2AVS4-FDT-EVB-WP300Wireless Power Reference Design

Fu Da Tong Technology Co., Ltd
Wireless Power Reference Design - FCC ID 2AVS4-FDT-EVB-WP300 - Fu Da Tong Technology Co., Ltd
Click to zoom

Application Details

Equipment Class
DCD - Part 15 Low Power Transmitter Below 1705 kHz
Date of Grant
Jun 07, 2020
Application Purpose
Original Equipment
Date of Application
May 27, 2020
Equipment Note
Wireless Power Reference Design
Frequency Range
0.11200000 - 0.20500000
Company
Fu Da Tong Technology Co., Ltd
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Wireless Power Reference Design User Guide Part Number: EVB-WP300TX14 & EVB-WP300RX14 Rev #200304 March 18, 2020 Note! Input voltage set in advance of wireless charging launch end is 24V, the input voltage higher than 37V will damage the circuit board. Power supply connecting please use thick wire line and Y-type terminal lock connecting circuit board use simple fixture connect power supply, operating can’t stabilize working when output big current Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. Federal Communication Commission (FCC) Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End user must follow the specific operating instructions for satisfying RF exposure compliance. Display introduce of setting board PAGE 1 - Power-on status display Power-on succeeds Boot V+ 24.24V Power-on voltage display. The voltage needs to be set in the rage and then it will continue to operate. -8 Check the difference between value of coil resonance oscillation frequency and recorded value Complete equation is±0, will display +999~-999 when it has deviation If the difference bigger than set item 25 [Limit]L-C ACC GAP then will be locked and can’t finish the start program ResonantFreq 85.8KHz Resonant frequency composed of TX and capacitors detected during power-on P.O.S.T→OK Power . On . Self . Test pass FuDaTong A6 Product name #200304 Software version number YYMMDD supply voltage is too low Pow SelfTest Failure Power-on self-test failure V+ 5.01V Detected voltage Vin is too LOW Input Voltage is too low Standard Vin =24.00V Recommending voltage using Supply voltage is too high V+ 25.66V Detected voltage Vin is too HI Input voltage is too high Standard Vin =24.00V Recommending voltage using Part fault MOSFET FAULT Drive element fault U4x 0.00 Fault in P/N U4 , the detected output voltage is 0.00V [12]x Pin12 Judging fault of IC corresponding port U5 4.92 Part Number U5 is normal, the detected output voltage is 4.92V [13] [14] [15] No fault detected in Pin13, 14, and 15 of IC corresponding port Part fault U4 4.95 Part Number U4 is normal, the detected output voltage is 4.95V [13]x Pin13 Judging fault of IC corresponding port U5x 0.00 Fault in part number U5, the detected output voltage is 0.00V [12] [14] [15] No fault detected in Pin 12, 14, and 15 of IC corresponding port Part fault U4 4.95 Part Number U4 is normal, the detected output voltage is 4.95V [14]x Judging fault in Pin14 of IC corresponding port U5x 0.00 Fault in Part Number U5, the detected output voltage is 0.00V [12] [13] [15] No fault detected in Pin12, 13, and 15 of IC corresponding port Part fault U4 4.95 The Part Number U4 is normal, the detective output voltage is 4.95V [15]x Judging fault in Pin15 of IC corresponding port U5 4.95 Part number U5 is normal, the detected output voltage is 4.95V [12] [13] [14] No fault detected in Pin12, 13, and 14 of IC corresponding port Part fault COIL FAULT Coil fault *Usually it is because of the loop open circuit of the coil and the capacitance, or the fault of coil voltage detective divider resistance U4 4.95 Part number U4 is normal, the detected output voltage is 4.95V U5 4.95 Part number U5 is normal, the detected output voltage is 4.95V [12] [13] [14] [15] No fault detected in Pin12, 13, 14, and 15 of IC corresponding port The coil and the capacitance is too large, which causes the resonant frequency becomes too low L^C too Large The inductance value of coil and the capacitance are too large 43.3 The measurement of resonant frequency is 43.3 KHz U4 4.91 Part number U4 is normal, the detected output voltage is 4.91V U5 4.91 Part number U5 is normal, the detected output voltage is 4.91V [12] [13] [14] [15] No fault is detected in Pin12, 13, 14 and 15 of IC corresponding port The coil and the capacitance are too small, which caused the resonant frequency too high L^C too Small The coil inductance value and capacitance are too small 145.9 The measurement of resonant frequency is 145.9KHz U4 24.19 Part number U4 is normal, the detected output voltage is 24.19V U5 24.02 The part number U5 is normal, the detected output voltage is 24.02V [12] [13] [14] [15] No fault is detected in Pin12, 13, 14, and 15of IC corresponding port PAGE 2 - Main operation status display Standby surveillance mode +24。C The detected tempe…
