Hyundai Onnyx III Plus User Manual 21 16.8 mm 75.00mm 10.11mm Hyundai Onnyx III Plus User Manual 1-year warranty service for any “damaged” or “defected” product. ecivres ytnarraw ruo ni dedulcn Plus i ton era snoitidnoc gniwollof ehT pr ogram, and the following repairs could and will be charged: The use of the device not in accordance with the pr oduct manual operation or improper operation of instructions. Man-made damage, computer viruses, moisture, improper installation or disassembled software and so on. Accessories, supplies, natural wear and tear caused by use. The need to re-install the software on behalf of the company or adjust computer settings, will be charged as appropriate. impossible to identify. We guarantee service, to make the purchase and user-experience satisfying. WARRANTY NOTICE Thank you for your choosing the new Onnyx III Plus. This guide serves to enable users to get to know and familiar with our pr oduct as soon as possible. Here we have made a brief introduction to INTRODUCTION This pr oduction is suitable for use in non-tropic ar eas below 2,000 meters, and the mark in the nameplate indicates the product is suitable for use in non-tropic areas. 2. Pr event the Onnyx III Plus fr om falling to the gr ound or being strongly impacted otherwise. 3. Do not use it in the long term in any environment where the air is too cold, too hot (<35), too humid or with too much dust. Do not expose the Onnyx III Plus to sunlight. 4. Avoid using it in the strong magnetic and strong static environment as much as possible. 5. Once any water or other liquid splashes onto the Onnyx III Plus, close it immediately and do not use it until it dries out. I. Precautions before Use 6. Do not clean the Onnyx III Plus with any detergent containing chemical element or other liquid to avoid causing damage due to corrosion and becoming damp. If cleaning is really necessary, clean it with dry soft cloth tissue paper. 7.Our company shall not bear any and all responsibilities for loss or deletion of material inside the machine caused due to abnormal software and hardware operation, maintenance or any other accident. 8. Please back up your important material at any time to avoid loss. 9. Please do not disassemble the Onnyx III Plus by yourself; otherwise you will lose the right to warranty. 11. Quick Use Guide and the relevant software shall be updated at any time. For updated software version, visit www .hyundaitechnology.com for downloading by yourself, and no notice shall be given otherwise. If anything is found to be inconsistent with the Quick Use Guide, the material object shall prevail. 12. Replacement with incorrect type batteries may cause explosion. Make sure to use original batteries. in the image. These application pr ograms ar e displayed in the form of “magnet”. As long as you click them, you can easily visit them. 2. You need to log on your Microsoft account before the application pr ogram completely runs. Intr oduction to Desktop 3. Introduction to App Interface start other application pr ograms in all application pr ograms, such as other software application programs attached to the Onnyx III . If you want to fix more application programs on the start interface, see the operation in the figure below, (1) Click the properties icon (2) press and hold the application program magnet for about one second and then let go (3) Click the Pin to start. Conversely, if you want to cancel or delete a certain application in the start screen, (1) lightly touch, press and hold the application program magnet for about one second and then let it go and run, and select. 4. Start Menu Under PC mode,press Start ion, Start Menu will display, including: Start, Device, Setup, Share, and Search Program. Usually: File Explorer , Settings, Power, and All Apps. Can Sleep/Shut down/Restart the Onnyx III Plus. Allows you to set up the Table PC. Can scan more apps. POWER FILE EXPLORERFILE EXPLORER SETTINGS ALL APPS mode, Wi-Fi, Bluetooth etc. Action Center Setup Menu 5. Multitasking Operating Interface Slide it right from the left side of the screen, Let go when Can see the running applications. We can enter the application, also can be deleted. Basic Operations 1. Sleep, Restart and Power Off

Differences Declaration To whom concern, We company Hyundai Technology Group, Inc. Here by declares: The product model(s) LO14WA1BK, LO14WA1B, LO14WB1B, LO14WA1S, LO14WA1RG, LO14WB1S, Hyundai Onnyx III are the same electronic schematic and Antenna with Hyundai Onnyx III Plus, which tested in Shenzhen Huatongwei International Inspection Co., Ltd., the only difference is different model names for commercial purpose. Sincerely yours, Name (in print): Moe Kalbouneh Company name: Hyundai Technology Group, Inc. Company address: 2601 Walnut Ave. Tustin, CA, USA Tel: 1.949.679.7960 Ext: 125 E-Mail: [email protected]

2020-05-27 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Huatongwei International Inspection Co., Ltd./ 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China / Hans Hu,. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Hyundai Technology Group, Inc. / 2601 Walnut Ave. Tustin, CA, USA. Dated this May 27, 2020 Agency agreement expiration date: May 27, 2021 By: Moe Kalbouneh Signature Printed Title: Product Manager On behalf of : Hyundai Technology Group, Inc. Telephone: 1.949.679.7960 Ext: 125

2020-05-27 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AVTH-LO14WB Product Name: Notebook Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this May 27, 2020 By: Moe Kalbouneh Signature Printed Title: Product Manager On behalf of : Hyundai Technology Group, Inc. Telephone: 1.949.679.7960 Ext: 125

