2AW7K-IBACK1Posture Corrector iBack

Posture corrector iBACK User’s manual Manufacturer: SMART Solutions Ltd. 634012, Russia, Tomsk, Kosareva street, building 15/1, office 65 +7-995-965-60-61 http://en.iback.online/ Posture corrector iBACK User’s manual Page 2 from 10 Introduction Thank you for purchasing of SMART Solutions LLC product! This manual is applicable for posture corrector iBACK, intended for improving your posture. iBACK very effectively measures and trains your posture, though it is not a medical device. The manual is designed to describe correct mounting, using, and maintenance of iBACK device. Carefully read the user’s manual. The warnings in this manual mean the following: WARNING Indicates a hazardous situation that, if not avoided, could result in death or serious injury. CAUTION Indicates a hazardous situation that, if not avoided, could result in minor or moderate injury. NOTICE Indicates information considered important, but not hazard- related (e.g. messages relating to property damage). Safety Instructions Indicates an information that helps to avoid hazardous situation. Posture corrector iBACK User’s manual Page 3 from 10 Table of contents 1 Contents ........................................................................................................................... 4 2 Charge the batteries before use ....................................................................................... 4 3 Battery installation............................................................................................................. 4 4 Turning on / off the sensor ................................................................................................ 5 5 Installing the application .................................................................................................... 5 6 Mounting the sensor ......................................................................................................... 5 7 Sensor calibration ............................................................................................................. 6 8 Train the skill of correct posture in the "Posture Trainer" mode ("Settings" menu) ........... 7 9 Evaluation of the results of training is the skill of correct posture ...................................... 7 10 “Stretch Coach” mode (“Settings” menu) ........................................................................ 8 11 In the "Settings" menu there is access to your "Account", where a detailed individual training program is located, as well as other useful materials .............................................. 8 12 Wear and care ................................................................................................................ 8 13 Regulatory information .................................................................................................... 9 14 Disposal and Recycling Information ................................................................................ 9 15 iBACK limited warranty ................................................................................................. 10 Posture corrector iBACK User’s manual Page 4 from 10 1 Contents 2 Charge the batteries before use 2.1 A red LED flickers on the charger - the batteries are being charged; 2.2 The green LED is on - the batteries are charged and ready for use. WARNING Do not insert magnets into the charger! Safety Instructions There are identification marks on the rechargeable batteries; there aren't any on the magnets. 3 Battery installation 3.1 Remove the clip from the case by pulling back on the tab (A) on the bottom of the device. 3.2 It is not necessary to put the clip back on. 3.3 Open the case by pulling the top (B) and back covers (C) in different directions. 3.4 Remove the circuit board from the top case cover by pulling the vibration motor (D) towards you. 3.5 Install the battery in the board with the “+” sign up (if the sensor vibrates, the battery has a charge). CAUTION If the battery heats up, you have installed it incorrectly. Safety Instructions Remove battery immediately in this case! 3.6 Install the circuit board with the battery up in the upper case cover, two tabs on the back side of the upper case cover (G) should fall into the two slots on the circuit board (F). 3.7 Having installed the board in the top cover of the case (the board should not protrude from the case), close the case. Posture corrector iBACK User’s manual Page 5 from 10 4 Turning on / off the sensor Switching on - press the button on the back cover of the case to a single vibration. Shutdown - hold down (do not release) the back cover button for more than 4 seconds until double vibration. 5 Installing the application By entering “iBACK” in the App Store or Google Play you can download the application to your smartphone and register. Turn on the sensor, connect to your smartphone using Bluetooth, and attach it to your body. 6 Mounting the sensor 3 mounting options: sticker (we recommend that the measurement error of the sensor is minimal), a clip and a magnet (we do not recommend these two options because of the sensor's high measurement error). 1st option: “Stick sensor to the body” 1.1 Remove the upper protective (yellow) layer and attach the sticker to the back of the case. 1.2 Remove the protective (white) layer from the sticker and attach the sensor to the chest just below the throat. 1.3 The arrow on the front cover of the case should point down. Posture corrector iBACK User’s manual Page 6 from 10 2nd option: “Mounting the sensor using a clip”: 2.1 Put the clip on the back cover of the sensor. 2.2 Attach the sensor to the bra strap under the collarbone or on the bra on the chest. 2.3 The arrow on the front cover of the case should point down. 3rd option “Mounting the sensor on a magnet”: 3.1 Put the sensor back cover to the body under the collarbone 3.2. Clothing above the sensor should be tight-fitting to the body 3.3 Put the magnet on top of clothing. 3.4 The arrow on th…

Text truncated - open the document above for the full version.

September, 28, 2020 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Greetings, This is a letter of authorization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for Smart Solutions Ltd., Kosareva 15/1, ap. 65 Tomsk, Tomskaya oblast, 634000, Russia, for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following Smart Solutions Ltd. product: Posture Corrector “iBack” FCC ID: 2AW7K-IBACK1 Please also accept this letter as an attestation that neither Smart Solutions Ltd. nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or nonvoting, have been denied federal benefits under section 5301 of the Anti-Drug- Abuse act of 1988, 21 U.S.C. 853(a). In addition, Smart Solutions Ltd. will notify the Federal Communications Commission if, at any time, the situation changes causing Smart Solutions Ltd. to be denied federal benefits. If you have any questions, please do not hesitate to contact us at Phone #+79138247962. Sincerely, Vladimir Vesnin CEO

Smart Solutions Ltd. iBACK Posture Corrector FCC ID: 2AW7K-IBACK1 Internal Photos 1 Smart Solutions Ltd. iBACK Posture Corrector FCC ID: 2AW7K-IBACK1 Internal Photos 2 Smart Solutions Ltd. iBACK Posture Corrector FCC ID: 2AW7K-IBACK1 Internal Photos 3

