2AVRVCLT2156R15.6 inch laptop

Page: 1/11 SHENZHEN STS TEST SERVICES CO., LTD. 1/F, BUILDING 2, ZHUOKE SCIENCE PARK, 190 CHONGQING ROAD FUYONG, BAO’ AN DISTRICT, SHENZHEN,CHINA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 08/21 EPGO352 Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Iroise – 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Calibration date: 09/15/2025 Accreditations #2-6789 Scope available on www.cofrac.fr The use of the Cofrac brand and the accreditation references is prohibited from any reproduction. Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed at MVG, using the CALIPROBE test bench, for use with a MVG COMO SAR system only. The test results covered by accreditation are traceable to the International System of Units (SI). COMOSAR E-Field Probe Calibration Report Ref : ACR.95.19.25.BES.A Docusign Envelope ID: 711C3E09-7054-43A0-BF16-C536091746C4 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.95.19.25.BES.A Page: 2/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Function Date Signature Prepared by : Pedro Ruiz Measurement Responsible 9/16/2025 Checked & approved by: Jérôme L uc Technical Manager 9/16/2025 Authorized by: Laboratory Director Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Name Date Modifications A Pedro Ruiz 9/16/2025 Initial release Docusign Envelope ID: 711C3E09-7054-43A0-BF16-C536091746C4 Geraldine Toutain 9/16/2025 COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 3/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Sensitivity _______________________________________________________________ 4 3.2 Linearity ________________________________________________________________ 5 3.3 Isotropy _________________________________________________________________ 5 3.4 Boundary Effect __________________________________________________________ 5 3.5 Probe Modulation Response _________________________________________________ 6 4 Measurement Uncertainty .......................................................................................... 6 5 Calibration Results ..................................................................................................... 6 5.1 Calibration in air __________________________________________________________ 6 5.2 Calibration in liquid _______________________________________________________ 7 6 Verification Results ................................................................................................... 8 7 List of Equipment ...................................................................................................... 9 Docusign Envelope ID: 711C3E09-7054-43A0-BF16-C536091746C4 Ref: ACR.95.19.25.BES.A COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 4/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer MVG Model SSE2 Serial Number SN 08/21 EPGO352 Product Condition (new / used) Used Frequency Range of Probe 0.15 GHz-7.5GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.222 M: Dipole 2: R2=0.198 M: Dipole 3: R3=0.191 M: 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOSAR E field Probes are built in accordance to the IEC/IEEE 62209-1528 and FCC KDB865664 D01 standards. Figure 1 – MVG COMOSAR Dosimetric E field Probe Probe Length 330 mm Length of Individual Dipoles 2 mm Maximum external diameter 8 mm Probe Tip External Diameter 2.5 mm Distance between dipoles / probe extremity 1 mm 3 MEASUREMENT METHOD The IEC/IEEE 62209-1528 and FCC KDB865664 D01 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their effect. All calibrations / measurements performed meet the fore-mentioned standards. 3.1 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards for frequency range 600- 7500MHz and using the calorimeter cell method (transfer method) as outlined in the standards for frequency 150-450 MHz. Docusign Envelope ID: 711C3E09-7054-43A0-BF16-C536091746C4 Ref: ACR.95.19.25.BES.A COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 5/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 3.2 LINEARITY The evaluation of the linearity was done in fr…

Text truncated - open the document above for the full version.

Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit (dBm) Verdict NVNT a 5745 Ant B 12.16 30 Pass NVNT a 5785 Ant B 11.7 30 Pass NVNT a 5825 Ant B 10.87 30 Pass NVNT n20 5745 Ant B 11.11 30 Pass NVNT n20 5785 Ant B 10.64 30 Pass NVNT n20 5825 Ant B 9.7 30 Pass NVNT n40 5755 Ant B 9.95 30 Pass NVNT n40 5795 Ant B 9.33 30 Pass NVNT ac20 5745 Ant B 11.13 30 Pass NVNT ac20 5785 Ant B 10.61 30 Pass NVNT ac20 5825 Ant B 9.81 30 Pass NVNT ac40 5755 Ant B 9.99 30 Pass NVNT ac40 5795 Ant B 9.35 30 Pass NVNT ac80 5775 Ant B 8.88 30 Pass Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Test Graphs Power NVNT a 5745MHz Ant B Power NVNT a 5785MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Power NVNT a 5825MHz Ant B Power NVNT n20 5745MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Power NVNT n20 5785MHz Ant B Power NVNT n20 5825MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Power NVNT n40 5755MHz Ant B Power NVNT n40 5795MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Power NVNT ac20 5745MHz Ant B Power NVNT ac20 5785MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Power NVNT ac20 5825MHz Ant B Power NVNT ac40 5755MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Power NVNT ac40 5795MHz Ant B Power NVNT ac80 5775MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT a 5745 Ant B 16.184 0.5 Pass 5785 16.168 0.5 Pass 5825 16.184 0.5 Pass n20 5745 17.346 0.5 Pass 5785 17.415 0.5 Pass 5825 17.252 0.5 Pass n40 5755 35.22 0.5 Pass 5795 35.498 0.5 Pass ac20 5745 17.416 0.5 Pass 5785 17.323 0.5 Pass 5825 17.394 0.5 Pass ac40 5755 35.558 0.5 Pass 5795 35.69 0.5 Pass ac80 5775 74.984 0.5 Pass Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Test Graphs -6dB Bandwidth NVNT a 5745MHz Ant B -6dB Bandwidth NVNT a 5785MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 -6dB Bandwidth NVNT a 5825MHz Ant B -6dB Bandwidth NVNT n20 5745MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 -6dB Bandwidth NVNT n20 5785MHz Ant B -6dB Bandwidth NVNT n20 5825MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 -6dB Bandwidth NVNT n40 5755MHz Ant B -6dB Bandwidth NVNT n40 5795MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 -6dB Bandwidth NVNT ac20 5745MHz Ant B -6dB Bandwidth NVNT ac20 5785MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 -6dB Bandwidth NVNT ac20 5825MHz Ant B -6dB Bandwidth NVNT ac40 5755MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 -6dB Bandwidth NVNT ac40 5795MHz Ant B -6dB Bandwidth NVNT ac80 5775MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT a 5745 Ant B 16.54 5785 16.512 5825 16.485 n20 5745 17.653 5785 17.652 5825 17.648 n40 5755 36.047 5795 36.017 ac20 5745 17.661 5785 17.637 5825 17.651 ac40 5755 35.979 5795 36.003 ac80 5775 75.078 Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Test Graphs OBW NVNT a 5745MHz Ant B OBW NVNT a 5785MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 OBW NVNT a 5825MHz Ant B OBW NVNT n20 5745MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 OBW NVNT n20 5785MHz Ant B OBW NVNT n20 5825MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 OBW NVNT n40 5755MHz Ant B OBW NVNT n40 5795MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 OBW NVNT ac20 5745MHz Ant B OBW NVNT ac20 5785MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 OBW NVNT ac20 5825MHz Ant B OBW NVNT ac40 5755MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 OBW NVNT ac40 5795MHz Ant B OBW NVNT ac80 5775MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm/510kHz) Conducted PSD (dBm/500kHz) Limit (dBm/500kHz) Verdict NVNT a 5745 Ant B -3.3 -3.386 30 Pass NVNT a 5785 Ant