2AVSJSWTPWMIT0120Soiltech Wireless Sensor

www.soiltechwireless.com 1 Soiltech Sensor User Manual www.soiltechwireless.com 2 The Soiltech Wireless Sensor is a wireless device designed to aid in the management of crops during their growth, harvest, transit and storage. The Sensor has the ability to wirelessly transmit data to the Soiltech APP to inform users of: - Soil moisture levels - Humidity levels - Temperature levels - ‘Bruising’ - Location User Guidelines: The Soiltech sensor is a device intended to be handled i n the same way that crops are handled. It is designed to be planted alongside crops to provide users with real-time insights i nto the environmental conditions surrounding the sensor i n order to provide them with actionable information, that may guide their farmi ng and harvesting practices – such as irrigation scheduling, harvest equipment set-up or alert them to anomalies in storages. User Warnings: - Before installing the device, ensure that the battery has been charged and that all screws are locked tight, to prevent moisture entering the device. - The sensor is water resistant but it is not designed to be fully submerged under water. The Humidity Sensor Cover should be properly screwed on before planting under the soil to prevent moisture entering the device. - The sensor is rugged and can withstand bumps and drops that crops would typically incur during their lifecycle, but it should not be considered to be indestructible - so please refrain from excessively dropping the device. - Do not open the bottom cap of the device without prior approval from the device manufacturer or authorized dealer. Doing so may cause uni ntended hard to the user or compromise the effectiveness of the device. Product faults or defects that occur as a result of unauthori zed bottom cap removal will void any warranty or claims against the manufacturer. - Do not attempt to modify the device in any way without prior approval from device manufacturer or authorized dealer. Doing so may compromise the effecti veness of the device. Product faults or defects that occur as a result of user modification will void any warranty or claims against the manufacturer Getting to know the product www.soiltechwireless.com 3 Side View Top View LED Indicators: - Bright Orange LED indicates device is charging - Faint Orange LED indicates device has completed charging - Flashing Blue LED indicates the device is reading/transmitting data in ‘growth mode’ - Flashing White LED indicates the devices is in active ‘bruise’ mode Installation Advice The Soiltech Sensor is designed to be easy to use and quick to install: Humi di ty Sens or Cover LED Indi cator USB Chargi ng Port Seri al Number Moi s ture/Temperature s ens or ri ngs www.soiltechwireless.com 4 - charge the device - ensure all screws are tightly sealed - then just plant it under the soil or place in storage! That’s it! The device will automatically locate itself and be visible on the Soiltech App – where users can begin to customize (names, fields, groupings, soil types, safe-zones) and monitor environmental conditions immediately. User accounts will be pre-configured before devices ship out and there is no need for any set-up. How to view the data? Users can view all of their sensors from their computers or mobile devices. The Soiltech Wireless Mobile App, which is available from the Apple App Store or the Google Play Store, can be found by searching ‘Soiltech Wireless’. To view from a computer or laptop, please visit www.soiltechwireless.com and click ‘Login’ at the top right hand side of the screen. User credentials will be emailed after the purchase process has completed. App instructions are provided separately. Signal The Soiltech Sensor uses cellular frequencies in order to transmit data in real-time to users’ computers and cellphones. Cellular signal strength can vary from location to location, even within a short range. Therefore, if the device appears not to be transmitting a signal, try moving the device a few feet to try to find a better signal strength. As a general rule, if a cellphone works in a location then the Sensor should work. If any issues persist, please contact us for technical assistance. In the Field The sensor is a tool to provide real-time environmental conditions, wirelessly. There is not a ‘right or wrong’ location to place the device. Instead, it should be planted wherever users would like to remotely monitor soil moisture, temperature, humidity, location or ‘bruise’ - whether in locations that have historically been monitored or trouble areas that users would like to get visibility on. The sensor can be planted completely under the soil, alongside the seeds or in the location where users typically measure moisture for the crop in question. Whilst under the soil or placed in storage, the ideal orientation is for the unit to be www.soiltechwireless.com 5 placed horizontally, with the Humidity Sensor Cover facing down. Some suggested planting strategies: - In pivot irrigated fields, plant multiple units in a row parallel to the pivot (as illustrated in the image below) and then take an average reading of the row before the pivot runs over those devices in order to guide irrigation decision making. - plant devices in different parts of the field that have different soil textures (our app can help users determine soil type at any given location) - plant devices at high spots or low spots in a field. - plant devices in historically dry or wet areas in the field. In Storage Before placing the unit in a cellar or storage facility, users should remove the Humidity Sensor Cover in order to allow air to flow into the device via the laser holes and provide a more accurate reading. If placing the Sensor into a storage facility, users should take note of its location since GPS signals are not reliable indoors. Battery and Charging The Soiltech Sensor can be charged using the supplied USB cable. To charge to 100% from 0% takes approximately 12 hours. When charged to 100%, the Sensor h…

