1 Quick Start Guide 2 Introduction Thank you for your choosing the new Tablet PC. This guide serves to enable users to get to know and familiar with our product as soon as possible. Here we have made a brief introduction to the key layout and definitions in figures and words. Contents . IPrecautions before Use .......................................................................................... 3 II.Key Layout and Definitions ................................................................................... 4 III. Descriptions of Keys .............................................................................................. 5 IV. Usage scenario ........................................................................................................ 6 V. Introduction to Desktop ........................................................................................ 7 1. Image Slide Application ...................................................................................... 7 2. Cortana ................................................................................................................ 7 3. Introduction to app Interface ............................................................................... 8 4. Start Menu ......................................................................................................... 10 5. Multitasking operating interface ....................................................................... 12 . Basic OperationsVI .................................................................................................. 13 1.Sleep, Shut down and Restart ............................................................................ 13 3 . IPrecautions before Use 1. This production is suitable for use in non-tropic areas below 2,000 meters, and the mark in the nameplate indicates the product is suitable for use in non-tropic areas. 2. Prevent the Tablet PC from falling to the ground or being strongly impacted otherwise. 3. Do not use it in the long term in any environment where the air is too cold, too hot (<35°C), too humid or with too much dust. Do not expose the Notebook PC to sunlight. 4. Avoid using it in the strong magnetic and strong static environment as much as possible. 5. Once any water or other liquid splashes onto the Notebook PC, close it immediately and do not use it until it dries out. 6. Do not clean the Tablet PC with any detergent containing chemical element or other liquid to avoid causing damage due to corrosion and becoming damp. If cleaning is really necessary, clean it with dry soft cloth tissue paper. 7. Our company shall not bear any and all responsibilities for loss or deletion of material inside the machine caused due to abnormal software and hardware operation, maintenance or any other accident. 8. Please back up your important material at any time to avoid loss. 9. Please do not disassemble the Tablet PC by yourself; otherwise you will lose the right to warranty. 10. This product supports the overwhelming majority of mainstream brands of 3G DONGLE network cards. The cases for 3G Dongle may be different. It is suggested that you test it to make sure it is OK before buying it. 11. Quick Use Guide and the relevant software shall be updated at any time. For updated software version, visit www.xxx.com for downloading by yourself, and no notice shall be given otherwise. If any anything is found to be inconsistent with the Quick Use Guide, the material object shall prevail. 12. Replacement with incorrect type batteries may cause explosion. Make sure to use original batteries. 4 II.Key Layout and Definitions YP11G-E正面 Touch Panel Front Camera Keyboard group DC&Power light 5 YP11G-E侧面2 YP11G-E侧面1 III. Descriptions of Keys Attention: Keyboard is optional, and configure the product according to the specific type of the tablet PC you have bought. YP11G-E背面 Base-C Base-D DC USB3.0 Typ e- C HDMI USB3.0 Socket for earphone TF 6 IV. Usage scenario 360° Free rotation in 360 degrees brings the convenience for users. Hall-Power Screen with keyboard to Cover，Windows OS Automatically entered into the Sleep. 7 V. Introduction to Desktop 1. Image Slide Application Windows 10 start image: On the start screen, you can see many programs fixed in the image. These application programs are displayed in the form of “magnet”. As long as you click them, you can easily visit them. You need to log on your Microsoft account before the application program completely runs. 2. Cortana Use Cortana for fast smart searching. 8 3. Introduction to app Interface Besides the application programs already fixed on the “start” screen, you can also fix other applications, programs, folders, etc to the "start" screen. 3.1. If you want to fix more application programs on the start interface, see the operation in the figure below. In the start menu, right-click the application you want to fix and select "Pin to Star". You can also drag the application onto the “start” screen, as follows: Conversely, if you want to cancel or delete a certain application in the start screen, (1) Right-Clicking the application, (2)Click the “Unpin from Start”. 9 3.2. If you want to fix more application programs on the taskbar, see the operation in the figure below. In the start menu, right-click the application you want to fix and select "More"，and then select"Pin to taskbar". You can also drag the application onto the taskbar, as follows: Conversely, if you want to cancel or delete a certain application in the taskbar, (1) Right-Clicking the application, (2)Click the “Unpin this program from taskbar”. 10 4. Start Menu Under PC mode, press Start icon, Start Menu will display including: Start, Device, Setup, Share, and Search Program. 11 Usually: Power, Settings and Account. Can Change account setting/Lock/Sign out . Can let you set up the Table PC. Can Sleep/Shut down/Restart the Notebook PC Action Center is a notification center also allows for quick settings like Tablet / PC mod…

Text truncated - open the document above for the full version.

