2AW8DBS-I7MINITWS earbuds with charging box

FCC Warning Statement Changes or modif ications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B d igital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐‐ Reorient or relocate the receiving antenna. ‐‐ Increase the separation between the equipment and receiver. ‐‐ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐‐ Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.

FCC ID LABEL: Label Location: FCC ID:2AW8DBS- I7 MINI

Model: BS-i7mini Model: BS-i7mini Model: BS-i7mini Model: BS-i7mini Model: BS-i7mini PCB Antenna

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10- g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m Sopt = (EXd) 2 /30 x gt Ant gain= 0.8dBi ; so Ant numeric gain= 1.2 Field strength =77.76dBμV/m @3m So Pt={ [10 (77.76/20) /10 6 x3] 2 /30x 1.2 }x1000 mW = 0.015 mW So (0.015 mW/5mm)x √2.402 GHz =0.00465< 3 Then SAR evaluation is not required

Page 1 of 33 Report No.: UNIA20072306ER-01 FCC RADIO TEST REPORT FCC ID: 2AW8DBS-I7MINI Product Name TWS earbuds with charging box Trade Mark N/A Main Model BS-i7mini Additional Model BS-i9S, BS-i11, BS-i12, BS-i16, BS-i18, BS-A3, BS-A4, BS-Y8, BS-Y9 Report No. UNIA20072306ER-01 Prepared for Shenzhen Benstartech Electronics Co., Ltd XingHua Building 803,Fenghuang Street,Guangming New District, Shenzhen,China Prepared by Shenzhen United Testing Technology Co., Ltd. 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China Page 2 of 33 Report No.: UNIA20072306ER-01 TEST RESULT CERTIFICATION Applicant .............................. : Shenzhen Benstartech Electronics Co., Ltd Address ................................. : XingHua Building 803,Fenghuang Street,Guangming New District, Shenzhen,China Manufacturer ........................ : Shenzhen Benstartech Electronics Co., Ltd Address ................................. : XingHua Building 803,Fenghuang Street,Guangming New District, Shenzhen,China Product description Product Name .............................. : TWS earbuds with charging box Trade Mark ............................ : N/A Model Name .......................... : BS-i7mini, BS-i9S, BS-i11, BS-i12, BS-i16, BS-i18, BS-A3, BS-A4, BS-Y8, BS-Y9 Test Methods ........................ : FCC Rules and Regulations Part 15 Subpart C Section 15.249, ANSI C63.10: 2013 This device described above has been tested by Shenzhen United Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of UNI, this document may be altered or revised by Shenzhen United Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. Date of Test ..........................................: Date (s) of performance of tests .............: Jul. 23, 2020 ~ Aug. 18, 2020 Date of Issue ........................................: Aug. 18, 2020 Test Result ............................................: Pass Prepared by: Bob liao/Editor Reviewer: Kahn yang/Supervisor Approved & Authorized Signer: Liuze/Manager Page 3 of 33 Report No.: UNIA20072306ER-01 