Text truncated - open the document above for the full version.

Soiltech Wireless Inc 3980 Osborn Loop, American Falls, Idaho 83211, United States Tel: +1-202-705-9993 Date: March 19, 2020 Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Request for Confidentiality FCC ID: 2AVSJSWTPWMIT0120 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure indefinitely. l Schematic Diagram l Block Diagram l Part List l Operational Description l Tune-up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFT §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachment(s) for 180 days after the grant as outlined in Public Notice DA 04-1705. l External Photos l Internal Photos l Test Setup Photos l User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards, ______________________ Ehsan Soltan [email protected]

Soiltech Wireless Inc 3980 Osborn Loop, American Falls, Idaho 83211, United States Tel: +1-202-705-9993 Date: March 19, 2020 To whom it may concern, Please be notified that I, Ehsan Soltan, have designated Jones Tsai in Sporton International Inc. as the person being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Jones Tsai in Sporton International Inc. on the matters of relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. We further certify that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 862. This authorization is limited to the product of as following: FCC ID: 2AVSJSWTPWMIT0120 If you have any acknowledgement and response, please send it to Sporton International Inc. directly. Sincerely yours, Ehsan Soltan [email protected]

PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 1 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 720510 1. External Photograph of EUT PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 2 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 3 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 4 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 5 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 6 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 7 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 Specification of Accessory Battery Brand Name Soiltech Wireless Inc. Model Name 18650 USB Cable Brand Name N/A Model Name USB AM TO MICRO 5P WWAN Module Brand Name Quectel Model Name BG96 Bluetooth Module Brand Name HOLSER TECHNOLOGY CO., LTD. Model Name HS-BT01-2 Remark: For accessories equipped with this EUT, please refer to the following photos. 2. Photograph of Accessory PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 8 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 720510 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 9 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 Battery PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 10 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 11 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01

Th is d e vice c o m pl ies w i th p a rt 15 of the FCC Ru les. Opera ti o n is s ub je ct to t he following two conditions: (1)Th is d e vi ce ma y not c aus e ha rm fu l interference, and (2)Th is de v ice mu st a cce p t a ny interference rec ei ve d, including i nt erference t ha t ma y c aus e un de si re d operation . FCC ID: 2 AVSJ SWTPWMIT01 20 Co n t a i n s FCC I D : X MR201 707 BG96 www.s oi l techwi rel es s .com Made in Taiwan Mode l : Soiltech Sensor

Label Location For the first time of use, the user needs to open the front cap to charge the device, and the label is visible the user. Label Location Bottom of EUT

PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 12 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 720510 3. Internal Photograph of EUT PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 13 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 14 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 15 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 16 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 17 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 18 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 19 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 20 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 21 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 22 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 23 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 24 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 25 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 26 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 27 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 28 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 29 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 WWAN Module PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 30 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 31 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 Bluetooth-LE Module PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 32 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 WWAN Antenna PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 33 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 34 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 Bluetooth-LE Antenna PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 35 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 GPS Antenna PHOTOGRAPHS OF EUT Report No.: EP021946 Brand Name: Soiltech Wireless Inc / Model Name: Soiltech Sensor TEL : 886-3-327-3456 Page Number : 36 of 36 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Version : 01 ─────THE END────