B -3.91 -3.996 30 Pass NVNT a 5825 Ant B -4.56 -4.646 30 Pass NVNT n20 5745 Ant B -4.82 -4.906 30 Pass NVNT n20 5785 Ant B -4.92 -5.006 30 Pass NVNT n20 5825 Ant B -6.12 -6.206 30 Pass NVNT n40 5755 Ant B -9.12 -9.206 30 Pass NVNT n40 5795 Ant B -9.81 -9.896 30 Pass NVNT ac20 5745 Ant B -4.9 -4.986 30 Pass NVNT ac20 5785 Ant B -5.12 -5.206 30 Pass NVNT ac20 5825 Ant B -5.92 -6.006 30 Pass NVNT ac40 5755 Ant B -8.96 -9.046 30 Pass NVNT ac40 5795 Ant B -9.7 -9.786 30 Pass NVNT ac80 5775 Ant B -13.07 -13.156 30 Pass This product does not support MIMO mode and is a single-transmit-single-receive type. Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Test Graphs PSD NVNT a 5745MHz Ant B PSD NVNT a 5785MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 PSD NVNT a 5825MHz Ant B PSD NVNT n20 5745MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 PSD NVNT n20 5785MHz Ant B PSD NVNT n20 5825MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 PSD NVNT n40 5755MHz Ant B PSD NVNT n40 5795MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 PSD NVNT ac20 5745MHz Ant B PSD NVNT ac20 5785MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 PSD NVNT ac20 5825MHz Ant B PSD NVNT ac40 5755MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 PSD NVNT ac40 5795MHz Ant B PSD NVNT ac80 5775MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Band Edge Condition Mode Frequency (MHz) Antenna Max Value (dBm) Limit (dBm) Verdict NVNT a 5745 Ant B -41.57 Pass 5825 -43.06 Pass n20 5745 -43.03 Pass 5825 -44.53 Pass n40 5755 -42.71 Pass 5795 -44.84 Pass ac20 5745 -42.99 Pass 5825 -44.49 Pass ac40 5755 -42.58 Pass 5795 -44.65 Pass ac80 5775 -44.9 Pass -39.09 Pass Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Test Graphs Band Edge NVNT a 5745MHz Low Ant B Band E…

Text truncated - open the document above for the full version.

Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) NVNT a 5745 Ant A 100 0 NVNT n20 5745 Ant A 100 0 NVNT n40 5755 Ant A 100 0 NVNT ac20 5745 Ant A 100 0 NVNT ac40 5755 Ant A 100 0 NVNT ac80 5775 Ant A 100 0 Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Test Graphs Duty Cycle NVNT a 5745MHz Ant A Duty Cycle NVNT n20 5745MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Duty Cycle NVNT n40 5755MHz Ant A Duty Cycle NVNT ac20 5745MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Duty Cycle NVNT ac40 5755MHz Ant A Duty Cycle NVNT ac80 5775MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit (dBm) Verdict NVNT a 5745 Ant A 11.87 30 Pass NVNT a 5785 Ant A 11.67 30 Pass NVNT a 5825 Ant A 11.28 30 Pass NVNT n20 5745 Ant A 10.9 30 Pass NVNT n20 5785 Ant A 10.56 30 Pass NVNT n20 5825 Ant A 10.15 30 Pass NVNT n40 5755 Ant A 9.65 30 Pass NVNT n40 5795 Ant A 9.37 30 Pass NVNT ac20 5745 Ant A 10.84 30 Pass NVNT ac20 5785 Ant A 10.57 30 Pass NVNT ac20 5825 Ant A 9.99 30 Pass NVNT ac40 5755 Ant A 9.55 30 Pass NVNT ac40 5795 Ant A 9.35 30 Pass NVNT ac80 5775 Ant A 8.2 30 Pass This product does not support MIMO mode and is a single-transmit-single-receive type. Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Test Graphs Power NVNT a 5745MHz Ant A Power NVNT a 5785MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Power NVNT a 5825MHz Ant A Power NVNT n20 5745MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Power NVNT n20 5785MHz Ant A Power NVNT n20 5825MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Power NVNT n40 5755MHz Ant A Power NVNT n40 5795MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Power NVNT ac20 5745MHz Ant A Power NVNT ac20 5785MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Power NVNT ac20 