DATE :03/23/2020 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AVWN-ES1AU11 _ Product Name: netbook Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Pablo Cuello / General Manager Company: CASA DUARTE SRL Addess: Socrates Nolasco No.2, Santo Domingo, Republica Dominicana. Tel: +809-566-7577 Fax: +809-566-7577 E-mail: [email protected]

DATE :03/23/2020 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). < <Signature> Name: Pablo Cuello / General Manager Company: CASA DUARTE SRL Addess: Socrates Nolasco No.2, Santo Domingo, Republica Dominicana. Tel: +809-566-7577 Fax: +809-566-7577 E-mail: [email protected]

DATE :03/23/2020 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Flux Compliance Service Laboratory/ Baohao Technology Bldg. 1, No.15 Gongye W. Rd. Hi-Tech Industrial Park, Songsham Lake, DongGuan, China (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with CASA DUARTE SRL / Socrates Nolasco No.2, Santo Domingo, Republica Dominicana. (Applicant Name and address) <Signature> Name: Pablo Cuello / General Manager Company: CASA DUARTE SRL Addess: Socrates Nolasco No.2, Santo Domingo, Republica Dominicana. Tel: +809-566-7577 Fax: +809-566-7577 E-mail: [email protected]

Page 1 of 12 FCC ID: 2AVWN-ES1AU11 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model No.: ES1AU11 Photo 1 Photo 2 Page 2 of 12 FCC ID: 2AVWN-ES1AU11 Photo 3 Photo 4 Page 3 of 12 FCC ID: 2AVWN-ES1AU11 Photo 5 Photo 6 Page 4 of 12 FCC ID: 2AVWN-ES1AU11 Photo 7 Photo 8 Page 5 of 12 FCC ID: 2AVWN-ES1AU11 Photo 9 Photo 10

LABELING AND LOCATION Label Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

Page 6 of 12 FCC ID: 2AVWN-ES1AU11 Photo 11 Photo 12 BT&WIFI AntennaB WIFI AntennaA Page 7 of 12 FCC ID: 2AVWN-ES1AU11 Photo 13 Photo 14 Page 8 of 12 FCC ID: 2AVWN-ES1AU11 Photo 15 Photo 16 Page 9 of 12 FCC ID: 2AVWN-ES1AU11 Photo 17 Photo 18 Page 10 of 12 FCC ID: 2AVWN-ES1AU11 Photo 19 Photo 20 Page 11 of 12 FCC ID: 2AVWN-ES1AU11 Photo 21 Photo 22 Page 12 of 12 FCC ID: 2AVWN-ES1AU11 Photo 23 Photo 24