TEL : 886-3-327-3456 Page Number : 1 of 11 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Template No.: BU5-FD15B Version 2.5 Report Version : 01 FCC EMI TEST REPORT Report No. : FC021946 FCC EMI TEST REPORT FCC ID : 2AVSJSWTPWMIT0120 Equipment : Soiltech Wireless Sensor Brand Name : Soiltech Wireless Inc Model Name : Soiltech Sensor Applicant : Soiltech Wireless Inc 8 The Green, STE A, Dover, DE 19901, USA Manufacturer : Soiltech Wireless Inc 8 The Green, STE A, Dover, DE 19901, USA Standard : FCC 47 CFR FCC Part 15 Subpart B Class B The product was received on Feb. 19, 2020 and testing was started from Mar. 20, 2020 and completed on Apr. 01, 2020. We, SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory, would like to declare that the tested sample has been evaluated in accordance with the test procedures given in ANSI C63.4-2014 and has been in compliance with the applicable technical standards. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any agency of government. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory, the test report shall not be reproduced except in full. Approved by: Louis Wu SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory No. 52, Huaya 1st Rd., Guishan Dist., Taoyuan City, Taiwan (R.O.C.) TEL : 886-3-327-3456 Page Number : 2 of 11 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Template No.: BU5-FD15B Version 2.5 Report Version : 01 FCC EMI TEST REPORT Report No. : FC021946 Table of Contents History of this test report ................................................................................................................................. 3 Summary of Test Result................................................................................................................................... 4 1. General Description ................................................................................................................................... 5 1.1. Product Feature of Equipment Under Test ....................................................................................... 5 1.2. Modification of EUT ........................................................................................................................... 5 1.3. Test Location ..................................................................................................................................... 5 1.4. Applicable Standards ........................................................................................................................ 5 2. Test Configuration of Equipment Under Test ......................................................................................... 6 2.1. Test Mode ......................................................................................................................................... 6 2.2. Connection Diagram of Test System ................................................................................................ 6 2.3. Support Unit used in test configuration and system .......................................................................... 7 2.4. EUT Operation Test Setup ................................................................................................................ 7 3. Test Result .................................................................................................................................................. 8 3.1. Test of Radiated Emission Measurement ......................................................................................... 8 4. List of Measuring Equipment .................................................................................................................. 10 5. Uncertainty of Evaluation ........................................................................................................................ 11 Appendix A. Radiated Emission Test Result Appendix B. Setup Photographs TEL : 886-3-327-3456 Page Number : 3 of 11 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Template No.: BU5-FD15B Version 2.5 Report Version : 01 FCC EMI TEST REPORT Report No. : FC021946 History of this test report Report No. Version Description Issued Date FC021946 01 Initial issue of report Apr. 06, 2020 TEL : 886-3-327-3456 Page Number : 4 of 11 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Template No.: BU5-FD15B Version 2.5 Report Version : 01 FCC EMI TEST REPORT Report No. : FC021946 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark - 15.107 AC Conducted Emission Not Required - 3.1 15.109 Radiated Emission Pass Under limit 13.73 dB at 958.700 MHz Note: Not required means after assessing, test items are not necessary to carry out. Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Reviewed by: Dara Chiu Report Producer: Lucy Wu TEL : 886-3-327-3456 Page Number : 5 of 11 FAX : 886-3-328-4978 Issued Date : Apr. 06, 2020 Report Template No.: BU5-FD15B Version 2.5 Report Version : 01 FCC EMI TEST REPORT Report No. : FC021946 1. General Description 1.1. Product Feature of Equipment Under Test LTE, Bluetooth, and GNSS. Product Specification subjective to this standard Integrated the WWAN Module Brand: QUECTEL Model: BG96 Integrated the Bluetooth-LE Module Brand: HOLSER TECHNOLOGY CO., LTD. Model: HS-BT01-2 Antenna Type WWAN: PCB Antenna Bluetooth: PCA Antenna GPS/Glonass/BDS: Ceramic Antenna 1.2. Modification of EUT No modifications are…