Report Number: D01028P1 20621 PASCAL WAY, LAKE FOREST, CA 92630 • PHONE: (949) 587-0400 Page 1 of 19 FCC PART 15, SUBPART B TEST REPORT TEST METHOD: ANSI C63.4: 2014 LIMITS: CLASS B For iBACK Posture Corrector Model: 1.0 Prepared for SMART Solutions, Ltd Kosareva 15\1 – 65 634012, Tomsk Russia Prepared by: _____________________ CARLA ATIZADO Approved by: _________________________ JOEY MADLANGBAYAN COMPATIBLE ELECTRONICS INC. 20621 PASCAL WAY LAKE FOREST, CA 92630 (949) 587-0400 DATE: OCTOBER 30, 2020 REPORT APPENDICES TOTAL BODY A B C D E PAGES 18 2 2 2 11 5 40 This report shall not be reproduced, except in full, without the written approval of Compatible Electronics. Report Number: D01028P1 20621 PASCAL WAY, LAKE FOREST, CA 92630 • PHONE: (949) 587-0400 Page 2 of 19 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 1.1 DECISION RULE & RISK 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample Was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration – (Emissions) 9 4.1.1 Photograph of Test Configuration – (Emissions) 9 4.1.2 Cable Construction and Termination 10 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 11 5.1 EUT and Accessory List 11 5.2 Emissions Test Equipment 12 5.3 Software 12 6. TEST SITE DESCRIPTION 13 6.1 Test Facility Description 13 6.2 EUT Mounting, Bonding and Grounding 13 6.3 Measurement Uncertainty 13 7. TEST PROCEDURES 14 7.1 RF Emissions 14 7.1.1 Conducted Emissions Test 14 7.1.2 Radiated Emissions Test 15 7.1.3 RF Emissions Test Results 16 7.1.4 Sample Calculations 17 8. DEVIATIONS FROM THE TEST PROCEDURES 18 9. CONCLUSIONS 18 Report Number: D01028P1 20621 PASCAL WAY, LAKE FOREST, CA 92630 • PHONE: (949) 587-0400 Page 3 of 19 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations B Modifications to the EUT C Additional Models D Diagrams, Charts and Photos • Test Setup Diagrams • Antenna and Amplifier Gain Factors • Radiated and Conducted Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map and Layout of Test Site 3 High Frequency Test Volume LIST OF TABLES TABLE TITLE 1 Radiated Emissions Results Report Number: D01028P1 20621 PASCAL WAY, LAKE FOREST, CA 92630 • PHONE: (949) 587-0400 Page 4 of 19 GENERAL REPORT SUMMARY This electromagnetic emission report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced in any form except in full, without the written permission of Compatible Electronics. This report must not be used by the client to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the U.S. Government. Device Tested: iBACK Posture Corrector Model: 1.0 S/N: 1.0 Product Description: The iBACK is a posture corrector device. Clock Frequencies: 2400 MHz Dimensions: 27x27x10 mm Modifications: The EUT was not modified during the testing in order to comply with the specifications. Manufacturer: SMART Solutions, Ltd Kosareva 15\1 – 65 634012, Tomsk Russia Test Date: October 28, 2020 Test Specifications covered by accreditation: Emissions requirements FCC CFR Title 47, Part 15 Subpart B Test Procedure: ANSI C63.4: 2014. Report Number: D01028P1 20621 PASCAL WAY, LAKE FOREST, CA 92630 • PHONE: (949) 587-0400 Page 5 of 19 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz. The EUT is DC powered; therefore, this test was deemed unnecessary and thus was not performed. 2 Radiated RF Emissions, 30 MHz – 6 GHz. Complies with the Class B limits of FCC CFR Title 47, Part 15 Subpart B. Report Number: D01028P1 20621 PASCAL WAY, LAKE FOREST, CA 92630 • PHONE: (949) 587-0400 Page 6 of 19 1. PURPOSE This document is a qualification test report based on the Emissions tests performed on the iBACK Posture Corrector Model: 1.0. The Emissions measurements were performed according to the measurement procedure described in ANSI C63.4: 2014. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by the FCC Code of Federal Regulations Title 47, Part 15 Subpart B. 1.1 DECISION RULE & RISK If a measured value exceeds a specification limit it implies non-compliance. If the value is below a specification limit it implies compliance. Measurement uncertainty of the laboratory is reported with all measurement results but generally not taken into consideration unless a standard, rule or law requires it to be considered. Qualification test reports are only produced for products that are in compliance with the test requirements, therefore results are always in conformity. Otherwise, an engineering report or just the data is provided to the customer. When performing a measurement and making a statement of conformity, in or out-of -specification to manufacturer’s specifications or Pass/Fail against a requirement, there are two possible outcomes: • The result is reported as conforming with the specification • The result is reported as not conforming with the specification The decision rule is defined below. When the test result is found to be below the limit but within our measurement uncertainty of the limit, it is our policy that the final acceptance decision is left to the customer, after discussing the implications and potential risks of the decision. When the test result is found to be exact…

Text truncated - open the document above for the full version.

1 Smart Solutions Ltd. iBACK Posture Corrector FCC ID: 2AW7K-IBACK1 Test Setup Photos Radiated Emissions HF Front Radiated Emissions HF Rear 2 Smart Solutions Ltd. iBACK Posture Corrector FCC ID: 2AW7K-IBACK1 Test Setup Photos Radiated Emissions LF Front Radiated Emissions HF Rear
