2AVXZPD526Pet Training Systems

 A: If you test Receiver Collar by your hand or leg, please touch the 2 screw caps (electrodes) at the same time, touching only one screw cap (electrodes) will not work. Q: What's the function of anti-abrasion buckle? A: 1. Use the anti-abrasion buckle could prevent skin abrasion, avoid hurt of dog' skin when wearing the iron column (rubber column) for long, and also it could be insulated from electricity. 2. After stop using the device, but the dog starts to bark again, we can use the anti-abrasion buckle and let the dog keep wearing the device. 3. When it becomes better after using the device for several times, dog doesn't bark, please use the anti-abrasion buckle. Q: What do I do if my pet's neck becomes red and irritated? A: Discontinue use of the pet training systems for a few days. If the condition persists beyond 48 hours, see your veterinarian. Even if the skin returns to normal, monitor your pet's skin condition closely. If your dog knows the command but responds inconsistently or acts slower than your requirement, a training collar can sharpen his skill. For example, you have taught your dog to come when called, but over time he responds slower. You can communicate with him via the remote trainer, so that he immediately responds to your call. Altogether, both methods of stopping unwanted behaviour and reinforcing learning behaviours can be applied to nearly every training scenario. Training collars are used to train the dogs and not for punishment. Use properly and with care and the collar can be a safe and effective tool to train, build communication and strengthen your bond with your best friend. Attention 1.High-end transmission technology is used in the remote control Transmitter, no need to aim directly to Receiver Collar, the signal can go through obstacles such as walls and other things, but the effective distance will be decreased. 2. A list of factors, including but not limited to signal station, magnetic Please read this entire guide before using! Model Number:3'   Warm Notice 1. Charge the remote transmitter and receiver at least 2 hours for the first charging. 2. 3. The receiver will turn off automatically when battery energy is low after 10 seconds “beep” sound. 4. This product is rechargeable. In order to keep it continuous use,please charge it once a monthly if it is not used. How to Use Note: Please charge before using the product! 1. Charge the remote transmitter: (1) Connect the charger cable to the charging port. (2) Plug the charger into a standard outlet. (3) 2. To turn the Transmitter on and off (1) Press power button to turn on /off the Transmitter. The backlight on/off. (2) The backlight will stay for about 30 seconds. if no operation then backlight off. 3. Charge the collar receiver: (1) Open the rubber cover, connect the receiver to a charger into a standard socket. (2) The LED flash light on the receiver turns red when charging. (3) Once the receiver is fully charged, the red LED flash light will turn off automatically. To turn the Receiver Collar on Press the power button once, the receiver will has a short"beep" sound, now the receiver is turned on. And the red LED light will flash one time every 8 seconds. To turn the Receiver Collar off. Press the On/Off Button once, the receiver will has a "beep" sound and no red LED light flash any more.      5. The space between Receiver Collar and Pet's Neck shall be maintained to a finger distance, can't be too loose, otherwise static effectiveness shall be badly influenced. How to Wear Receiver Collar Correctly 1.Correct wearing position helps healthy and effective pet training. Receiver shall be placed on bottom of your pet's neck, and the screw cap must contact pet's skin directly. 2.If your pet has a thick fur in the neck place, please use longer screw caps. A: Try to find the best suitable levels of Vibration and Static Stimulation for your pet starting from the lowest level. Excessive levels of stimulation shall cause strong response from your pet. Q: Any other better training methods? A: You can prepare some dog food for training incentive to achieve better training outcomes. Each time after you restrain your pet's misbehavior, you can tell your pet what is supposed to do and what is not supposed to do. And after a number of repetitions your pet understand what you like and what you don't like. Q: How long will it take to get my pet trained well? A: It takes time to eliminate a misbehavior or teach an obedience command. Please be patient. Overquick training may not lead to ideal outcomes. Q: The pet training systems does not work, or my pet does not respond after correct installation of the pet training systems, how should I solve this problem? A: 1. Make sure both Remote Transmitter and Receiver Collar have enough power to operate. 2. Check to see if Receiver Collar is turned on. 3. Check “CH ” button on Remote Transmitter to ensure Dog Channels are correctly configured. 4. Try re-pairing Remote Transmitter and Receiver Collar. 5. Take off Receiver Collar and test all of the three functions work properly. 6. Make sure Re ceiver Collar is properly worn and the collar can't be too loose. 7. Trim your pet's fur where the screw caps (contact points) touch the neck and/or change to the longer contact points. Pet Training Systems User Manual L· l·Flashlight:It has different shows when charging and work,the following will introduce it. .Contact points (static stimulation): choose Vibration function test Press the vibration function button, the receiver will shake. Tone function test Tone function does not need to adjust. Press the tone button, the receiver will make a sound. Key Definition  Vibration level Stimulation level   Remote transmitter Receiver Sensor hole 3.The soft silicone prong is also with conductive function, could put it on to prevent rusty. put the conductive silicone on the prong to the bottom Regular Maintenance 1.Please examine regularly to ensure tightness of Remote…

Text truncated - open the document above for the full version.

