2AVVCT35DRF Card Reader

T-35 Installation and operation manual ( EN : V1.0 ) www.arvratech.com Contents 1. T-35 product specification2. Installation environment3. Components4. Device description5. Connector layout6. Connector pin assign7. Installation8. Device Setup Top Of Security Company 2 www.arvratech.com www.arvratech.com 1.T-35 Specification Item Specification CPU 32bit Microcontroller + 240Mhz H.264 Codec MPU Memory 64MB RAM + 128MB Flash Firmware Update By USB Flash Memory LCD 3.5” TFT Color LCD Touch Screen Capacitive glass full touch screen Video Play H.264 (MPEG4) RF 13.56 Mhz Card formats ISO 14443A/B, 15693, EMVO Wiegand D0, D1, Pass LED, Fail LED, Buzzer, Tamper Sound SupportedPower 12V (9~ 40V Input)Current 100mA Size 120 X 70 X 17mm Operation Temperature -20 ~ 70°C 2. Installation environment Please choose the installation location after checking the foll owing conditions. The installation method requires to receive consent by users. 1. Setup the device internal place. When you must terminal outsi de, please make supplement box to protect terminal at outside environment. 2. Do not install in place under direct sunlight, water, severe change of temperature and explosives. 3. The connecting cable should not be exposed to the outside (recommend to reclaiming work). If it’s impossible, we recommen d to receive consent by users before installation. 4. Turn the power on after finishing the cable installation and do not any cable work with power connection. 5. Install user-friendly height and near the door for easy to us e 4 www.arvratech.com 3. Components Metal Bracket Device Screws T-35 terminal Extension Bracket www.arvratech.com 6pin & 2pin connector cable 4. Device description -Front - 6 3.5” Color LCD window-Display the wallpaperand all operation status Speaker-Voice guidance-Buzzer sounds Card reading-MIFARE(13.56Mhz)-EM(125Khz)-HID Prox Front : Touch screen www.arvratech.com Power LED 5.Connector layout www.arvratech.com No Description 1 J16 : Power supply (Direct connection with 12V adapter) 2 J19 : Wiegand Out - J24 - - J10 - TEL_LINE1TEL_LINE2 12V DC GND I/O Man 을 통해서 파워를 공급 받지 않고 바로 12 V adaptor 에 연결 시킬 시 -J3 - 6.Connector pin assign J16(Power) J19(Wiegnad_OUT) Wiegand D1Wiegand D0PASSFAILBEEPTAMPER +12VGND www.arvratech.com 7.Installation < Wall mounting screw > < Wall mounting metal bracket>  Mounting the metal bracket to a wall  Joining the device with the bracket  Screw it in the device at the bottom side <T-35> www.arvratech.com * Administrator Login The settings is for setup Input card, Operation mode, Format setting, Setup and System. • Go into Settings : Scroll down th e wall paper with the finger t ap. • Press the “Settings” icon and press the password set to ‘ 1111 ’ as initial password and then press “Enter( )” button. Appears the setting menu.  CAUTION : Please change the factory setting administrator passwo rd. (Settings=> Setup => Admin pass word=> Admin password => Enter bu tton) 8. Device setup 1 Scroll down It’s for setting the menu of ‘Authentication mode’, ‘Authentic ation result’ ,‘Video’, ‘ Display date time’ and Antenna output level’.• Authentication mode : Select ‘General mode(Keypad+Card)’ or ‘Card only’. • Authentication result : Setup ‘LED’ and ‘Beep’. • Video : Setup ‘Video’ play. • Antenna output : Setup ‘Antenna output’. * Operation mode www.arvratech.com 8.Device setup 2 <Setup ‘Authentication mode’> <Setup ‘Authentication result’> <Setup ‘Video’> It’s for setting menu for ‘system’, ‘Firmware’ and ‘Resources’ etc. • View All Settings : Display a firmware version and model No. • Initialize : Initialize the system setup.(Init Setup - • Import from USB : Upgrade a Firmware, Resources, Background screen(wall paper) and Setup files from USB flash memory.• Export to USB : Save the device setup files to USB flash memory. • Re-initialize Device : Restart system. (It’s same as a power reset without any chang ing data) * System www.arvratech.com 8.Device setup3 www.arvratech.com NOTE: THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIF ICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUC H MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQ UIPMENT. 15.105(b):- NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designe d to provide reasonable protection against harmful interference in a res idential installation. This equipment generates uses and can radiate radio frequency e nergy and, if not installed and used in accordance with the instructions, may cause harmful interferen ce to radio communications. However, there is no guarantee that interference will not occur in a par ticular installation. If this equipment does cause harmful interference to radio or t elevision reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna.- Increase the separation between the equipment and receiver.- Connect the equipment into an outlet on a circuit different fr om that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for h elp. FCC Warnning Statment E‐mail:sales @arvratech.com , Website: www.arvratech.com Arvratech Co.,Ltd. 508, Woolim Lions Valley 2cha , 2, Gasan digital 1-ro, Geumcheon-gu, Seoul, Korea Tel : 82-2-2027-2027 Fax : 82-2-2027-2028 E-mail : [email protected]