Table of Contents Page 1 TEST SUMMARY 4 2 GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 CARRIER FREQUENCY OF CHANNELS 7 2.3 TEST MODE7 2.4 TEST SETUP 8 2.5 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 8 2.6 MEASUREMENT INSTRUMENTS LIST 9 3 CONDUCTED EMISSION 10 3.1 TEST LIMIT 10 3.2 TEST SETUP 10 3.3 TEST PROCEDURE 11 3.4 TEST RESULT 11 4 RADIATED EMISSION 14 4.1 TEST LIMIT 14 4.2 TEST SETUP 15 4.3 TEST PROCEDURE 16 4.4 TEST RESULT 16 5 BAND EDGE 22 5.1 TEST LIMIT 22 5.2 TEST PROCEDURE 22 5.3 TEST RESULT 22 6 OCCUPIED BANDWIDTH 25 6.1 TEST SETUP 25 6.2 TEST PROCEDURE 25 6.4 TEST RESULT 25 7 ANTENNA REQUIREMENT 31 8 PHOTO OF TEST 32 8.1 RADIATED EMISSION 32 8.2 CONDUCTED EMISSION 33 Page 4 of 33 Report No.: UNIA20072306ER-01 1 TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS ITEM STANGARD RESULT CONDUCTED EMISSION FCC Part 15.207 COMPLIANT RADIATED EMISSION FCC Part 15.209/15.249 COMPLIANT BAND EDGE FCC Part 15.249/15.205 COMPLIANT OCCUPIED BANDWIDTH FCC Part 15.249 COMPLIANT ANTENNA REQUIREMENT FCC Part 15.203 COMPLIANT 1.2 TEST FACILITY Test Firm : Shenzhen United Testing Technology Co., Ltd. Address : 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19.The testing quality system of our laboratory meets with ISO/IEC-17025 requirements. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: A2LA Certificate Number: 4747.01 The EMC Laboratory has been accredited by A2LA, and in compliance with ISO/IEC 17025:2017 General Requirements for testing Laboratories. FCC Registration Number: 674885 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. IC Registration Number: 21947 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. Page 5 of 33 Report No.: UNIA20072306ER-01 1.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. A. Conducted Measurement: Test SiteMethodMeasurement Frequency RangeU, (dB)NOTE UNI ANSI 9kHz ~ 150kHz 2.96 150kHz ~ 30MHz 2.44 B. Radiated Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9kHz ~ 30MHz 2.50 30MHz ~ 1000MHz 4.80 1000MHz ~ 6000MHz 4.13 Page 6 of 33 Report No.: UNIA20072306ER-01 2 GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: TWS earbuds with charging box Trade Mark: N/A Main Model: BS-i7mini Additional Model: BS-i9S, BS-i11, BS-i12, BS-i16, BS-i18, BS-A3, BS-A4, BS-Y8, BS-Y9 Model Difference: same, only with a product color and model named different. Test sample model: BS-i7mini. FCC ID: 2AW8DBS-I7MINI Operation Frequency: 2402MHz~2480MHz Number of Channels: 79CH Modulation Type: GFSK, , 8DPSK Antenna Type: PCB Antenna Antenna Gain: 0.8dBi Battery: DC 3.7V, 30mAh Adapter: N/A Power Source: DC 5.0V from adapter with AC 120(240)V/60Hz Note: 1. EUT consists of a pair of headphones, divided into left and right headphone. Two headphones have the same software and electric circuit. 2. This report shows the right headphone. Page 7 of 33 Report No.: UNIA20072306ER-01 2.2 CARRIER FREQUENCY OF CHANNELS Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) …