Shenzhen Paipai Pet Products Co.,Ltd 2020.3.20 Eurofins MET Labs 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Pet Training Systems Trademark: N/A FCC ID: 2AVXZPD526 MODEL : PD 526, PD 525, PD 528, T720, 721, T722 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : YUANZHUO JIANG/Manager Contact information / address: Rm306, Minle S&T BIdg, Minzhi Street, Longhua New District, Shenzhen, China

Shenzhen Paipai Pet Products Co.,Ltd 2020.3.20 Eurofins MET Labs 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Testing Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : YUANZHUO JIANG/Manager Contact information / address: Rm306, Minle S&T BIdg, Minzhi Street, Longhua New District, Shenzhen, China

Shenzhen Paipai Pet Products Co.,Ltd Model Difference EUT NAME: Pet Training Systems Trademark: N/A FCC ID: 2AVXZPD526 MODEL : PD 526, PD 525, PD 528, T720, 721, T722 All the model are the same circuit and RF module, except model names. Regards Sincerely Client’s signature: Client’s name / title : YUANZHUO JIANG/Manager Contact information / address: Rm306, Minle S&T BIdg, Minzhi Street, Longhua New District, Shenzhen, China

External Photos

40*20mm Label Location FCC ID: 2AVXZPD526 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause und esired operation.

Internal Photos Antenna

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912001375E FCC Part 15C Test Report FCC ID: 2AVXZPD526 Product Name: Pet Training Systems Trademark: N/A Model Name : PD 526 PD 525, PD 528, T720, 721, T722 Prepared For : Shenzhen Paipai Pet Products Co.,Ltd Address : Rm306, Minle S&T BIdg, Minzhi Street, Longhua New District, Shenzhen, China Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Dec. 13, 2019 – Mar. 02, 2020 Date of Report : Mar. 02, 2020 Report No.: BCTC1912001375E Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912001375E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 2 of 35 VERIFICATION OF COMPLIANCE Applicant’s name ........ Shenzhen Paipai Pet Products Co.,Ltd Address ........................ Rm306, Minle S&T BIdg, Minzhi Street, Longhua New District, Shenzhen, China Manufacture's Name ... Shenzhen Paipai Pet Products Co.,Ltd Address ........................ Rm306, Minle S&T BIdg, Minzhi Street, Longhua New District, Shenzhen, China Product description Product name ................ Pet Training Systems Trademark: N/A Model Name: PD 526 PD 525, PD 528, T720, 721, T722 Test Standards: FCC Part15.231 ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result ....................................... Pass Prepared by(Engineer): Cai Fang Zhong Reviewer(Supervisor): Eric Yang Approved(Manager): Zero Zhou Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912001375E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 3 of 35 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 11 3.1.2 TEST PROCEDURE 12 3.1.3 DEVIATION FROM TEST STANDARD 12 3.1.4 TEST SETUP 12 3.1.5 EUT OPERATING CONDITIONS 12 3.1.6 TEST RESULTS 12 3.2 RADIATED EMISSION MEASUREMENT 15 3.2.1 RADIATED EMISSION LIMITS 15 3.2.2 TEST PROCEDURE 16 3.2.3 TEST SETUP 17 3.2.4 EUT OPERATING CONDITIONS 18 3.2.5 TEST RESULTS 19 4 . BANDWIDTH TEST 26 4.1 APPLIED PROCEDURES / LIMIT 26 4.1.1 TEST PROCEDURE 26 4.1.2 DEVIATION FROM STANDARD 26 4.1.3 TEST SETUP 26 4.1.4 EUT OPERATION CONDITIONS 26 4.1.5 TEST RESULTS 27 5 . CALCULATION OF AVERAGE FACTOR 28 6 . DWELL TIME 30 6.1 DEVIATION FROM STANDARD 30 6.2 TEST SETUP 30 6.3 EUT OPERATION CONDITIONS 30 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912001375E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 4 of 35 Table of Contents Page 6.4 TEST RESULTS 31 7 . ANTENNA REQUIREMENT 32 7.1 STANDARD REQUIREMENT 32 7.2 EUT ANTENNA 32 8 . EUT TEST PHOTO 33 9 . EUT PHOTO 35 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912001375E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 5 of 35 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.231) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.209,15.231b Fundamental &Radiated Spurious Emission Measurement PASS 15.231c Occupy Bandwidth PASS 15.231a Transmission Deactivated Time PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912001375E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 6 of 35 1.1 TEST FACILITY Shenzhen BCTC Testing Co., Ltd. Add.: BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China FCC Test Firm Registration Number: 712850 IC Registered No.: 23583 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 3m camber Radiated spurious emission(30MHz-1GHz) U=4.3dB 2 3m chamber Radiated spurious emission(1GHz-18GHz) U=4.5dB 3 3m chamber Radiated spurious emission(18GHz-40GHz) U=3.34dB 4 Conducted Adjacent channel power U=1.38dB 5 Conducted output power uncertainty Above 1G U=1.576dB 6 Conducted output power uncertainty below 1G U=1.28dB 7 humidity uncertainty U=5.3% 8 Temperature uncertainty U=0.59°C Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912001375E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 7 of 35 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Pet Training Systems Trade Name N/A Model Name PD 526 Serial Model PD 525, PD 528, T720, 721, T722 Model Difference All the model are the same circuit and RF module, except model names. Product Description Operation Frequency: 433.92MHz Modulation Type: ASK Antenna Type: Spring antenna Antenna Gain: 1dBi Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Ratings DC3.7V From Batt…

Text truncated - open the document above for the full version.

Shenzhen BCTC Testing Co., Ltd. Conducted Measurement Photos Shenzhen BCTC Testing Co., Ltd. Radiated Measurement Photos
