2AVYL-UW505smart phone

GEMINI UW505 The is a Single SIM mobile phone allowing you to use the facility of one networks. 1.Switchff the mobile phone. 2. Insert th e SIM card correctly in the card slot(s) (See figure below) GEMINI UW505 SIM card Speaker 7 Press the power button to put your phone to sleep. Press the power button again to wake your phone up, then swipe upwards to unlock the screen. 8 9 10 11 12 13 14 15 17 18 20 21 Touch to manage apps notification. You can set permission of apps notification, the authority to show the notifications on lacked screen, etc. 25 26 System Settings FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  -Reorient or relocate the receiving antenna.  -Increase the separation between the equipment and receiver.  -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  -Consult the dealer or an experienced radio/TV technician for help. Specific Absorption Rate (SAR) information: This Smart phone meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: smart phone (FCC ID:2AVYL-UW505) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at the ear is 0.977 W/kg and when properly 33 worn on the body is 0.774W/kg. This device was tested for typical body-worn operations with the back of the handset kept 10mm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain a 10mm separation distance between the user's body and the back of the handset. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. Body-worn Operation This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 10mm must be maintained between the user’s body and the handset, including the antenna. Third-party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components. Body-worn accessories that do not meet these requirements may not comply with RF exposure requirements and should be avoided. Use only the supplied or an approved antenna. 34

SHENZHENETERNITYTECHNOLOGYCO.,LTD U.S.AgentDesignationforServiceofProcess- CertificationAttestationLetter Date:2023-5-10 TO:FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 ATTN:ReviewingEngineer FCCID:2AVYL-UW505 FRNofapplicant:0029350253 Perection2.911(d)(7)oftheFCCrules,SHENZHENETERNITYTECHNOLOGYCO.,LTD(“theApplicant”) certifiesthattheequipmentforwhichauthorizationissoughtisdesignatedtothefollowingU.S. agent*forserviceofprocess: CompanyName:AdvancedWirelessInnovations,LLC FCCRegistrationNumber(FRN):0029350253 PhysicalU.S.CompanyAddress:420WillowgreenLane ， Titusville,Fl32780 Contactperson:DavidAlberico AgentEmailAddress:[email protected] Theabovecontactpersonacceptstheobigationforserviceofprocess. Theapplicantacceptstomaintainanagentfornolessthanoneyearafterthegranteehasterminated allmarketingandimportationortheconclusionofanyCommision-relatedproceedinginvolvingthe equipment. ApplicantSigned:AgentSigned(ifdifferentfromApplicant)： Signed:Signed: Printedname:AndyQiuPrintedname:DavidAlberico Title:SalesmanagerTitle:Partner Companyname:Companyname: SHENZHENETERNITYTECHNOLOGYCO.,LTDAdvancedWirelessInnovations,LLC Date:2023-5-10Date:2023-5-10

SHENZHEN ETERNITY TECHNOLOGY CO.,LTD 2023/5/6 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID:2AVYL-UW505) SHENZHEN ETERNITY TECHNOLOGY CO.,LTD (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature: James Moon SHENZHEN ETERNITY TECHNOLOGY CO.,LTD 2023/5/6 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID:2AVYL-UW505) SHENZHEN ETERNITY TECHNOLOGY CO.,LTD (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature: James Moon

SHENZHEN ETERNITY TECHNOLOGY CO.,LTD 2023.5.6 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen LGT Test Service Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Date: 2023. 05.06 Name: James Moon Title: President Company: SHENZHEN ETERNITY TECHNOLOGY CO.,LTD

SHENZHEN ETERNITY TECHNOLOGY CO.,LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.5.6 Subject; Request for Confidentiality FCC ID:2AVYL-UW505 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. We request Long Term Confidentiality of the following attachment(s); Schematic Diagram Block Diagram Operational Description Tune-up Procedure Part List In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name:James Moon/SHENZHEN ETERNITY TECHNOLOGY CO.,LTD Title:President

