2AW73-2E417Magnetic wireless charging mobile power supply

- Shenzhen Xiangdangwen Technology Co.,Ltd. - Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 8/5/2024 U.S. Agent Designation Shenzhen Xiangdangwen Technology Co.,Ltd. acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2AW73-2E417): Name and company of U.S. agent: UUX GROUP INC Physical U.S. address of agent: 36 South 18th Avenue, Suite A Brighton, CO USA 80601 FRN of U.S. agent: 0033701590 Email address of U.S. agent: [email protected] UUX GROUP INC acknowledges their obligation to accept service of process on behalf of Shenzhen Xiangdangwen Technology Co.,Ltd.. Shenzhen Xiangdangwen Technology Co.,Ltd. with the FRN [0029844610] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature kai xu Product manager Shenzhen Xiangdangwen Technology Co.,Ltd. Signature Jack Fu Manager UUX GROUP INC 48_[model] US_Agent_2.911(d)(7) - U, V05

Page 1 of 5 FCC ID: 2AW73-2E417 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. External Photos Photo 1 Photo 2 Page 2 of 5 FCC ID: 2AW73-2E417 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 3 Photo 4 Page 3 of 5 FCC ID: 2AW73-2E417 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 5 Photo 6 Page 4 of 5 FCC ID: 2AW73-2E417 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 7 Photo 8 Page 5 of 5 FCC ID: 2AW73-2E417 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 9 Photo 10 ------End------

Label Size: L30mm * W15mm 1. The label is silk-screen on the sample Magnetic wireless charging mobile power supply Model Name: 2E417 FCC ID: 2AW73-2E417 L W

Page 1 of 3 FCC ID: 2AW73-2E417 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Internal Photos Photo 1 Photo 2 Antenna Page 2 of 3 FCC ID: 2AW73-2E417 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 3 Photo 4 Page 3 of 3 FCC ID: 2AW73-2E417 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 5 ------End------

