2AVXWWSBRS001Wireless Seat Belt Reminder - Seat Unit

Manual 2K7959760A Date: 07/23/2020 version 0.2 page1 of 3 1.1.1 Frequencies Bluetooth Low Energy f=2402MHz ÷ 2480MHz 1.1.2 Function description Image1 S-SG The S-SG in the car seat is powered by a built-in battery. The mechanical construction enabling the exchange of the battery without special tools or soldering. The S-SG sends the status information of the belt buckles and the status of seat occupancy sensors. The information is sent either at the time when a change is detected, or every 25 seconds cyclically. The reading period of the AD value of the resistance circuit in the seat occupancy sensor is 200 ms, it can be changed by software. The battery voltage is read once a day. The algorithm for the evaluation of the battery status then sends the current value in every Bluetooth message. The S-SG is contacted only at the time of data transmission with the F-SG, otherwise it is in the (low power mode) power saving mode. Manual 2K7959760A Date: 07/23/2020 version 0.2 page2 of 3 1.1.3 Error conditions The device can not detect faulty state of belt buckle, the analog value is not measured at the entrance, there is only detected a logic signal. The device detects error state values at the inputs to determine the seat occupancy. The following error conditions are detected: Table1 Limit values of the sitting sensor error signal value tolerance description delivery status After switching on the device, the value is not read (not used in practice) Low resistance value R <60 Ω 60 ± 4 Ω The wires are connected or shorted to GND Seat occupied 60 Ω <= R <= 250 Ω 60 ± 4 Ω 250 ± 8 Ω Correct value is expected Average resistance value Is not used unexpected invalid resistance Vacant seat 250 Ω <R <= 620 Ω 250 ± 8 Ω 620 ± 15 Ω Expected valid value High resistance value R> 620 Ω 620 ± 15 Ω Wires broken or high resistance Image2 Error detection algorithm on the input of the occupied seat Manual 2K7959760A Date: 07/23/2020 version 0.2 page3 of 3 1.1.4 Temparature or voltage operating range temperature: -40C ÷ +80C voltage: battery 3,3V; CR2477 The manufacturer of this radio equipment declare that devicecomply with the ISED regulation: IC: 25953-WSBRS001 NOTICE: This device complies with Part 15 of the FCC Rules [and contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS standard(s)]. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. NOTICE: Changes or modifications made to this equipment not expressly approved by (manufacturer name) may void the FCC authorization to operate this equipment.

CONFIDENTIALITY REQUEST for Certification Service in USA Feder al Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 20 20-07-23 TO WHOM IT MAY CONCERN P ursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b) (4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID 2AVXWWSBRS001 Model name Wireless Seat Belt Reminder - Seat Unit For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos 180 Internal Photos 180 Block Diagram Schematics Test Setup Photos 180 User’s Manual 180 Parts List Tune Up Operational Descriptions The l ong-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. I f you have any questions, please feel free to contact me at the address shown below. Sincerely, (Signed) Ing. Milan Trubelik AEV spol. s r.o. J.Silneho 2783 Kromeriz, 76701 Czech Republic Phone: +420573500011 Fax: +420573500036 E-Mail: [email protected]

