2AVZEMRMCRUS20PT206Health Management Exoskeleton

Health management robot Instruction Manual 上海博灵机器人科技有限责任公司 CMIITID： Table of Contents 1. Product information ........................................................................................................................ 5 2. Product composition ....................................................................................................................... 6 3. Parts Details ........................................................................................................................................ 7 4. Software Introduction ..................................................................................................................... 9 5. Product maintenance .................................................................................................................... 14 6. Precautions ....................................................................................................................................... 14 7. After sales service ........................................................................................................................... 15 8. Radiation Exposure Statement....................................................................................................16 1.Product information Note: The appearance color and logo of the product in the following pictures are for reference only, and are only used to explain the structure and wearing method. Product name: Health Management Robot Product model: Mercury-Sports-1901 Product Specifications Name Sub-name Description Basic specifications Brand Name Move Robotics Waist Size Range CS56~110 CL74~130 Charging time 2.5hours Rated working hours 10hours Catetory Health Management Robot Packaging dimensions 600mm (length) * 500mm (width) * 160mm (thickness) Product weight 2KG Packaging weight 1.8KG The main material Aluminum alloy, PC + ABS Working temperature range -20°~50° Product composition Central Control +Waist Belt Module + strap (at the left thigh) Module + strap (at the right thigh) Module + strap (at the left lower leg) Module + strap (at the right leg) Module + strap (left foot) module + strap (right foot) Packing box, lining Manual, instruction manual, warranty card, certificate of conformity Power cord + charging adapter Router + router adapter Technical specifications and hardware Login Method Scan QR code to login Software Platfomr Operator: iOS (IPAD preferred) User: iOS/Android (Wechat required) parameters Forwarding Performance 200Kpps Wireless Network Frequency 5G Precautions Before using the product, you need to confirm that the product initialization is complete and the module connection status is normal; The product needs to be placed stably during storage and transportation. Prevent the product from falling and ventilate it from moisture; During the wearing process, the subject under test is recommended to wear it with the assistance of the operator. Avoid squeezing the device during use of the product People with joint instability, osteoporosis, muscle weakness / muscle paralysis, muscle control ability, behavioral capacity, loss of balance function, cerebellar injury, etc. are prohibited from using this product. Do not place the product near fire sources or hot objects, and please avoid direct sunlight. The charger may become hot during charging, which is normal. Product label (adhesive sticker behind the central control): 2.Product composition Hardware composition: ① Central Control + Waist Band ② Module + strap (at the left thigh) ③ Module + strap (at the right thigh) ④ Module + strap (at the left lower leg) ⑤ Module + strap (at the right leg) ⑥ Module + strap (left foot) ⑦ module + strap (right foot) material: Manual x1, User's Guide x1, Warranty Card x1, Certificate of Qualification x1 3.Parts Details Central control light bar: composed of seven white light bars; 1. Charging status display: When the magnetic charging head is plugged into the module, the module displays the current power, which is displayed by four light bars (LED), and the remaining power (LED) is displayed by a marquee. 2. Power display: The central control module is displayed in 7 segments, which are gradually decreased from both sides, and each side is reduced by 1 each time. When the power is less than 25%, the last light flashes. 3. Initialization status display: After the module is powered on, if it passes the dynamic and static detection, the initialization status will be displayed on the light bar. If the initialization fails, the 4 lights flash simultaneously. 4. If the module is successfully initialized, the light bar will show the power. (Working condition is normal) 5. Module communication connection status display: currently displayed on the IPAD. Charging: using magnetic charging Thigh components: left and right thigh parts, elastic straps, batteries, electronic parts Calf components: left and right calf parts, elastic straps, batteries, electronic parts Foot components: left and right foot parts, elastic straps, batteries, electronic parts Out of power Notlit Charging status Marquee Use state Light bar with current power on Initialization success status Light bar with current power on Initialization failed status Light bar flashes simultaneously Blocking state Not lit Fully charged The light bar is breathing 4. Software Introduction Software: PC version, IPAD version Software function flowchart Software requires mobile phone to scan QR code to log in (the first time you need to fill in the registration information) Feature selection Equipment calibration (standing calibration and sitting calibration) Follow the Pad to complete a series of actions View report We Chat user report Backstage management: Permission levels are divided into super administrator, operational administrator, organization management and store management User Management Report statistics: 5. Product maintenance ① Hardware failure and maintenance The flashing of the module light indicates tha…
