth Connected Activity Tracker, FCC ID:2AVMJXMV, Model name: XMOVE) The chipset nRF52832 supports BT and BLE mode, but only BLE 1M were active, the other were disable by software. Sincerely Yours, Client’s signature Printed Name: Sanghyo Kim Title: Manager

QA-FR-171-A XPLORA Technologies AS Add: Tangerudvegen 13 Fjerdingby 2008 Norway Tel: +447479553848 Fax: +442081236688 Email: [email protected] FCC Confidential Authorization Date: 2021-05-19 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID:2AVMJXMV In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, XPLORA Technologies AS hereby requests long-term confidential treatment of information accompanying this application as outlined below: x Block Diagram x Schematics x Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Printed name: Sanghyo Kim Title: Manager

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Chip ANT

FCC PART 15.247 RSS-GEN, ISSUE 5, MARCH 2019 AMENDMENT 1 RSS-247, ISSUE 2, FEBRUARY 2017 TEST REPORT For XPLORA Technologies AS Tangerudvegen 13 Fjerdingby 2008 Norway Report Type: Original Report Product Name: Bluetooth Connected Activity Tracker Report Number: RDG210416003-00B Re port Date: 2021-05-14 Reviewed By: Ivan Cao Assistant Manager Test Laboratory: Bay Area Compliance Laboratories Corp. (Dongguan) No.12, Pulong East 1 st Road, Tangxia Town, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn FCC ID: 2AVMJXMV IC:26094-XMV Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG210416003-00B Page 2 of 38 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 TEST METHODOLOGY .................................................................................................................................................. 4 MEASUREMENT UNCERTAINTY .................................................................................................................................... 5 TEST FACILITY ............................................................................................................................................................. 5 DECLARATIONS ............................................................................................................................................................ 5 SYSTEM TEST CONFIGURATION .......................................................................................................................... 6 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 6 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 6 EUT EXERCISE SOFTWARE .......................................................................................................................................... 6 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 7 LOCAL SUPPORT EQUIPMENT LIST AND DETAILS ........................................................................................................ 7 SUPPORT CABLE LIST AND DETAILS ............................................................................................................................ 7 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 8 SUMMARY OF TEST RESULTS ............................................................................................................................... 9 FCC §15.247 (i) & §1.1310 & §2.1093- RF EXPOSURE .......................................................................................... 10 APPLICABLE STANDARD ............................................................................................................................................ 10 RSS-102 § 2.5.1 EXEMPTION LIMITS FOR ROUTINE EVALUATION – SAR EVALUATION ................... 11 APPLICABLE STANDARD ............................................................................................................................................ 11 FCC §15.203 & RSS-GEN CLAUSE 6.8 - ANTENNA REQUIREMENT ............................................................. 12 APPLICABLE STANDARD ............................................................................................................................................ 12 ANTENNA INFORMATION AND CONNECTOR CONSTRUCTION ..................................................................................... 12 FCC §15.207 (a) & RSS-GEN CLAUSE 8.8– AC LINE CONDUCTED EMISSIONS ......................................... 13 APPLICABLE STANDARD ............................................................................................................................................ 13 EUT SETUP ................................................................................................................................................................ 13 EMI TEST RECEIVER SETUP ....................................................................................................................................... 13 TEST PROCEDURE ...................................................................................................................................................... 13 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................. 14 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 14 TEST DATA ................................................................................................................................................................ 15 FCC §15.209, §15.205, §15.247(d) & RSS-247 CLAUSE 5.5, RSS-GEN CLAUSE 8.10- SPURIOUS EMISSIONS ................................................................................................................................................................. 17 APPLICABLE STANDARD ............................................................................................................................................ 17 EUT SETUP ..................................................................................…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emissions Front View Conducted Emissions Side View Radiated Emission Below 1GHz View Radiated Emission Above 1GHz View
