2AVTWZHXEFPIELECTRIC FIREPLACE

• Y X Y W Y Y X Z Z Z Z Z Z W Z B.FLAME A.POWER C.HEATER D.TIMER F.FUNCTION INDICATOR E.DISPLAY FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.

Rev1/26/2023 HuizhouZihanxuanHouseholdElectricalCo.,Ltd. FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:2026-05-29 FCCID:2AVTWZHXEFPI Ref.#1:AttestationStatementsPart2.911(d)(5)(i)Filing HuizhouZihanxuanHouseholdElectricalCo.,Ltd.certifiesthattheequipmentforwhichauthorizationis soughtisnot“covered”equipmentprohibitedfromreceivinganequipmentauthorizationpursuantto section2.903oftheFCCrules. HuizhouZihanxuanHouseholdElectricalCo.,Ltd.certifiesthattheequipmentforwhichauthorizationis soughtdoesnotincludecybersecurityoranti-virussoftwareproducedorprovidedbyKasperskyLab,Inc. oranyofitssuccessorsandassignees,includingequipmentwithintegratedKasperskyLab,Inc.(oranyof itssuccessorsandassignees)cybersecurityoranti-virussoftwarepursuanttoDA-24-886andKDB 986446D01CoveredEquipmentGuidancesectionB(2a). Deviceisinherentlycompliantbasedonhardwarelimitationsorsoftwarecontrols. or ASoftwareBillofMaterials(SBOM)isprovidedtotheTCBforreview,and Theend-userorthirdpartiescannotinstalladditionalsoftwareonthisdevice. Ref.#2:AttestationStatementsPart2.911(d)(5)(ii)Filing HuizhouZihanxuanHouseholdElectricalCo.,Ltd.certifiesthat,asofthedateofthefilingofthe application,theapplicantisnotidentifiedontheCoveredList(asaspecificallynamedentityoranyofits subsidiariesoraffiliates)asanentityproducing“covered”equipment. Applicant:HuizhouZihanxuanHouseholdElectricalCo.,Ltd. Address:YinglongIndustrialpark,TiantouVillage,YuanzhouTown,BoluoCounty,HuizhouCity, Guangdong,China ContactPerson:SNOWWANG Tel.:86-13480441248 Email:[email protected] Sincerely, Signature:

AttestationStatements Date:2026-05-29 TO:FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046,USA RE:AttestationStatementsPart2.911(d)(7)requestfor(FCCID:2AVTWZHXEFPI) HuizhouZihanxuanHouseholdElectricalCo.,Ltd.,theundersigned,herebyauthorizeFCC USAgent,LLCtoactasourdesignatedagentforserviceofprocess,HuizhouZihanxuan HouseholdElectricalCo.,Ltd.acceptstomaintainanagentfornolessthanoneyearafterthe granteehasterminatedallmarketingandimportationortheconclusionofanyCommission- relatedproceedinginvolvingtheequipment. FCCUSAgent,LLCacceptstheresponsibilitytoactasdesignatedagentforserviceofprocess. ApplicantInformation： Companyname:HuizhouZihanxuanHouseholdElectricalCo.,Ltd. ContactName:SNOWWANG Address:YinglongIndustrialpark,TiantouVillage,YuanzhouTown,BoluoCounty,HuizhouCity, Guangdong,China TelephoneNo:86-13480441248 Email:[email protected] FRN:0029296290 Signature: SNOWWANG AgentInformation: CompanyName:FCCUSAgent,LLC Address:3722IllinoisAvenue,SaintCharles,IL,60174,USA FRN:0033402884 ContactName:TimPayne TelephoneNo:708-571-3148 Email:[email protected] Signature: TimPayne

HuizhouZihanxuanHouseholdElectricalCo.,Ltd. OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:June1,2026 Subject;RequestforConfidentiality FCCID: 2AVTWZHXEFPI ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthese documentsmightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantage inthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure SOFTWARESECURITYREQUIREMENTSFORU-NIIDEVICES Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:SNOWWANG Title:MANAGER

