USER MANUAL 14.1” Windows Laptop HYBOOK PLUS User Manual 4 WARRANTY NOTICE Limited Warranty does NOT cover: Any costs associated with the repair or replacement of the Product including labor, installation or other costs incurred by you, and in particular, any costs relating to the removal or replacement of any Product that is soldered or otherwise permanently affixed to any printed circuit board; OR Damage to the Product due to external causes, including accident, problems with electrical power, abnormal electrical, mechanical or environmental conditions, usage not in accordance with product instructions, misuse, neglect, alteration, repair, improper installation, or improper testing; OR Any Product which has been modified or operated outside of specifications or where the original identification markings (trademark or serial number) has been removed, altered or obliterated from the Product, or where the label or screw on the exterior of the Product is removed or broken. 5 Technical Specifications Getting to know your laptop Keyboard Layout Turning on your Laptop Using the Touchpad Charging the Laptop Turning on the Laptop for the first time Unlocking the Display Start Menu The Action Center Activating WIFI and Opening the Browser Reset Standby Shutting Down Saving Energy Taking a Full Backup of a Windows 10 on an External Hard Drive Safety Notices for your Laptop CONTENTS: 6 8 11 13 13 16 16 17 17 18 18 19 19 19 19 20 20 6 CPU Operating system RAM Storage Screen Panel Aspect Ratio Resolution Camera Wireless Lan Bluetooth Speakers Microphone I/O interface Intel Core i5 Processor 8259U Windows 10 Home Single Language 8GB PCDDR 256GB 14.1’’ 16:9 1366x768 Front Webcam Wireless Lan BT 4.2 Built-in Box Speakers Built in Microphone 1*Audio Jack 3.5mm 1*DC Charging Port 1*USB Type-C 1*Expandable M.2 SATA SSD Slot 1*Mini HDMI Port 2*USB 3.0 1*microSD Slot TECHNICAL SPECIFICATIONS: 7 Battery Keyboard Touchpad AC Adapter Measurement Weight Materials 11.4V / 3400mAh (Lithium-ion Polymer Battery) Full Size Keys Supports PTP 19V / 2.1A 13.07” x 8.7” x 0.84” 3.06 lbs Plastic 8 GETTING TO KNOW YOUR LAPTOP: Camera Display Speakers 9 Power DC Input Port USB 3.0 Port Mini HDMI USB Type-C Port Audio Jack 3.5mm USB 3.0 Port microSD Slot 10 M.2 SATA SSD Slot 11 KEYBOARD LAYOUT: Execute the lock touchpad and F1-F12 keys when pressed with the said keys. Description Open the Start Menu. Press again to close the Start Menu. Press to disable scrolling with the arrows keys. Press again to disable this function. Key Capture a screenshot of the entire screen. Pause Continuous Output. Scr ik Prt Scr Pause 12 FunctionKeyPressed with Fn ESC KeyLock Touchpad Enter Sleep ModeF1 Turn On/Off LCDF2 Mute/UnMuteF3 Volume DownF4 Volume UpF5 Screen Brightness DownF6 Screen Brightness UpF7 Turn On/Off WiFiF8 Fast BackwardF9 Play / PauseF10 Fast ForwardF11 External DisplayF12 Up ArrowPage Up Key Down ArrowPage Down Key Left ArrowHome Key Right ArrowEnd Key 13 TURNING ON YOUR LAPTOP: Short press the POWER button to start your laptop. USING THE TOUCHPAD: Slide HorizontallySlide Vertically Slide DiagonallyLeft Click 14 Right ClickTwo Fingers Tap Two Fingers Scroll (Up/Down)Two Fingers Scroll (Left/ Right) Zoom OutZoom In Two Fingers Drag and DropThree Fingers Swipe Left/ Right 15 Three Fingers Swipe Left/ Right Three Fingers Swipe Up Three Fingers Swipe Down 16 Please charge your Laptop fully before using it for the first time. Connect the DC plug on the supplied power adapter to the charging socket (DC IN) on the laptop. Then plug the power adapter into a socket. The charging LED light is red while the device is charging. Only leave the power adapter connected to the socket until the battery of the laptop is fully charged. Note: You can also purchase power adapter with a Type-C output to power up the laptop, but this adapter is not included and the adapter output should be 19V/2.1A. CHARGING THE LAPTOP : TURNING ON THE LAPTOP FOR THE FIRST TIME: Open the screen until it is standing at a minimum angle of 90° to the keyboard. Press and hold the Power button to switch on the laptop. The setup assistant will then appear on the screen. Follow the setup assistant instructions to set up your laptop. During the startup, the wizard prompts you to register for your Microsoft account. If you do not yet have a Microsoft account, please set one up here. After completion of the startup, your laptop is being configured. This process may take several minutes to complete. Do not turn the laptop off during this time. 17 UNLOCKING THE DISPLAY: As soon as the device has been set up (and every time it is subsequently switched on and booted up), the lock screen appears, press any key on the keyboard to unlock the screen. If your laptop is password-protected, you must then enter the password. START MENU: To display the Start menu, click the Windows icon in the bottom left of the display or press the Windows button on the keyboard. Press the icon a second time to hide the Start menu. The Start menu consists of the classic navigation list (A) and a useful app area (B) to the right of the navigation list. Among other things, the navigation list includes a link to open Settings (cog wheel icon). In the app area, you can pin apps and favorites in the form of live tiles and organize them. In the navigation list (A) you find a list of all installed apps in alphabetical order. An alphabetic quick access to the navigation list appears when you click on the respective first letter. 18 The Info Center is a bar with quick links to some important laptop functions, which you can either display or hide. To access the Info Center click the memo symbol in the bottom right-hand corner. ACTIVATING WIFI AND OPENING THE BROWSER: Bring up Settings (see “Start menu”). In the Settings, click “Network & Internet”. Click “Wi-Fi” on the left in the next screen. Click the slider or the word “Off”. The word “On” now appears next to the slider. The laptop searches for all available w…
