2AVTH-HT14CCIC14.1 inch Windows Laptop

USER MANUAL 14.1” Windows Laptop HYBOOK User Manual Limited Warranty does NOT cover: Any costs associated with the repair or replacement of the Product including labor, installation or other costs incurred by you, and in particular, any costs relating to the removal or replacement of any Product that is soldered or otherwise permanently affixed to any printed circuit board; OR Damage to the Product due to external causes, including accident, problems with electrical power, abnormal electrical, mechanical or environmental conditions, usage not in accordance with product instructions, misuse, neglect, alteration, repair, improper installation, or improper testing; OR Any Product which has been modified or operated outside of specifications or where the original identification markings (trademark or serial number) has been removed, altered or obliterated from the Product, or where the label or screw on the exterior of the Product is removed or broken. WARRANTY NOTICE INTRODUCTION Precautions Before Use: Thank you for choosing the new Hyundai Hybook. This guide serves to enable users to familiarize themselves with our product as quickly as possible. Below is a brief introduction to the key layout, features, definitions in figures and words. This production is suitable for use in non-tropic areas below 2,000 meters, and in the mark in the nameplate indicates the product is suitable for use in non-tropic areas. 1. Prevent the Hybook from falling to the ground or being strongly impacted otherwise. 2. Not for long-term use in an environment where the air is too hot (<35 o C), too humid or with too much dust. Do not expose the Hybook directly to sunlight. 3. Avoid using in strong magnetic or strong static environment as much as possible. 4. Once any water or other liquid splashes onto the Hybook, leave it open and do not use it until it dries out. 5. Do not clean the Hybook with any detergents, chemicals or liquids to avoid causing damage due to corrosion and becoming damp. If cleaning is necessary, clean it with a dry soft cloth. 6. Our company shall not be held responsible for any loss or deletion of data inside the Hybook due to abnormal software and hardware operation, maintenance or any other accident. 7. Please back up your Hybook to avoid any loss of important data or information. 8. Please do not disassemble the Hybook by yourself; otherwise you will lose the right to warranty. 9. Quick Start Guide and relevant software shall be updated at any time. Please visit www. hyundaitechnology.com to check for avilable software updates. 10. Replacement with incorrect type of batteries may cause explosion. Make sure to use original batteries. 1. Power Button: Press it down to start or close the touch screen panel. You can also let the computer to enter dormancy through this button or wake from the dormacy mode. 2. Front Camera: Take pictures, shoot video. 3. Touchpad: The device can be operated directly. 4. Keyboard Board: The device can be operated directly. 5. Indicators: a) Is the green light when the Caps Lock indicator Caps Lock; b) charging indicator, red when charging connector adapter; c) work light, bright green when the machine starts to work. 6. Microphone: It can transmit audio signals to a device at work. 7. Charge Indicator: Red light when plug adapter. 8. DC Charging Base: Use the built-12V / 2A charger. 9. USB Interface: You can insert U disk, mouse, keyboard directly. 10. Mini-HDMI Interface: High-Definition Multimedia Interface. 11. USB 2.0: You can insert U disk, mouse, keyboard directly. 12. RJ-45: Physical Interface to Connect Computer Networks 13. USB 2.0: You can insert U disk, mouse, keyboard directly. 14. MicroSD Slot: You can insert a microSD up to 128GB 15. Speakers: The built-in speaker lets you hear the sound of work without additional connected devices Key Layout And Definitions: 2 1 5 66 4 3 11 13 12 8 10 9 7 1515 14 Windows 10 start image: On the start screen, you will see many applications fixed in the image. These application programs are displayed in the form “magnet”. Click on an application to begin. You will need to log in with your Micosoft account before the application will run. Interface Introduction: Applications Introduction: In addition to being available on the start screen, you can also open all applications from the homepage. If you want to add multiple applications on the Start screen, refer to the operation as shown below: (1) Right-click on the Properties icon. (2) Select fixed at the beginning of the page. Menu Bar: Use mouse to click windows home button to appear on the menu bar. Conversely, if you want to change or delete an application from the startup screen, (1) Right-click (2), and then select the undocked from the start page. Search Menu: After you login, your account can be set up with your preferred language or text dialogue. If not logged into your account, only text searches will be available. Expand the menu bar from the screen, usually: a file manager, settings, power supply and all applications, you can sleep / shutdown / restart the device. Here you can manage your files and applications on the device. Here you can set up and customize the settings on your device. Here you browse and choose more applications. Search Menu: After you login, your account can be set up with your preferred language or text dialogue. If not logged into your account, only text searches will be available. Device menu Click on the notification menu. Multitasking Operation Interface. Basic Operations: Sleep, Restart, Power Off: Short press the power button Hibernation. HYUNDAI The information contained herein is subject to change without notice. The only warranties for Connect and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Connect shall not be liable for technical or editorial errors or omissions contained herein. First Edition: M…