EffectiveDate:April2,2020QSF7.6.4-8–AgentAuthorizationLetterTemplatePage1of1 RevisionDate:Revision:0 HuizhouZihanxuanHouseholdElectricalCo.,Ltd. Date：2026-05-29 ProductModelNumber:ZHX-23-103,ZHX-23-102,ZHX-23-104,ZHX-26-022,ZHX-26-122,ZHX-30-112, ZHX-30-113,ZHX-36-029,ZHX-36-030,ZHX-36-059,ZHX-20-153A,ZHX-30-150A,ZHX-24-207A FCCID：2AVTWZHXEFPI Towhomitmayconcern, Re:ProductCertificationRepresentativeAuthorizationLetter WeauthorizeQAILaboratoriesLtd.3980NorthFraserWay,BurnabyB.C.CanadaV5J5K5to actonourbehalfonallmattersconcerningtheabovenamedequipment. Thisshallincludethefollowing: Testing Approvalapplicationsandprocedures WedeclarethatQAILaboratoriesLtd.isallowedtoforwardallinformationrelatedtothe approvalprojecttotheappliedcertificationbodyandtothenotificationentitiesandtodiscuss anyissuesconcerningtheapprovalapplication.AnyandallactscarriedoutbyQAI LaboratoriesLtd.onourbehalfshallhavethesameeffectasactsofourown. Signature: By:SNOWWANG ContactListedonFCCWesbite Title:MANAGER Email:[email protected] Onbehalfof:HuizhouZihanxuanHouseholdElectricalCo.,Ltd.

HuizhouZihanxuanHouseholdElectricalCo.,Ltd. DeclarationLetterofModelDifference Date:2026-05-29 FCCID:2AVTWZHXEFPI TestedModelNumber:ZHX-23-103 AddingModelNumber(s):ZHX-23-102,ZHX-23-104,ZHX-26-022,ZHX-26-122,ZHX-30-112, ZHX-30-113,ZHX-36-029,ZHX-36-030,ZHX-36-059,ZHX-20-153A,ZHX-30-150A,ZHX-24-207A AllAddingModelNumber(s)is/aresameelectricallyidenticalasTestedModelNumber.Only differenceinmodelname. YoursSincerely, Applicant:HuizhouZihanxuanHouseholdElectricalCo.,Ltd. Address:YinglongIndustrialpark,TiantouVillage,YuanzhouTown,BoluoCounty,HuizhouCity, Guangdong,China ContactPerson:SNOWWANG Tel.:86-13480441248 Email:[email protected] Sincerely, Signature:

Page 1 of 5 Report No.: LGT26E079 Appendix - External Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 5 Report No.: LGT26E079 Appendix - External Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 5 Report No.: LGT26E079 Appendix - External Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 5 Report No.: LGT26E079 Appendix - External Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 5 Report No.: LGT26E079 Appendix - External Photographs of EUT Constructional Details Photo 9

Label Size: 21*53mm Model Name: ZHX-23-103 FCC ID: 2AVTWZHXEFPI

Page 1 of 7 Report No.: LGT26E079 Appendix - Internal Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 7 Report No.: LGT26E079 Appendix - Internal Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 7 Report No.: LGT26E079 Appendix - Internal Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 7 Report No.: LGT26E079 Appendix - Internal Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 7 Report No.: LGT26E079 Appendix - Internal Photographs of EUT Constructional Details Photo 9 Photo 10 BT ANT Page 6 of 7 Report No.: LGT26E079 Appendix - Internal Photographs of EUT Constructional Details Photo 11 Photo 12 Page 7 of 7 Report No.: LGT26E079 Appendix - Internal Photographs of EUT Constructional Details Photo 13 Photo 14

