2AW9X-ECRF232CNFC Reader

ECARPLUG Co.,Ltd. User Manual ECRF232C ECARPLUG Co.,Ltd. ECARPLUG Co.,Ltd. Contents 1. Overview 2. Composition 3. Use 4. Specification ECARPLUG Co.,Ltd. 2 1. Overview This device is a reader device that reads HF RF Card and transmits/receives data by connecting to the Host Interface through RS-232C. Through this document, we define the specifications of the terminal that performs the above role. 2. Composition - Host Interface - Send and receive data by connecting to the RS-232C port. - Status display function - Display the current status using LED 3. Use - ID is identified and used in devices that require user recognition (e.g., electric vehicle charger) ECARPLUG Co.,Ltd. 3 4. Specification  MCU  STM32F042F6P6  ARM® 32-bit Cortex®-M0 CPU  Internal 2 USART  User Interface  Status LED x 1  Debug & Download Port  USART 1 Port [5 Pin]  F/W Download GPIO Port [5 Pin]  Power  External 5 VDC  Internal 3.3V LDO Specification Frequency 13.56MHz Temperature -20°C ~ 50°C Power DC 5V ECARPLUG Co.,Ltd. 4 Certification and Safety Approvals FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment on and off, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antennae -Increase the separation between the equipment and the receiver -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC RF Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. The antenna used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures ecarPlug Co., Ltd. Mega-712, SKn Techno Park, 124, Sagimakgol-ro, Jungwon-gu, Seongnam-si, Gyeonggi-do, Republic of Korea TEL : +82-31-778-6181

ecarPlug Co., Ltd. Aug 21, 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370a Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Kenneth Kim of NCT Co.,Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: 2AW9X-ECRF232C including signing of all documents relating to these matters. Any and all acts carried out by Kenneth Kim of NCT Co.,Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from ecarPlug Co., Ltd. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Park Hyungil / Senior Engineer ecarPlug Co., Ltd.

ecarPlug Co., Ltd. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AW9X-ECRF232C Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Operational Description Part List [ECRF232C] BLK [ECRF232C] SCH [ECRF232C] OpDes [ECRF232C] Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); Exhibit Type File Name External Photos Internal Photos Test Setup Photos Manual [ECRF232C] EXT Photo [ECRF232C] INT Photo [ECRF232C] Test Setup Photo [ECRF232C] Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. Sincerely, Park Hyungil / Senior Engineer ecarPlug Co., Ltd.
