2AVYR-HKCPB2710Q1Q10 Magnetic Power Bank

陈舜美 说明书 105g双铜 陈金燕赵文博安少杰 V01 技术要求： 1.材质：105g双铜； 2.尺寸：65*65mm,公差+/-0.5mm; 3.风琴折,双面黑白印刷，字迹清晰整洁； 4.具体见签样； 5.需满足航嘉无卤要求,所有物料及生产工艺必须满足相关安规要求 及《Q01-731-18航嘉环境有害物质管理标准》最新版和《Q01-8 24-17充电器类产品包装外观检验标准》最新版。 352-xxxx 2024.09.09 说明书/充电宝 反面 正面 Q10 Magnetic Power Bank Manual 前言 尊敬的用户，感谢您选购航嘉产品。为了您能更进一步的了解产品，使用前请仔 细阅读本说明书。祝您体验愉快！ 产品示意图 Product OverviewPreface Thank you for purchasing the Huntkey products. For optimum operation, please read this manual carefully before using. Package Contents 1 × Magnetic Power Bank 1 × Charging Cable 1 × User Manual Instructions Before its first use, please click the power button to light up the screen to exit sleep mode, and fully charge the power bank. The charging cable is below the blister. Please don’t use all-in-one cables to charge multiple devices at the same time, as it may damage your devices. For optimal performance, we recommend that you use Huntkey accessories such as 30W(or above) PD charger. Stop all use if the battery is swollen, leaking or deformed. Stop all use if the battery is submerged. Electric Quantity: Press the power button at the bottom, and the LCD screen will display the percentage of remaining electric quantity. Double-click the power button quickly to close the screen display. Low Current Charging Mode: Press the power button for more than 3 seconds, and the USB-C port will start the low current charging mode, which is for charging low-power devices such as wristbands and earphones. FOD Protected Mode: When the wireless charging panel detects a metal foreign object, it automatically starts the protected mode. Remove all metal objects from the wireless charging panel and quickly double-click the power button to end protected mode. Hidden Holder: Press the “OPEN” key on the left and the back hidden holder will pop up. Please keep the product out of reach of children. When not in use, store the product in dry environment. To preserve lifespan, recharge and discharge it every 3 months. Cautions Do not expose the product to excessive temperature or areas which may become hot, including but not limited to, on or near vehicles, space heaters, cooking appliances like oven. Use unapproved or incompatible power adapters, cables may result in fire, explosion or other hazards. Do not store the product in a restricted ventilation area like handbag for a long time, a closed-in area may result in fire or other hazards. The product contains a Lithium-ion battery. Disassembling product may cause property damage or fire. Do not drop, crush, puncture, short-circuit, or dispose of the product in fire or water. Disposal of the product separately from household waste, following local regulations. Do not use the product during a thunderstorm, it may cause malfunctions or electric shocks. Warranty Description If there is a failure caused by non-man-made reasons, consumers who purchased Huntkey products through legal channels can enjoy product warranty services within 12 months from the date of purchase. In order to ensure your legitimate rights and interests, please keep in mind the following : (1) The warranty card should be properly kept by the user. No replacement if lost. Invalid if altered. (2) If there is a failure caused by non-man-made reasons, the user can use the warranty card and the purchase certificate for free maintenance at the designated maintenance point during the warranty period. The following are not covered by warranty services: The product exceeds the warranty period; Damage caused by human factors; The warranty card model does not match the product model; There is no warranty card or the warranty card has been altered; There is no valid purchase certificate or no proof that the purchased product is within the warranty period; Unauthorized maintenance, violent operation, disassembling, modification, extrusion, liquid inlet, corrosion; Damage caused by force majeure such as flood, fire, lightning strike. If the warranty service is void, the maintenance service is still required, Huntkey will calculate the appropriate maintenance fee according to the cost of parts and labor, make a maintenance quote to the user, and then provide maintenance services after obtaining the user's consent and payment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC RF exposure statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. 型号: HKCPB2710Q1 产品说明书 Q10磁吸移动电源 Model: HKCPB2710Q1 Q10 Magnetic Power Bank Manual Model: HKCPB2710Q1 包装清单 型号: HKCPB2710Q1 产品说明书 Q10磁吸移动电源 说明书 × 1磁吸移动电源 × 1充电线 × 1 ① USB-C输入/输出接口 ② 电源键 ③ 无线充模组 ④ 电量显示 ⑤ 剩余充/放电时间 ⑥ 功率显示 ⑦ 支架控制键 ① ⑥ ② ③ ⑦ ④ ⑤ ⑥ ① USB-C Input/Output Port ② Power Button ③ Wireless Charging Module ④ Electric Quantity ⑤ Remaining Charging/Discharging T ime ⑥ Power Display ⑦ Holder Control Key ① ② ③ ⑦ ④ ⑤ 产品参数 -5°C~35°C -20°C~50°C 30cm/USB-C转USB-C 15W(MAX) 5V 3A 或 9V 3A(MAX) 103*70*19.8mm 5V 3A 5000mAh 7.2VDC/36Wh 6400mAh(5V 3A) 237g(近似值) -5°C~35°C -20°C~50°C 约 2.5 小时(使用30W电源适配器) Specifications Dimensions Battery Type Magnetic Wireless Charging 103*70*19.8mm Lithium-ion polymer battery 15W(MAX) USB-C Input/Output + USB-C Output 5V 3A or 9V 3A(MAX) 5V 3A Rated Capacity Product Weight Operating Temperature 237g (approximation) Storage Temperature Charging Cable Charging Time 30cm/USB-C to USB-C About 2.5 hours (using a 30W power adapter) 首次使用时，请先短按电源键点亮屏幕以退出休眠模式，并将移动电源充满电。 充电线位于吸塑下方。 请勿使用多合一的数据线同时给多台设备充电，以免损坏您的设备。 消费者若使用电源适配器供电，则应购买配套使用获得CCC认证并满足标准 要求的电源适配器。 推荐搭配使用航嘉30W及以上PD充电器，以获得理想充电体验。 若本产品存在电池膨胀、漏液、变形等异常时，请停止使用。 浸水后禁止使用。 电量查询：短按底部电源键，LCD显示屏将显示剩余电量的百分比，快速双 击电源键可以关闭屏幕显示。 小电流充电模式：长按电源键持续3秒以上，USB-C接口将进入小电流充电 模式，适合为手环、耳机等低功率设备充电。 异物检测 (FOD) 保护模式： 当无线充电面板检测到金属异物时，自动进入 保护模式。请移除无线充电面板上的所有金属异物，快速双击电源键以退出 保护模式。 隐…