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 8 EMF TEST REPORT Product Name: ELECTRIC FIREPLACE Model Number: ZHX-23-103, ZHX-23-102, ZHX-23-104, ZHX-26-022, ZHX- 26-122, ZHX-30-112, ZHX-30-113, ZHX-36-029, ZHX-36-030, ZHX-36-059, ZHX-20-153A, ZHX-30-150A, ZHX-24-207A FCC ID: 2AVTWZHXEFPI Issued For : Huizhou Zihanxuan Household Electrical Co., Ltd. Yinglong Industrial park, Tiantou Village, Yuanzhou Town, Boluo County, Huizhou City, Guangdong, China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26E079HA01 Sample Received Date: May 14, 2026 Date of Test: May 14, 2026 ~ May 21, 2026 Date of Issue: May 26, 2026 Report No.: LGT26E079HA01 Page 2 of 8 TEST REPORT CERTIFICATION Applicant: Huizhou Zihanxuan Household Electrical Co., Ltd. Address: Yinglong Industrial park, Tiantou Village, Yuanzhou Town, Boluo County, Huizhou City, Guangdong, China Manufacturer: Huizhou Zihanxuan Household Electrical Co., Ltd. Address: Yinglong Industrial park, Tiantou Village, Yuanzhou Town, Boluo County, Huizhou City, Guangdong, China Product Name: ELECTRIC FIREPLACE Trademark: N/A Model Number: ZHX-23-103, ZHX-23-102, ZHX-23-104, ZHX-26-022, ZHX-26- 122, ZHX-30-112, ZHX-30-113, ZHX-36-029, ZHX-36-030, ZHX- 36-059, ZHX-20-153A, ZHX-30-150A, ZHX-24-207A Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1091 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT26E079HA01 Page 3 of 8 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 EUT OPERATION CONDITION 7 2.4 CLASSIFICATION 7 2.5 TEST RESULT 8 Report No.: LGT26E079HA01 Page 4 of 8 Revision History Rev. Issue Date Revisions 00 May 26, 2026 Initial Issue Report No.: LGT26E079HA01 Page 5 of 8 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: ELECTRIC FIREPLACE Test Model Number: ZHX-23-103 Series Number: ZHX-23-102, ZHX-23-104, ZHX-26-022, ZHX-26-122, ZHX-30- 112, ZHX-30-113, ZHX-36-029, ZHX-36-030, ZHX-36-059, ZHX-20-153A, ZHX-30-150A, ZHX-24-207A Model Difference: Only difference in model name Frequency Bands: 2402-2480MHz Adapter: 120V-60Hz,12.5A,1500W Battery: N/A Hardware Version: N/A Software Version: N/A 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT26E079HA01 Page 6 of 8 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 0.3-3.0 614 1.63 *(100) 3.0-30 1842/f 4.89/f *(900/f 2 ) 30-300 61.4 0.163 1.0 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 1.34-30 824/f 2.19/f *(180/f 2 ) 30-300 27.5 0.073 0.2 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 F= Frequency in MHz * = Plane-wave equivalent power density. Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. Report No.: LGT26E079HA01 Page 7 of 8 2.3 EUT OPERATION CONDITION EUT was enabled to transmit and receive at lowest, middle and highest channels. 2.4 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance from the antenna should be included in the User manual. So, this device is classified as Mobile device. Report No.: LGT26E079HA01 Page 8 of 8 2.5 TEST RESULT Turn up Result Mode Turn up Power BLE 1M-GFSK 4±1dBm BLE 2M-GFSK 4.5±1dBm The MPE result of worst mode: RF Function Max Turn up Power (dBm) Max Turn up Power (mW) ANT Gain (dBi) ANT Gain (gain of antenna in linear scale) Power Density (mW/cm²) Limit (mW/ cm²) Ratio Resul t BT 5.50 3.55 2.5 1.78 0.001 1 0.001 Pass Note: 1. T…

Text truncated - open the document above for the full version.