External Photos

Internal Photos

Page: 1 of 34 TEST REPORT Report No. ...................................... : CHTEW20050084 Report Verification: Project No.................................： SHT2005029401EW FCC ID ............................................. : 2AVTH-LO14WB Applicant’s name ........................... : Hyundai Technology Group, Inc. Address ............................................. : 2601 Walnut Ave. Tustin, CA, USA Manufacturer.....................................: Hyundai Technology Group, Inc. Address..............................................: 2601 Walnut Ave. Tustin, CA, USA Test item description .................... : Notebook Trade Mark ....................................... : HYUNDAI Model/Type reference ....................... : Hyundai Onnyx III Plus Listed Model(s) ................................. : LO14WA1BK, LO14WA1B, LO14WB1B, LO14WA1S, LO14WA1RG, LO14WB1S, Hyundai Onnyx III Standard ......................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of receipt of test sample..........: May 13, 2020 Date of testing.............................: May 13, 2020- May 20, 2020 Date of issue...............................: May 21, 2020 Result .................. ........................: PASS Compiled by ( Position+Printed name+Signature): File administrator Echo Wei Supervised by (Position+Printed name+Signature): Project Engineer Cheng Xiao Approved by (Position+Printed name+Signature): RF Manager Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW20050084 Page: 2 of 34 Issued: 2020-05-21 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2019-10) Contents 1. TEST S T AN D AR D S A N D R E P O R T V E R S I O N 3 1.1. Test Standards 3 1.2. Report version 3 2. TEST DESCRIPTION 4 3. SUMMARY 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 5 3.4. Testing Laboratory Information 6 4. TEST CONFIGURATION 7 4.1. Test frequency list 7 4.2. Descriptions of Test mode 7 4.3. Test mode 7 4.4. Support unit used in test configuration and system 8 4.5. Testing environmental condition 8 4.6. Measurement uncertainty 8 4.7. Equipment Used during the Test 9 5. TEST CONDITIONS AND RESULTS 11 5.1. Antenna Requirement 11 5.2. AC Conducted Emission 12 5.3. Peak Output Power 15 5.4. 20 dB Bandwidth 16 5.5. 99% Occupied Bandwidth 17 5.6. Carrier Frequencies Separation 18 5.7. Hopping Channel Number 19 5.8. Dwell Time 20 5.9. Duty Cycle Correction Factor (DCCF) 21 5.10. Pseudorandom Frequency Hopping Sequence 22 5.11. Conducted Band edge and Spurious Emission 23 5.12. Radiated Band edge Emission 25 5.13. Radiated Spurious Emission 27 6. TEST SETUP PHOTOS 32 7. EXTERANAL AND INTERNAL PHOTOS 34 8. APPENDIX REPORT 34 Report No.: CHTEW20050084 Page: 3 of 34 Issued: 2020-05-21 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2019-10) 1. TEST STAND ARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: ‒ FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz ‒ ANSI C63.10:2013: American National Standard for Testing Unlicensed Wireless Devices ‒ KDB 558074 D01 15.247 Meas Guidance v05r02: Guidance for Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid System Devices Operating under Section 15.247 of The FCC Rules 1.2. Report version Revision No. Date of issue Description N/A 2020-05-21 Original Report No.: CHTEW20050084 Page: 4 of 34 Issued: 2020-05-21 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2019-10) 2. TEST DESCRIPTION Report clause Test Items Standard Requirement Result 5.1 Antenna Requirement 15.203/15.247 (c) PASS 5.2 AC Conducted Emission 15.207 PASS 5.3 Peak Output Power 15.247 (b)(1) PASS 5.4 20 dB Bandwidth 15.247 (a)(1) PASS 5.5 99% Occupied Bandwidth - PASS *1 5.6 Carrier Frequency Separation 15.247 (a)(1) PASS 5.7 Hopping Channel Number 15.247 (a)(1) PASS 5.8 Dwell Time 15.247 (a)(1) PASS 5.9 Duty Cycle Correction Factor - PASS *1 5.10 Pseudorandom Frequency Hopping Sequence 15.247(b)(4) PASS 5.11 Conducted Band Edge and Spurious Emission 15.247(d)/15.205 PASS 5.12 Radiated Band Edge Emission 15.205/15.209 PASS 5.13 Radiated Spurious Emission 15.247(d)/15.205/15.209 PASS Note: ‒ The measurement uncertainty is not included in the test result. ‒ *1: No requirement on standard, only report these test data. Report No.: CHTEW20050084 Page: 5 of 34 Issued: 2020-05-21 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2019-10) 3. SUMMARY 3.1. Client Information Applicant: Hyundai Technology Group, Inc. Address: 2601 Walnut Ave. Tustin, CA, USA Manufacturer: Hyundai Technology Group, Inc. Address: 2601 Walnut Ave. Tustin, CA, USA 3.2. Product Description Name of EUT: Notebook Trade Mark: HYUNDAI Model No.: Hyundai Onnyx III Plus Listed Model(s): LO14WA1BK, LO14WA1B, LO14WB1B, LO14WA1S, LO14WA1RG, LO14WB1S, Hyundai Onnyx III Power supply: DC 7.6V Hardware version: EM_A8316C_366B_V1.0 Software versio…