5825MHz Ant A Power NVNT ac40 5755MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Power NVNT ac40 5795MHz Ant A Power NVNT ac80 5775MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT a 5745 Ant A 16.013 0.5 Pass 5785 16.003 0.5 Pass 5825 15.997 0.5 Pass n20 5745 17.183 0.5 Pass 5785 17.461 0.5 Pass 5825 17.307 0.5 Pass n40 5755 35.475 0.5 Pass 5795 35.713 0.5 Pass ac20 5745 17.399 0.5 Pass 5785 17.13 0.5 Pass 5825 17.376 0.5 Pass ac40 5755 35.381 0.5 Pass 5795 35.785 0.5 Pass ac80 5775 75.313 0.5 Pass Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Test Graphs -6dB Bandwidth NVNT a 5745MHz Ant A -6dB Bandwidth NVNT a 5785MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 -6dB Bandwidth NVNT a 5825MHz Ant A -6dB Bandwidth NVNT n20 5745MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 -6dB Bandwidth NVNT n20 5785MHz Ant A -6dB Bandwidth NVNT n20 5825MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 -6dB Bandwidth NVNT n40 5755MHz Ant A -6dB Bandwidth NVNT n40 5795MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 -6dB Bandwidth NVNT ac20 5745MHz Ant A -6dB Bandwidth NVNT ac20 5785MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 -6dB Bandwidth NVNT ac20 5825MHz Ant A -6dB Bandwidth NVNT ac40 5755MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 -6dB Bandwidth NVNT ac40 5795MHz Ant A -6dB Bandwidth NVNT ac80 5775MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT a 5745 Ant A 16.49 5785 16.474 5825 16.523 n20 5745 17.69 5785 17.651 5825 17.664 n40 5755 36.007 5795 36.032 ac20 5745 17.654 5785 17.616 5825 17.658 ac40 5755 36.039 5795 36.034 ac80 5775 75.023 Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Test Graphs OBW NVNT a 5745MHz Ant A OBW NVNT a 5785MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 OBW NVNT a 5825MHz Ant A OBW NVNT n20 5745MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 OBW NVNT n20 5785MHz Ant A OBW NVNT n20 5825MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 OBW NVNT n40 5755MHz Ant A OBW NVNT n40 5795MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 OBW NVNT ac20 5745MHz Ant A OBW NVNT ac20 5785MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 OBW NVNT ac20 5825MHz Ant A OBW NVNT ac40 5755MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 OBW NVNT ac40 5795MHz Ant A OBW NVNT ac80 5775MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm/510kHz) Conducted PSD (dBm/500kHz) Limit (dBm/500kHz) Verdict NVNT a 5745 Ant A -3.79 -3.876 30 Pass NVNT a 5785 Ant A -3.91 -3.996 30 Pass NVNT a 5825 Ant A -4.45 -4.536 30 Pass NVNT n20 5745 Ant A -4.98 -5.066 30 Pass NVNT n20 5785 Ant A -5.1 -5.186 30 Pass NVNT n20 5825 Ant A -5.54 -5.626 30 Pass NVNT n40 5755 Ant A -9.14 -9.226 30 Pass NVNT n40 5795 Ant A -9.7 -9.786 30 Pass NVNT ac20 5745 Ant A -4.71 -4.796 30 Pass NVNT ac20 5785 Ant A -5 -5.086 30 Pass NVNT ac20 5825 Ant A -5.66 -5.746 30 Pass NVNT ac40 5755 Ant A -9.35 -9.436 30 Pass NVNT ac40 5795 Ant A -9.71 -9.796 30 Pass NVNT ac80 5775 Ant A -13.84 -13.926 30 Pass This product does not support MIMO mode and is a single-transmit-single-receive type. Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 Test Graphs PSD NVNT a 5745MHz Ant A PSD NVNT a 5785MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 PSD NVNT a 5825MHz Ant A PSD NVNT n20 5745MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 PSD NVNT n20 5785MHz Ant A PSD NVNT n20 5825MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-3 PSD NVNT n40 5755MHz Ant A PSD NVNT n40 5795MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U…

Text truncated - open the document above for the full version.

Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) NVNT a 5180 Ant B 100 0 NVNT n20 5180 Ant B 100 0 NVNT n40 5190 Ant B 100 0 NVNT ac20 5180 Ant B 100 0 NVNT ac40 5190 Ant B 100 0 NVNT ac80 5210 Ant B 100 0 Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Test Graphs Duty Cycle NVNT a 5180MHz Ant B Duty Cycle NVNT n20 5180MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Duty Cycle NVNT n40 5190MHz Ant B Duty Cycle NVNT ac20 5180MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Duty Cycle NVNT ac40 5190MHz Ant B Duty Cycle NVNT ac80 5210MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit (dBm) Verdict NVNT a 5180 Ant B 12.4 24 Pass NVNT a 5200 Ant B 12.31 24 Pass NVNT a 5240 Ant B 13.14 24 Pass NVNT n20 5180 Ant B 11.08 24 Pass NVNT n20 5200 Ant B 10.38 24 Pass NVNT n20 5240 Ant B 10 24 Pass NVNT n40 5190 Ant B 9.29 24 Pass NVNT n40 5230 Ant B 9.88 24 Pass NVNT ac20 5180 Ant B 11.05 24 Pass NVNT ac20 5200 Ant B 10.36 24 Pass NVNT ac20 5240 Ant B 11.4 24 Pass NVNT ac40 5190 Ant B 9.41 24 Pass NVNT ac40 5230 Ant B 9.75 24 Pass NVNT ac80 5210 Ant B 8.75 24 Pass This product does not support MIMO mode and is a single-transmit-single-receive type. Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Test Graphs Power NVNT a 5180MHz Ant B Power NVNT a 5200MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Power NVNT a 5240MHz Ant B Power NVNT n20 5180MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Power NVNT n20 5200MHz Ant B Power NVNT n20 5240MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Power NVNT n40 5190MHz Ant B Power NVNT n40 5230MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Power NVNT ac20 5180MHz Ant B Power NVNT ac20 5200MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Power NVNT ac20 5240MHz Ant B Power NVNT ac40 5190MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Power NVNT ac40 5230MHz Ant B Power NVNT ac80 5210MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 -26dB Bandwidth Condition Mode Frequency (MHz) Antenna -26 dB Bandwidth (MHz) Limit -26 dB Bandwidth (MHz) Verdict NVNT a 5180 Ant B 22.566 0.5 Pass 5200 21.75 0.5 Pass 5240 21.978 0.5 Pass n20 5180 22.173 0.5 Pass 5200 22.601 0.5 Pass 5240 22.455 0.5 Pass n40 5190 43.756 0.5 Pass 5230 43.198 0.5 Pass ac20 5180 22.202 0.5 Pass 5200 23.194 0.5 Pass 5240 23.509 0.5 Pass ac40 5190 43.894 0.5 Pass 5230 44.339 0.5 Pass ac80 5210 82.506 0.5 Pass Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Test Graphs -26dB Bandwidth NVNT a 5180MHz Ant B -26dB Bandwidth NVNT a 5200MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT a 5240MHz Ant B -26dB Bandwidth NVNT n20 5180MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT n20 5200MHz Ant B -26dB Bandwidth NVNT n20 5240MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT n40 5190MHz Ant B -26dB Bandwidth NVNT n40 5230MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT ac20 5180MHz Ant B -26dB Bandwidth NVNT ac20 5200MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT ac20 5240MHz Ant B -26dB Bandwidth NVNT ac40 5190MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT ac40 5230MHz Ant B -26dB Bandwidth NVNT ac80 5210MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT a 5180 Ant B 16.497 5200 16.503 5240 16.506 n20 5180 17.65 5200 17.655 5240 17.644 n40 5190 36.076 5230 36.015 ac20 5180 17.646 5200 17.615 5240 17.67 ac40 5190 36.079 5230 36.006 ac80 5210 74.992 Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Test Graphs OBW NVNT a 5180MHz Ant B OBW NVNT a 5200MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 OBW NVNT a 5240MHz Ant B OBW