2AVTH-14CB7HYBOOK_PLUS

HYBOOK_PLUS USER MANUAL 4 Limited Warranty does NOT cover: Any costs associated with the repair or replacement of the Product including labor, installation or other costs incurred by you, and in particular, any costs relating to the removal or replacement of any Product that is soldered or otherwise permanently affixed to any printed circuit board; OR Damage to the Product due to external causes, including accident, problems with electrical power, abnormal electrical, mechanical or environmental conditions, usage not in accordance with product instructions, misuse, neglect, alteration, repair, improper installation, or improper testing; OR Any Product which has been modified or operated outside of specifications or where the original identification markings (trademark or serial number) has been removed, altered or obliterated from the Product, or where the label or screw on the exterior of the Product is removed or broken. WARRANTY NOTICE 5 INTRODUCTION Precautions Before Use: Thank you for choosing the new Hyundai Hybook. This guide serves to enable users to familiarize themselves with our product as quickly as possible. Below is a brief introduction to the key layout, features, definitions in figures and words. This production is suitable for use in non-tropic areas below 2,000 meters, and in the mark in the nameplate indicates the product is suitable for use in non-tropic areas. 1. Prevent the Hybook from falling to the ground or being strongly impacted otherwise. 2. Not for long-term use in an environment where the air is too hot (<35 o C), too humid or with too much dust. Do not expose the Hybook directly to sunlight. 3. Avoid using in strong magnetic or strong static environment as much as possible. 4. Once any water or other liquid splashes onto the Hybook, leave it open and do not use it until it dries out. 5. Do not clean the Hybook with any detergents, chemicals or liquids to avoid causing damage due to corrosion and becoming damp. If cleaning is necessary, clean it with a dry soft cloth. 6. Our company shall not be held responsible for any loss or deletion of data inside the Hybook due to abnormal software and hardware operation, maintenance or any other accident. 7. Please back up your Hybook to avoid any loss of important data or information. 6 8. Please do not disassemble the Hybook by yourself; otherwise you will lose the right to warranty. 9. Quick Start Guide and relevant software shall be updated at any time. Please visit www. hyundaitechnology.com to check for avilable software updates. 10. Replacement with incorrect type of batteries may cause explosion. Make sure to use original batteries. 5 2 16 13 10 12 11 15 14 4 3 1 6 7 8 9 6 7 1. Power button: Press down to start or close the screen panel. This button will allow you to enter or wake the laptop from sleep mode. 2. Front Camera: take pictures, record video, video chat. 3. Touchpad: The device can be operated directly. 4. Keyboard: The device can be operated directly. 5. Indicators: Power Indicator / Caps Lock Indicator / Num Lock Indicator 6. Microphone: Transmits audio signals. 7. Charge Indicator: Red light turns on when you plug the charging adapter. 8. USB Interface: You can insert USBs, mouse, keyboard directly. 9. DC Charging Base: Use the included 19V Charger. 10. HDMI Interface: High-Definition Multimedia Interface. 11. TYPE-C Interface: You can insert U disk, mouse, keyboard directly. 12. Kensington Anti-Theft lock 13. USB Interface: You can insert U disk, mouse, keyboard directly. 14. Headphone Jack: This jack port transmits audio signals to the laptop speakers or headphones. 15. Micro SD Card Slot: Built-in memory card reader slot that supports MicroSD. 16. Speakers: the built-in speaker transmits audio without additional connected devices. Key Layout And Definitions: 8 Windows 10 start image: On the start screen, you will see many applications fixed in the image. These application programs are displayed in the form “magnet”. Click on an application to begin. You will need to log in with your Micosoft account before the application will run. Interface Introduction: Applications Introduction: In addition to being available on the start screen, you can also open all applications from the homepage. If you want to add multiple applications on the Start screen, refer to the operation as shown below: (1) Right-click on the Properties icon. (2) Select fixed at the beginning of the page. 9 10 Menu Bar: Use mouse to click windows home button to appear on the menu bar. Conversely, if you want to change or delete an application from the startup screen, (1) Right-click (2), and then select the undocked from the start page. Search Menu: After you login, your account can be set up with your preferred language or text dialogue. If not logged into your account, only text searches will be available. 11 Expand the menu bar from the screen, usually: a file manager, settings, power supply and all applications, you can sleep / shutdown / restart the device. Here you can manage your files and applications on the device. Here you can set up and customize the settings on your device. Here you browse and choose more applications. Search Menu: After you login, your account can be set up with your preferred language or text dialogue. If not logged into your account, only text searches will be available. 12 Device menu Click on the notification menu. Multitasking Operation Interface. 13 Basic Operations: Sleep, Restart, Power Off: Short press the power button Hibernation. HYUNDAI The information contained herein is subject to change without notice. The only warranties for Connect and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Connect shall not be liable for technical or editorial errors or omissions contained herein. First Edition: May 2016 Advertencia Nota para uso en México La operación de este equip…

Text truncated - open the document above for the full version.