Text truncated - open the document above for the full version.

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Huntkey Electric Co., Ltd Grantee code: 2AVYR FRN: 0029350899 FCC ID: 2AVYR-HKCPB2710Q1 Contact Name: QINGPING ZHU Address: Huntkey Industrial Park, Xue-Xiang Village, Banxue Road, Bantian, Shenzhen, Guangdong, 518129, PEOPLE'S REPUBLIC OF CHINA Telephone No: +86-755-89606344 Fax No: 86-755-89606333-6344 Email: [email protected] i. [Shenzhen Huntkey Electric Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [ Shenzhen Huntkey Electric Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Shenzhen Huntkey Electric Co., Ltd certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Date: 09.18.2024 Applicant’s Name: QINGPING ZHU Title: General Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Shenzhen Huntkey Electric Co., Ltd Address: Huntkey Industrial Park, Xue-Xiang Village, Banxue Road, Bantian, Shenzhen, Guangdong, 518129, PEOPLE'S REPUBLIC OF CHINA Product Name: Q10 Magnetic Power Bank Model Number: HKCPB2710Q1 FCC Identifier: 2AVYR-HKCPB2710Q1 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: QINGPING ZHU Date: 9/18/2024 Title: General Manager Signature of applicant:

C5266091_X10_Ed.2 1/1 Shenzhen Huntkey Electric Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 9/18/2024 Subject: Request for Confidentiality FCC ID: 2AVYR-HKCPB2710Q1 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: QINGPING ZHU Title: General Manager

Page 1 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Photographs of the EUT (External Photos) Model: HKCPB2710Q1 Page 2 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Page 3 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Page 4 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected]