NVNT n20 5180MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 OBW NVNT n20 5200MHz Ant B OBW NVNT n20 5240MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 OBW NVNT n40 5190MHz Ant B OBW NVNT n40 5230MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 OBW NVNT ac20 5180MHz Ant B OBW NVNT ac20 5200MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 OBW NVNT ac20 5240MHz Ant B OBW NVNT ac40 5190MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 OBW NVNT ac40 5230MHz Ant B OBW NVNT ac80 5210MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm) Limit (dBm) Verdict NVNT a 5180 Ant B -0.25 11 Pass NVNT a 5200 Ant B -0.17 11 Pass NVNT a 5240 Ant B 0.44 11 Pass NVNT n20 5180 Ant B -1.72 11 Pass NVNT n20 5200 Ant B -2.47 11 Pass NVNT n20 5240 Ant B -2.67 11 Pass NVNT n40 5190 Ant B -6.89 11 Pass NVNT n40 5230 Ant B -6.18 11 Pass NVNT ac20 5180 Ant B -1.86 11 Pass NVNT ac20 5200 Ant B -2.49 11 Pass NVNT ac20 5240 Ant B -1.34 11 Pass NVNT ac40 5190 Ant B -6.94 11 Pass NVNT ac40 5230 Ant B -6.27 11 Pass NVNT ac80 5210 Ant B -10.82 11 Pass This product does not support MIMO mode and is a single-transmit-single-receive type. Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Test Graphs PSD NVNT a 5180MHz Ant B PSD NVNT a 5200MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 PSD NVNT a 5240MHz Ant B PSD NVNT n20 5180MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 PSD NVNT n20 5200MHz Ant B PSD NVNT n20 5240MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 PSD NVNT n40 5190MHz Ant B PSD NVNT n40 5230MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 PSD NVNT ac20 5180MHz Ant B PSD NVNT ac20 5200MHz Ant B Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 PSD NV…

Text truncated - open the document above for the full version.

Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) NVNT a 5180 Ant A 100 0 NVNT n20 5180 Ant A 100 0 NVNT n40 5190 Ant A 100 0 NVNT ac20 5180 Ant A 100 0 NVNT ac40 5190 Ant A 100 0 NVNT ac80 5210 Ant A 100 0 Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Test Graphs Duty Cycle NVNT a 5180MHz Ant A Duty Cycle NVNT n20 5180MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Duty Cycle NVNT n40 5190MHz Ant A Duty Cycle NVNT ac20 5180MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Duty Cycle NVNT ac40 5190MHz Ant A Duty Cycle NVNT ac80 5210MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit (dBm) Verdict NVNT a 5180 Ant A 12.94 24 Pass NVNT a 5200 Ant A 12.34 24 Pass NVNT a 5240 Ant A 12.36 24 Pass NVNT n20 5180 Ant A 10.75 24 Pass NVNT n20 5200 Ant A 10.2 24 Pass NVNT n20 5240 Ant A 10.15 24 Pass NVNT n40 5190 Ant A 9.43 24 Pass NVNT n40 5230 Ant A 9.96 24 Pass NVNT ac20 5180 Ant A 11.23 24 Pass NVNT ac20 5200 Ant A 11.13 24 Pass NVNT ac20 5240 Ant A 11.38 24 Pass NVNT ac40 5190 Ant A 9.4 24 Pass NVNT ac40 5230 Ant A 10.07 24 Pass NVNT ac80 5210 Ant A 8.72 24 Pass Note: This product does not support MIMO mode and is a single-transmit-single-receive type. Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Test Graphs Power NVNT a 5180MHz Ant A Power NVNT a 5200MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Power NVNT a 5240MHz Ant A Power NVNT n20 5180MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Power NVNT n20 5200MHz Ant A Power NVNT n20 5240MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Power NVNT n40 5190MHz Ant A Power NVNT n40 5230MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Power NVNT ac20 5180MHz Ant A Power NVNT ac20 5200MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Power NVNT ac20 5240MHz Ant A Power NVNT ac40 