FCC Software Configuration Control Declaration Rev1.1 Hyundai Technology Group, Inc. FCC Software Configuration Control Declaration Date: March 29, 2022 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Attn: OET Dept. Product Name: HYBOOK_PLUS Trade Mark: Hyundai Model Number: 14CB7S01 FCC ID: 2AVTH-14CB7 Regarding FCC Country Code Selection guidelines identified in KDB 594280 D02 U-NII Device Security v01r03. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Signature: Date: 2022-03-25 Name: Sophia Wong Title: procurement manager Company: Hyundai Technology Group, Inc.

Hyundai Technology Group, Inc. Agent Authorization Company: Hyundai Technology Group, Inc. Address: 2601 Walnut Ave. Tustin, CA 92780 Product Name: HYBOOK_PLUS Trade Mark: Hyundai Model Number: 14CB7S01 FCC ID: 2AVTH-14CB7 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022-03-25 Name: Sophia Wong Title: procurement manager Company: Hyundai Technology Group, Inc.

Hyundai Technology Group, Inc. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022-03-25 Subject; Request for Confidentiality FCC ID: 2AVTH-14CB7 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Declaration of Software Security Requirements For U-NII Devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Sophia Wong Title: procurement manager

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 6 External Photos of the EUT Fig. 1 Fig. 2 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 6 Fig. 3 Fig. 4 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 6 Fig. 5 Fig. 6 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 6 Fig. 7 Fig. 8 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 5 of 6 Fig. 9 Fig. 10 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 6 of 6 Fig. 11 Fig. 12

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 _____________________________________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 1 LABEL AND LOCATION (Size: L4cm x 3cm) Label Location HYBOOK_PLUS Model: 14CB7S01 FCC ID: 2AVTH-14CB7 Caution:This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 7 Internal Photos of the EUT Fig. 1 Fig. 2 BT&WIFI ANT 0 WIFI ANT 1 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 7 Fig. 3 Fig. 4 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 7 Fig. 5 Fig. 6 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 7 Fig. 7 Fig. 8 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 5 of 7 Fig. 9 Fig. 10 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 6 of 7 Fig. 11 Fig. 12 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 7 of 7 Fig. 13

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 12 FCC RF Exposure Evaluation 1. Product Information FCC ID : 2AVTH-14CB7 Product name : HYBOOK_PLUS Test Model : 14CB7S01 Power supply : Input: 19.0V2.1A For AC Adapter Input: 100-240V~, 50/60Hz, 1.7A Max Adapter Output: 19.0V2.1A, 39.9W DC 7.6V by Rechargeable Li-ion Battery, 5000mAh Frequency Range : 2402MHz-2480MHz 2412MHz-2462MHz 5180-5240MHz 5745MHz-5825MHz Channel Number : 79 channels for Bluetooth V4.2(DSS) 40 channels for Bluetooth V4.2 (DTS) 11 Channels for 20MHz bandwidth (2412~2462MHz) 7 Channels for 40MHz bandwidth (2422~2452MHz) 4 Channels for 20MHz bandwidth(5180MHz-5240MHz) 2 channels for 40MHz bandwidth(5190MHz~5230MHz) 1 channels for 80MHz bandwidth(5210MHz) Channel Spacing : 1MHz for Bluetooth V4.2 (DSS) 2MHz for Bluetooth V4.2 (DTS) 5MHz Modulation Type : GFSK, π/4-DQPSK, 8-DPSK for Bluetooth V4.2(DSS) GFSK for Bluetooth V4.2 (DTS) IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11a/n/ac: OFDM (256QAM, 64QAM, 16QAM, QPSK, BPSK) Bluetooth Version : V4.2 Antenna Type : PIFA Antenna Antenna Gain : 0dBi(Max.) Hardware version : / Software version : / Exposure category : General population/uncontrolled environment EUT Type : Production Unit Device Type : Portable Device Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 12 2. Evaluation method and Limit According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.“ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)+ · *√f (GHz)+ ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to f) in section 4.1 is applied to determine SAR test exclusion. When one of the following test exclusion conditions is satisfied for all combinations of simultaneous transmission configurations, further equipment approval is not required to incorporate transmitter modules in host devices that operate in the mixed mobile and portable host platform exposure conditions. The grantee is responsible for documenting this according to Class I permissive change requirements. Antennas that qualify for standalone SAR test exclusion must apply the estimated standalone SAR to determine simultaneous transmission test exclusion. a) The [∑ of (the highest measured or estimated SAR for each standalone antenna configuration, adjusted for maximum tune-up tolerance) / 1.6 W/kg] + [∑ of MPE ratios] is ≤ 1.0. b)The SAR to peak location separation ratios of all simultaneously transmitting antenna pairs operating in portable device exposure conditions are all ≤ 0.04, and the [∑ of MPE ratios] is ≤ 1.0. 3. Refer Evaluation Method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1093: Radiofrequency radiation exposure evaluation: portable devices Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 ________________________________________________…