SHENZHEN ETERNITY TECHNOLOGY CO., LTD A2, Yingzhan Industrial Park, Longtian, Pingshan, Shenzhen, China Declaration Letter Date: 2023/5/6 To: Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: For our business issue and marketing requirement, we would like to list different model number on the FCC certificates and reports, as following: FCC ID:2AVYL-UW505 Model Number:UW505, GEMINI; GENESIS Model Difference: The difference between models is for different market sale, the other (hardware and software) was the same as before. Sincerely, James Moon/ President SHENZHEN ETERNITY TECHNOLOGY CO.,LTD A2, Yingzhan Industrial Park, Longtian, Pingshan,Shenzhen,China Tel: 8228981006 Fax: 8228981172 Email: [email protected]

Page 1 of 5 Report No.: LGT23C062 Appendix - External Photographs of EUT Constructional Details Model: UW505 Photo 1 Photo 2 Page 2 of 5 Report No.: LGT23C062 Photo 3 Photo 4 Page 3 of 5 Report No.: LGT23C062 Photo 5 Photo 6 Page 4 of 5 Report No.: LGT23C062 Photo 7 Photo 8 Page 5 of 5 Report No.: LGT23C062 Photo 9 Photo 10

Label Smartphone FCC ID:2AVYL-UW505

Page 1 of 8 Report No.: LGT23C062 Appendix - Internal Photographs of EUT Constructional Details Model: UW505 Photo 1 Photo 2 Page 2 of 8 Report No.: LGT23C062 Photo 3 Photo 4 GSM/WCDMA/LTE MAIN ANT Page 3 of 8 Report No.: LGT23C062 Photo 5 Photo 6 LTE DIV ANT BT/Wi-Fi ANT Page 4 of 8 Report No.: LGT23C062 Photo 7 Photo 8 Page 5 of 8 Report No.: LGT23C062 Photo 9 Photo 10 Page 6 of 8 Report No.: LGT23C062 Photo 11 Photo 12 Page 7 of 8 Report No.: LGT23C062 Photo 13 Photo 14 Page 8 of 8 Report No.: LGT23C062 Photo 15 Photo 16