Text truncated - open the document above for the full version.

Page 1 of 30 Report No.: UNIA20072306ER-02 FCC RADIO TEST REPORT FCC ID: 2AW8DBS-I7MINI Product Name TWS earbuds with charging box Trade Mark N/A Main Model BS-i7mini Additional Model BS-i9S, BS-i11, BS-i12, BS-i16, BS-i18, BS-A3, BS-A4, BS-Y8, BS-Y9 Report No. UNIA20072306ER-02 Prepared for Shenzhen Benstartech Electronics Co., Ltd XingHua Building 803,Fenghuang Street,Guangming New District, Shenzhen,China Prepared by Shenzhen United Testing Technology Co., Ltd. 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China Page 2 of 30 Report No.: UNIA20072306ER-02 TEST RESULT CERTIFICATION Applicant .............................. : Shenzhen Benstartech Electronics Co., Ltd Address ................................. : XingHua Building 803,Fenghuang Street,Guangming New District, Shenzhen,China Manufacturer ........................ : Shenzhen Benstartech Electronics Co., Ltd Address ................................. : XingHua Building 803,Fenghuang Street,Guangming New District, Shenzhen,China Product description Product Name .............................. : TWS earbuds with charging box Trade Mark ............................ : N/A Model Name .......................... : BS-i7mini, BS-i9S, BS-i11, BS-i12, BS-i16, BS-i18, BS-A3, BS-A4, BS-Y8, BS-Y9 Test Methods ........................ : FCC Rules and Regulations Part 15 Subpart C Section 15.249, ANSI C63.10: 2013 This device described above has been tested by Shenzhen United Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of UNI, this document may be altered or revised by Shenzhen United Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. Date of Test ..........................................: Date (s) of performance of tests .............: Jul. 23, 2020 ~ Aug. 18, 2020 Date of Issue ........................................: Aug. 18, 2020 Test Result ............................................: Pass Prepared by: Bob liao/Editor Reviewer: Kahn yang/Supervisor Approved & Authorized Signer: Liuze/Manager Page 3 of 30 Report No.: UNIA20072306ER-02 Table of Contents Page 1 TEST SUMMARY 4 2 GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 CARRIER FREQUENCY OF CHANNELS 7 2.3 TEST MODE7 2.4 TEST SETUP 7 2.5 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 8 2.6 MEASUREMENT INSTRUMENTS LIST 9 3 CONDUCTED EMISSION 10 3.1 TEST LIMIT 10 3.2 TEST SETUP 10 3.3 TEST PROCEDURE 11 3.4 TEST RESULT 11 4 RADIATED EMISSION 14 4.1 TEST LIMIT 14 4.2 TEST SETUP 15 4.3 TEST PROCEDURE 16 4.4 TEST RESULT 16 5 BAND EDGE 23 5.1 TEST LIMIT 23 5.2 TEST PROCEDURE 23 5.3 TEST RESULT 23 6 OCCUPIED BANDWIDTH 26 6.1 TEST SETUP 26 6.2 TEST PROCEDURE 26 6.4 TEST RESULT 26 7 ANTENNA REQUIREMENT 28 8 PHOTO OF TEST 29 8.1 RADIATED EMISSION 29 8.2 CONDUCTED EMISSION 30 Page 4 of 30 Report No.: UNIA20072306ER-02 1 TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS ITEM STANGARD RESULT CONDUCTED EMISSION FCC Part 15.207 COMPLIANT RADIATED EMISSION FCC Part 15.209/15.249 COMPLIANT BAND EDGE FCC Part 15.249/15.205 COMPLIANT OCCUPIED BANDWIDTH FCC Part 15.249 COMPLIANT ANTENNA REQUIREMENT FCC Part 15.203 COMPLIANT 1.2 TEST FACILITY Test Firm : Shenzhen United Testing Technology Co., Ltd. Address : 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19.The testing quality system of our laboratory meets with ISO/IEC-17025 requirements. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: A2LA Certificate Number: 4747.01 The EMC Laboratory has been accredited by A2LA, and in compliance with ISO/IEC 17025:2017 General Requirements for testing Laboratories. FCC Registration Number: 674885 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. IC Registration Number: 21947 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. Page 5 of 30 Report No.: UNIA20072306ER-02 1.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. A. Conducted Measurement: Test SiteMethodMeasurement Frequency RangeU, (dB)NOTE UNI ANSI 9kHz ~ 150kHz 2.96 150kHz ~ 30MHz 2.44 B. Radiated Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9kHz ~ 30MHz 2.50 30MHz ~ 1000MHz 4.80 1000MHz ~ 6000MHz 4.13 Page 6 of 30 Report No.: UNIA20072306ER-02 2 GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: TWS earbuds with charging box Trade Mark: N/A Main Model: BS-i7mini Additional Model: BS-i9S, BS-i11, BS-i12, BS-i16, BS-i18, BS-A3, BS-A4, BS-Y8, BS-Y9 Model Difference: same, only with a product color and model named different. Test sample model: BS-i7mini. FCC ID: 2AW8DBS-I7MINI Operation Frequency: 2402MHz~2480MHz Number of Channels: 40CH Modulation Type: GFSK Antenna Type: PCB Antenna Antenna Gain: 0.8dBi Battery: DC 3.7V, 30mAh Adapter: N/A Power Source: DC 5.0V from adapter with AC 120(240)V/60Hz Note: 1. EUT consists of a pair of headphones, divided into left and right headphone. Two headphones have the same software and electric circuit. 2. This report shows the right headphone. Page 7 of 30 Report No.: UNIA20072306ER-02 2.2 CARRIER FREQUENCY OF CHANNELS Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 1…

Text truncated - open the document above for the full version.

Model: BS-i7mini Radiated Emission test Model: BS-i7mini Conducted Emission test