5190MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Power NVNT ac40 5230MHz Ant A Power NVNT ac80 5210MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 -26dB Bandwidth Condition Mode Frequency (MHz) Antenna -26 dB Bandwidth (MHz) Limit -26 dB Bandwidth (MHz) Verdict NVNT a 5180 Ant A 22.257 0.5 Pass 5200 22.69 0.5 Pass 5240 22.23 0.5 Pass n20 5180 22.11 0.5 Pass 5200 22.771 0.5 Pass 5240 22.593 0.5 Pass n40 5190 43.011 0.5 Pass 5230 43.305 0.5 Pass ac20 5180 23.353 0.5 Pass 5200 22.101 0.5 Pass 5240 22.469 0.5 Pass ac40 5190 44.259 0.5 Pass 5230 43.575 0.5 Pass ac80 5210 82.875 0.5 Pass Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Test Graphs -26dB Bandwidth NVNT a 5180MHz Ant A -26dB Bandwidth NVNT a 5200MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT a 5240MHz Ant A -26dB Bandwidth NVNT n20 5180MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT n20 5200MHz Ant A -26dB Bandwidth NVNT n20 5240MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT n40 5190MHz Ant A -26dB Bandwidth NVNT n40 5230MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT ac20 5180MHz Ant A -26dB Bandwidth NVNT ac20 5200MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT ac20 5240MHz Ant A -26dB Bandwidth NVNT ac40 5190MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 -26dB Bandwidth NVNT ac40 5230MHz Ant A -26dB Bandwidth NVNT ac80 5210MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT a 5180 Ant A 16.525 5200 16.522 5240 16.465 n20 5180 17.621 5200 17.65 5240 17.654 n40 5190 36.094 5230 36.038 ac20 5180 17.648 5200 17.659 5240 17.641 ac40 5190 36.071 5230 36.085 ac80 5210 75.043 Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Test Graphs OBW NVNT a 5180MHz Ant A OBW NVNT a 5200MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 OBW NVNT a 5240MHz Ant A OBW NVNT n20 5180MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 OBW NVNT n20 5200MHz Ant A OBW NVNT n20 5240MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 OBW NVNT n40 5190MHz Ant A OBW NVNT n40 5230MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 OBW NVNT ac20 5180MHz Ant A OBW NVNT ac20 5200MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 OBW NVNT ac20 5240MHz Ant A OBW NVNT ac40 5190MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 OBW NVNT ac40 5230MHz Ant A OBW NVNT ac80 5210MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm) Limit (dBm) Verdict NVNT a 5180 Ant A 0.31 11 Pass NVNT a 5200 Ant A -0.34 11 Pass NVNT a 5240 Ant A 0.13 11 Pass NVNT n20 5180 Ant A -1.92 11 Pass NVNT n20 5200 Ant A -2.69 11 Pass NVNT n20 5240 Ant A -2.52 11 Pass NVNT n40 5190 Ant A -6.64 11 Pass NVNT n40 5230 Ant A -6.17 11 Pass NVNT ac20 5180 Ant A -1.43 11 Pass NVNT ac20 5200 Ant A -1.48 11 Pass NVNT ac20 5240 Ant A -1.53 11 Pass NVNT ac40 5190 Ant A -7.01 11 Pass NVNT ac40 5230 Ant A -6.11 11 Pass NVNT ac80 5210 Ant A -10.53 11 Pass This product does not support MIMO mode and is a single-transmit-single-receive type. Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 Test Graphs PSD NVNT a 5180MHz Ant A PSD NVNT a 5200MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 PSD NVNT a 5240MHz Ant A PSD NVNT n20 5180MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 PSD NVNT n20 5200MHz Ant A PSD NVNT n20 5240MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 PSD NVNT n40 5190MHz Ant A PSD NVNT n40 5230MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-1 PSD NVNT ac20 5180MHz Ant A PSD NVNT ac20 5200MHz Ant A Report No.: STS2512369W04 _Appendix 5G WIFI_U-NII-…

Text truncated - open the document above for the full version.