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 55 RF TEST REPORT Product Name: ELECTRIC FIREPLACE Model Number: ZHX-23-103, ZHX-23-102, ZHX-23-104, ZHX-26-022, ZHX-26-122, ZHX-30-112, ZHX-30-113, ZHX-36-029, ZHX-36-030, ZHX-36-059, ZHX-20-153A, ZHX-30-150A, ZHX-24-207A FCC ID: 2AVTWZHXEFPI Issued For : Huizhou Zihanxuan Household Electrical Co., Ltd. Yinglong Industrial park, Tiantou Village, Yuanzhou Town, Boluo County, Huizhou City, Guangdong, China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26E079RF01 Sample Received Date: May 14, 2026 Date of Test: May 14, 2026 ~ May 21, 2026 Date of Issue: May 26, 2026 Report No.: LGT26E079RF01 Page 2 of 55 TEST REPORT CERTIFICATION Applicant: Huizhou Zihanxuan Household Electrical Co., Ltd. Address: Yinglong Industrial park, Tiantou Village, Yuanzhou Town, Boluo County, Huizhou City, Guangdong, China Manufacturer: Huizhou Zihanxuan Household Electrical Co., Ltd. Address: Yinglong Industrial park, Tiantou Village, Yuanzhou Town, Boluo County, Huizhou City, Guangdong, China Product Name: ELECTRIC FIREPLACE Trademark: N/A Model Number: ZHX-23-103, ZHX-23-102, ZHX-23-104, ZHX-26-022, ZHX-26-122, ZHX-30-112, ZHX-30-113, ZHX-36-029, ZHX-36-030, ZHX-36-059, ZHX-20-153A, ZHX-30-150A, ZHX-24-207A Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2020 PASS Prepared by: Approved by: Chris Chen Vita Li Engineer Technical Director Report No.: LGT26E079RF01 Page 3 of 55 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST LABORATORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 9 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.5 EQUIPMENTS LIST 11 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 TEST PROCEDURE 14 3.3 TEST SETUP 14 3.4 EUT OPERATING CONDITIONS 14 3.5 TEST RESULTS 15 4. RADIATED EMISSION MEASUREMENT 19 4.1 RADIATED EMISSION LIMITS 19 4.2 TEST PROCEDURE 21 4.3 TEST SETUP 21 4.4 EUT OPERATING CONDITIONS 22 4.5 FIELD STRENGTH CALCULATION 22 4.6 TEST RESULTS (BAND EDGE REQUIREMENTS) 28 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 29 5.1 LIMIT 29 5.2 TEST PROCEDURE 29 5.3 TEST SETUP 29 5.4 EUT OPERATION CONDITIONS 29 5.5 TEST RESULTS 29 6. POWER SPECTRAL DENSITY TEST 30 6.1 LIMIT 30 6.2 TEST PROCEDURE 30 6.3 TEST SETUP 30 6.4 EUT OPERATION CONDITIONS 30 Report No.: LGT26E079RF01 Page 4 of 55 6.5 TEST RESULTS 30 7. BANDWIDTH TEST 31 7.1 LIMIT 31 7.2 TEST PROCEDURE 31 7.3 TEST SETUP 31 7.4 EUT OPERATION CONDITIONS 31 7.5 TEST RESULTS 31 8. PEAK OUTPUT POWER TEST 32 8.1 LIMIT 32 8.2 TEST PROCEDURE 32 8.3 TEST SETUP 32 8.4 EUT OPERATION CONDITIONS 32 8.5 TEST RESULTS 32 9. ANTENNA REQUIREMENT 33 9.1 STANDARD REQUIREMENT 33 9.2 EUT ANTENNA 33 APPENDIX I - TEST RESULTS 34 1. DUTY CYCLE 34 2. BANDWIDTH 37 3. MAXIMUM CONDUCTED OUTPUT POWER 42 4. MAXIMUM POWER SPECTRAL DENSITY 45 5. UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS 48 APPENDIX II - MEASUREMENT PHOTOS 55 Report No.: LGT26E079RF01 Page 5 of 55 Revision History Rev. Issue Date Revisions 00 May 26, 2026 Initial Issue Report No.: LGT26E079RF01 Page 6 of 55 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 Part 15.247 Meas Guidance v05r02. FCC Part 15.247, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Report No.: LGT26E079RF01 Page 7 of 55 1.1 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Occupied Channel Bandwidth ±0.46% 2 RF Output Power, Conducted ±0.71dB 3 Power Spectral Density, Conducted ±1.57dB 4 Unwanted Emission, Conducted ±0.63dB 5 Conducted emission ±2.80dB 6 All Emissions, Radiated (0.009-30MHz) ±2.16dB 7 All Emissions, Radiated (30MHz-1GHz) ±4.61dB 8 All Emissions, Radiated (1GHz-18GHz) ±5.49dB 9 Temperature ±0.5°C 10 Humidity ±2% 11 Duty Cycle ±2.3% Note: The measurement uncertainty is not included in the test result. Report No.: LGT26E079RF01 Page 8 of 55 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: ELECTRIC FIREPLACE Test Model Number: ZHX-23-103 Series Number: ZHX-23-102, ZHX-23-104, ZHX-26-022, ZHX-26-122, ZHX-30-112, ZHX-30-113, ZHX-36-029, ZHX-36-030, ZHX-36-059, ZHX-20-153A, ZHX-30-150A, ZHX-24-207A Model Difference: Only difference in model name Product Description: Operation Freq…