Text truncated - open the document above for the full version.

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 1 Appendix D RF Test Data for 5.2G WIFI (Conducted Measurement) Product Name: HYBOOK_PLUS Test Model: 14CB7S01 Environmental Conditions Temperature: 22.5 C Relative Humidity: 53.5% ATM Pressure: 100.0 kPa Test Engineer: Ling Zhu Supervised by: Li Huan Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 2 D.1 26dB Bandwidth Test Result TestMode Antenna Channel 26db EBW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant0 5180 22.320 5168.480 5190.800 --- PASS 5200 23.280 5188.320 5211.600 --- PASS 5240 24.280 5227.400 5251.680 --- PASS 11N20SISO Ant0 5180 22.680 5168.920 5191.600 --- PASS 5200 22.400 5188.640 5211.040 --- PASS 5240 23.880 5228.040 5251.920 --- PASS 11N40SISO Ant0 5190 41.760 5169.360 5211.120 --- PASS 5230 42.800 5208.720 5251.520 --- PASS 11AC20SISO Ant0 5180 22.760 5168.240 5191.000 --- PASS 5200 22.320 5189.000 5211.320 --- PASS 5240 22.680 5228.600 5251.280 --- PASS 11AC40SISO Ant0 5190 41.600 5169.360 5210.960 --- PASS 5230 42.400 5208.640 5251.040 --- PASS 11AC80SISO Ant0 5210 81.760 5168.880 5250.640 --- PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 3 Test Graphs 11A_Ant0_5180 11A_Ant0_5200 11A_Ant0_5240 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 4 11N20SISO_Ant0_5180 11N20SISO_Ant0_5200 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 5 11N20SISO_Ant0_5240 11N40SISO_Ant0_5190 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 6 11N40SISO_Ant0_5230 11AC20SISO_Ant0_5180 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 7 11AC20SISO_Ant0_5200 11AC20SISO_Ant0_5240 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 8 11AC40SISO_Ant0_5190 11AC40SISO_Ant0_5230 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 9 11AC80SISO_Ant0_5210 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 10 TestMode Antenna Channel 26db EBW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant1 5180 19.560 5170.240 5189.800 --- PASS 5200 19.920 5190.000 5209.920 --- PASS 5240 20.040 5230.080 5250.120 --- PASS 11N20SISO Ant1 5180 19.920 5170.080 5190.000 --- PASS 5200 20.000 5190.000 5210.000 --- PASS 5240 20.120 5229.880 5250.000 --- PASS 11N40SISO Ant1 5190 40.160 5169.920 5210.080 --- PASS 5230 40.320 5209.760 5250.080 --- PASS 11AC20SISO Ant1 5180 19.880 5170.000 5189.880 --- PASS 5200 20.000 5189.960 5209.960 --- PASS 5240 20.040 5229.960 5250.000 --- PASS 11AC40SISO Ant1 5190 39.840 5170.000 5209.840 --- PASS 5230 40.320 5209.920 5250.240 --- PASS 11AC80SISO Ant1 5210 81.760 5169.360 5251.120 --- PASS Test Graphs 11A_Ant1_5180 11A_Ant1_5200 