FCC SAR exemption letter 19-1-0055001T17a-C1 FCC SAR exemption letter according KDB 447498 D01 v06 For AEV spol. s.r.o. , wireless Seat Belt Reminder - seat unit with HW version 036 and SW version 159. Declared minimum distance to human body according to customer = 5 mm according to external document “MPE Information Requirements_Sensor_20200805.pdf” provided by customer. According to KDB 447498 D01 General RF Exposure Guidance V06 SAR testing can be exempted if the following exclusion threshold are met: P threshold calculation based on external document “MPE Information Requirements_Sensor_20200805.pdf” provided by customer. P threshold = Maximum Rated Conducted Output Power (dBm) + Tune-Up Tolerance - Maximum Path Loss to Antenna P threshold_DUT = 1 mW * 10 ((-11.2 dBm + 1.4 dB)/10) = 0.1047 mW < 10 mW @ 2450 MHz with 5 mm test separation. The user manual must list the given usage position. The current version of the FCC SAR exemption letter CETECOM_TR19_1_0055001T17a_C1 replaces the FCC SAR exemption letter CETECOM_TR19_1_0055001T17a dated 2020-08-03. The replaced FCC SAR exemption letter is herewith invalid. ____________________ __________________ Dipl.-Ing. Ninovic Perez B.Eng. Martin Nunier

The test results relate only to the individual items which have been tested. This report shall not be reproduced in parts without the written approval of the testing laboratory © Copyright: All rights reserved by CETECOM Annex 1: Measurement diagrams to Test Report 19-1-0055004T05a-A1 Number of pages: 54 Date of Report: 2020-Jul-29 Testing company: CETECOM GmbH Im Teelbruch 116 45219 Essen Germany Tel. + 49 (0) 20 54 / 95 19-0 Fax: + 49 (0) 20 54 / 95 19-150 Applicant: AEV spol. s.r.o. Test Object / Tested Device(s): Wireless sensor part / wireless Seat Belt Reminder - seat unit FCC ID: 2AVXWWSBRS001 ISED: 25953-WSBRS001 Testing has been carried out in accordance with: Title 47 CFR, Chapter I FCC Regulations, Subchapter A Subpart C: §15.247 (DTS) , RSS-247, Issue 2 (DTS) RSS-Gen., Issue 5 Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Test Report 19-1-0055004T05a-A1 CETECOM_19-1-0055004T05a-A1 2 / 54 1 Measurement diagrams RF output power (2402 MHz; BT-LE_GFSK (-8 dBm); 2 MHz) Test according to FCC title 47 part 15 §15.247(b), KDB 558074 D01 DTS Meas Guidance v04 and ANSI C63.10-2013 Result DUT Frequency (MHz) Gated RMS (dBm) Limit Max (dBm) Gated EIRP (dBm) DutyCycle (%) Result 2402.000000 -11.6 30.0 -11.6 100.000 PASS OSP PowerMeter settings Setting Instrument Value Target Value Measurement Time 1.000 s 1.000 s Points 1000000 1000000 Time resolution 1.000 μs 1.000 μs Level in dBm Test Report 19-1-0055004T05a-A1 CETECOM_19-1-0055004T05a-A1 3 / 54 RF output power (2440 MHz; BT-LE_GFSK (-8 dBm); 2 MHz) Test according to FCC title 47 part 15 §15.247(b), KDB 558074 D01 DTS Meas Guidance v04 and ANSI C63.10-2013 Result DUT Frequency (MHz) Gated RMS (dBm) Limit Max (dBm) Gated EIRP (dBm) DutyCycle (%) Result 2440.000000 -11.3 30.0 -11.3 100.000 PASS OSP PowerMeter settings Setting Instrument Value Target Value Measurement Time 1.000 s 1.000 s Points 1000000 1000000 Time resolution 1.000 μs 1.000 μs Level in dBm Test Report 19-1-0055004T05a-A1 CETECOM_19-1-0055004T05a-A1 4 / 54 RF output power (2480 MHz; BT-LE_GFSK (-8 dBm); 2 MHz) Test according to FCC title 47 part 15 §15.247(b), KDB 558074 D01 DTS Meas Guidance v04 and ANSI C63.10-2013 Result DUT Frequency (MHz) Gated RMS (dBm) Limit Max (dBm) Gated EIRP (dBm) DutyCycle (%) Result 2480.000000 -11.3 30.0 -11.3 100.000 PASS OSP PowerMeter settings Setting Instrument Value Target Value Measurement Time 