2AVU6-T8652RFID Card (RFID Active Tag)

RFID 2.4GHz Active Tag Series Page 1, Total 2 2.4GHz RFID Card Description This 2.4GHz RFID Active Tag is widely used in tracking, attendance management. With spontaneous emission signal, it has a long reading distance and can be identified without triggering. Regarding to the card design, it is sealed with Ultrasonic, so it is completely waterproof. RFID 2.4GHz Active Tag Series Page 2, Total 2 Electrical Characteristics  Static Current: < 3μA  Operating Current: < 15mA, Peak Current: < 40mA  Battery Life: > 4.5 years  Working Speed: About 5 times / 2s Microwave Link Characteristics  Rate of Communication: Bidirectional, 1024K bits/s  Operating Frequency: 2.45GHz  Reading Distance: < 80M Physical Characteristics  Material of Shell: ABS  Type: Read Only  Dimension: 86*52*5mm  Color: White or other customized  Protection Standard: Waterproof IP68  Installation: Hanging, Sticking to the Object Surface Working Environment  Operating Temperature: -40°C~ +80°C  Operating Humidity: < 85%  Storage Temperature: -40°C ~ +80°C  Shake: 10 ~ 2000Hz, 15g Three Axis  Anti Electromagnetic Interference: 10V/m 0.1 ~ 1000MHz AM Amplitude Modulated Electromagnetic Wave Feature & Advantage 1. Anti-Collision: Identify 100pcs Tags/s 2. High Identification Rate: Up to 180km/h 3. Identification Security: Encryption and Authentication to ensure Data Security and Prevent Eavesdropping and Data Cracking 4. Identification Direction: Directional and Non directional Identification Available 5. High Identification Reliability: -40°C ~ +85°C, Anti Shock 6. Effective Cost: Using 0.18uM Chips lead to Lower Cost Remark: 1. Specifications are subject to change, please pay attention to our latest one. 2. DAILY RFID reserve the right to the final interpretation of the above terms. RFID 2.4GHz Active Tag Series Page 3, Total 2 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Warning: changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment The devices has been evaluated to meet general RF exposure requirement， the device can be used in portable exposure condition with restriction

Model difference letter Model: 2.4GHz RFID Active Tag-10(T8652), 2.4GHz RFID Active Tag-09(T5030), 2.4GHzRFID Active Student Card-14(T8351), 2.4GHz RFID Active Tag-15(T29030) DL9230Plus, DL9230W, DL9230G, DL9330, 2.4GHz~2.5GHz RFID Reader (RFID Active Reader) DL9230. All model’s the function, software and electric circuit are the same, the appearance color and model named of product are different. Test sample model: 2.4GHz RFID Active Tag-10(T8652) Sincerely Signature Name: Jack Wang Title: Manager Company: DAILY RFID CO., LIMITED Address: 5/F, China Hotel Commercial Building,NO.122,Liuhua Road, Guangzhou

DAILY RFID CO., LIMITED (March 31. 2020) MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR EUT: RFID Card (RFID Active Tag) Model: 2.4GHz RFID Active Tag-10(T8652) FCC ID: 2AVU6- T8652 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the -Schematic -Block diagram -Operation description required to be submitted with this application be permanently withheld from public review. the above documents are company proprietary information that could never get into the possession of your competition). Please contact me if there is any information you may need. Sincerely, Signature Name: Jack Wang Title: Manager Company: DAILY RFID CO., LIMITED Address: 5/F,China Hotel Commercial Building,NO.122,Liuhua Road, Guangzhou

DAILY RFID CO., LIMITED (March 31. 2020) Eurofins MET Labs 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Flux Compliance Service Laboratory to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature Name: Jack Wang Title: Manager Company: DAILY RFID CO., LIMITED Address: 5/F,China Hotel Commercial Building,NO.122,Liuhua Road, Guangzhou

Label and Label Location FCC ID: 2AVU6-T8652 L*W: 15mm*4mm Black font on a white label