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 11 11A_Ant1_5240 11N20SISO_Ant1_5180 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 12 11N20SISO_Ant1_5200 11N20SISO_Ant1_5240 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 13 11N40SISO_Ant1_5190 11N40SISO_Ant1_5230 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 14 11AC20SISO_Ant1_5180 11AC20SISO_Ant1_5200 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 15 11AC20SISO_Ant1_5240 11AC40SISO_Ant1_5190 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 16 11AC40SISO_Ant1_5230 11AC80SISO_Ant1_5210 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 17 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 18 D.2 Maximum conducted output power Test Result TestMode Antenna Channel Result[dBm] Limit[dBm] Verdict 11A Ant0 5180 5.88 ≤23.98 PASS 5200 5.77 ≤23.98 PASS 5240 5.45 ≤23.98 PASS 11N20SISO Ant0 5180 4.17 ≤23.98 PASS 5200 4.45 ≤23.98 PASS 5240 4.38 ≤23.98 PASS 11N40SISO Ant0 5190 4.19 ≤23.98 PASS 5230 3.38 ≤23.98 PASS 11AC20SISO Ant0 5180 3.91 ≤23.98 PASS 5200 3.84 ≤23.98 PASS 5240 3.62 ≤23.98 PASS 11AC40SISO Ant0 5190 4.11 ≤23.98 PASS 5230 3.11 ≤23.98 PASS 11AC80SISO Ant0 5210 3.65 ≤23.98 PASS TestMode Antenna Channel Result[dBm] Limit[dBm] Verdict 11A Ant1 5180 5.87 ≤23.98 PASS 5200 5.54 ≤23.98 PASS 5240 5.74 ≤23.98 PASS 11N20SISO Ant1 5180 4.43 ≤23.98 PASS 5200 4.45 ≤23.98 PASS 5240 4.49 ≤23.98 PASS 11N40SISO Ant1 5190 4.62 ≤23.98 PASS 5230 4.69 ≤23.98 PASS 11AC20SISO Ant1 5180 4.39 ≤23.98 PASS 5200 4.84 ≤23.98 PASS 5240 4.61 ≤23.98 PASS 11AC40SISO Ant1 5190 4.90 ≤23.98 PASS 5230 4.98 ≤23.98 PASS 11AC80SISO Ant1 5210 4.93 ≤23.98 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 19 MIMO Test Mode Channel Frequency (MHz) ANT 0 Conducted Power (dBm) ANT 1 Conducted Power (dBm) MIMO AV Conducted Power (dBm) Limit (dBm) Verdict 11N20 36 5180 4.17 4.43 7.31 ≤23.98 Pass 40 5200 4.45 4.45 7.46 Pass 48 5240 4.38 4.49 7.45 Pass 11N40 38 5190 4.19 4.62 7.42 ≤23.98 Pass 46 5230 3.38 4.69 7.09 Pass 11AC20 36 5180 3.91 4.39 7.17 ≤23.98 Pass 40 5200 3.84 4.84 7.38 Pass 48 5240 3.62 4.61 7.15 Pass 11AC40 38 5190 4.11 4.90 7.53 ≤23.98 Pass 46 5230 3.11 4.98 7.16 Pass 11AC80 42 5210 3.65 4.93 7.35 ≤23.98 Pass Note：The Duty Cycle Factor is compensated in the graph. Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AED 20 D.3 Maximum power spectral density Test Result TestMode Antenna Channel Result [dBm/MHz] Limit[dBm/MHz] Verdict 11A Ant0 5180 -4.13 ≤11 PASS 5200 -4.54 ≤11 PASS 5240 -5.17 ≤11 PASS 11N20SISO Ant0 5180 -4.85 ≤11 PASS 5200 -5.43 ≤11 PASS 5240 -5.0…

Text truncated - open the document above for the full version.