1.000 s 1.000 s Points 1000000 1000000 Time resolution 1.000 μs 1.000 μs Level in dBm Test Report 19-1-0055004T05a-A1 CETECOM_19-1-0055004T05a-A1 5 / 54 Minimum Emission Bandwidth 6 dB (2402 MHz; BT-LE_GFSK (-8 dBm); 2 MHz) Test according to FCC title 47 part 15 §15.247(a), KDB 558074 D01 DTS Meas Guidance v04 and ANSI C63.10-2013 6 dB Bandwidth DUT Frequency (MHz) Bandwidth (MHz) Limit Min (MHz) Limit Max (MHz) Band Edge Left (MHz) Band Edge Right (MHz) 2402.000000 0.752476 0.500000 --- 2401.603960 2402.356436 (continuation of the "6 dB Bandwidth" table from column 6 ...) DUT Frequency (MHz) Max Level (dBm) Result 2402.000000 -11.7 PASS Measurement Setting Instrument Value Target Value Start Frequency 2.40000 GHz 2.40000 GHz Stop Frequency 2.40400 GHz 2.40400 GHz Span 4.000 MHz 4.000 MHz RBW 100.000 kHz ~ 100.000 kHz VBW 300.000 kHz ~ 300.000 kHz SweepPoints 101 ~ 80 Sweeptime 1.000 ms AUTO Reference Level -20.000 dBm -20.000 dBm Attenuation 0.000 dB AUTO Detector MaxPeak MaxPeak SweepCount 100 100 Filter 3 dB 3 dB Trace Mode Max Hold Max Hold Sweeptype Sweep AUTO Preamp off off Stablemode Trace Trace Stablevalue 0.50 dB 0.50 dB Run 7 / max. 150 max. 150 Level in dBm Test Report 19-1-0055004T05a-A1 CETECOM_19-1-0055004T05a-A1 6 / 54 Stable 5 / 5 5 Max Stable Difference 0.00 dB 0.50 dB Minimum Emission Bandwidth 6 dB (2440 MHz; BT-LE_GFSK (-8 dBm); 2 MHz) Test according to FCC title 47 part 15 §15.247(a), KDB 558074 D01 DTS Meas Guidance v04 and ANSI C63.10-2013 6 dB Bandwidth DUT Frequency (MHz) Bandwidth (MHz) Limit Min (MHz) Limit Max (MHz) Band Edge Left (MHz) Band Edge Right (MHz) 2440.000000 0.752476 0.500000 --- 2439.603960 2440.356436 (continuation of the "6 dB Bandwidth" table from column 6 ...) DUT Frequency (MHz) Max Level (dBm) Result 2440.000000 -11.3 PASS Measurement Setting Instrument Value Target Value Start Frequency 2.43800 GHz 2.43800 GHz Stop Frequency 2.44200 GHz 2.44200 GHz Span 4.000 MHz 4.000 MHz RBW 100.000 kHz ~ 100.000 kHz VBW 300.000 kHz ~ 300.000 kHz SweepPoints 101 ~ 80 Sweeptime 1.000 ms AUTO Reference Level -20.000 dBm -20.000 dBm Attenuation 0.000 dB AUTO Detector MaxPeak MaxPeak SweepCount 100 100 Filter 3 dB 3 dB Trace Mode Max Hold Max Hold Sweeptype Sweep AUTO Preamp off off Level in dBm Test Report 19-1-0055004T05a-A1 CETECOM_19-1-0055004T05a-A1 7 / 54 Stablemode Trace Trace Stablevalue 0.50 dB 0.50 dB Run 6 / max. 150 max. 150 Stable 5 / 5 5 Max Stable Difference 0.03 dB 0.50 dB Minimum Emission Bandwidth 6 dB (2480 MHz; BT-LE_GFSK (-8 dBm); 2 MHz) Test according to FCC title 47 part 15 §15.247(a), KDB 558074 D01 DTS Meas Guidance v04 and ANSI C63.10-2013 6 dB Bandwidth DUT Frequency (MHz) Bandwidth (MHz) Limit Min (MHz) Limit Max (MHz) Band Edge Left (MHz) Band Edge Right (MHz) 2480.000000 0.752476 0.500000 --- 2479.603960 2480.356436 (continuation of the "6 dB Bandwidth" table from column 6 ...) DUT Frequency (MHz) Max Level (dBm) Result 2480.000000 -11.1 PASS Measurement Setting Instrument Value Target Value Start Frequency 2.47800 GHz 2.47800 GHz Stop Frequency 2.48200 GHz 2.48200 GHz Span 4.000 MHz 4.000 MHz RBW 100.000 kHz ~ 100.000 kHz VBW 300.000 kHz ~ 300.000 kHz SweepPoints 101 ~ 80 Sweeptime 1.000 ms AUTO Reference Level -20.000 dBm -20.000 dBm Attenuation 0.000 dB AUTO Detector MaxPeak MaxPeak SweepCount 100 100 Filter 3 dB 3 dB Level in dBm Test Report 19-1-0055004T05a-A1 CETECOM_19-1-0055004T05a-A1 8 / 54 Trace Mode Max Hold Max Hold Sweeptype Sweep AUTO Preamp off off Stablemode Trace Trace Stableval…