Page 1 of 24 Report No.: AITSZ24052002FW2 RF Exposure Evaluation Client Information: Applicant: Shenzhen Xiangdangwen Technology Co.,Ltd. Applicant add.: 106, 1/F, No.313-4 Building, Huachang Road, Langkou Community, Dalang Street, Longhua District,Shenzhen, China Manufacturer: Huizhou Yimai Electronics Technology Co., Ltd. Manufacturer add.: 3rd Floor, Building B, Huakai High-tech Industrial Park, Electronic City Road, Longxi Street, Boluo Country Product Information: Product Name: Magnetic wireless charging mobile power supply Model No.: 2E417 Brand Name: LISEN , AINOPE , VEICO FCC ID: 2AW73-2E417 Applicable standards: FCC CFR 47 PART 1, § 1.1310 KDB 680106 D01 Wireless Power Transfer v04 Prepared By: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Tel.: +86 0755-230967639 Fax.: +86 0755-230967639 Date of Receipt: May 20, 2024 Date of Test: May 20, 2024 ~ May 28, 2024 Date of Issue: May 29, 2024 Test Result: Pass This device described above has been tested by Guangdong Asia Hongke Test Technology Limited and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. Note: This report shall not be reproduced except in full, without the written approval of Guangdong Asia Hongke Test Technology Limited, this document may be altered or revised by Guangdong Asia Hongke Test Technology Limited, personal only, and shall be noted in the revision of the document. This test report must not be used by the client to claim product endorsement. Reviewed by: Approved by: Leon.yi Sean She Page 2 of 24 Report No.: AITSZ24052002FW2 TABLE OF CONTENTS 1 TEST FACILITY 4 1.1 Deviation from standard 4 1.2 Abnormalities from standard conditions 4 1.3 Test Location 4 2 GENERAL INFORMATION 5 2.1 Coil Specifications 6 2.2 Coil Size 6 2.3 Location(s) – Coil to the outer surface of the enclosure(s) 7 3 TEST METHODOLOGY 8 3.1 Measuring Standard 8 3.2 Requirements 8 3.3 Test Setup 9 3.4 Test Procedure 10 4 Equipment Approval Considerations 11 4.1 Description of the test mode 12 4.2 Peripheral List 12 4.3 Test Instruments list 12 4.4 Duty Cycle 13 4.5 Compliance Location: Center vs Tip-Surface of the Probe 14 4.6 Test Result 16 5 Test Setup photo 19 Page 3 of 24 Report No.: AITSZ24052002FW2 Revision History Revision Issue Date Revisions Revised By 00 May 29, 2024 Initial Issue Sean She Page 4 of 24 Report No.: AITSZ24052002FW2 1 TEST FACILITY The test facility is recognized, certified or accredited by the following organizations: FCC-Registration No.: 251906 Designation Number: CN1376 Guangdong Asia Hongke Test Technology Limited has been registered and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. IC —Registration No.: 31737 CAB identifier: CN0165 The 3m Semi-anechoic chamber of Guangdong Asia Hongke Test Technology Limited has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 31737 A2LA-Lab Cert. No.: 7133.01 Guangdong Asia Hongke Test Technology Limited has been accredited by A2LA for technical competence in the field of electrical testing, and proved to be in compliance with ISO/IEC 17025: 2017 General Requirements for the Competence of Testing and Calibration Laboratories and any additional program requirements in the identified field of testing. 1.1 Deviation from standard None 1.2 Abnormalities from standard conditions None 1.3 Test Location Guangdong Asia Hongke Test Technology Limited Address: B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Tel.: +86 0755-230967639 Fax.: +86 0755-230967639 Page 5 of 24 Report No.: AITSZ24052002FW2 2 GENERAL INFORMATION EUT Name: Magnetic wireless charging mobile power supply Model No: 2E417 Serial Model: N/A Test sample(s) ID: AITSZ24052002001 Sample(s) Status: Engineer sample Operation frequency: 113kHz-205kHz Modulation Technology: ASK Antenna Type: loop coil Antenna Antenna gain: 0dBi Hardware version.: N/A Software version.: N/A Power supply: Capacity:5000mAh/19.25Wh USB-C Input: 5V3A,9V2A,12V1.5A(PD18W) USB-C Output :5V3A,9V2.22A,12V1.67A (PD20W) Wireless Out :5W/7.5W/10W/15W Model different: N/A Note: For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 6 of 24 Report No.: AITSZ24052002FW2 2.1 Coil Specifications ltem Parameter Input inductance: L: 6.5uH±10% Material of enclosure(s): Hot Air Line Number of turns: Transmitter 1: 10 turns 2.2 Coil Size Unit: mm A B C D2 E H 43.8±0.5 20.5±0.5 0.8±0.5 47±3 3±2 1.8MAX Page 7 of 24 Report No.: AITSZ24052002FW2 2.3 Location(s) – Coil to the outer surface of the enclosure(s) Unit: mm Front A Rear B Left C Right D Top E Bottom F 3 9 13 13 11 52 Right Rear Left Front Top Bottom Page 8 of 24 Report No.: AITSZ24052002FW2 3 TEST METHODOLOGY 3.1 Measuring Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Cocmission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. According KDB680106 D01: KDB 680106 D01 Wireless Power Transfer v04. 3.2 Requirements According to the item 3 of KDB 680106 D01v04: Inductive wireless power transfer applications that meet all of the following requirements are excluded from submitting an RF exposure evaluation. (1) Mobile Device and Portable Device Configurations (2) Equipment Authorization Procedures for Devices Operating at Frequencies Below 4 MHz (3) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away …

Text truncated - open the document above for the full version.

Page 1 of 23 Report No.: AITSZ24052002FW1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. FCC TEST REPORT Client Information: Applicant: Shenzhen Xiangdangwen Technology Co.,Ltd. Applicant add.: 106, 1/F, No.313-4 Building, Huachang Road, Langkou Community, Dalang Street, Longhua District,Shenzhen, China Manufacturer: Huizhou Yimai Electronics Technology Co., Ltd. Manufacturer add.: 3rd Floor, Building B, Huakai High-tech Industrial Park, Electronic City Road, Longxi Street, Boluo Country Product Information: Product Name: Magnetic wireless charging mobile power supply Model No.: 2E417 Brand Name: LISEN , AINOPE , VEICO FCC ID: 2AW73-2E417 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Prepared By: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Tel.: +86 0755-230967639 Fax.: +86 0755-230967639 Date of Receipt: May 20, 2024 Date of Test: May 20, 2024 ~ May 28, 2024 Date of Issue: May 29, 2024 Test Result: Pass This device described above has been tested by Guangdong Asia Hongke Test Technology Limited and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. Note: This report shall not be reproduced except in full, without the written approval of Guangdong Asia Hongke Test Technology Limited, this document may be altered or revised by Guangdong Asia Hongke Test Technology Limited, personal only, and shall be noted in the revision of the document. This test report must not be used by the client to claim product endorsement. Reviewed by: Approved by: Leon.yi Sean She Page 2 of 23 Report No.: AITSZ24052002FW1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. 1 Contents Page COVER PAGE 1 CONTENTS ........................................................................................................................................................... 2 2 TEST SUMMARY .................................................................................................................................................. 5 2.1 STATEMENT OF THE MEASUREMENT UNCERTAINTY ............................................................................................. 5 2.2 MEASUREMENT UNCERTAINTY ............................................................................................................................ 5 3 TEST FACILITY ..................................................................................................................................................... 6 3.1 DEVIATION FROM STANDARD ............................................................................................................................... 6 3.2 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................................... 6 3.3 TEST LOCATION ................................................................................................................................................. 6 4 GENERAL INFORMATION ................................................................................................................................... 7 4.1 EUT TEST MODE ............................................................................................................................................... 8 4.2 DESCRIPTION OF TEST SETUP............................................................................................................................. 8 4.3 PERIPHERAL LIST ............................................................................................................................................... 9 4.4 EUT PERIPHERAL LIST ....................................................................................................................................... 9 5 EQUIPMENTS LIST FOR ALL TEST ITEMS ..................................................................................................... 10 6 CONDUCTED EMISSION TEST ......................................................................................................................... 10 6.1 CONDUCTED EMISSION MEASUREMENT ................................................................................................ 11 6.2 POWER LINE CONDUCTED EMISSION LIMITS ........................................................................................... 11 6.3 TEST PROCEDURE ...................................................................................................................................... 11 6.4 DEVIATION FROM TEST STANDARD ......................................................................................................... 11 6.5 TEST SETUP ................................................................................................................................................. 12 6.6 EUT OPERATING CONDITIONS .................................................................................................................. 12 6.7 TEST RESULT .................................................................................................................................................. 13 7 RADIATED EMISSION MEASUREMENT .......................................................................................................... 15 7.1 RADIATED EMISSION LIMITS .............................................................................................................................. 15 7.2 ANECHOIC CHAMBER TEST SETUP DIAGRAM ..................................................................................................... 16 …