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China SAR TEST REPORT Product Name: Smart phone Model Name: UW505, GEMINI; GENESIS FCC ID: 2AVYL-UW505 Issued For : SHENZHEN ETERNITY TECHNOLOGY CO.,LTD A2, Yingzhan Industrial Park, Longtian, Pingshan,Shenzhen,China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Report Number: LGT23C062HA01 Sample Received Date: Mar. 23, 2023 Date of Test:Mar. 29, 2023~Apr. 08, 2023 Date of Issue: Apr. 12, 2023 Max. SAR (1g): Head: 0.977 W/kg Body: 0.774 W/kg Report No.: LGT2 3C062HA01Page 2 of 124 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 8 1.3 Test Factory 8 2. Test Standards and Limits 9 3. SAR Measurement System 10 3.1 Definition of Specific Absorption Rate (SAR) 10 3.2 SAR System 10 4. Tissue Simulating Liquids 13 4.1 Simulating Liquids Parameter Check 13 5. SAR System Validation 15 5.1 Validation System 15 5.2 Validation Result 16 6. SAR Evaluation Procedures 17 7. EUT Antenna Location Sketch 18 7.1 SAR test exclusion consider table 19 8. EUT Test Position 25 8.1 Define Two Imaginary Lines on the Handset 25 8.2 Hotspot mode exposure position condition 26 9. Uncertainty 27 9.1 Measurement Uncertainty 27 9.2 System validation uncertainty 28 10. Conducted Power Measurement 29 10.1 Test Result: 29 11. EUT and Test Setup Photo 51 11 .1 EUT Photos 51 11.2 Setup Photos 54 12. SAR Result Summary 60 12.1 Head SAR 60 12.2 Body-worn and Hotspot SAR 63 13. Equipment List 69 Appendix A. System Validation Plots 70 Appendix B. SAR Test Plots 88 Appendix C. Probe Calibration and Dipole Calibration Report 124 Report No.: LGT2 3C062HA01Page 3 of 124 Revision History Rev. Issue Date Contents 00Apr. 12, 2023 Initial Issue Report No.: LGT2 3C062HA01Page 4 of 124 TEST REPORT CERTIFICATION Applicant SHENZHEN ETERNITY TECHNOLOGY CO.,LTD Address A2, Yingzhan Industrial Park, Longtian, Pingshan, Shenzhen, China Manufacture SHENZHEN ETERNITY TECHNOLOGY CO.,LTD Address A2, Yingzhan Industrial Park, Longtian, Pingshan, Shenzhen, China Product Namesmart phone Trademark KOOLMAAX Model Name UW505, GEMINI, GENESIS Sample number LGT2303053 APPLICABLE STANDARDS STANDARD TEST RESULTS ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 (2.1093) IEEE 1528: 2013 PASS Prepared by: Approved by: Zane Shan Engineer Vita Li Manager Report No.: LGT2 3C062HA01Page 5 of 124 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Namesmartphone Trademark KOOLMAAX Model Name UW505 Series Model GEMINI; GENESIS Model Difference Only the model is different. Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled Hardware Version 8149TQ_MMI_V01 Software Version N/A Frequency Range GSM 850: 824 MHz ~ 849 MHz PCS 1900: 1850 MHz ~ 1910 MHz WCDMA Band II: 1850 MHz ~ 1910 MHz WCDMA Band IV:1710 MHz ~ 1755 MHz WCDMA Band V: 824 MHz ~ 849 MHz LTE Band 2:1850 MHz ~1910MHz LTE Band 4:1710 MHz ~1755MHz LTE Band 5:824 MHz ~ 849MHz LTE Band 12:699 MHz ~716MHz LTE Band 17:704 MHz ~ 716MHz LTE Band 66:1710 MHz ~1780MHz LTE Band 71:663 MHz ~ 698MHz WLAN 802.11b/g/n20: 2412 MHz ~ 2462 MHz WLAN 802.11n40: 2422 MHz ~ 2452 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5150 MHz ~ 5250 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5250 MHz ~ 5350 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5470 MHz ~ 5725 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5725 MHz ~ 5850 MHz Bluetooth: 2402 MHz ~ 2480 MHz Report No.: LGT2 3C062HA01Page 6 of 124 Max. Reported SAR(1g): (Limit:1.6W/kg) Test distance: Head:0mm Body:10mm Mode Head(W/ kg) Body Worn and Hotspot (W/ kg) GSM 850 0.143 0.774 PCS 1900 0.149 0.582 WCDMA Band II 0.233 0.332 WCDMA Band IV 0.175 0.263 WCDMA Band V 0.136 0.187 LTE Band 2 0.1310.263 LTE Band 4 0.095 0.246 LTE Band 5 0.139 0.157 LTE Band 12 0.140 0.288 LTE Band 17 0.151 0.326 LTE Band 66 0.117 0.229 LTE Band 71 0.104 0.263 2.4G WLAN 0.278 0.135 5.2G WLAN 0.498 0.241 5.3G WLAN 0.584 0.154 5.6G WLAN 0.921 0.366 5.8G WLAN 0.977 0.369 Bluetooth 0.051 0.039 1-g Sum SAR 1.210 1.143 Battery Rated Voltage:3.8V Capacity: 2500mAh Description test modes Only support single SIM Card. Operating Mode: GSM: GSM Voice; GPRS/EGPRS Class 12 WCDMA: RMC, HSDPA, HSUPA Release 6 LTE: QPSK, 16QAM 2.4G WLAN: 802.11b(DSSS): CCK, DQPSK, DBPSK 802.11g(OFDM): BPSK, QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK, QPSK,16-QAM,64-QAM Report No.: LGT2 3C062HA01Page 7 of 124 5G WLAN: 802.11a(OFDM): BPSK, QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK, QPSK,16-QAM,64-QAM 802.11ac (OFDM): BPSK, QPSK,16-QAM,64-QAM,256-QAM Bluetooth: GFSK +π/4 DQPSK+8DPSK BLE: GFSK Antenna Specification GSM/WCDMA/LTE: PIFA Antenna Bluetooth: PIFA Antenna WLAN: PIFA Antenna Operating Mode Maximum continuous output Hotspot Mode Support DTM Mode Not Support Report No.: LGT2 3C062HA01Page 8 of 124 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Temperature (°C) 18-25 Humidity (%RH) 30-70 1.3 Test Factory Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, …

Text truncated - open the document above for the full version.