Page 1 of 5 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Photographs of the EUT (Internal Photos) Model: HKCPB2710Q1 Coil Page 2 of 5 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Page 3 of 5 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Page 4 of 5 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Page 5 of 5 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected]

Page 1 of 20 Report No.: MTi231103009-13E2 Address: Headquarters: Microtest Hi-tech Building, Zone 2, Xinxing Industrial Park, Fuzhou Avenue, Bao'an District, Shenzhen, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.cn E-mail: [email protected] Test Report Report No.: MTi240710002-08E2 Date of issue: 2024-08-31 Applicant: Shenzhen Huntkey Electric Co., Ltd. Product: Q10 Magnetic Power Bank Model(s): HKCPB2710Q1 FCC ID: 2AVYR-HKCPB2710Q1 Shenzhen Microtest Co., Ltd. http:// Web: www.mtitest.cn Page 2 of 20 Report No.: MTi231103009-13E2 Address: Headquarters: Microtest Hi-tech Building, Zone 2, Xinxing Industrial Park, Fuzhou Avenue, Bao'an District, Shenzhen, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.cn E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 20 Report No.: MTi231103009-13E2 Address: Headquarters: Microtest Hi-tech Building, Zone 2, Xinxing Industrial Park, Fuzhou Avenue, Bao'an District, Shenzhen, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.cn E-mail: [email protected] Contents 1 General Description ........................................................................................................................ 5 1.1 Description of the EUT ...................................................................................................................................... 5 1.2 Description of test modes .................................................................................................................................. 5 1.3 Description of support units ............................................................................................................................... 6 2 Measurement uncertainty ............................................................................................................... 6 3 Test facilities and accreditations ................................................................................................... 7 3.1 Test laboratory ................................................................................................................................................... 7 4 List of test equipment ..................................................................................................................... 8 5 Test result ........................................................................................................................................ 9 5.2 Test setup ........................................................................................................................................................ 10 5.3 Test Procedures ............................................................................................................................................... 10 5.4 Information of test equipment ........................................................................................................................... 11 5.5 Test results ....................................................................................................................................................... 12 Photographs of the Test Setup ............................................................................................................ 20 Photographs of the EUT ...................................................................................................................... 20 Page 4 of 20 Report No.: MTi231103009-13E2 Address: Headquarters: Microtest Hi-tech Building, Zone 2, Xinxing Industrial Park, Fuzhou Avenue, Bao'an District, Shenzhen, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.cn E-mail: [email protected] Test Result Certification Applicant: Shenzhen Huntkey Electric Co., Ltd. Address: Huntkey Industrial Park, Xue-Xiang Village, Banxue Road, Bantian, Shenzhen, Guangdong, 518129, PEOPLE'S REPUBLIC OF CHINA Manufacturer: Shenzhen Huntkey Electric Co., Ltd. Address: Huntkey Industrial Park, Xue-Xiang Village, Banxue Road, Bantian, Shenzhen, Guangdong, 518129, PEOPLE'S REPUBLIC OF CHINA Product description Product name: Q10 Magnetic Power Bank Trademark: Huntkey Model name: HKCPB2710Q1 Series Model: N/A Standards: 47 CFR PART 1, § 1.1310 Test method: KDB 680106 D01 Wireless Power Transfer v04 Date of Test Date of test: 2024-08-06 to 2024-08-30 Test result: Pass Test Engineer : (Letter Lan) Reviewed By : (David Lee) Approved By : (Leon Chen) Page 5 of 20 Report No.: MTi231103009-13E2 Address: Headquarters: Microtest Hi-tech Building, Zone 2, Xinxing Industrial Park, Fuzhou Avenue, Bao'an District, Shenzhen, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.cn E-mail: [email protected] 1 General Description 1.1 Description of the EUT Product name: Q10 Magnetic Power Bank Model name: HKCPB2710Q1 Series Model(s): N/A Model difference: N/A Electrical rating: Input: DC 5V/3A, 9V/3A Wireless Output: 15W(MAX) USB-C output: DC 5V/3A, 9V/3A Total output: DC 5V/3A Battery: DC 7.2V 5000mAh 36Wh Accessories: Cable: Type-C to Type-C cable (0.3m) *1 Hardware version: 1.0 Software version: 1.0 Test sample(s) number: MTi240710002-08S1001 RF specification Operating frequency range: 115-205KHz (5W, 7.5W, 10W, 15W) 360kHz (15W) Modulation type: ASK Antenna(s) type: Coil 1.2 Description of test modes All the test modes were carried out with the EUT in normal operation, the final test mode of the EUT was the worst test mode for emission test, which was shown in this report and defined as: No. Emission test m…