Text truncated - open the document above for the full version.

acknowledgment SPECIFICATION FOR APPROVAL 客户名称（ CUSTOMER): Beibeidian technology co., ltd 客户料号（CUSTOMER P/N）:YE.L.XXXQ64043401 品名（DESCRIPTION) : Wireless charging coil DATE:2023/3/29 规格（SPECIFICATION) ：G43.8 Slotting+47-long line-surface adhesive REV.NO.:A0 Hongri Shengwei Technology acknowledges the signature and seal. departmen t confirmcheckapprove Company seal quality DongwanghonglvhuiVivian engineeri ng heweihuaweilihongweilihong 备注： Beibeidian Technology Co., Ltd. confirmed that departmen t confirmcheckapprove Company seal engineeri ng purchase quality 备注： Shenzhen hong ri sheng Wei technology co., ltd address ：2/F, Building 1, No.48 Guanlan Huanguan Middle Road, Longhua New District, Shenzhen. TEL：+86-755-23461055 FAX：+86-0755-28015170 page:1/3 SPECIFICATION FOR APPROVAL 1.MECHANICAL DIMENSION (UNIT:mm) 2.SCHEMATICS: Need to add 40mm casing length. ABC D2EH备注 43.8±0.520.5±0.50.8±0.0547±33±21.8MAX G43.8 grooving+line-surface adhesive backing 3.WINDING ： 1.1 底 ST EP START-FINISHWIRE TYPETURNSTAPE REMAR K N1S-F0.08*24 hot air line10TS (Ref) 4.ELECTRICAL SPECIFICATION: ITEMLDCRHI-POT TES T CON D Coil plus magnetic sheet S-F 100KHz,0.25V AT 25°C SPEC6.5uH±10% 50mΩ Max 5.BILF OF MATERIAL： NO.ITEMMATERIAL SPECIFICATIONMANUFACTURER SGS NO. 1 0.08*24 hot air line0.08*24 hot air line NANJINGJINNINGCO,LTD 2 Solder BarSolder Bar QIAODO 3 Magnetic sheet 43.8mm diameter, 0.8 thick l-slot magnetic sheet TAIYI CO.,LTD 4 glueYellow glue 999 LIANCHENG CO.,LTD 5 High temperature adhesive tape 8mm wide high-temperature adhesive tape CUDAK CO.,LTD 6 Adhesive backing ⌀41.8*0.1 CUDAK CO.,LTD 7 Black membrane ⌀41.8*0.1 CUDAK CO.,LTD Shenzhen hong ri sheng Wei technology co., ltd PART NO TITLE G43.8 grooving+line-surface adhesive backing DRAWN BYCHECKED BY APPROVED BY heweihuaweilihongweilihong page:2/3

Page 1 of 2 FCC ID: 2AW73-2E417 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Test Setup Photo DCD Conduction Radiation (9KHz-30MHz) Page 2 of 2 FCC ID: 2AW73-2E417 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Radiation (30MHz-1000MHz) ------End------