Text truncated - open the document above for the full version.

AntennaSpecification Manufacture：TUYA ProductName：BT3LAntenna AntennaType：PCB TestDate：2020.05.12 Testedby：YinhuaZhang Approvedby：Licco Antenna TestReport Content 1.GeneralDescription..............................................................................1 2.TestConfigurations................................................................................2 2.1TestEnvironment.........................................................................2 2.2TestEquipment............................................................................2 2.3TestPrinciple................................................................................2 3.TestResults...........................................................................................3 3.1GainandEfficiency.......................................................................3 3.2RadiationPattern.........................................................................4 4.AntennaDimensions.............................................................................5 5.EUTPhoto.............................................................................................5 6.TestSetupPhoto...................................................................................6 1 1.GeneralDescription ManufacturerHangzhouTuyaInformationTechnologyCo.,Ltd Address Room701,Building3,MoreCenter,No.87GuDunRoad, Hangzhou,Zhejiang,China TestLocation Room106,Building3,LetongSciencePark,No.500, QiuyiRoad,BinjiangDistrict,Hangzhou ProductNameBT3LAntenna Productmodel BT3L AntennaType PCBAntenna TestItems Gain;Efficiency;RadiationPattern TestFrequency 2400-2500MHz TestStandard ANSI/IEEEStd149-1979 2 2.TestConfigurations 2.1TestEnvironment Temperature(°C)25 Humidity(%RH)60 AtmosphericPressure(kPa)100.5 2.2TestEquipment TestSystemTEM24Multi-probeMicrowaveChamber TestInstrumentAgilentE5071B 2.3TestPrinciple 3 3.TestResults 3.1GainandEfficiency Frequency(MHz)PeakGain(dBi)Efficiency(%) 24001.6252.29 24101.7152.17 24201.9353.14 24301.9854.16 24402.0057.62 24502.1759.64 24602.4561.55 24702.3860.64 24802.5062.86 24902.3059.85 25002.4960.41 4 3.2RadiationPattern Phi02D Phi902D Theta902D 5 2480MHz3D 4.AntennaDimensions 5.EUTPhoto 6 6.TestSetupPhoto

Page 1 of 2 Report No.: LGT26E079 Appendix - Test Setup photos Set-up for Radiated Spurious Emission, Below 1GHz Set-up for Radiated Spurious Emission, Above 1GHz Page 2 of 2 Report No.: LGT26E079 Set-up for Conducted Emission