807, housD The SkyValley 2‐Cha, Beoman‐ro 1142, Geumcheon‐gu, Seoul, 08595, South Korea Tel/Fax: 82‐2‐2027‐2028 / 82‐2‐2027‐2027 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 2020. 03. 09 Product: RF Card Reader Model: T-35D FCC ID: 2AVVCT35D SUBJECT: Attestation letter for Declaration of Conformity Dear Sir or Madam: We, the undersigned, hereby attest to declare that the composite portion categorized as all other devices has been authorized under the Supplier’s Declaration of Conformity procedures. Sincerely, ___________________________________ Su Hyeon Choe / President Telephone Number: +82-2-2027-2028 Address: 807, housD The SkyValley 2-Cha, Beoman-ro 1142, Geumcheon-gu, Seoul, 08595, South Korea

Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 TIMCO ENGINEERING INC. TCB & FCB 849 NW State Road 45 FCC Approvals Newberry, Florida 32669 Industry Canada Approvals http://www.timcoengr.com Notified Body for Europe 888.472.2424 F 352.472.2030 email: [email protected] 2020. 03. 11. SUBJECT: UPLOAD FILES TO WEBSITE Product: RF Card Reader Applicant: ARVRATECH Co., Ltd Model: T-35D Address: 807, housD The SkyValley 2-Cha, Beoman-ro 1142, Geumcheon-gu, Seoul, 08595, South Korea FCC ID: 2AVVCT35D Dear Sir/Madam As appointed agent for ARVRATECH Co., Ltd, we submit the application to Timco Engineering Inc, for certification of the above product. Please review all files uploaded to Timco web site. If you have any queries, please do not hesitate to contact us Best regards, Kwang-Yeol Choo / Test Engineer e-mail: [email protected]

807, housD The SkyValley 2‐Cha, Beoman‐ro 1142, Geumcheon‐gu, Seoul, 08595, South Korea Tel/Fax: 82‐2‐2027‐2028 / 82‐2‐2027‐2027 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC Application for FCC ID: 2AVVCT35D To Whom It May Concern: We, the undersigned, hereby authorize Kwang-Yeol, Choo at Kostec Co., Ltd on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Kwang-Yeol, Choo at Kostec Co.,Ltd on our behalf shall have the same effect as acts of our own. Sincerely, Date: 2020. 03. 09. ____________________________ Su Hyeon Choe President

807, housD The SkyValley 2‐Cha, Beoman‐ro 1142, Geumcheon‐gu, Seoul, 08595, South Korea Tel/Fax: 82‐2‐2027‐2028 / 82‐2‐2027‐2027 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Confidentiality Request regarding application for certification of FCC ID: 2AVVCT35D Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File name Block diagram Circuit Description Operational Description Part list CONF APPENDIX_T-35D_BLK CONF APPENDIX_T-35D_SCH CONF APPENDIX_T-35D_Operational Description CONF APPENDIX_T-35D_BOM The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 and 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Date: 2020. 03. 09. ____________________________ Su Hyeon Choe President

Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Page: 1 / 4 Appendix 2. Photographs of EUT [External View] [Front] [Rear] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Page: 2 / 4 [ Top ] [ Bottom ] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Page: 3 / 4 [ Left ] [ Right ] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Page: 4 / 4 [ Port 1 ] [ Port 2 ]

Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Page: 1 / 1 ppendix 4. Sample Label & Location Label Information The following is a sample copy of the label that will be placed on back side of the product. The FCC ID is marked in the product label and below information is visible printed on the label. Label location The label shown above shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase. The label is located here. RF Card Reader INPUT POWER: 12 V MODEL NAME: T-35D FCC ID: 2AVVCT35D MANUFACTURER: ARVRATECH Co., Ltd This device complies with part 15 of the FCC Rules, Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Page: 1 / 4 Appendix 3. Photographs of EUT [Internal View] [ Main Board Top] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Page: 2 / 4 [Main Board Bottom] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Page: 3 / 4 [Inside] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Page: 4 / 4 [Antenna] Antenna