Text truncated - open the document above for the full version.

Hyundai Technology Group, Inc. Add: 2601 Walnut Ave.Tustin, California, United States, 92780 Date: 2021-4-27 FCC ID: 2AVTH-HT14CCIC Dear Sir/Madam, We, Hyundai Technology Group, Inc. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: 14.1” Windows Laptop Model no.: HT14CCIC81ES, HT14CCIC81EG Sincerely, Name/Title： Sophia Wong/procurement manager Company: Hyundai Technology Group, Inc. Address: 2601 Walnut Ave.Tustin, California, United States, 92780 Phone: 949-679-7960 Fax: 714-409-3091 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2021-4-27> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AVTH-HT14CCIC HT14CCIC81ES For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Sophia Wong/procurement manager Company: Hyundai Technology Group, Inc. Address: 2601 Walnut Ave.Tustin, California, United States, 92780 Phone: 949-679-7960 Fax: 714-409-3091 E-Mail: [email protected]

Hyundai Technology Group, Inc. 2601 Walnut Ave.Tustin, California, United States, 92780 Date: 2021-4-27 FCC ID: 2AVTH-HT14CCIC Model Number: HT14CCIC81ES To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Hyundai Technology Group, Inc., declare that this EUT (FCC ID: 2AVTH-HT14CCIC) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Sophia Wong/procurement manager Company: Hyundai Technology Group, Inc. Address: 2601 Walnut Ave.Tustin, California, United States, 92780 Phone: 949-679-7960 Fax: 714-409-3091 E-Mail: [email protected]

Hyundai Technology Group, Inc. 2601 Walnut Ave.Tustin, California, United States, 92780 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2021-4-27 To whom it may concern: We, Hyundai Technology Group, Inc. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AVTH-HT14CCIC including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Sophia Wong/procurement manager Company: Hyundai Technology Group, Inc. Address: 2601 Walnut Ave.Tustin, California, United States, 92780 Phone: 949-679-7960 Fax: 714-409-3091 E-Mail: [email protected]

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC EXTERIOR PHOTOGRAPHS Fig.1 Fig.2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Fig.5 Fig.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Fig.7 Fig.8 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Fig.9 Fig.10 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Fig.11

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 1 Label and Location Size: L4cm*W4cm Label Location 14.1" Windows Laptop Model No.: HT14CCIC81ES FCC ID: 2AVTH-HT14CCIC This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC INTERIOR PHOTOGRAPHS Fig.1 Fig.2 BT /WIFI ANT SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Fig.5 Fig.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Fig.7 Fig.8 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Fig.9 Fig.10 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Fig.11 Fig.12 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Fig.13 Fig.14 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Fig.15