Text truncated - open the document above for the full version.

The test report is only used for customer scientific research, teaching, internal quality control and other purposes, and is for internal reference only. Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Test Report Report No.: MTi240710002-08E1 Date of issue: 2024-08-31 Applicant: Shenzhen Huntkey Electric Co., Ltd. Product name: Q10 Magnetic Power Bank Model(s): HKCPB2710Q1 FCC ID: 2AVYR-HKCPB2710Q1 Shenzhen Microtest Co., Ltd. http://www.mtitest.cn Page 2 of 27 Report No.: MTi240710002-08E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 27 Report No.: MTi240710002-08E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Table of contents 1 General Description ......................................................................................................................... 5 1.1 Description of the EUT ............................................................................................................................... 5 1.2 Description of test modes .......................................................................................................................... 5 1.3 Environmental Conditions .......................................................................................................................... 6 1.4 Description of support units ....................................................................................................................... 6 1.5 Measurement uncertainty .......................................................................................................................... 6 2 Summary of Test Result .................................................................................................................. 7 3 Test Facilities and accreditations ................................................................................................... 8 3.1 Test laboratory ........................................................................................................................................... 8 4 List of test equipment ...................................................................................................................... 9 5 Evaluation Results (Evaluation) .................................................................................................... 10 5.1 Antenna requirement ............................................................................................................................... 10 6 Radio Spectrum Matter Test Results (RF) .................................................................................... 11 6.1 Conducted Emission at AC power line .................................................................................................... 11 6.2 20dB Occupied Bandwidth ...................................................................................................................... 14 6.3 Emissions in frequency bands (below 30MHz)........................................................................................ 18 6.4 Emissions in frequency bands (30MHz - 1GHz)...................................................................................... 23 Photographs of the test setup ............................................................................................................. 26 Photographs of the EUT....................................................................................................................... 27 Page 4 of 27 Report No.: MTi240710002-08E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Test Result Certification Applicant: Shenzhen Huntkey Electric Co., Ltd. Address: Huntkey Industrial Park, Xue-Xiang Village, Banxue Road, Bantian, Shenzhen, Guangdong, 518129, PEOPLE'S REPUBLIC OF CHINA Manufacturer: Shenzhen Huntkey Electric Co., Ltd. Address: Huntkey Industrial Park, Xue-Xiang Village, Banxue Road, Bantian, Shenzhen, Guangdong, 518129, PEOPLE'S REPUBLIC OF CHINA Product description Product name: Q10 Magnetic Power Bank Trademark: Huntkey Model name: HKCPB2710Q1 Series Model(s): N/A Standards: 47 CFR Part 15C Test Method: ANSI C63.10-2013 Date of Test Date of test: 2024-08-06 to 2024-08-30 Test result: Pass Test Engineer : (Letter Lan) Reviewed By : (David Lee) Approved By : (Leon Chen) Page 5 of 27 Report No.: MTi240710002-08E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] 1 General Description 1.1 Description of the EUT Product name: Q10 Magnetic Power…

Text truncated - open the document above for the full version.