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 1 Appendix E RF Test Data for 5.8G WIFI (Conducted Measurement) Product Name: HYBOOK_PLUS Test Model: 14CB7S01 Environmental Conditions Temperature: 22.5 C Relative Humidity: 53.5% ATM Pressure: 100.0 kPa Test Engineer: Ling Zhu Supervised by: Li Huan Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 2 E.1 6dB Bandwidth Test Result TestMode Antenna Channel 6db EBW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant0 5745 15.160 5737.400 5752.560 0.5 PASS 5785 13.880 5777.440 5791.320 0.5 PASS 5825 15.120 5817.440 5832.560 0.5 PASS 11N20SISO Ant0 5745 15.200 5737.400 5752.600 0.5 PASS 5785 15.120 5777.440 5792.560 0.5 PASS 5825 13.880 5818.640 5832.520 0.5 PASS 11N40SISO Ant0 5755 35.280 5737.320 5772.600 0.5 PASS 5795 35.200 5777.320 5812.520 0.5 PASS 11AC20SISO Ant0 5745 12.680 5738.640 5751.320 0.5 PASS 5785 15.080 5777.440 5792.520 0.5 PASS 5825 15.120 5817.400 5832.520 0.5 PASS 11AC40SISO Ant0 5755 35.200 5737.400 5772.600 0.5 PASS 5795 35.200 5777.400 5812.600 0.5 PASS 11AC80SISO Ant0 5775 75.520 5737.240 5812.760 0.5 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 3 Test Graphs 11A_Ant0_5745 11A_Ant0_5785 11A_Ant0_5825 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 4 11N20SISO_Ant0_5745 11N20SISO_Ant0_5785 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 5 11N20SISO_Ant0_5825 11N40SISO_Ant0_5755 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 6 11N40SISO_Ant0_5795 11AC20SISO_Ant0_5745 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 7 11AC20SISO_Ant0_5785 11AC20SISO_Ant0_5825 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 8 11AC40SISO_Ant0_5755 11AC40SISO_Ant0_5795 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 9 11AC80SISO_Ant0_5775 TestMode Antenna Channel 6db EBW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant1 5745 15.240 5737.360 5752.600 0.5 PASS 5785 13.560 5778.600 5792.160 0.5 PASS 5825 15.440 5817.040 5832.480 0.5 PASS 11N20SISO Ant1 5745 15.160 5737.360 5752.520 0.5 PASS 5785 15.160 5777.400 5792.560 0.5 PASS 5825 15.080 5817.440 5832.520 0.5 PASS 11N40SISO Ant1 5755 35.280 5737.320 5772.600 0.5 PASS 5795 35.280 5777.320 5812.600 0.5 PASS 11AC20SISO Ant1 5745 13.960 5737.560 5751.520 0.5 PASS 5785 15.080 5777.400 5792.480 0.5 PASS 5825 15.200 5817.360 5832.560 0.5 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 10 11AC40SISO Ant1 5755 35.280 5737.320 5772.600 0.5 PASS 5795 35.200 5777.400 5812.600 0.5 PASS 11AC80SISO Ant1 5775 75.520 5737.240 5812.760 0.5 PASS Test Graphs 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 11 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 12 11N20SISO_Ant1_5825 11N40SISO_Ant1_5755 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 13 11N40SISO_Ant1_5795 11AC20SISO_Ant1_5745 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 14 11AC20SISO_Ant1_5785 11AC20SISO_Ant1_5825 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 15 11AC40SISO_Ant1_5755 11AC40SISO_Ant1_5795 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 16 11AC80SISO_Ant1_5775 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AVTH-14CB7 Report No.: LCS211112074AEE 17 E.2 Maximum conducted output power Test Result TestMode Antenna Channel Result[dBm] Limit[dBm] Verdict 11A Ant0 5745 5.23 ≤30 PASS 5785 5.92 ≤30 PASS 5825 5.44 ≤30 PASS 11N20SISO Ant0 5745 3.21 ≤30 PASS 5785 3.89 ≤30 PASS 5825 3.87 ≤30 PASS 11N40SISO Ant0 5755 3.52 ≤30 PASS 5795 3.92 ≤30 PASS 11AC20SISO Ant0 5745 3.49 ≤30 PASS 5785 3.77 ≤30 PASS 5825 3.91 ≤30 PASS 11AC40SISO Ant0 5755 3.39 ≤30 PASS 5795 3.89 ≤30 PASS 11AC80SISO Ant0 5775 3.91 ≤30 PASS TestMode Antenna Channel Result[dBm] Limit[dBm] Verdict 11A Ant1 5745 4.98 ≤30 PASS 5785 5.60 ≤30 PASS 5825 5.91 ≤30 PASS 11N20SISO Ant1 5745 3.45 ≤30 PASS 5785 3.77 ≤30 PASS 5825 3.45 ≤30 PASS 11N40SISO Ant1 …