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 6 FCC RF Exposure Evaluation 1. Product Information FCC ID: 2AVTH-HT14CCIC Product name 14.1” Windows Laptop Test Model HT14CCIC81ES Additional Model No HT14CCIC81EG Model Declaration PCB board, structure and internal of these model(s) are the same, So no additional models were tested Power supply Input: 12V2500mA For AC Adapter: Input: 100-240V~, 50/60Hz, 0.8A Output: 12V2500mA DC 7.4V by Rechargeable Li-ion Battery, 5000mAh Modulation Type GFSK, π/4-DQPSK, 8-DPSK for Bluetooth V4.2 (DSS) GFSK for Bluetooth V4.2 (DTS) IEEE 802.11b: DSSS (CCK,DQPSK,DBPSK); IEEE 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11a/n/ac: OFDM (64QAM, 16QAM, QPSK, BPSK) Antenna Type PIFA Antenna Antenna Gain Bluetooth: 1.61dBi(Max.) WIFI: 1.69dBi(Max.) for 2.4G WIFI 0.74dBi(Max.) for 5.2G WIFI 0.72dBi(Max.) for 5.2G WIFI Hardware version G116X-1 REV02 2020.10.29 Software version OS build:19041.685 /BIOS Version/Date: American Megatrends inc. E.G116X_3.D8.E1.036 01/22/2021 19:35:41 Operation frequency Bluetooth: 2402MHz-2480MHz 2.4G WIFI: 2412MHz-2462MHz 5.2G WIFI: 5180MHz-5240MHz 5.8G WIFI: 5745MHz-5825MHz Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type Portable Device SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 6 2. Evaluation method and Limit According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)+ · *√f (GHz)+ ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to f) in section 4.1 is applied to determine SAR test exclusion. 3. Refer evaluation method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1093: Radiofrequency radiation exposure evaluation: portable devices SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 6 4. Conducted Power Results [BT Max Peak Conducted Power] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) GFSK 0 2402 2.582 39 2441 2.163 78 2480 1.000 π/4DQPSK 0 2402 3.318 39 2441 2.851 78 2480 1.721 8-DPSK 0 2402 3.653 39 2441 3.207 78 2480 2.158 [BLE Max Peak Conducted Power] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) BLE 0 2402 0.385 19 2441 1.901 40 2480 0.39 [2.4GWLAN Max Peak Conducted Power] Mode Channel Frequency(MHz) Max Conducted Power (dBm) IEEE 802.11b 1 2412 9.12 6 2437 9.63 11 2462 9.07 IEEE 802.11g 1 2412 9.23 6 2437 9.42 11 2462 9.03 IEEE 802.11n HT20 1 2412 9.17 6 2437 9.54 11 2462 9.04 IEEE 802.11n HT40 3 2422 9.37 6 2437 9.51 9 2452 9.43 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC ________________________________________________…