SHENZHEN.ETERNITY.TECHNOLOGY.CO.,.LTD A2,.Yingzhan.Industrial.Park,.Longtian,.Pingshan,.Shenzhen,.China Antenna Test Report 1.The Equipment of Active Test 1. ETS Chamber7×4×3(m)(3D 喑室) 2. 矢量网络分析仪(无源测试仪) 3. Network analyzer-8960/LTE CMW500/8820 支持 2G、3G、4G 网络.（有源测试仪） 2.Matching Circuit主天线（匹配有更改） Element匹配值 E1(0201) E2(0201)0 欧姆 E3(0201) 3.0：天线测试 OTA 测试数据： Model：天线实现方式 :FPC单位：dBm 信道 GSM850GSM900DCS1800PCS1900 CH128CH192CH251CH1CH62CH124CH512CH698CH885CH512CH661CH810 TRP26.5727.2027.3528.0827.3125.8126.226.4527.2126.3227.6227.9 TIS-104.45-99.32-103.56-104.53 信道 WCDMA-850WCDMA-1900WCDMA-1700 CH4357CH4408CH4458CH9662CH9800CH9938CH1537CH1637CH1738 TRP18.0618.6618.719.0219.0519.1119.0119.0519.35 TIS-104.42-104.88-103.01 4G：FDD 主天线开关逻辑： •RF1路用一个0欧电阻,控制2G频段850/900/1800/1900。3G频段W2/4/5 4G频段的B2/4/5/66 •RF2路并联一个18电感对地,控制4G频段的B12/B17/B71. 信道 245 186501890019150200002017520350204502052520600 TRP19.6119.7218.8819.6519.3719.2418.2418.3619.54 TIS-94.01-89.87-93.21 信道 12176671 230602309523130237802379023800132022132322132622133712133297133422 TRP18.8818.6218.9818.7618.6218.3419.0219.4218.9116.116.3216.61 TIS-91.55-90.57-90.01-88.46 4.Gain/Efficiency Passive Test For 800-960 FreqEffi (%) Gain (MHz)(dBi) 72021.1501.2 74022.360.14 76022.680.14 78023.350.17 80023.450.31 88031.360.34 82023.890.34 84026.030.33 86027.860.38 88031.780.34 90038.060.39 92041.680.41 94042.620.40 96044.550.41 Passive Test For 1700-2700 FreqEffi (%) Gain (MHz)(dBi) 170039.370.59 175045.840.62 180054.630.63 185061.220.61 190052.140.58 195049.750.59 200042.930.59 205042.960.53 210042.070.72 215032.350.75 220041.740.69 225050.640.72 230048.330.71 235046.730.7 240033.960.73 245030.670.72 250056.310.71 255046.540.67 260046.160.72 265050.660.72 270051.680.69 4. WIFI Gain/Efficiency Passive Test For 800-960 FreqEffi (%) Gain (MHz)(dBi) 240034.851.25 245035.741.32 250036.681.44 515023.350.93 520023.450.91 525031.361.02 530023.891.14 535036.031.23 540037.861.38 545031.781.34 550038.061.39 555041.181.41 560042.721.26 565040.231.19 570038.751.08 575036.5310.02 580036.120.95 585035.360.96 2.4GWIFI 5.8GWIFI 5.环境处理 耳机座底部先用麦拉绝缘起来，然后包导电布接地屏蔽干扰。 电感去掉 喇叭导电布位置加导电泡棉 主板背面加导电泡棉 屏幕的导电布必须要保证接地性能好 同轴线座子跟屏幕接地。 马达底下贴导电泡棉跟屏幕 接地。 屏幕导电布需要贴大一点，把屏幕APC在包住 一些。