FCC Test Report Report No: FCS20200221006W01 Issued for Applicant: DAILY RFID CO., LIMITED Address: 5/F,China Hotel Commercial Building,NO.122,Liuhua Road, Guangzhou Product Name: RFID Card (RFID Active Tag) Brand Name: N/A Model Name: 2.4GHz RFID Active Tag-10(T8652) Series Model: 2.4GHz RFID Active Tag-09(T5030), 2.4GHzRFID Active Student Card-14(T8351), 2.4GHz RFID Active Tag-15(T29030) DL9230Plus, DL9230W, DL9230G, DL9330, 2.4GHz~2.5GHz RFID Reader (RFID Active Reader) DL9230. FCC ID: 2AVU6- T8652 Issued By: Flux Compliance Service Laboratory Add: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com Page 2 of 29 Test Report No.: FCS20200221006W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com TEST RESULT CERTIFICATION Applicant’s Name ................... : DAILY RFID CO., LIMITED Address ................................. : 5/F,China Hotel Commercial Building,NO.122,Liuhua Road, Guangzhou Manufacture's Name .............. : DAILY RFID CO., LIMITED Address ................................. : 3/F, Building A, Huadu Industrial park, Huadu District, Guangzhou Product Description Product Name ........................ : RFID Card (RFID Active Tag) Brand Name ......................... : N/A Model Name .......................... : 2.4GHz RFID Active Tag-10(T8652) Series Model .......................... : 2.4GHz RFID Active Tag-09(T5030), 2.4GHzRFID Active Student Card-14(T8351), 2.4GHz RFID Active Tag-15(T29030) DL9230Plus, DL9230W, DL9230G, DL9330, 2.4GHz~2.5GHz RFID Reader (RFID Active Reader) DL9230. Test Standards ....................... : FCC Rules and Regulations Part 15 Subpart C, Section 249 Test Procedure ...................... : ANSI C63.10:2013 This device described above has been tested FCS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of FCS, this document may be altered or revised by FCS, personal only, and shall be noted in the revision of the document.. Date of Test ...............................: Date (s) of performance of tests ...................: 10 Feb. 2020 ~ 22 Feb. 2020 Date of Issue ............................. : 22 Feb. 2020 Test Result ..................................: Pass Tested by : (Chris Chen) Reviewed by : (Jack Chen) Approved by : ( Andy yue) Page 3 of 29 Test Report No.: FCS20200221006W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF THE EUT 7 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.4 EQUIPMENTS LIST 11 3 CONDUCTED EMISSION MEASUREMENT 12 3.1 LIMIT 12 3.2 TEST PROCEDURE 12 3.3 TEST SETUP 13 3.5 TEST RESULTS 13 4. RADIATED EMISSION MEASUREMENT 14 4.1 LIMIT 14 4.2 TEST PROCEDURE 15 4.3 TEST SETUP 16 4.5 TEST RESULTS 17 5. BAND EDGE TEST 21 5.1 LIMIT 21 5.2 TEST PROCEDURE 21 5.3 TEST SETUP 22 5.4 TEST RESULTS 23 6. 20 DB BANDWIDTH TEST 27 6.1 LIMIT 27 6.2 TEST PROCEDURE 27 6.3 TEST SETUP 27 6.4 TEST RESULTS 28 7. ANTENNA REQUIREMENT 29 7.1 STANDARD REQUIREMENT 29 7.2 EUT ANTENNA 29 Page 4 of 29 Test Report No.: FCS20200221006W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com Revision History Rev. Issue Date Effect Page Contents 00 22 Feb. 2020 All Initial Issue Page 5 of 29 Test Report No.: FCS20200221006W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.249 Meas Guidance v05r02 FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A -- 15.205(a), 15.209(a), 15.249(a), 15.249(c) Radiated Spurious Emission PASS -- 15.209 Field strength of fundamental PASS -- 15.249(d) Band Edge Emission PASS -- 15.215(c) 20dB Bandwidth PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1)” N/A” denotes test is not applicable in this Test Report (2) All tests are according to ANSI C63.10-2013 Page 6 of 29 Test Report No.: FCS20200221006W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com 1.1 TEST FACTORY Company Name: Flux Compliance Service Laboratory Address: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Telephone: +86-769-27280901 Fax: +86-769-27280901 FCC Test Firm Registration Number: 514908 Designation number: CN0127 A2LA accreditation number：5545.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.71dB 2 Unwanted Emissions, conducted ±2.98 dB 3 Conducted Emission (9KHz-150KHz) ±4.13 dB 4 Conducted Emission (150KHz-30MHz) ±4.74 dB 5 All emissions,radiated(<1G) 30MHz-1000MHz ±3.2 dB 6 All emissions,radiated (1GHz -18GHz) ±3.…

Text truncated - open the document above for the full version.

Blow 1GHz for radiated emission test setup Above 1GHz for radiated emission test setup