深圳市志泽科技有限公司 Shenzhen ZHIZE Technology Co.,Ltd 承 认 书 SPECIFICATION FOR APPROVAL Approval No. 承 认 书 编 号： Customer Name 供 应 商 名 称: Shenzhen Shenguang Electronic Technology Co.,LTD Product Name: 产 品 名 称: MPP Wireless charging Product Specification 产 品 规 格: 单线圈+线长50MM 42.5-18-11TS-8.4uH-0.08-72P+NTC 3950 10k Customer P/N 客户料号/版本: 料号：0404037-000023 版本：A.0 Timcofmakingtable 制 作 日 期: 2024-9-7 供 应 商 HSF 确认 （HSF BY） 制作 （TESTED BY) 审核 （CHECKED BY) 批准 （APPROVED BY） 送样日期 （DELIVER DATE) 吴丽萍谢燕琪段家旺谢小仔2024/7/1 志 泽 HSF 确认 （HSF BY） 制作 （TESTED BY) 审核 （CHECKED BY) 批准 （APPROVED BY） 承认日期 （ACCEPT DATE) 产品类别说明项（□外观接触件 □非外观接触件 □电池 □包材 □其他）：类别由志泽研发勾选 环保要求： 欧洲：RoHS 2.0、REACH（SVHC，附录17项）、POPs 、包装指令、电池指令 美国：CP65、TSCA、包装法案（TPCH）、电池法案 中国：中国RoHS 其他： 注：所有材料必须符合《志泽有害物质管理标准》，如志泽环保要求与法规要求有冲突时，以各国或地方官方最新 公布的版本为准。 特别说明： 深圳市志泽科技有限公司（简称“志泽”），仅对样品的部分内容进行检测，供应商送至志泽的样品除应符合承认 书的要求，还需要符合国家标准、行业标准、企业标准、安规认证要求、各国HSF环保法规要求等（如上述各标准之 间存在不一致的，以较高标准为准。）如有不符，相应责任由供应商承担。志泽签样行为不能作为供应商对供货产 品质量及HSF环保问题的免责依据。 最终承认结果： □符合 □有条件承认 □不符合 备注： 地址：深圳市龙华区观澜街道观光路1165号4楼 电话：18688713269 传真： E-mail:[email protected] 文件编号：ZZ-FR-RD-020 版本：B/3 深圳市志泽科技有限公司 Shenzhen ZHIZE Technology Co.,LTD 目 录 0.承认书封面 ..........................................##### 1.目录 .............................................................................. 2.变更记录 .............................................................................. 3.产品图纸 .................................................................. 4.电气性能 ............................................................... 5.包装 ............................................................... 深圳市志泽科技有限公司 Shenzhen ZHIZE Technology Co.,LTD Revision 版本 Change record 变更记录 Draw up 制作者 Arbiter 确认者 Changed/Issu ed date 变更/发行日期 A.0首次制订/发行 谢燕琪谢小仔9月7日 SPECIFICATION CHANGE RECORD 变更记录 备注：磁片中间贴B3950 10K L=70MM NTC 单位:MM 标准 ABCDEHIT STD42.5±0.540±120.5±0.518±0.52-550±21.2Max2.5Max 一、 线圈工艺/Winding Procese: NO 绕组线规匝数绕线方向备注 1N1 2UEW-B- 0.08*72P 11TSCCW 2 二．电气性能/FEATURES: 1.测试条件（Test conditions）：25°C,65%RH@100KHz/1V 1.1 电感量（Inductance） 1.11 L0A（单独线圈）=4.1uH±20% 1.12 L0A(线圈+磁片)=8.4uH±7% 1.2 Q值=45MIN 1.3 直流电阻（DCR）：65mΩ MAX 1.4 工作温度(Operating Temperature)：-25°C~85°C 2.测试仪器(Test instrument)：L:创达1068+1310;DCR:502BC;SIZE:Callipers 3.材料清单 项目材料 WIRE ￠0.08*72p 2UEW-0.95mm FERRITE G42.5 开双槽 18*0.8 开单槽 GLUE 白胶/黄胶 SOLDER XCD-907B Adhesive 双面背胶 High temperature adhesive 3MM (Ref) 高温胶纸 5.3包装以现有包装盘为参照标准，以实际出货包装为准，如有特需要求可以定制。 The packaging shall be based on the exusting packing plate and the actual delivery package shall prevail .If there is any requirement,we can customize it. 360 1080

Page 1 of 2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Photographs of the test setup Model: HKCPB2710Q1 Conducted Emission at AC power line Page 2 of 2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Emissions in frequency bands (30MHz - 1GHz) MPE
