2AVXN-KW-M01Wireless microphone

538.50MHz - 592.1MHz Wireless microphone Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC STATMENT： This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. RF exposure compliance statement: This device has been evaluated to meet the general RF exposure requirement 1.CH:03(539.700MHz) is the frequency band value; NOTE: Please use the receiver 3.5mm out to connect your amplifer/speaker.

Shenzhen Travor Technology Co, Ltd. Agent Authorization Company: Shenzhen Travor Technology Co, Ltd. Address: Room A5B6, Building 2, Shangrong Industrial Park Baolong 5th Road, Longgang Street, Longgang District, Shenzhen, China Product Name: Wireless microphone Model Number(s): KW-M01 Product Description: wireless microphone We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Date: Apr. 01, 2020Signature: Name: Youmei Li Title: manager Company: Shenzhen Travor Technology Co, Ltd.

Shenzhen Travor Technology Co, Ltd. Date: Apr.01, 2020 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject; Request for Confidentiality FCC ID: 2AVXN-KW-M01 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Youmei Li Title: manager

SIZE: 30*10mm Wireless microphone MODEL: KW-M01 FCC ID: 2AVXN-KW-M01

ANTENNA battery

RF Exposure Evaluation Test report On Behalf of Shenzhen Travor Technology Co, Ltd. For Wireless microphone Model No.: KW-M01 FCC ID: 2AVXN-KW-M01 Prepared for : Shenzhen Travor Technology Co, Ltd. Room A5B6, Building 2, Shangrong Industrial Park Baolong 5th Road, Longgang Street, Longgang District, Shenzhen, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China Date of Test: Mar. 18, 2020~ Mar. 28, 2020 Date of Report: Mar. 28, 2020 1 General Description of EUT Equipment Wireless microphone Model Name KW-M01 Serial No. N/A Trade Mark Travor FCC ID 2AVXN-KW-M01 Hardware Version: V1.3 Software Version: V1.1.0.3 Operation frequency 538.5MHz – 592.1MHz (both mode A and mode B) Number of Channels 50 (both mode A and mode B) Antenna Type External Antenna Antenna Gain 0dBi Modulation Type FM Power Source DC 3.7V from battery 2 RF Exposure Compliance Requirement 2.1 Standard Requirement According to KDB447498D01 General RF Exposure Guidance v06 4.3.1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. 2.2 Limits The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, Where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearset mW and mm before calcution The results is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion 3 EUT RF Exposure FM Channel Maximum Peak Conducted Output Power (dBm) Tune up tolerance (dBm) Maximum tune-up Power Calculated value Exclusion threshold (dBm) (mW) Lowest (538.5MHz) 10.889 11±1 12 15.849 2.326 3.0 Middle (548.1MHz) 10.894 11±1 12 15.849 2.347 Highest (558.1MHz) 10.946 11±1 12 15.849 2.368 Conclusion: the calculated value ≤3.0, SAR is exempted. FM Channel Maximum Peak Conducted Output Power (dBm) Tune up tolerance (dBm) Maximum tune-up Power Calculated value Exclusion threshold (dBm) (mW) Lowest (572.5MHz) 10.120 11±1 12 15.849 2.398 3.0 Middle (582.1MHz) 10.990 11±1 12 15.849 2.418 Highest (592.1MHz) 10.961 11±1 12 15.849 2.439 Conclusion: the calculated value ≤3.0, SAR is exempted. Remark: The Max Conducted Peak Output Power data refer to report Report No.: HK2003190350-E

Page 1 of 37 Report No.: HK2003190350-E FCC TEST REPORT Test report On Behalf of Shenzhen Travor Technology Co, Ltd. For Wireless microphone Model No.: KW-M01 FCC ID: 2AVXN-KW-M01 Prepared for : Shenzhen Travor Technology Co, Ltd. Room A5B6, Building 2, Shangrong Industrial Park Baolong 5th Road, Longgang Street, Longgang District, Shenzhen, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China Date of Test: Mar. 18, 2020~ Apr. 07, 2020 Date of Report: Apr. 07, 2020 Report Number: HK2003190350-E Page 2 of 37 Report No.: HK2003190350-E TEST RESULT CERTIFICATION Applicant’s name .................. : Shenzhen Travor Technology Co, Ltd. Address ................................... : Room A5B6, Building 2, Shangrong Industrial Park Baolong 5th Road, Longgang Street, Longgang District, Shenzhen, China Manufacture's Name ............. : Shenzhen Kicada Technology Co, Ltd. Address ................................... : 9 Buildings , Xinlifeng Industrial Zone, Pinghu Street, Longgang District, Shenzhen City, Guangdong Province, China Product description Trade Mark ................................ : Travor Product name............................ : Wireless microphone Model and/or type reference . : KW-M01 Standards ............................... : FCC Rules and Regulations Part 15 Subpart C Section 15.236 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test .............................................. : Date (s) of performance of tests .............. : Mar. 18, 2020~ Apr. 07, 2020 Date of Issue ............................................. : Apr. 07, 2020 Test Result ................................................. : Pass Testing Engineer : (Gary Qian) Technical Manager : (Eden Hu) Authorized Signatory : (Jason Zhou) Page 3 of 37 Report No.: HK2003190350-E TABLE OF CONTENTS 1 TEST SUMMARY ......................................................................................................................................................... 4 1.1 TEST PROCEDURES AND RESULTS .............................................................................................................................. 4 1.2 TEST FACILITY ............................................................................................................................................................ 4 1.3 Measurement Uncertainty ........................................................................................................................................ 4 2 GENERAL INFORMATION ........................................................................................................................................... 5 2.1 GENERAL DESCRIPTION OF EUT ................................................................................................................................. 5 2.2 Carrier Frequency of Channels .................................................................................................................................. 5 2.3 Operation of EUT during testing ................................................................................................................................ 6 2.4 DESCRIPTION OF TEST SETUP .................................................................................................................................... 6 2.5 Description of Support Units ..................................................................................................................................... 7 3 TEST RESULTS AND MEASUREMENT DATA ................................................................................................................ 9 3.1 CONDUCTED EMISSIONS TEST ................................................................................................................................... 9 3.2 RADIATED EMISSION TEST ....................................................................................................................................... 12 3.4 Conducted Output Power ....................................................................................................................................... 17 3.5 OCCUPIED BANDWIDTH MEASUREMENT ................................................................................................................ 20 3.5 Necessary bandwidth .............................................................................................................................................. 22 3.6 FREQUENCY STABILITY ............................................................................................................................................ 27 4 PHOTOGRAPH OF TEST ............................................................................................................................................ 30 5 PHOTOGRAPH OF EUT ............................................................................................................................................. 32 Page 4 of 37 Report No.: HK2003190350-E 1 TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS Requirement CFR 47 Section Result Conducted Emission 15.207 PASS Conducted Peak Output Power 15.236(d)(1) PASS Occupied Bandwidth Emission 15.236(f)(2) PASS Emission Mask 15.236(g) ETSI EN 300 422-1 PASS Radiated Spurious Emission 15.236(g) PASS Frequency Stability 15.236(f)(3) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by …

Text truncated - open the document above for the full version.

30MHz-1000MHz Above 1000MHz Conducted Emission