Text truncated - open the document above for the full version.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB Page 1 of 14 Appendix B RF Test Data for BLE (Conducted Measurement) Product Name: 14.1" Windows Laptop Trade Mark: N/A Test Model: HT14CCIC81ES Environmental Conditions Temperature: 24.8 C Relative Humidity: 56.5% ATM Pressure: 100.0 kPa Test Engineer: Ben Jin Supervised by: Li Huan B.1 Duty Cycle Test Mode Test Channel Ant Duty Cycle[%] Verdict BT LE 2440 Ant1 100 PASS #im grbble1hchnnav SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB Page 2 of 14 B.2 Maximum Conducted Peak Output Power Mode Channel Conduct Peak Power[dBm] Limit [dBm] Verdict BT LE LCH 0.385 30 PASS BT LE MCH 1.901 30 PASS BT LE HCH 0.39 30 PASS Test Graphs LCH MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB Page 3 of 14 HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB Page 4 of 14 B.3 Maximum Power Spectral Density Mode Channel PSD [dBm/3KHz] Limit [dBm/3KHz] Verdict BT LE LCH -14.429 8 PASS BT LE MCH -12.785 8 PASS BT LE HCH -14.362 8 PASS Test Graphs LCH MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB Page 5 of 14 HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB Page 6 of 14 B.4 6dB Bandwidth Mode Channel 6dB Bandwidth [MHz] Limit [MHz] Verdict BT LE LCH 0.6732 ≥0.5 PASS BT LE MCH 0.6634 ≥0.5 PASS BT LE HCH 0.6662 ≥0.5 PASS Test Graphs LCH MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB Page 7 of 14 HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB Page 8 of 14 B.5 RF Conducted Spurious Emissions Mode Channel Pref [dBm] Max. Level [dBm] Limit [dBm] Verdict BT LE LCH -0.16 -37.935 -20.160 PASS BT LE MCH 1.381 -37.975 -18.619 PASS BT LE HCH -0.151 -38.053 -20.151 PASS BT LE_LCH_Graphs Pref/BT LE/LCH Puw/BT LE/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB Page 9 of 14 BT LE_MCH_Graphs Pref/BT LE/MCH Puw/BT LE/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB Page 10 of 14 BT LE_HCH_Graphs Pref/BT LE/HCH Puw/BT LE/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB Page 11 of 14 B.6 Band-edge for RF Conducted Emissions Mode Channel Carrier Power[dBm] Max.Spurious Level [dBm] Limit [dBm] Verdict BT LE LCH -0.263 -49.532 -20.26 PASS BT LE HCH 0.028 -49.269 -19.97 PASS Test Graphs LCH HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB Page 12 of 14 B.7 Restrict-band band-edge measurements Test Mode Test Chann el Ant Freq. Power [dBm] Gain Ground Factor E [dBuV/m] Detector Limit [dBuV/ m] Verdi ct BT LE 2402 Ant1 2310.0 -42.42 2.0 0 54.81 PEAK 74 PASS Ant1 2310.0 -53.55 2.0 0 43.68 AV 54 PASS Ant1 2390.0 -42.82 2.0 0 54.41 PEAK 74 PASS Ant1 2390.0 -53.18 2.0 0 44.05 AV 54 PASS 2480 Ant1 2483.5 -42.91 2.0 0 54.32 PEAK 74 PASS Ant1 2483.5 -52.69 2.0 0 44.54 AV 54 PASS Ant1 2500.0 -43.51 2.0 0 53.72 PEAK 74 PASS Ant1 2500.0 -52.60 2.0 0 44.63 AV 54 PASS SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB Page 13 of 14 Restrict-band band-edge measurements_BT LE_2402_Ant1_PEAK Restrict-band band-edge measurements_BT LE_2402_Ant1_AV SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB Page 14 of 14 Restrict-band band-edge measurements_BT LE_2480_Ant1_PEAK Restrict-band band-edge measurements_BT LE_2480_Ant1_AV