Report No.: KST-FCR-200003 KST-FCR-RFS-Rev.0.5 Page: 2 / 20 This report shall not be reproduced except in full without the written approval of KOSTEC Co., Ltd, Table of Contents 1. GENERAL INFORMATION .............................................................................................................. 3 1.1 Test Facility ............................................................................................................................................... 3 1.2 Location .................................................................................................................................................... 3 1.3 Revision History of test report .................................................................................................................. 4 2. EQUIPMENT DESCRIPTION ........................................................................................................... 5 3. SYSTEM CONFIGURATION FOR TEST ......................................................................................... 6 3.1 Characteristics of equipment .................................................................................................................... 6 3.2 Used peripherals list ................................................................................................................................. 6 3.3 Product Modification ................................................................................................................................. 6 3.4 Operating Mode ........................................................................................................................................ 6 3.5 Test Setup of EUT .................................................................................................................................... 6 3.6 Used Test Equipment List ......................................................................................................................... 7 4. SUMMARY TEST RESULTS ............................................................................................................ 9 5. MEASUREMENT RESULTS .......................................................................................................... 10 5.1 Carrier Frequency tolerance ................................................................................................................... 10 5.2 Field strength of radiated emissions ...................................................................................................... 11 5.3 Antenna requirement .............................................................................................................................. 17 5.4 AC Power Conducted emissions ............................................................................................................ 18 5.5 20 ㏈ bandwidth measurement ............................................................................................................. 20 Report No.: KST-FCR-200003 KST-FCR-RFS-Rev.0.5 Page: 3 / 20 This report shall not be reproduced except in full without the written approval of KOSTEC Co., Ltd, 1. GENERAL INFORMATION 1.1 Test Facility Test laboratory and address KOSTEC Co., Ltd. 28(175-20,Annyeong-dong)406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Telephone Number: 82-31-222-4251 Facsimile Number: 82-31-222-4252 Registration information KOLAS No.: KT232 RRA (National Radio Research Agency): KR0041 FCC Designation No.: KR0041 IC Designation No.: KR0041 VCCI Membership No.: 2005 1.2 Location KOSTEC Co., Ltd. Report No.: KST-FCR-200003 KST-FCR-RFS-Rev.0.5 Page: 4 / 20 This report shall not be reproduced except in full without the written approval of KOSTEC Co., Ltd, 1.3 Revision History of test report Rev. Revisions Effect page Reviewed Date - Initial issue All Gyeong Hyeon, Park 2020. 03. 11. Report No.: KST-FCR-200003 KST-FCR-RFS-Rev.0.5 Page: 5 / 20 This report shall not be reproduced except in full without the written approval of KOSTEC Co., Ltd, 2. EQUIPMENT DESCRIPTION The product specification described herein was declared by manufacturer. And refer to user’s manual for the details. Equipment Name RF Card Reader Model No T-35D Usage RF Card Reader Serial Number Proto type Modulation type ASK Oscillation Type X-tal Maximum output power 17.19 ㏈㎶/m @ 30 meter Operated Frequency 13.561 3 MHz Channel Number 1 Operation temperature -20 °C - + 50 °C Power Source DC 12 V Antenna Description Internal PCB antenna Remark 1. The device was operating at its maximum output power for all measurements. 2. The radiation measurements are performed in X, Y, Z axis positioning. Only the worst case (Y) is shown in the report. 3. The above DUT’s information was declared by manufacturer. Please refer to the specifications or user manual for more detailed description. FCC ID 2AVVCT35D Report No.: KST-FCR-200003 KST-FCR-RFS-Rev.0.5 Page: 6 / 20 This report shall not be reproduced except in full without the written approval of KOSTEC Co., Ltd, 3. SYSTEM CONFIGURATION FOR TEST 3.1 Characteristics of equipment The Equipment Under Test (EUT) contains the following capabilities: This equipment is RF Card Reader. The detailed explanation is refer as user manual. 3.2 Used peripherals list Description Model No. Serial No. Manufacture Remark Measuring Instrument None None None - Adaptor CAD24122 None NingBo Iso Electronic Co., Ltd. - RFID Card None None None - 3.3 Product Modification N/A 3.4 Operating Mode Constantly transmitting with a modulated carrier at maximum power. 3.5 Test Setup of EUT The measurements were taken in continuous transmit mode using the test mode. The test program and the cables were provided by the applicant. EUT Measuring Instrument Adaptor RFID Card Report No.: KST-FCR-200003 KST-FCR-RFS-Rev.0.5 Page: 7 / 20 This report shall not be reproduced except in full without the written approval of KOSTEC Co., Ltd, 3.6 Used Test Equipment List No. Instrument Model S/N Manufacturer Next Cal Da…

Text truncated - open the document above for the full version.

Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Page: 1 / 2 Appendix 1. Photographs of test setup Radiated RF measurement (Below 30 MHz) Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Page: 2 / 2 Radiated RF measurement (Above 30 MHz)