FCS REPORT FCC Test Report Report No: FCS20200308007W02 Issued for Applicant: CASA DUARTE SRL Address: Socrates Nolasco No.2, Santo Domingo, República Dominicana. Product Name: netbook Brand Name: SAELITE Model Name: ES1AU11 Series Model: YP11G-E FCC ID: 2AVWN-ES1AU11 Issued By: Flux Compliance Service Laboratory Add: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong yeWest Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com Page 2 of 62 Test Report No.: FCS20200308007W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong yeWest Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com Table of Contents Page 1. SUMMARY OF TEST RESULTS 7 1.1TEST LABORATORY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 TEST ENVIRONMENT CONDITIONS 8 2. GENERAL INFORMATION 9 2.1 GENERAL DESCRIPTION OF THE EUT 9 2.2 CHANNEL LIST 10 2.3 ASSISTANT EQUIPMENT USED FOR TEST 11 2.4 DESCRIPTION OF THE TEST MODES 11 2.5 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 2.6 EQUIPMENTS LIST 12 3. MAXIMUM PEAK OUTPUT POWER 13 3.1 BLOCK DIAGRAM OF TEST SETUP 13 3.2 LIMIT 13 3.3 TEST PROCEDURE 13 3.5 TEST RESULT 13 3.6 ORIGINAL TEST DATA 14 4. 20DB BANDWIDTH AND 99% BANDWIDTH 19 4. 1 BLOCK DIAGRAM OF TEST SETUP 19 4.2LIMIT 19 4.3 TEST PROCEDURE 19 4.4 TEST RESULT 19 4.5 ORIGINAL TEST DATA 20 5. CARRIER FREQUENCY SEPARATION 23 5.1 BLOCK DIAGRAM OF TEST SETUP 23 5.2LIMIT 23 5.3 TEST PROCEDURE 23 Page 3 of 62 Test Report No.: FCS20200308007W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong yeWest Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com Table of Contents Page 5.4 TEST RESULT 23 5.5 ORIGINAL TEST DATA 24 6. NUMBER OF HOPPING CHANNEL 25 6.1 BLOCK DIAGRAM OF TEST SETUP 25 6.2LIMIT 25 6.3 TEST PROCEDURE 25 6.4 TEST RESULT 25 6.5 ORIGINAL TEST DATA 26 7. DWELL TIME 27 7.1 BLOCK DIAGRAM OF TEST SETUP 27 7.2LIMIT 27 7.3 TEST PROCEDURE 27 7.4 TEST RESULT 27 7.5 ORIGINAL TEST DATA 28 8. BAND EDGE COMPLIANCE (CONDUCTED METHOD) 31 8.1 BLOCK DIAGRAM OF TEST SETUP 31 8.2LIMIT 31 8.3 TEST PROCEDURE 31 8.4 TEST RESULT 31 8.5 ORIGINAL TEST DATA 32 9. RADIATED EMISSION 34 9.1 BLOCK DIAGRAM OF TEST SETUP 34 9.2 FCC 15.209 LIMIT 35 9.3 TEST PROCEDURE 36 9.4 TEST RESULT 37 10. CONDUCTED SPURIOUS EMISSIONS 45 10.1 BLOCK DIAGRAM OF TEST SETUP 45 Page 4 of 62 Test Report No.: FCS20200308007W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong yeWest Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com Table of Contents Page 10.2LIMIT 45 10.3 TEST PROCEDURE 45 10.4 TEST RESULT 46 10.5 ORIGINAL TEST DATA 47 11. BAND EDGE COMPLIANCE(RADIATED METHOD) 53 11.1 BLOCK DIAGRAM OF TEST SETUP 53 11.2LIMIT 53 11.3 TEST PROCEDURE 53 11.4 TEST RESULT 53 11.5 ORIGINAL TEST DATA 54 12. POWER LINE CONDUCTED EMISSION 58 12.1 BLOCK DIAGRAM OF TEST SETUP 58 12.2LIMIT 58 12.3 TEST PROCEDURE 58 12.4 TEST RESULT 59 12.5 ORIGINAL TEST DATA 60 13. ANTENNA REQUIREMENTS 62 13.1 LIMIT 62 13.2 RESULT 62 Page 5 of 62 Test Report No.: FCS20200308007W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong yeWest Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com Revision History Rev. Issue Date Effect Page Contents 01 01 March 2020 All Initial Issue Page 6 of 62 Test Report No.: FCS20200308007W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong yeWest Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com TEST RESULT CERTIFICATION Applicant’s Name ................... : CASA DUARTE SRL Address .................................. : Socrates Nolasco No.2, Santo Domingo, República Dominicana. Manufacture's Name .............. : CASA DUARTE SRL Address .................................. : Socrates Nolasco No.2, Santo Domingo, República Dominicana. Product Description Product Name ........................ : netbook Brand Name ......................... : SAELITE Model Name ........................... : ES1AU11 Series Model .......................... : YP11G-E Test Standards ....................... : FCC Rules and Regulations Part 15 Subpart C(15.247) Test Procedure ....................... : ANSI C63.10:2013. This device described above has been tested FCS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of FCS, this document may be altered or revised byFCS, personal only, and shall be noted in the revision of the document.. Date of Test ................................ : Date (s) of performance of tests . : 09 January 2020 ~ 01 March 2020 Date of Issue .............................. : 01 March 2020 Test Result .................................. : Pass Prepared By : (Chris Chen) Approved By : (Andy Yue) Page 7 of 62 Test Report No.: FCS20200308007W02 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong yeWest Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.FCS-lab.com 1. Summary of Test Results Standard Section Test Item Judgment Remark FCC Part 15.247(b)(1) ANSI C63.10:2013 Maximum Peak Output Power PASS FCC Part 15.215 ANSI C63.10:2013 20dB Bandwidth and 99% Bandwidth PASS FCC Part 15.247(a)(1) ANSI C63.10:2013 Carrier Frequency Separation PASS -- FCC Part 15.247(a)(iii) ANSI C63.10:2013 Number of Hopping Frequency PASS FCC Part 15.247(a)(iii) ANSI C63.10:2013 Dwell Time PASS FCC Part 15.209 FCC Part 15.247(d) ANSI C63.10:2013 Radiated Emission PASS FCC Part 15.247(d…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: 2AVWN-ES1AU11 Radiated Emission Test Setup Below 1G Above 1G Page 2 of 2 FCC ID: 2AVWN-ES1AU11 Power Line Conducted Emission Test Setup