Page: 1/6 Ref : ACR.126.5.22.BES.A BTF TESTING LAB (SHENZHEN) CO., LTD. F101,201 AND 301, BUILDING 1, BLOCK 2, TANTOU INDUSTRIAL PARK, TANTOU COMMUNITY SONGGANG STREET, BAO'AN DISTRICT, SHENZHEN, CHINA MVG COMOHAC MAGNETIC FIELD SIMULATOR SERIAL NO.: SN 13/22 TMFS30 Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Iroise – 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Calibration date: 05/06/2022 Accreditations #2-6789 Scope available on www.cofrac.fr The use of the Cofrac brand and the accreditation references is prohibited from any reproduction. Summary: This document presents the method and results from an accredited COMOHAC TMFS calibration performed at MVG, using the COMOHAC test bench, for use with a MVG COMOHAC system only. The test results covered by accreditation are traceable to the International System of Units (SI). COMOHAC TMFS Calibration Report COMOHAC TMFS` PROBE CALIBRATION REPORT Ref: ACR.126.5.22.BES.A Page: 2/6 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOHAC TMFS vG This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Function Date Signature Prepared by : Jérôme Luc Technical Manager 5/6/2022 Checked by : Jérôme Luc Technical Manager 5/6/2022 Approved by : Yann Toutain Laboratory Director 5/9/2022 Customer Name Distribution : BTF Testing Lab (Shenzhen) Co., Ltd. Issue Name Date Modifications A Jérôme Luc 5/6/2022 Initial release COMOHAC TMFS` PROBE CALIBRATION REPORT Ref: ACR.126.5.22.BES.A Page: 3/6 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOHAC TMFS vG This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Maximum Axial and Radial Magnetic Field Values ______________________________ 4 4 Measurement Uncertainty .......................................................................................... 4 5 Calibration Measurement Results .............................................................................. 5 5.1 Maximum Axial and Radial Magnetic Field Values ______________________________ 5 6 List of Equipment ...................................................................................................... 6 COMOHAC TMFS` PROBE CALIBRATION REPORT Ref: ACR.126.5.22.BES.A Page: 4/6 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOHAC TMFS vG This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 DEVICE UNDER TEST Device Under Test Device Type COMOHAC Magnetic Field Simulator Manufacturer MVG Model STMFS Serial Number SN 13/22 TMFS30 Product Condition (new / used) New Frequency Range 200-5000 Hz 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOHAC T-coil Probes are built in accordance to the ANSI C63.19 and ANSI S3.22- 2014 standards. Figure 1 – MVG COMOHAC Magnetic Field Simulator 3 MEASUREMENT METHOD All methods used to perform the measurements and calibrations comply with the ANSI C63.19. All measurements were performed with the TMFS in the standard device test configuration, with the TMFS in free space, 10 mm below the coil center. 3.1 MAXIMUM AXIAL AND RADIAL MAGNETIC FIELD VALUES An audio signal was fed into the TMFS and the magnetic field measured and recorded over an area scan with the T-coil probe in three orientations; axial and two radial. The maximum magnetic field is recorded for all three T-coil orientations. 4 MEASUREMENT UNCERTAINTY The guideline outlined in the IEEE ANSI C63.19 standard was followed to generate the measurement uncertainty for validation measurements. All uncertainties listed below represent an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2, traceable to the Internationally Accepted Guides to Measurement Uncertainty. COMOHAC TMFS` PROBE CALIBRATION REPORT Ref: ACR.126.5.22.BES.A Page: 5/6 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOHAC TMFS vG This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Uncertainty analysis of the probe calibration in Helmholtz Coil Uncertainty Component Tol. (± dB) Prob. Dist. Div. Uncertainty (dB) Expanded uncertainty 95 % confidence level k = 2 N 2 0.95 5 CALIBRATION MEASUREMENT RESULTS Calibration Parameters Software OpenHAC V2 HAC positioning ruler SN 42/09 TABH12 T-Coil probe SN 47/10 TCP18 Distance between TMFS and coil center 10 mm Frequency 1025 Hz Scan Size X=70mm/Y=70mm Scan Resolution dx=5mm/dy=5mm Output level 0.5 VAC Lab Temperature 20 +/- 1°C Lab Humidity 30-70 % 5.1 MAXIMUM AXIAL AND RADIAL MAGNETIC FIELD VALUES Test Description Measured Magnetic Field Location Intensity (dB A/m) Axial Max -10.79 Radial H Right side -17.47 Left side -17.25 Radial V Upper side -16.88 Lower side -16.75 AXIAL ABM1 RADIAL H ABM1 RADIAL V ABM1 COMOHAC TMFS` PROBE CALIBRATION REPORT Ref: ACR.126.5.22.BES.A Page: 6/6 Template_AC…

Text truncated - open the document above for the full version.