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 1 of 46 Appendix C RF Test Data for 2.4G WIFI (Conducted Measurement) Product Name: 14.1" Windows Laptop Trade Mark: N/A Test Model: HT14CCIC81ES Environmental Conditions Temperature: 24.8 C Relative Humidity: 56.5% ATM Pressure: 100.0 kPa Test Engineer: Ben Jin Supervised by: Li Huan C.1 Duty Cycle Test Mode Test Channel Ant Duty Cycle[%] Verdict 11B 2437 Ant1 100 PASS 11G 2437 Ant1 100 PASS 11N20SISO 2437 Ant1 100 PASS 11N40SISO 2437 Ant1 100 PASS SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 2 of 46 Duty Cycle_11B_2437_Ant1 Duty Cycle_11G_2437_Ant1 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 3 of 46 Duty Cycle_11N20SISO_2437_Ant1 Duty Cycle_11N40SISO_2437_Ant1 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 4 of 46 C.2 Maximum Conducted Output Power Mode Channel Meas.Level [dBm] Limit [dBm] Verdict 11B LCH 9.12 30 PASS MCH 9.63 30 PASS HCH 9.07 30 PASS 11G LCH 9.23 30 PASS MCH 9.42 30 PASS HCH 9.03 30 PASS 11N20SISO LCH 9.17 30 PASS MCH 9.54 30 PASS HCH 9.04 30 PASS 11N40SISO LCH 9.37 30 PASS MCH 9.51 30 PASS HCH 9.43 30 PASS SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 5 of 46 C.3 Maximum Power Spectral Density Mode Channel Meas.Level [dBm/3KHz] Limit [dBm/3KHz] Verdict 11B LCH -21.737 8 PASS MCH -21.049 8 PASS HCH -21.883 8 PASS 11G LCH -26.020 8 PASS MCH -25.744 8 PASS HCH -26.100 8 PASS 11N20SISO LCH -26.241 8 PASS MCH -25.615 8 PASS HCH -25.696 8 PASS 11N40SISO LCH -26.605 8 PASS MCH -26.367 8 PASS HCH -27.903 8 PASS Test Graphs 11B/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 6 of 46 11B/MCH 11B/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 7 of 46 11G/LCH 11G/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 8 of 46 11G/HCH 11N20SISO/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 9 of 46 11N20SISO/MCH 11N20SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 10 of 46 11N40SISO/LCH 11N40SISO/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 11 of 46 11N40SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 12 of 46 C.4 6dB Bandwidth Mode Channel 6dB Bandwidth [MHz] Limit [MHz] Verdict 11B LCH 9.977 ≥0.5 PASS MCH 9.616 ≥0.5 PASS HCH 9.620 ≥0.5 PASS 11G LCH 16.62 ≥0.5 PASS MCH 16.57 ≥0.5 PASS HCH 16.54 ≥0.5 PASS 11N20SISO LCH 17.83 ≥0.5 PASS MCH 17.78 ≥0.5 PASS HCH 17.75 ≥0.5 PASS 11N40SISO LCH 36.50 ≥0.5 PASS MCH 36.23 ≥0.5 PASS HCH 36.11 ≥0.5 PASS Test Graphs 11B/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 13 of 46 11B/MCH 11B/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 14 of 46 11G/LCH 11G/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 15 of 46 11G/HCH 11N20SISO/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 16 of 46 11N20SISO/MCH 11N20SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 17 of 46 11N40SISO/LCH 11N40SISO/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 18 of 46 11N40SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 19 of 46 C.5 RF Conducted Spurious Emissions Mode Channel Pref [dBm] Max. Level [dBm] Limit [dBm] Verdict 11B LCH -3.227 -37.481 -23.227 PASS MCH -2.519 -37.158 -22.519 PASS HCH -3.146 -37.499 -23.146 PASS 11G LCH -11.994 -37.455 -31.994 PASS MCH -11.12 -38.196 -31.120 PASS HCH -11.443 -37.710 -31.443 PASS 11N20 SISO LCH -11.759 -38.490 -31.759 PASS MCH -11.128 -37.931 -31.128 PASS HCH -11.467 -37.814 -31.467 PASS 11N40 SISO LCH -13.99 -35.917 -33.990 PASS MCH -14.012 -36.692 -34.012 PASS HCH -13.916 -37.747 -33.916 PASS SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 20 of 46 11B_LCH_Graphs Pref/11B/LCH Puw/11B/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 21 of 46 11B_MCH_Graphs Pref/11B/MCH Puw/11B/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 22 of 46 11B_HCH_Graphs Pref/11B/HCH Puw/11B/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 23 of 46 11G_LCH_Graphs Pref/11G/LCH Puw/11G/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 24 of 46 11G_MCH_Graphs Pref/11G/MCH Puw/11G/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 25 of 46 11G_HCH_Graphs Pref/11G/HCH Puw/11G/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 26 of 46 11N20SISO_LCH_Graphs Pref/11N20SIS O/LCH Puw/11N20 SISO/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 27 of 46 11N20SISO_MCH_Graphs Pref/11N20 SISO/MCH Puw/11N20 SISO/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEC Page 28 of 46 11N20SISO_HCH_Graphs Pref/11N20 SISO/HCH Puw/11N20 SISO/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC I…

Text truncated - open the document above for the full version.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 33 FCC TEST REPORT For Hyundai Technology Group.Inc 14.1” Windows Laptop Test Model: HT14CCIC81ES Additional Model No.: HT14CCIC81EG Prepared for : Hyundai Technology Group.Inc Address : 2601 Walnut Ave.Tustin, CA 92780 Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : March 04, 2021 Number of tested samples : 2 Sample No. : 210204006A-1, 210204006A-2 Serial number : Prototype Date of Test : March 04, 2021 ~ March 17, 2021 Date of Report : March 19, 2021 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AVTH-HT14CCIC Report No.: LCS210204006AEB This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 33 FCC TEST REPORT FCC CFR 47 PART 15 C (15.247) Report Reference No. ................. : LCS210204006AEB Date of Issue ................................... : March 19, 2021 Testing Laboratory Name ............. : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ........................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure ........... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name .......................... : Hyundai Technology Group.Inc Address ........................................... : 2601 Walnut Ave.Tustin, CA 92780 Test Specification Standard .......................................... : FCC CFR 47 PART 15 C (15.247) Test Report Form No. ................... : LCSEMC-1.0 TRF Originator ................................ : Shenzhen LCS Co…