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China RF TEST REPORT Product Name: smart phone Model Name: UW505, GEMINI, GENESIS FCC ID: 2AVYL-UW505 Issued For : SHENZHEN ETERNITY TECHNOLOGY CO., LTD A2, Yingzhan Industrial Park, Longtian, Pingshan, Shenzhen, China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Report Number: LGT23C062RF02 Sample Received Date: Mar. 23, 2023 Date of Test: Mar. 23, 2023 ~ Apr. 10, 2023 Date of Issue: Apr. 12, 2023 Report No.: LGT23C062RF02 Page 2 of 49 TEST REPORT CERTIFICATION Applicant: SHENZHEN ETERNITY TECHNOLOGY CO., LTD Address: A2, Yingzhan Industrial Park, Longtian, Pingshan, Shenzhen, China Manufacturer: SHENZHEN ETERNITY TECHNOLOGY CO., LTD Address: A2, Yingzhan Industrial Park, Longtian, Pingshan, Shenzhen, China Product Name: smart phone Trademark: KOOLMAAX Model Name: UW505, GEMINI, GENESIS Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2013 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT23C062RF02 Page 3 of 49 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.5 EQUIPMENTS LIST 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 TEST PROCEDURE 14 3.3 TEST SETUP 14 3.4 EUT OPERATING CONDITIONS 14 4. RADIATED EMISSION MEASUREMENT 17 4.2 TEST PROCEDURE 19 4.3 TEST SETUP 20 4.4 EUT OPERATING CONDITIONS 20 4.5 FIELD STRENGTH CALCULATION 21 4.7 TEST RESULTS (BAND EDGE REQUIREMENTS) 26 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 28 5.1 LIMIT 28 5.2 TEST PROCEDURE 28 5.3 TEST SETUP 28 5.4 EUT OPERATION CONDITIONS 28 5.5 TEST RESULTS 28 6. POWER SPECTRAL DENSITY TEST 29 6.1 LIMIT 29 6.2 TEST PROCEDURE 29 6.3 TEST SETUP 29 6.4 EUT OPERATION CONDITIONS 29 6.5 TEST RESULTS 29 7. BANDWIDTH TEST 30 Report No.: LGT23C062RF02 Page 4 of 49 Table of Contents Page 7.1 LIMIT 30 7.2 TEST PROCEDURE 30 7.3 TEST SETUP 30 7.4 EUT OPERATION CONDITIONS 30 7.5 TEST RESULTS 30 8. PEAK OUTPUT POWER TEST 31 8.1 LIMIT 31 8.2 TEST PROCEDURE 31 8.3 TEST SETUP 31 8.4 EUT OPERATION CONDITIONS 31 8.5 TEST RESULTS 31 9. ANTENNA REQUIREMENT 32 9.1 STANDARD REQUIREMENT 32 9.2 EUT ANTENNA 32 APPENDIX I:TEST RESULTS 33 DUTY CYCLE 33 MAXIMUM PEAK CONDUCTED OUTPUT POWER 35 -6DB BANDWIDTH 36 OCCUPIED CHANNEL BANDWIDTH 38 MAXIMUM POWER SPECTRAL DENSITY LEVEL 40 BAND EDGE 42 CONDUCTED RF SPURIOUS EMISSION 45 APPENDIX II: TEST PHOTO 48 Report No.: LGT23C062RF02 Page 5 of 49 Revision History Rev. Issue Date Contents 00 Apr. 12, 2023 Initial Issue Report No.: LGT23C062RF02 Page 6 of 49 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Report No.: LGT23C062RF02 Page 7 of 49 1.1 TEST FACTORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 9K-30MHz ±2.84dB 4 All emissions, radiated 30M-1GHz ±4.39dB 5 All emissions, radiated 1G-6GHz ±5.10dB 6 All emissions, radiated>6G ±5.48dB 7 Conducted Emission (9KHz-150KHz) ±2.79dB 8 Conducted Emission (150KHz-30MHz) ±2.80dB Report No.: LGT23C062RF02 Page 8 of 49 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: smart phone Trademark: KOOLMAAX Model Name: UW505 Series Model: GEMINI, GENESIS Model Difference: Only the model is different. Product Description: The EUT is a Smartphone Operation Frequency: 2402~2480 MHz Modulation…
